INSTALLATION INSTRUCTIONS
THERMO HAND EXTENSION #2-260
For Valve Model No: 1-540
NWP-2-260 Rev -
2001 CARNEGIE AVE, SANTA ANA CA 92705
[phone]
WWW.NEWPORTBRASS.COM

NWP-2-260
Installing Extension kit (See Fig.1)
1. Remove and discard mud cover and screws.
2. Slide Extension Sleeve-Asm onto thermo valve.
3. Secure Extension Sleeve-Asm with M4 Screw.
4. Slide Sleeve over Valve Body with grooved notch to topside.
5. Slide cover plate with gasket over sleeve and attach with Decorative Screws provided.
Fig. 1
Valve Body
Coverplate
Sleeve
Extension
Sleeve-Asm
12/07/16
M4 Screw
Decorative
Screw

12/07/16
Installing Trim
1. Orient and position stop ring as shown below (See Fig. 2).
2. Open shut-off valve and verify water temperature at outlet device by using a thermometer.
NOTE: The safe and factory set temperature is 100°F. If the temperature needs to be
adjusted follow step 3, otherwise skip to step 4.
3. Rotate cartridge stem to adjust temperature:
(clockwise = colder or counterclockwise = hotter)
4. Place bonnet onto cartridge stem with red button (100°F) positioned straight up and inline
with notch on the sleeve (See Fig. 3).
5. Secure bonnet in place with long flat head screw.
6. Place decorative handle onto stem and secure with setscrew.
NWP-2-260
EN-3212
Stop ring
Cartridge
stem
Fig. 2
Fig. 3
Bonnet
Handle
