Newton EVO 10 User manual

Newton Scientific
EVO 10 Floor Centrifuge
Instruction Manual
CEN0721-MAN1801
The Right Solution for Every Application

Newton Scientific
EVO 10 Centrifuge | 4
Table of Contents
Preface............................................................................................................. 6
Items Supplied.........................................................................................................6
Intended Use............................................................................................................6
Precautions..............................................................................................................7
Preparation..........................................................................................................................................7
Hazardous Substances.......................................................................................................................7
Operating.............................................................................................................................................8
Maintenance.........................................................................................................................9
Symbols used in the manual ................................................................................10
Technical Specifications.............................................................................. 11
Technical Data.......................................................................................................11
EVO 10..............................................................................................................................................11
Refrigerants ...........................................................................................................11
Rotor Selection......................................................................................................12
Transport and Set Up......................................................................................... 13
Before Setting Up ........................................................................................................ 13
Location .................................................................................................................14
Transporting/Moving.............................................................................................14
Setting up and Leveling........................................................................................15
Mains Connection..................................................................................................15
Storage...................................................................................................................16
Shipping.................................................................................................................16
Lifting & Transporting...........................................................................................16
Control Panel ................................................................................................ 17
Operation....................................................................................................... 18
Switching on the Centrifuge.................................................................................18
Open the Centrifuge Door........................................................................................... 18
Rotor Installation...................................................................................................19
Acceleration / Deceleration Rates .................................................................20
Pre-Selecting Speed/RCF ................................................................................................................20
Running Time Pre-Selection.............................................................................................................20
Continuous Operation.......................................................................................................................20
Preselecting the Temperature ..........................................................................................................20
Precooling the Centrifuge.................................................................................................................21
Programs................................................................................................................21

Newton Scientific
EVO 10 Centrifuge | 5
Saving a Program .............................................................................................................................21
Selecting a Program .........................................................................................................................21
Centrifugation........................................................................................................21
Maximum Loading.............................................................................................................................21
Starting the Centrifuge Run..............................................................................................................22
Imbalance Indicator...........................................................................................................................22
Stopping the Centrifuge Run............................................................................................................22
Removing the Rotor ..............................................................................................22
System Menu ................................................................................................ 23
Maintenance and Care ................................................................................. 24
Cleaning Intervals..................................................................................................24
Basics.....................................................................................................................24
Rotor and Accessories Inspection....................................................................................................25
Cleaning .................................................................................................................25
Shipping and Disposal..........................................................................................26
Troubleshooting ........................................................................................... 27
Mechanical Emergency Door Release.................................................................27
Troubleshooting Guide.........................................................................................28
Error Code.................................................................................................................... 29
When to contact Customer Service .....................................................................29
Limited Warranty ..................................................................................................30

Newton Scientific
EVO 10 Centrifuge | 6
P
Preface
Before starting to use the centrifuge, read through this instruction manual carefully and follow the
instructions.
Failure to follow the instructions and safety information in this instruction manual will result in the
expiration of the warranty.
Items Supplied
If any parts are missing, please contact the nearest Newton Scientific representative.
Intended Use
This centrifuge is a laboratory product used to separate substance mixtures of different densities.
This centrifuge must be operated by trained specialists only.
Item
Quantity
Newton Scientific EVO 10 Centrifuge
1
Power Supply Cable
1
Tool Kit for Rotor Exchange and Installation
1

Newton Scientific
EVO 10 Centrifuge | 7
Precautions
WARNING
Observe the safety instructions. Not following these instructions can cause damage.
The centrifuge is to be used for its intended use only. Improper use can cause damages,
contamination, and injuries with fatal consequences.
The centrifuge should be operated by trained specialists only.
To ensure safe operation of the Newton Scientific Avante 8 / 8R Centrifuge, general safety
regulations must be followed. Mind the regulations in your country.
Set Up Conditions
WARNING
■ Connect the power cord of the centrifuge to isolator/switch which have been properly grounded.
■ Turn off the centrifuge using the power switch located by the right-hand side on the centrifuge.
■ As safety zone maintain a clear radius of at least 30 cm around the centrifuge. Do not place any
dangerous substances within this security zone.
■ Set up in a well-ventilated environment, on a horizontally levelled and rigid surface with
adequate load-bearing capacity.
Preparation
WARNING
■ It is the obligation of the operator to make sure, that the proper protective clothing is used. Mind
the “Laboratory Biosafety Manual” of the World Health Organization (WHO) and the regulations
in your country.
■ Do not make any changes to the mechanical components of the rotor.

Newton Scientific
EVO 10 Centrifuge | 8
■ Do not touch the electronic components of the centrifuge nor alter any electronic or mechanical
components.
■ Use only with rotors which have been properly installed.
■ Do not use rotors, buckets or accessories which show any signs of corrosion or cracks. Contact
technical support for further advice or inspections.
■ Use only with rotors which have been loaded properly.
■ Never overload the rotor.
■ Always balance the samples.
■ Use only rotors and accessories for this centrifuge which have been approved by Newton
Scientific. Exceptions to this rule are commercially available glass or plastic centrifuge labware,
provided they have been designed to fit rotor or adapter cavities and are approved for the speed
or the RCF value of the rotor.
■ Make sure the rotor is locked properly into place before operating the centrifuge.
■ Implement measures which ensure that no one can approach the centrifuge for longer than
necessary while it is running.
Hazardous Substances
WARNING
■ Especially when working with corrosive samples (salt solutions, acids, bases), the accessory parts
and vessel must be cleaned thoroughly.
■ Do not centrifuge explosive or flammable materials or substances.
■ The centrifuge is neither inert nor protected against explosion. Never use the centrifuge in an
explosion-prone environment.
■ Do not centrifuge toxic or radioactive materials or any pathogenic micro-organisms without
suitable safety precautions.
For materials in a higher risk group, extra safety measures have to be taken.
■ If toxins or pathogenic substances have contaminated the centrifuge or its parts, appropriate
disinfection measures must be taken.
■ Extreme care should be taken with highly corrosive substances which can cause damage and
impair the mechanical stability of the rotor. These should only be centrifuged in fully sealed
tubes.
■ If a hazardous situation occurs, turn off the power supply to the centrifuge and leave the area
immediately.

Newton Scientific
EVO 10 Centrifuge | 9
Operating
WARNING
■ Never use the centrifuge if parts of its cover panels are damaged or missing.
■ Never start the centrifuge when the centrifuge door is open.
■ Do not move the centrifuge while it is running.
■ Do not lean on the centrifuge.
■ Do not place anything on top of the centrifuge during a run.
■ Never open the centrifuge door until the rotor has come to a complete stop and this has been
confirmed in the display.
■ The emergency door release may be used in emergencies only to recover the samples from the
centrifuge, e.g. during a power failure (see section “Mechanical Emergency Door Release” on
page 27). Do not open the centrifuge, while it is running.
In any case of severe mechanical failure, such as rotor or bucket crash, the centrifuge is not aerosol
tight. In case of rotor failure, the centrifuge can be damaged. Leave the room. Inform technical
support.
Maintenance
WARNING
The centrifuge housing is not to be opened by the operator. For user perform maintenance and care,
refer to page 24.

Newton Scientific
EVO 10 Centrifuge | 10
Symbols used in the manual
This symbol refers to general hazards.
CAUTION means that material damage could occur.
WARNING means that injuries or material damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the instruction manual to keep yourself and your
environment safe.
This symbol refers to electrical hazards.

Newton Scientific
EVO 10 Centrifuge | 11
Technical Specifications
Technical Data
Refrigerants
Article No.
Centrifuge
Refrigerant
Quantity
Pressure
GWP
CO
2
e
88001801
Newton Scientific Avante 8R
R-134a
1.25 kg
26 bar
1430
1.75 t
Contains fluorinated greenhouse gases in a hermetically sealed system.
Newton Scientific EVO 10
Cat. No.
87001000
Max RPM (rpm)
10,000 rpm
RPM accuracy
±20 rpm
Max RCF
18,300 × g
Max Capacity
6×1000 ml
Set Time
1s to 99h 59min 59s
Temp Range
-20℃～40℃
Temp Accuracy
±2.0℃
Power Supply
AC 200-240V, 50Hz, 19.6A
Sound Level
≤ 65dBa
1

Newton Scientific
EVO 10 Centrifuge | 12
Rotor Selection
The Newton Scientific Avante 8 / 8R Centrifuge is supplied without a rotor. Various rotors are
available. If not stated otherwise the rotors can be used in the Newton Scientific Avante 8 centrifuge
as also in the Newton Scientific Avante 8R centrifuge.
Cat. No.
Type
Capacity
Max Speed
(rpm)
RCF (x g)
87160250
NSA-6.250
6 x 250ml
10,000
18,300
87160500
NSA-6.500
6 x 500ml
8,000
11,620
87161000
NSA-6.1000
6 x 1000ml
8,000
13,765
87241000
NSS-4.1000
4 x 1000ml
4,200
4,430
87261000
NSS-6.1000
6 x 1000ml
4,200
5,100
For further details on rotor use and safety, additional accessories, adapters and spare parts, please visit our
website at http://www.newton-scientific.com/centrifuge

Newton Scientific
EVO 10 Centrifuge | 13
Transport and Set Up
Before Setting Up
•Check the centrifuge and the packaging for any shipping damage. Inform the shipping
company and Newton Scientific immediately if any damage is discovered.
•Remove the packaging by first removing the bolts use to secure the wooden box using a
spanner. Remove the box top cover and then the side covers. The unit can now be removed
from the wooden base and position onto the floor. Remove all protection foam and plastic
wrapped.
•Check if the items supplied are complete. See “Items Supplied” on page 6 or your delivery
note. If the items supplied are incomplete, please contact Newton Scientific.
2

Newton Scientific
EVO 10 Centrifuge | 14
Location
The centrifuge is only to be operated indoors. The set-up location must fulfill the following
requirements:
•A safety zone of at least 30 cm must be maintained around the centrifuge. People and
hazardous substances must be kept out of this safety zone while centrifuging.
•The supporting structure must be stable and free of resonance.
•The supporting structure must be suitable for horizontal setup of the centrifuge.
•The centrifuge is not to be exposed to heat and strong sunlight.
WARNING
UV rays reduce the stability of plastics.
Do not subject the centrifuge, rotors and plastic accessories to direct sunlight.
•The set-up location must be always well-ventilated.
Transporting/Moving
WARNING
Always ensure all rubber foot are off the ground by unscrewing using a spanner. Once the wheels
are in contact with the floor, you can move the centrifuge by rolling. Never lift the centrifuge by its
front panel, its back panel or at its door. Always remove the rotor before moving the centrifuge.
Due to its weight, the centrifuge should be controlled/moved by at least two people.
To prevent possible injuries at least two people should lift and carry the centrifuge by holding it at
the bottom from opposite sides.
Transport the centrifuge and accessories upright within the associated packaging, if possible.
NOTICE
Store the original centrifuge packaging. Contact a shipping company or the technical support for the
transport.
Always remove the rotor before moving the centrifuge. If you do not remove the rotor you might
damage the centrifuge drive or centrifuge spindle.

Newton Scientific
EVO 10 Centrifuge | 15
Setting up & Leveling
Once the centrifuge is in its final position screw the rubber feet entirely down. First use your hand
then the wrench to lower the feet. The casters should be 5-15 mm off the ground.
Level the centrifuge as follows:
1. Place the enclosed bubble level on the top surface of the rotor.
2. Adjust the centrifuge feet until the bubble inside the level is completely inside the marked
area.
3. Turn the rotor with the bubble level around a full 360°.
When 50 % of the bubble remains within the marked area, the leveling of the centrifuge is OK. If
more than 50 % of the bubble leaves the marking, the centrifuge must be leveled again
CAUTION
If the centrifuge isn’t leveled, imbalances can occur and the centrifuge can be damaged. Never place
anything under the centrifuge feet to level the centrifuge.
The centrifuge is to be placed on horizontal and level supporting structures or floor. Horizontal level
is to be checked when moving the centrifuge to a new location.
Mains Connection
NOTICE
Only connect the centrifuge power cable to grounded electrical socket/isolator.
1. Turn off the power supply switch when not in use. Power supply switch is on the right-hand
side of the EVO 10 centrifuge.
2. Check whether the cable complies with the safety standards of your country.
3. Make sure that the voltage and frequency correspond to the figures on the rating plate.
4. Establish the connection to the power supply with the supplied power cable.

Newton Scientific
EVO 10 Centrifuge | 16
Storage
WARNING
When removing the centrifuge and accessories from use if necessary clean, disinfect or
decontaminate the entire system. In doubt contact the Newton Scientific technical support.
•Before storing the centrifuge and the accessories, it must be cleaned and if necessary
disinfected and decontaminated. Centrifuge, rotors, buckets and accessories have to be
thoroughly dried before storage.
•Store the centrifuge in a clean, dust-free location.
•Be sure to place the centrifuge on its feet.
•Avoid direct sunlight.
Shipping
WARNING
Before shipping the centrifuge, please bear the following in mind:
•The centrifuge must be clean and decontaminated.
•The decontamination must be confirmed in a decontamination certificate. Contact technical
support for more details.
•Ensure that the rotor is removed before moving the centrifuge.
Lifting and Transporting
• Use a forklift to lift the centrifuge is possible.
• The centrifuge can be damaged by impact.
• Transport the centrifuge upright and if at all possible in packaging.

Newton Scientific
EVO 10 Centrifuge | 17
Touchscreen Control Panel
3
Control Panel
The touchscreen control panel contains all the keys required for you to operate the centrifuge (only
the power switch is located on the right-hand side of the centrifuge).
1. Actual RCF
2. Current temperature inside the chamber
3. Time set and display
4. Set RPM (rotating speed)
5. Rotor selected
6. Acceleration rate
7. Deceleration rate
8. Program number
9. Start
10. Stop / Door Open
11. Menu

Newton Scientific
EVO 10 Centrifuge | 18
4
Operation
Switching on the Centrifuge
1. Turn on the power switch of the device. The device performs a self-check of its software.
a) When the centrifuge door is closed the display shows:
The speed and time displays read “0” and “00:00:00”; the current temperature inside the
rotor chamber is displayed.
Open the Centrifuge Door
Press the <Open> key.
WARNING
Do not reach into the gap between the centrifuge door and the housing.
Use the emergency release only for malfunctions and power failures (see “Mechanical Emergency
Door Release” on page 27).
Keep hands and objects well clear of the underside and side of the centrifuge door when closing.
Close the centrifuge door by pressing down on it lightly in the middle or on both sides of it. The
centrifuge door mechanism will click and lock in place. Lids should not be slammed as excessive
force may cause damage or disrupt samples.
NOTICE
The centrifuge door should audibly click into place.

Newton Scientific
EVO 10 Centrifuge | 19
Rotor Installation
The approved rotors for the Newton Scientific EVO 10 are listed in section “Rotor Selection” on page
12. Use only the rotors from this list in the centrifuge.
CAUTION
Unapproved or incorrectly combined accessories can cause serious damage to the centrifuge.
Use the supplied tools to tighten or release the rotor from the centrifuge spindle.
Proceed as follows:
1. Open the centrifuge door and if necessary, remove any dust, foreign objects, or residue from
the chamber.
2. Place the rotor over the centrifuge spindle and lower vertically and slowly down the
centrifuge spindle. Use the locking nut provided to tighten the rotor onto the spindle. Hand
tight is sufficient.
CAUTION: Do not over tighten the rotor onto the centrifuge spindle.
3. Check if the rotor is properly installed by lifting it slightly on the handle or from beneath the
rotor. If the rotor can be pulled up, then it must be adjusted and retighten to the centrifuge
spindle.
WARNING: If the rotor cannot be properly secured in place. Check for any damage to
the rotor and the spindle: Damaged rotors must not be used. Keep the centrifuge spindle
area of the rotor clear of objects.
If in doubt, please contact Newton Scientific Technical support.
CAUTION: Check that the rotor is properly locked on the centrifuge spindle before
each use by pulling it from beneath the rotor. The rotor must be locked tight.
4. Close the centrifuge door.

Newton Scientific
EVO 10 Centrifuge | 20
Acceleration / Deceleration Rates
The Newton Scientific Evo 10 offers you 10 selections for each plus the ability to have the option to
set to “0” brake. The setting is displayed above the ACCEL / DECEL button on the touchscreen.
Press the ACCL / DECL button to key in the desired rates. Press Enter to confirm. The last profile is
saved when you restart the centrifuge.
Pre-Selecting Speed/RCF
RPM stands for Revolutions Per Minute.
RCF stands for Relative Centrifugal Force and allows better transfer of protocols between centrifuges
and rotors of differing size.
Ensure that the rpm or RCF is correctly set.
1. Press the RPM/RCF button to select RPM or RCF.
2. Enter the desired value by using the number keypad and press Enter to confirm. RPM / RCF can
be viewed during a run on the top left-hand corner of the screen.
NOTICE
The minimum motor speed is 150 rpm. Any extremely low RPM settings will be automatically
increased to the minimum RPM at 150 rpm.
Running Time Pre-Selection
1. Press the Time display window to access the number keypad.
2. Enter the desired runtime in hh:mm:ss.
3. Press Enter to confirm.
Preselecting the Temperature
You can preselect temperatures between -20 °C and +40 °C. To set the temperature, proceed as
follows:
1. Press the TEMP display area to access the number keypad.
2. Key in the desired temperature.
3. Press Enter to confirm.
