Newlab L458MB04T1A01 User manual
User Manual L458MB04T1A01
L458MB04T1A01
Converter WIFI/PUSH to DALI broadcast without integrated BUS DALI power supply
Device Wifi to DALI converter with push interface.
Without Integrated DALI bus power supply.
Controllable with Android/iOS app Omni.
Input Controls
Type Qty
Wifi 1
Output Sync
Type Qty
DALI 1
TECHNICAL NOTES
- Device Wifi to DALI converter with push interface.
- Without Integrated DALI bus power supply.
- Power 144W @ 12V, 288W @ 24V, 576W @ 48V.
- The device is not equipped with earth connection
Protection against accidental contact with live parts is garantied by the
enclosure.
- Power Connector Cross-section of conductors 14-30 AWG (0.05-2.08
mmq).
- Interface Connector Cross-section of conductors 15-30 AWG (0.05-1.65
mmq).
- Controllable with Android/iOS app Omni.
- Input Controls: Wifi x1.
- Output Sync: DALI x1.
- PWM Frequency: 390 Hz.
- Thermal foldback: 150 C. Degrees on uC.
- Storage Temperature Min: -40 Max: 60 C. Degrees.
- Working Temperature Min: -20 Max: 50 C. Degrees.
- Printed Circuit UL.
- Protection Class: IP20.
- Weight: 44 gr.
- Standard Dimension 40x80x24.45 mm.
- Dimension with accessories 40x100x24.45 mm.
- Works with the Google Assistant.
- Compatible with Amazon Alexa Voice Assistant through the skill Newlab.
- Open circuit protection.
- To supply the device you have to use a SELV power supply in order to
maintain the required elettrical security level.
All connections must be made with non-live devices and carried out by
specialized personnel.
- Use only in dry conditions.
2 NEWLAB - User Manual L458MB04T1A01
User Manual L458MB04T1A01
CODE INPUT
VOLTAGE
(MAX) OUTPUT
CURRENT
N. OUTPUT
CHANNELS
MAX OUTPUT
POWER
CONTROL
INPUTS
CASE DIMENSION
mm
L458MB04T1A01 8-53V DC from 0A
to 12A
1 576W at 48V DC Wifi x1 YES 40x80
h 24.45
3 NEWLAB - User Manual L458MB04T1A01
User Manual L458MB04T1A01
DEVICE POWER SUPPLY AND CONNECTION TO THE LED MODULE
POWER SUPPLY CONNECTION DIAGRAM AND LED L458MB04T1A01 - FIGURE N. 1
The L458MB04T1A01 dimmer has to be powered according to the polarity showed in FIG. 1
through the DC IN (+ and -) terminals.
The LED (LED PWR) positioned on the circuit board indicates the presence of power supply and the status of Wifi
Connection
The LED (LED DIM) shows the dimming level of the output.
The LED load connection has to be made by using the OUT (L+ and L-) terminals.
4 NEWLAB - User Manual L458MB04T1A01
User Manual L458MB04T1A01
DALI BUS WIRING DIAGRAM AND WIFI CONTROL VIA APP
WIRING DIAGRAM WIFI L458MB04T1A01 - FIGURE N. 2
L458MB04T1A01 acts as DALI master, sending continuously DALI commands to all connected devices.
DALI packets are sent in BROADCAST.
DALI connectors must be usede to connect L458MB04T1A01 to DALI bus. L458MB04T1A01 is a passive device,
it is necessary to connect an external DALI bus power supply unit.
5 NEWLAB - User Manual L458MB04T1A01
User Manual L458MB04T1A01
The device can be controlled via Omni app available for Android / iOS
The implemented features are:
Easy joining to your Wifi Network via BLE.
Switching on and off and the brightness level control of each individual light point.
Creation and recall of your favourite lighting sceneries.
Configuration of Power On Level luminosity
Configuration of Minimum and Maximum Level of luminosity
The system management from a single simplified user interface.
THE BLUETOOTH LE CONNECTION DOES NOT REQUIRE PAIRING PROCEDURE
Device L458MB04T1A01 requires a WIFI connection type B or G, configure your router / access point to
support at least one the two connection type indicated. Example configuration: (Mode B / BG / BGN
Mixed)
Device L458MB04T1A01 requires also a DHCP service active on the network
Omni App features (* depending on the device only some functions may be available)
6 NEWLAB - User Manual L458MB04T1A01
User Manual L458MB04T1A01
In order to install the app on your Apple or Android device you need to scan the desired QRCode to be
automatically redirected to the product data sheet of the Omni application.
As an alternative you can download the app by clicking on one of two links below:
Apple:
https://apps.apple.com/it/app/omni/id1499453223
Android:
https://play.google.com/store/apps/details?id=com.newlablight.omni&hl=en
FACTORY RESET
To reset the device to factory default it is necessary to short-circuit pins VSS e RST for at least 10 seconds.
After factory reset it is necessary to remove short-circuit and restart the device by removing and restoring power
supply.
Last Manual Update 04/03/2019
7 NEWLAB - User Manual L458MB04T1A01
