Newton VICTRON MULTIPLUS COMPACT Quick start guide

System Sump and Pump
VICTRON MULTIPLUS COMPACT
12/800/35 & 12/1200/50 - Advanced Battery Backup System
Rev 2.2 - 10 October 2017
© Newton Waterproong Systems
Operational Manual
®

2
For more information visit us online www.newtonwaterproong.co.uk Call us for more information on [phone]
3
The Victron range of Inverter/Chargers provide advanced solutions to ensure that Newton Pumping Systems
continue pumping during power interruption by inverting 12V DC power from a battery (or multiple batteries) to
clean and efcient 230V power.
The MultiPlus Compact is a powerful pure sine wave inverter, a sophisticated battery charger that features
adaptive charge technology and a high-speed AC transfer switch in a single compact enclosure.
WARRANTY STATEMENT
The Victron Inverter/Chargers are covered by a 5-year warranty. Warranty includes next day on-site replacement
(delivery and collection, not decommission and installation) of the Inverter/Charger units by a temporary
replacement of the same model. If the warranty claim is upheld, this temporary unit will be exchanged with
a new unit. If the warranty claim is not upheld, the client must decide the course of action, which will include
purchase of a new replacement unit, purchase of the temporary replacement unit, or return of the original unit.
Limited Product Warranties. 5-year limited product warranty from date on delivery note or invoice to the
customer.
WHAT IS COVERED BY THIS LIMITED HARDWARE WARRANTY?
This limited warranty covers replacement (Newton Waterproong Systems) only for defects in materials and
workmanship.
WHAT IS NOT COVERED BY THIS LIMITED HARDWARE WARRANTY?
• Products the supplier has not received payment for
• Normal wear and tear
• Failure to follow product installation instructions and user instructions
• Usage that is not in accordance with the product instructions
• Servicing not authorised by the manufacturer
• Problems caused by connecting devices not supplied or authorised by the manufacturer
WARRANTY INFORMATION
This warranty gives you specic legal rights, and you may also have other rights which may vary from area to
area (or jurisdiction to jurisdiction). The manufacturer’s responsibility for malfunctions and defects in the product
is limited to repair and replacement as set forth in this warranty statement. All expressed and implied warranties
for the product (including but not limited to any implied warranties and conditions of merchantability and
tness for a particular purpose), are limited in time to the term of the limited warranty which is the 2-year period
reected on your delivery note or invoice. No warranties, whether expressed or implied, will apply after the
limited warranty period has expired.
We do not accept liability beyond the remedies provided for in this limited product warranty or for
consequential or incidental damages, including without limitation, any liability for third-party claims against you,
for damages for products not being available for use. Our liability will be no more than the amount you paid for
the product that is the subject of a claim. This is the maximum amount for which we are responsible. Newton
Waterproong Systems reserve the right to change the product specication at any time.
INTRODUCTION CONTENTS
PAGE
INFORMATION 4
DIMENSIONS 4
SAFETY INSTRUCTIONS 4
INVERTER SIZING 5
TYPICAL DETAILS 5
INSTALLATION 6- 9
QUICK INSTALL GUIDE 9
OPTIONAL CONNECTIONS 10
CONFIGURATION 10
BATTERY SELECTION 10
OPERATION 11
MAINTENANCE 11
TECHNICAL DATA 11
TROUBLESHOOTING 12

4
For more information visit us online www.newtonwaterproong.co.uk Call us for more information on [phone]
5
This Operational Manual is written by Newton Waterproong Systems specically for the use of the Victron
Inverter Charger units used with Newton Pumping Systems to ensure continued pumping during power outages.
The original Victron installation manual may be used for reference but contains no specic information on the
use of the unit as a Newton Battery Backup System. It mentions uses that are not applicable to the Newton
System, therefore may be confusing when read in isolation.
DIMENSIONS
375 mm high x 214 mm wide x 110 mm deep.
Weight - 10 kg.
SAFETY INSTRUCTIONS
GENERAL
Please familiarise yourself with the safety features and instructions by rst reading this document before using
the equipment. This product has been designed and tested in accordance with international standards. The
equipment must be used exclusively for the purpose for which it was designed.
WARNING: ELECTRIC SHOCK HAZARD.
The product is used in conjunction with wall mains, a permanent energy source (battery). Input and/or output
terminals may still be dangerously energized, even when the equipment is switched off. ALWAYS SWITCH OFF
THE AC IN SUPPLY AND DISCONNECT FROM MAINS AND BATTERY WHEN INSTALLING, MAINTAINING OR
SERVICING THIS SYSTEM. The product has no internal user-serviceable components. Do not remove the front
plate or operate the product if any panels have been removed. All servicing must be undertaken by a qualied
professional.
Never use the product where there is a risk of gas or dust explosions. Consult the battery manufacturer’s
information to ascertain that the product is intended for use in conjunction with the battery. Always comply with
the battery manufacturer’s safety instructions.
WARNING: DO NOT LIFT HEAVY LOADS WITHOUT ASSISTANCE.
INSTALLATION
Read these installation instructions in full before installing the equipment. This is a Safety Class I product
(supplied with a protective grounding terminal for safety purposes). Uninterrupted protective grounding must
be provided at the AC input and/or output terminals. Alternatively the grounding point located externally on the
product may be used. Whenever it is likely that the grounding protection has been damaged, the product must
be turned off and secured against unintended operation; please contact qualied service staff.
Ensure that the DC and AC input cables are fused and tted with circuit breakers. Never replace a safety
component with a different type.
Before applying power, ensure that the available power source matches the conguration settings of the
product. This manual is to be used with the Victron MultiPlus 12/800/35 & 12/1200/50. 12/xxxx/xxx denotes the
charging volts - use with 12V batteries only. xx/800 or 1200/xx denotes the AC output capacity in VA. xx/xxxx/35
or 50 denotes the charging current in Ah.
Ensure that the equipment is used under the correct ambient conditions (refer to Data Sheet for unit
temperature operating parameters). Never operate the product in a wet or dusty environment. Ensure there is
adequate free space for ventilation around the product and check that the ventilation vents are not blocked.
Ensure that the required system voltage does not exceed the product’s capacity.
TRANSPORT AND STORAGE
Ensure that the mains power and battery leads have been disconnected before storing or transporting the
product.
No liability can be accepted for any transport damage if the equipment is shipped in non-original packaging.
Store the product in a dry environment; the storage temperature must be between -20°C and 60°C.
Consult the battery manufacturer’s manual in respect of transport, storage, charging, recharging and disposal of
the battery/batteries and ancillary products.
This Operational Manual is for the Victron MultiPlus Compact Inverter/Charger units 12/800/35 & 12/1200/50.
The maximum pump size that can be connected to these units is:
• 12/800/35 - 250W - Newton Pump CP250
• 12/1200/50 - 400W - Newton Pumps CP400, NP400 and NP400W
For conrmation of the correct size of Inverter for the Newton pump being used please refer to the Victron
Inverters Data Sheet.
TYPICAL DETAILS
Below is a typical setup as part of a Newton System 500 waterproong system which can be used as a quick
install schematic. If a control panel is not used, the pumps will be automatic versions and each pump will have
just one cable coming up from the conduit. Connect pump 1 directly to the mains and pump 2 to the MultiPlus
Compact.
Example 1 - 2 x Automatic Pumps - No Pump Control Panel - No Inverter/Charger Control Panels
SETUP SELECT
+
victron energy
BL U E P O W E R
BMV-600S
BATTERYMONITOR
BB5 Battery Monitor
18
Warning
SeeManual
WaterHigh
Mute
Test
JOHN NEWTON
WATERPROOFINGSYSTEMS
HighWater Alarm
victron energy
B L U E P O W E R
AC1
output
AC1
input
--
For Battery dimensions
please see drawings
prefixed Batt
High water alarm
Pumps compatible with
MultiPlus 12/1200/50
CP400/NP400/NP400W
BMV shunt
500A/50mV
Pumps compatible with
MultiPlus 12/800/35
CP250
Multiplus Invertor
12/1200/50
12/800/35
Pressure rated pipe. 50mm
internal including one way
valve and release
couplings - 50mm external.
Newton Titan-Pro
pumping system with
2 x NP400
fuse fuse
Main Earth
Section
NOTE: This is a waterproofing detail. For the design of the structure, please use a professional designer. We strongly recommend that Newton waterproofing systems are installed by our NSBC registered contractors who will guarantee,
insure and accept liability for both the design and the installation of our systems. Please refer to product data sheets before installation of our products. Newton Waterproofing Systems reserves the right to update drawings.
DO NOT SCALE
Checked by
Designed by
Date
Scale Drawing Reference
Drawn by
Original Reference Drawing Revision
17 - 20 Sovereign Way, Tonbridge, TN9 1RH
Tel: [phone] Fax: [phone]
www.newtonwaterproofing.co.uk - [email protected]
Notes
To access the details mentioned above,relevant NBS
Clauses, product data and MSDS sheets, please visit
Technical resources via
www.newtonwaterproofing.co.uk
®NEWTON
WATERPROOFING AJG AJG
AJG
P-05
28/06/17
Not to scale b
Newton System 500
Titan-Pro White pumping battery back
up High water alarm & Battery Monitor
This drawings shows a Victron battery
back up system used in conjunction
with Newton System 500 Waterproofing
system incorporating titan pro white
and Battery monitor.
The Victron Inverter/Charger ensures
that water is still removed during power
outage until the battery is discharged.
Protection can be increased with
additional batteries.
For unlimited protection use the Quattro
12/3000/120 Generator system, this
recharges the battery(s) to give
unlimited protection if the fuel is
replenished.
For pump system specification please
contact out technical team or a Newton
specialist contractor.
Newton Dialler also available providing
warnings via a standard BT Telephone
line.
INFORMATION, DIMENSIONS AND SAFETY INSTRUCTIONS INVERTER SIZING AND TYPICAL DETAILS

6
For more information visit us online www.newtonwaterproong.co.uk Call us for more information on [phone]
7
Example 2 - 2 x Manual Pumps - Pump Control Panel - No Inverter/Charger Control Panels
INSTALLATION
The Inverter/Charger units are mains powered and should be installed by persons who are electrically competent
by way of appropriate training to either t a fused plug or wire directly to a fused spur. Knowledge of DC input
by battery and the connection of DC battery leads to both the battery/batteries and the Inverter/Charger is
required.
The product must be installed in a dry and well-ventilated area, as close as possible to the batteries. There
should be a clear space of at least 100 mm around the appliance for cooling.
Excessively high ambient temperature will result in the following:
• Reduced service life
• Reduced charging current
• Reduced peak capacity, or shutdown of the inverter
The unit must be installed in a vertical position. Never mount the appliance directly above the batteries.
Example 3 - 2 x Automatic Pumps - 1 x Pump Control Panels - 1 x Inverter/Charger Control Panels - 1 x Battery
Monitor Module
POSITIONING
NOTE: ALL POWER INVERTERS NEED TO BE INSTALLED INTERNALLY IN A DRY AND WELL VENTILATED SPACE
• The product should be wall mounted
• Do not place the battery directly below the MultiPlus Compact
• Please note: All aspects of the installation must be done without AC being connected to mains until all
components of the system have been installed
• The interior of the product must remain accessible after installation
• Use only the DC cables supplied with the unit to minimize cable voltage losses
• For safety purposes, this product should not be installed close to chemicals, synthetic components, curtains
or other textiles, etc
INSTALLATION INSTALLATION
SETUP SELECT
+
victron energy
BLU E P O W E R
BMV-600S
BATTERYMONITOR
BB5 Battery Monitor
18
Inverter
charger
alarm
on
off
charge only
battery charger powerassist
sinewave
inverter parallel connectable
transfer
switch three phase connectable
MultiPlus Compact
AC Transfer capacity: 1x 16A Inverter 230V
victron energy
BL U E P O W E R
www.victronenergy.com
ACin ACout
Battery
12
VOLT
1200 50
VA
AMP
AC1
output
AC1
input
--
Pumps compatible with
MultiPlus 12/1200/50
CP400/NP400/NP400W
For Battery dimensions
please see drawings
prefixed Batt
Pump controller CP-9
Warning(See Manual)
HighWater Alarm
Operating
Pump1 On
Pump2 On
Pumps
High Water Alarm
Mains float
BMV shunt
500A/50mV
Pumps compatible with
MultiPlus 12/800/35
CP250
Multiplus Invertor
12/1200/50
12/800/35
Pressure rated pipe. 50mm
internal including one way
valve and release
couplings - 50mm external.
Newton Titan-Pro
pumping system with
2 x NP400
fuse fuse
Main Earth
18
Pressure rated pipe. 50mm
internal including one way
valve and release
couplings - 50mm external.
Newton Titan-Pro
pumping system with
2 x Newton
Manual pumps
Bat +
For Battery dimensions please
see drawings prefixed Batt
Shunt 1/2000A 50mV
pump one
pump two
Dialer is mounted within
the control panel with
purchase code CP7
Main Float
Alarm Float
Inverter
charger
alarm
on
off
charge only
battery charger powerassist
sinewave
inverter parallel connectable
transfer
switch three phase connectable
MultiPlus Compact
AC Transfer capacity: 1x 16A Inverter 230V
victron energy
BL U E PO W E R
www.victronenergy.com
ACin ACout
Battery
12
VOLT
1200 50
VA
AMP
AC1
output
AC1
input
Pumps compatible with
MultiPlus 12/3000/120
CP750
Pumps compatible with
MultiPlus 12/1200/50
CP400/NP400/NP400W
Pumps compatible with
MultiPlus 12/800/35
CP250
Multiplus Invertor
12/1200/50
12/800/35
Venus GX Unit or
Color Control Panel
fuse fuse
Main Earth
victron energy
BLU E P O W E R
Venus GX

8
For more information visit us online www.newtonwaterproong.co.uk Call us for more information on [phone]
9
FIXING TO THE WALL
Fix the provided blue top xing bracket to the wall via the 3 pre-drilled drilled holes. Screws are provided. It is
important to x the bracket level. Attach the MultiPlus to the top support bracket using the lugs on the rear of
the unit. Complete the x by screwing the bottom of the MultiPlus to the wall via the bottom 2 holes using the
screws provided. Carefully mark out the hole centres then take the MultiPlus off the wall to drill the holes.
Note: Rawl plugs will be required for the screws for certain wall types (not supplied).
CONNECTION OF BATTERY CABLES
1. Before connections are made, test the batteries open circuit voltage. This should be at a minimum of 13V
before installing
2. Use an insulated box spanner in order to avoid shorting the battery. Avoid shorting the battery cables
3. Connect the battery cables: the + (red) and the - (black), to the battery. Reverse polarity connection (+ to –
and – to +) will cause damage to the product and will void the warranty
4. The terminal nuts should be tightened to torque gure 8.0Nm/71 in-Ib
CONNECTION OF THE AC CABLING
This is a Safety Class I product (supplied with a protective grounding terminal). Uninterrupted protective
grounding must be provided at the AC input and/or output terminals and/or chassis grounding point located
externally on the product.
The MultiPlus Compact is provided with a ground relay that automatically connects the Neutral output to the
chassis if no external AC supply is available. If an external AC supply is provided, the ground relay H will open
before the input safety relay closes. This ensures the correct operation of an earth leakage circuit breaker that is
connected to the output. An uninterrupted grounding can also be secured by means of the grounding wire of
the AC input. Otherwise the casing must be grounded.
The mains input & output terminal connector can be found on the bottom of the MultiPlus Compact. The mains
cable must be connected to the connector with a three-wire cable. Use correctly rated cable.
PROCEDURE
Proceed as follows to connect the AC cables:
1. The AC output cable is connected directly to the male-connector, (the connector pulls out). The terminal
points are indicated clearly. From left to right: “N” (neutral), earth, and “L1” (phase)
2. The AC input is connected directly to the female-connector, (the connector pulls out). The terminal points
are indicated clearly. From left to right: “L1” (phase), earth, and “N” (neutral)
3. Push the “input” connector into the AC-in connector (near to rear-side)
4. Push the “output” connector into the AC-out connector (near to front-side)
QUICK INSTALL GUIDE
The steps in bold are indicated on the gure on page 8:
1. Screw the top bracket to a suitably strong substrate using the screws provided. Rawl plugs will be required
for the screws for certain wall types (not supplied)
2. Place unit onto the bracket using the lugs to the rear of the unit. Screw the bottom of the unit to the wall
3. Remove the left (AC IN) wiring block from the base of the inverter
4. Wire AC IN with correctly rated mains cable. Add fused spur or wire to a switched fused spare, both of
which should be tted with a 13amp fuse. Do not plug in or turn on at the spur at this stage
5. Plug in the AC IN wiring block back into the AC IN socket
6. Remove the right (AC OUT) wiring block from the base of the inverter
7. Wire AC OUT with correctly rated mains cable from either a Newton automatic pump, or from the ‘pump
2’ connection of the CP2, CP7 or CP9 control panel
8. Plug in the AC OUT wiring block back into the AC OUT socket
9. Connect the black battery cable and the temperature sensor cable to the negative terminal on the battery
10. Connect the red battery cable to the positive terminal on the battery
11. The system will start running off the batteries
12. Plug the AC IN into mains power or switch on the fused spur
AC
IN
T-SENSE
+-
MultiPlus Compact 12/800/35
MultiPlus Compact12/1200/50
(Battery cables pre-connected)
AC
OUT
Pump (Automatic) or Control panel (Manual)
Pre-wired
Pre-wired
Pre-wired
Connect to negative battery terminal
Mains
Red Black
CH-COM-IN
REMOTE SWITCH NO COM NC
STEP 6.
STEP 3.
STEP 4. STEP 7.
Main Earth
INSTALLATION INSTALLATION AND QUICK INSTALL GUIDE

10
For more information visit us online www.newtonwaterproong.co.uk Call us for more information on [phone]
11
OPERATION
On/Off/Charger Only Switch
For all operation as a battery backup system, the switch should be in the “on”, position meaning the product is
fully functional - powering the pumps with through power during times of normal power supply, inverter power
during power outage. When mains power is not interrupted, the unit will charge the batteries also.
• Charge States (see LED Indications below)
• Bulk - Heavy and fast charge for batteries that are very or fully depleted
• Absorption - Final top up charge at a lower charge rate than Bulk
• Float - Trickle charge for when batteries are fully charged to replace charge that is lost over time. This
ensures that the batteries are always fully charged
• If the voltage at the “AC-in” terminal is not within specications, during a power outage, for example, the
inverter will switch on
• There is no need to switch the unit to “charger only” mode
LED INDICATIONS
MAINTENANCE
The unit does not require specic maintenance. All connections should be checked once a year as part of the
pump servicing regime. Avoid moisture, oil/soot/vapours, and keep the device clean.
TECHNICAL DATA
All technical data is available on page 2 of the Data Sheet.
A number of optional connections are possible:
Undo the four screws at the front of the enclosure and remove the front panel.
NOTE: ALL 230V & 12V POWER must be fully isolated and turned off prior to removing the cover of this unit.
ONLY TECHNICALLY COMPETENT AND TRAINED technicians should alter and install any additional products
features to the unit.
TEMPERATURE SENSOR
The temperature sensor supplied with the product may be used for temperature-compensated charging. The
sensor is insulated and must be mounted on the batteries negative terminal. Default output voltages for Float
and Absorption are at 25°C. In adjust mode temperature compensation is disabled. The Temperature Sensor is
pre-wired as shown on the wiring diagram on page 8.
VICTRON BMV600S BATTERY MONITOR
The BMV600S provides real time information for the battery or bank of multiple batteries:
Battery voltage
Discharge current
Capacity as a %
Please refer to product installation manual.
VICTRON COLOR CONTROL PANEL
The Color Control Panel adds a number of extra features over the Blue Power Panel such as Ethernet or Sim Card
internet capability with remote monitoring via web portal and data storage on SD card. Please refer to product
installation manual.
CONFIGURATION
• Settings should be carried out by a competent person
• Carefully read the instructions before changes are made
• Batteries should be in a dry and well-ventilated area during charging and not directly below the MultiPlus
• Standard settings: ready for use
On delivery, the MultiPlus Compact is set to standard factory values ready for use as part of a Newton Pumping
System with charging voltages set for the three batteries, supplied by Newton Waterproong Systems for use
within power supplies of 230V input voltage and 50Hz frequency. Inverter output voltage is set to 230V AC. There
is no need to change any of the default settings for use within the UK.
BATTERY SELECTION
The following batteries have been selected to be used with the MultiPlus Compact Inverter/Charger units:
• NorthStar 60FT - 60Ah, 99.9% lead, extra long life battery - 12V - Purchase code B20. This is the minimum
battery size for the MultiPlus Compact 12/800/35 unit
• NorthStar 100FT - 100Ah, 99.9% lead, extra long life battery - 12V - Purchase code B21. This is the minimum
battery size for the MultiPlus Compact 12/1200/50 unit
• NorthStar 190FT - 190Ah, 99.9% lead, extra long life battery - 12V - Purchase code B22
Multiple batteries can be used in parallel to increase the charge of the 12V supply to the inverter. Please refer to
the Data Sheet for further information. The maximum sized battery bank that can be used is:
• MultiPlus Compact 12/800/35 - 400Ah
• MultiPlus Compact 12/1200/50 - 700Ah
inverter
charger
alarm
on
off
charger only
Unit switched on & connected to the mains. Pumps are
powered by the mains through the MultiPlus Compact. Charger
is operating in Bulk (heavy charge) or Absorption (top up
charge) mode. Charger light is on.
inverter
charger
alarm
on
off
charger only
Unit switched on & connected to the mains. Pumps are
powered by the mains through the MultiPlus Compact. Charger
is operating in Float (trickle charge) mode. Charger light is
ashing.
inverter
charger
alarm
on
off
charger only
Unit switched on. Power is interrupted. Pumps are powered by
the batteries through the inverter. No charging is taking place.
Inverter light is on.
Unit switched on. Power is interrupted. Pumps are powered by
the batteries through the inverter. No charging is taking place.
Inverter light is on. Alarm light is ashing. Pre Alarm: Unit is
overloaded, battery voltage is low or Inverter temperature is
too high.
inverter
charger
alarm
on
off
charger only
Unit switched on. Power is interrupted. Inverter circuit has
been suspended. The pumps are not powered. No charging is
taking place. Inverter light is on. Alarm light is on. Full Alarm:
Unit is overloaded or battery voltage is very low or Inverter
temperature is too high.
inverter
charger
alarm
on
off
charger only
OPTIONAL CONNECTIONS, CONFIGURATION, AND BATTERY SELECTION OPERATION, MAINTENANCE, AND TECHNICAL DATA

“As part of our policy of continuous product improvement we reserve the right to change our specifications at any time”
Newton Waterproong Systems Is A Trading Name Of
John Newton & Company Ltd.
Newton House, 17-20 Sovereign Way
Tonbridge, Kent TN9 1RH
T: [phone]
E: tech@newtonwaterproong.co.uk
W: www.newtonwaterproong.co.uk
®
TROUBLESHOOTING
The following table provides a quick reference of the more common faults. Disconnect the battery/batteries and
pumping systems before diagnosing the fault. Consult Newton Waterproong Systems if the fault cannot be
resolved.
Problem Cause Solution
The inverter fails to
operate
Processor in ‘no function mode’ Disconnect from mains. Switch off. Wait
4 seconds. Switch on again.
The charger is not
functioning
The thermal breaker has tripped Reset the 16A thermal circuit breaker
The battery is not
being fully charged
Defective battery connection Check the battery terminals
The internal DC fuse is defective Damaged inverter. Requires engineer
repair.
The battery is
overcharged
Defective battery/batteries Replace battery/batteries
