NewLine Streamline User manual

SCREEN INSTALLATION INSTRUCTIONS
Parts Includ d
1. One Aluminum Canister with Polyester Screen (PART )
2. Two Rails (PART )
3. Two End Caps (PART ) attached to Wall Jamb (PART )
Tools R quir d
B for Installation
• Clean surface.
• Measure wall to wall both top and bottom to make sure they are equal (1/4" difference per side
allowed). If more than 1/4" attach double-sided foam tape behind part of the shower screen frame
to make square.
Chec our website
www.newlinebathroom.com
and see an installation video.
• 1•
www.newlinebathroom.com
Level Tape Measure Metal Handsaw
Caulk Pencil
A
B
D
C

STEP ONE: Install Canist r and Wall Jamb with End Caps
1. Draw a straight line along tub edge where you would like to position your rail (pencil line).
2. Place on left or right side of shower with handle facing outward (HANDLE IS THE LATCH
DE ICE). Position the rail end cap at the edge of your pencil line. Use a level to ensure is
vertical. Peel off tape as shown, and press firmly against wall.
3. Position at the edge of your pencil line. Use level to ensure is vertical. Peel off tape as
shown, and press firmly against wall.
• 2•
www.newlinebathroom.com
A
A
D
D
PEEL
TAPE
PEEL
TAPE
NOTE: DO NOT REMOVE PART C UNTIL PART D IS INSTALLED.
RAIL END
CAP ON
THE LINE
RAIL END CAP
(PART C ) ON
THE LINE
A
A
CD
PENCIL LINE

STEP TWO: Install Rails
1. Measure the distance between walls for the UPPER rail , and subtract 2 3/4". Transfer
measurement to rail , and cut to measured length.
2. Slide on to the upper slider ( ), and push into the rail end cap. Unclip from ,
slip on to , and clip back in place.
3. Repeat for LOWER rail . (Measure again.)
• 3•
www.newlinebathroom.com
A
D
B
B
B
D
B
B
B
B
B
B
RAIL END CAP
C
C
C
C
B
B
IMPORTANT: MEASURE OPENING CORRECTLY TO AVOID CUTTING RAILS SHORT.

STEP THREE: Caulk
1. Caulk the exterior perimeter of the STREAMLINE®Screen. Allow caulk to dry.
Enjoy your STREAMLINE®Screen
—The Intelligent Shower Screen!
• 4•
www.newlinebathroom.com

WARRANTY
Limited Warranty for STREAMLINE®Screen
WHAT IS COVERED AND FOR WHAT PERIOD THE COVERAGE EXTENDS
Newline International (hereafter “NEWLINE”) warrants to the original purchaser of this product, living
in THE UNITED STATES OF AMERICA, who purchased their STREAMLINE®Screen from a
STREAMLINE®Screen authorized distributor or dealer:
a. that this product, including all of its STREAMLINE®Screen authorized components, is free of
defects in materials and workmanship.
b. that this product, if found to be defective within the stated warranty period, will be replaced, or
repaired (at the discretion of NEWLINE) free of charge to the consumer, provided the failure is
reported directly to NEWLINE and an original receipt, showing original purchase from authorized
distributor/dealer is presented at the time of claim date.
The warranty period is five (5) years from the date of purchase. The warranty applies to residential
usage only. If the item seems to have been used otherwise to NEWLINE, thereafter, this limited
warranty shall be null and void. Also, if proof of original purchase cannot be provided this limited
warranty shall be null and void.
WHAT IS NOT COVERED BY THIS WARRANTY
This warranty does not cover damage or defects caused by, or resulting from repairs, services or
alterations to the product or any of its parts or components which have been performed by service
or repair centers not authorized by NEWLINE, damages or defects caused by negligence, improper
installation, accident, abuse, misuse, or improper maintenance of the product, its parts and
components. Ordinary wear and tear shall not be considered a defect in product or materials.
LIMITATION OF LIABILITY FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES
NEWLINE specifically disclaims any and all liability, whether directly or by way of indemnity for
special, incidental or consequential or other damages, whether based on breach of contract, tort,
strict of product liability, or other damages, or any other legal theory.
ATTACH ORIGINAL RECEIPT TO THIS WARRANTY FOR VALIDATION.
