Nexaiot Nise 3800 series User manual

NexAIoT Co., Ltd.

Published August 2021 www.nexaiot.com

IoT Automation Solutions Business Group

Industrial Fanless Computer

NISE 3800 Series

User Manual

Content

Contents

Preface

Disclaimer.............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements........................................................ iv

Declaration of Conformity...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations...............................................................viii

Safety Precautions.................................................................................. ix

Technical Support and Assistance........................................................... xi

Conventions Used in this Manual........................................................... xi

Global Service Contact Information........................................................xii

Package Contents.................................................................................xiv

Ordering Information ............................................................................xix

Chapter 1: Product Introduction

NISE 3800E/E2/P2/P2E Overview..............................................................1

Key Features........................................................................................1

NISE 3800E-H110/NISE 3800R Overview .................................................2

Key Features........................................................................................2

Hardware Specifications..........................................................................3

Knowing Your NISE 3800 Series ..............................................................6

NISE 3800E/E2/P2/P2E & NISE 3800R ...................................................6

NISE 3800E-H110................................................................................7

NISE 3800E & NISE 3800R ...................................................................8

NISE 3800E2/P2/P2E ............................................................................9

NISE 3800E-H110..............................................................................10

Mechanical Dimensions.........................................................................11

Chapter 2: Jumpers and Connectors

Before You Begin ..................................................................................15

Precautions ..........................................................................................15

Chassis Ground Isolation.......................................................................16

Functional Ground Isolation ..................................................................16

Jumper Settings ....................................................................................17

Locations of the Jumpers and Connectors for NISE 3800E/E2/P2/P2E & NISE

3800R...................................................................................................18

Locations of the Jumpers and Connectors for NISE 3800E-H110 ...........20

Jumpers and DIP Switch Settings...........................................................22

AT/ATX Power Select .........................................................................22

PCI Express* Bifurcation ....................................................................22

Clear CMOS Select ............................................................................23

COM3 RS232 RI# Power Select..........................................................23

Connector Pin Definitions .....................................................................24

External I/O Interfaces - Front Panel ...................................................24

Power Button.................................................................................24

LED Indicators ................................................................................24

SIM Card Socket ............................................................................25

DisplayPort.....................................................................................25

Content

External I/O Interfaces - Rear Panel.....................................................26

9V - 30V DC Power Input...............................................................26

Remote Power On/Off & S3 Connector ..........................................26

LAN3 and USB 3.0 Ports.................................................................27

LAN2 and USB 3.0 Ports.................................................................28

LAN1 and USB 2.0 Ports.................................................................29

DVI-D Connector............................................................................29

HDMI.............................................................................................30

Internal Connectors...........................................................................31

Reset Connector ............................................................................31

FW BIOS Connector .......................................................................31

SMBus ...........................................................................................32

SATA Power Connectors.................................................................32

SATA Connectors ...........................................................................33

Line-in Pin Header..........................................................................33

Speaker-out Pin Header..................................................................34

Debug Connector ..........................................................................34

COM Port 1 Connector ..................................................................35

COM Port 2 Connector ..................................................................35

COM Port 3 Connector ..................................................................36

COM Port 4 Connector ..................................................................36

GPIO Pin Header ............................................................................37

Fan1 Connector .............................................................................37

Fan2 Connector .............................................................................38

USB 2.0 Connector ........................................................................38

LED Pin Header ..............................................................................39

MCU Connector.............................................................................40

Mini-PCIe.......................................................................................41

Mini-PCIe Connector......................................................................42

NGFF (M.2 M Key [2242]) Connector (SATA/PCIe x4)......................43

Chapter 3: System Setup

Removing the Top Cover ......................................................................44

Wallmount Brackets..............................................................................45

Removing the Bottom Cover.................................................................46

Installing a CPU.....................................................................................47

Installing a 3G/GSM Module .................................................................50

Installing an mSATA Module .................................................................52

Installing a SO-DIMM Memory Module .................................................54

Installing a SIM Card.............................................................................55

Installing an M.2 Card...........................................................................56

Installing a SATA Hard Drive ..................................................................58

Installing a PCIe/PCI Expansion Card......................................................61

PCI Volts Configuration on NISE 3800 Riser Cards..............................62

Chapter 4: BIOS Setup

About BIOS Setup.................................................................................63

When to Configure the BIOS.................................................................63

Default Configuration...........................................................................64

Entering Setup......................................................................................64

Legends................................................................................................64

BIOS Setup Utility..................................................................................66

Main .................................................................................................66

Advanced .........................................................................................67

Chipset..............................................................................................75

Security .............................................................................................79

Boot..................................................................................................80

Save & Exit ........................................................................................81

Preface

PrefaCe

This publication, including all photographs, illustrations and software, is

part of this manual may be reproduced, copied, translated or transmitted in

any form or by any means without the prior written consent from NEXCOM

International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and

does not represent commitment from NEXCOM International Co., Ltd. However,

users may update their knowledge of any product in use by constantly checking

its manual posted on our website: http://www.nexcom.com. NEXCOM shall

not be liable for direct, indirect, special, incidental, or consequential damages

arising out of the use of any product, nor for any infringements upon the rights

of third parties, which may result from such use. Any implied warranties of

merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

NISE 3800E, NISE 3800E2, NISE 3800P2, NISE 3800P2E, NISE 3800E-H110

and NISE 3800R are trademarks of NEXCOM International Co., Ltd. All

other product names mentioned herein are registered trademarks of their

respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class A devices and

describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for

a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference

to radio communications. Operation of this equipment in a residential area

(domestic environment) is likely to cause harmful interference, in which

case the user will be required to correct the interference (take adequate

measures) at their own expense.

The product(s) described in this manual complies with all applicable

European Union (CE) directives if it has a CE marking. For computer systems

to remain CE compliant, only CE-compliant parts may be used. Maintaining

CE compliance also requires proper cable and cabling techniques.

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status

Update

NEXCOM is a global citizen for building the digital

infrastructure. We are committed to providing green

products and services, which are compliant with

European Union RoHS (Restriction on Use of Hazardous Substance in

Electronic Equipment) directive 2011/65/EU, to be your trusted green

partner and to protect our environment.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%

or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium

(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or

1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established

an engineering and manufacturing task force to implement the introduction

of green products. The task force will ensure that we follow the standard

NEXCOM development procedure and that all the new RoHS components

and new manufacturing processes maintain the highest industry quality

levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and

suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the

suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2013 will be RoHS compliant.

They will use the usual NEXCOM naming convention.

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in

accordance with industry standard. NEXCOM warrants that products will be

free from defect in material and workmanship for 2 years, beginning on the

date of invoice by NEXCOM.

NEXCOM Return Merchandise Authorization (RMA)

▪Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen

messages, and describe the problems on the “NEXCOM RMA Service

Form” for the RMA number apply process.

▪Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU

and RAM. If the components were suspected as part of the problems,

please note clearly which components are included. Otherwise, NEXCOM

is not responsible for the devices/parts.

▪Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage

and deterioration during transportation. In case of damages occurred

during transportation, the repair is treated as “Out of Warranty.”

▪Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is

basic diagnostic fee and another is component (product) fee.

System Level

▪Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free,

ex: resistor, capacitor.

▪Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪Replace with 3rd party products if needed.

▪If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free,

ex: resistors, capacitors.

▪If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and

the documentation supplied with the chassis, power supply, and accessory

modules. If the instructions for the chassis and power supply are inconsistent

with these instructions or the instructions for accessory modules, contact

the supplier to find out how you can ensure that your computer meets

safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the

described procedures only at an ESD workstation. If no such station is

available, you can provide some ESD protection by wearing an antistatic

wrist strap and attaching it to a metal part of the computer chassis.

Preface

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get

into components and cause a malfunction. Use containers to keep small

components separated.

Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow

require only a few simple tools, including the following:

▪A Philips screwdriver

▪A flat-tipped screwdriver

▪A grounding strap

▪An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended

that you do not use needle-nose pliers to disconnect connections as these

can damage the soft metal or plastic parts of the connectors.

Safety Information

Before installing and using the device, note the following precautions:

▪Read all instructions carefully.

▪Do not place the unit on an unstable surface, cart, or stand.

▪Follow all warnings and cautions in this manual.

▪When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪Avoid using the system near water, in direct sunlight, or near a heating

device.

▪The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly

necessary in order to provide balance stability.

▪The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace

only with the same or equivalent type recommended by the manufacturer.

Discard used batteries according to the manufacturer’s instructions.

CAUTION!

CAUTION!CAUTION!

Danger of explosion if battery is incorrectly replaced.

Replace with the same or equivalent type recommended by

the manufacturer. Discard used batteries according to the

manufacturer’s instructions.

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been

approved for use with the product and that it matches the voltage and

current marked on the product’s electrical range label. The voltage and

current rating of the cord must be greater than the voltage and current

rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the

power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical

shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by

service personnel:

a. The power cord or plug is damaged.

b.Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d.The equipment does not work well, or you cannot get it to work

according to the user’s manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third

pin to ground the unit and prevent electric shock. Do not defeat the

purpose of this pin. If your outlet does not support this kind of plug,

contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Preface

18. Insert the positive and negative wires into the V+ and V- contacts on the

terminal block connector.

19. Tighten the wire-clamps screws to prevent the DC wires coming loose.

20. Take into consideration the following guidelines before wiring the

device.

21. The terminal block is suitable for 30-12 AWG (16A). Torque value 5 lb-in.

22. The temperature rating of the input connection cable should be higher

than 95°C.

23. WARNING! This equipment is intended for installation in a Restricted

Access Location only.

AVERTISSEMENT! Cet équipement est destiné à être installé dans un

lieu d’accès restreint uniquement.

24. There must be a disconnect device in front of “NISE 3800 series” to keep

the worker or field side maintainer be cautious and aware to close

the general power supply before they start to do maintenance. The

disconnect device hereby means a 20A circuit-breaker.

25. Power installation must be performed with qualified electrician and

followed with National Electrical Code, ANSI/NFPA 70 and Canadian

Electrical Code, Part I, CSA C22.1.

26. Tolerance within maximum operating voltage range 9 VDC to 36 VDC,

13.3A-4A.

27. WARNING! RISK OF EXPLOSION IF BATTERY IS REPLACED BY

INCORRECT BATTERY TYPE. DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS.

ATTENTION! IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST

REMPLACÉE PAR UNE BATTERIE DE TYPE INCORRECT. METTRE AU

REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS.

Preface

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s

website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or

sales representative, please have the following information ready before

calling:

– Product name and serial number

– Detailed information of the peripheral devices

– Detailed information of the installed software (operating system,

version, application software, etc.)

– A complete description of the problem

– The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products

or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a

CompactFlash storage card.

Conventions Used in this Manual

Warning:

Information about certain situations, which if not observed,

can cause personal injury. This will prevent injury to yourself

when performing a task.

CAUTION!

CAUTION!CAUTION! Caution:

Information to avoid damaging components or losing data.

Note:

Provides additional information to complete a task easily.

Safety Warning: This equipment is intended for installation

in a Restricted Access Location only.

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

9F, No. 920, Chung-Cheng Rd.,

Zhonghe District, New Taipei City, 23586,

Taiwan, R.O.C.

Tel: +886-2-8226-7786

Fax: +886-2-8226-7782

www.nexcom.com

Asia

Taiwan

NexAIoT Headquarters

Industry 4.0 and Cloud Services

13F, No.916, Zhongzheng Rd.,

Zhonghe District, New Taipei City,

23586, Taiwan, R.O.C.

Tel: +886-2-8226-7796

Fax: +886-2-8226-7926

Email: [email protected]

www.nexaiot.com

NexAIoT Co., Ltd.

Taichung Office

16F, No.250, Sec. 2, Chongde Rd.,

Beitun District,

Taichung City, 406, Taiwan, R.O.C.

Tel: +886-4-2249-1179

Fax: +886-4-2249-1172

Email: [email protected]

www.nexaiot.com

NexCOBOT Taiwan Co., Ltd.

13F, No.916, Chung-Cheng Rd.,

Zhonghe District,

New Taipei City, 23586, Taiwan, R.O.C.

Tel: +886-2-8226-7786

Fax: +886-2-8226-7926

Email: [email protected]

www.nexcobot.com

GreenBase Technology Corp.

13F, No.922, Chung-Cheng Rd.,

Zhonghe District,

New Taipei City, 23586, Taiwan, R.O.C.

Tel: +886-2-8226-7786

Fax: +886-2-8226-7900

Email: [email protected]

www.nexcom.com.tw

EMBUX Technology Co., Ltd.

13F, No.916, Chung-Cheng Rd.,

Zhonghe District,

New Taipei City, 23586, Taiwan, R.O.C.

Tel: +886-2-8226-7786

Fax: +886-2-8226-7782

Email: [email protected]

www.nexcom.com.tw

TMR Technology Corp.

13F, No.916, Chung-Cheng Rd.,

Zhonghe District,

New Taipei City, 23586, Taiwan, R.O.C.

Tel: +886-2-8226-7786

Fax: +886-2-8226-7782

Email: [email protected]

www.nexcom.com.tw

China

NEXSEC Incorporated

5F, No.4, No.7 Fengxian Middle Rd.,

(Beike Industrial Park), Haidian District,

Beijing, 100094, China

Tel: +86-10-5704-2680

Fax: +86-10-5704-2681

Email: [email protected]

www.nexsec.cn

NEXCOM Shanghai

No.4, 16 Building,

Shanghai OMNI Tech & Science Park

No. 1699, Douhui Rd.,

Shanghai, 201108, China

Tel: +86-21-5278-5868

Fax: +86-21-3251-6358

Email: [email protected]

www.nexcom.cn

Preface

NexCOBOT China

Room 501, Building 1, Haichuang Building,

No.7 Qingyi Road, Guicheng Street,

Nanhai District, Foshan City,

Guangdong Province, 528314, China

Tel: +86-757-8625-7118

Email: [email protected]

www.nexcobot.com.cn

Beijing NexGemo Technology Co.,Ltd.

5F, Gemotech Building, No.1, Development Rd.,

Changping International Information Industry Base,

Changping District,

Beijing, 102206, China

Tel: +86-10-8190-9328

Fax: +86-10-8190-9456

Email: [email protected]

www.nexgemo.cn

Japan

NEXCOM Japan

9F, Tamachi Hara Bldg.,

4-11-5, Shiba Minato-ku,

Tokyo, 108-0014, Japan

Tel: +81-3-5419-7830

Fax: +81-3-5419-7832

Email: [email protected]

www.nexcom-jp.com

NEXCOM Surveillance Technology Corp.

5F, Building C, ZhenHan Industrial Zone,

GanKeng Community, Buji Street,

LongGang District,

ShenZhen, 518112, China

Tel: +86-755-8364-7768

Fax: +86-755-8364-7738

Email: [email protected]

www.nexcom.cn

NEXCOM United System Service

Room 603/604, Huiyinmingzun Plaza Bldg. 1,

No. 609, Yunlin East Rd.,

Shanghai, 200062, China

Tel: +86-21-5278-5868

Fax: +86-21-3251-6358

Email: [email protected]

www.nexcom.cn

NEXGOL Chongqing

1F, Building B4, Electronic 2nd Area,

(Phoenix Lake Industrial Park), Yongchuan Dist.,

Chongqing City, 402160, China

Tel: +86-23-4960-9080

Fax: +86-23-4966-5855

Email: [email protected]

www.nexcobot.com/NexGOL

America

USA

NEXCOM USA

46665 Fremont Blvd.,

Fremont CA 94538, USA

Tel: +1-510-656-2248

Fax: +1-510-656-2158

Email: [email protected]

www.nexcomusa.com

Europe

United Kingdom

NEXCOM EUROPE

10 Vincent Avenue,

Crownhill Business Centre,

Milton Keynes, Buckinghamshire

MK8 0AB, United Kingdom

Tel: +44-1908-267121

Fax: +44-1908-262042

Email: [email protected]

www.nexcom.co.uk

Preface

Package Contents

Before continuing, verify that the NISE 3800 series package that you received is

complete. Your package should have all the items listed in the following table.

NISE 3800E

Item Part Number Description Qty

1 4NCPF00310X00 Terminal Blocks 3P Phoenix Contact:1803581 3.81mm Female DIP Green 1

2 4NCPM00302X00 Terminal Blocks 3P Phoenix Contact:1777992 5.08mm Male DIP Green 1

3 50311F0100X00 Round Head Screw w/Spring+Flat Washer Long Fei:P3x6L P3x6 iso/SW6x0.5 NI 2

4 50311F0143X00 Flat Head Screw Long Fei:F#6-32x8 F#6-32x8 TROX 10 NI+ Nylok 1

5 50311F0315X00 Round Head Screw Long Fei:P6#32T T10 Nylok P6#32T Outer Teeth Washer T10 Nylok 1

6 50311F0326X00 Flat Head Screw Long Fei:F3x5 Nylok NI+Heat Treatment F3x5 Nylok NI+Heat Treatment 4

7 50311F0330X00 Round Head Screw Long Fei:P2x3 ISO+Nylon P2x3 NI Nylok 4

8 50311P0001X00 Price For Plastic Screw HS6-75P 75mm 1

9 50322P0002X00 Plastic Nut Gin Lian:M6HW 10mmx6mm 1

10 5044440090X00 Thermal Pad APUS:3A2015001001500 15x10x1.5mm XR-PE 1

11 5061600245X00 Washer Kang Yang:TW-320-01 10.4x6.4mm T=1mm Nylon Black 4

12 60177B0364X00 NISE 3800E Quick Reference Guide VER:B SIZE:A4 Kramer 1

Preface

NISE 3800E-H110

Item Part Number Description Qty

1 4NCPF00310X00 Terminal Blocks 3P Phoenix Contact:1803581 3.81mm Female DIP Green 1

2 4NCPM00302X00 Terminal Blocks 3P Phoenix Contact:1777992 5.08mm Male DIP Green 1

3 50311F0100X00 Round Head Screw w/Spring+Flat Washer Long Fei:P3x6L P3x6 iso/SW6x0.5 NI 2

4 50311F0143X00 Flat Head Screw Long Fei:F#6-32x8 F#6-32x8 TROX 10 NI+ Nylok 1

5 50311F0315X00 Round Head Screw Long Fei:P6#32T T10 Nylok P6#32T Outer Teeth Washer T10 Nylok 1

6 50311F0326X00 Flat Head Screw Long Fei:F3x5 Nylok NI+Heat Treatment F3x5 Nylok NI+Heat Treatment 4

7 50311F0330X00 Round Head Screw Long Fei:P2x3 ISO+NYLON P2x3 NI Nylok 4

8 50311P0001X00 Price For Plastic Screw HS6-75P 75mm 1

9 50311P0014X00 P Head Screw Kang Yang:M3-5 5.5x2.1x5mm Plastics 1

10 50322P0002X00 Plastic Nut Gin Lian:M6HW 10mmx6mm 1

11 5044440090X00 Thermal Pad APUS:3A2015001001500 15x10x1.5mm XR-PE 1

12 5061600106X00 Washer Kang Yang:WS6-3.2-1A D6.0mm T=1.0mm 2

13 5061600245X00 Washer Kang Yang:TW-320-01 10.4x6.4mm T=1mm Nylon Black 4

14 60177B0364X00 NISE 3800E Quick Reference Guide VER:B SIZE:A4 Kramer 1

15 6029900037X00 Dow Corning 340 Silicone Heat Sink Compound (3g) 1

Preface

NISE 3800R

Item Part Number Description Qty

1 4NCPF00310X00 Terminal Blocks 3P Phoenix Contact:1803581 3.81mm Female DIP Green 1

2 4NCPM00302X00 Terminal Blocks 3P Phoenix Contact:1777992 5.08mm Male DIP Green 1

3 50311F0143X00 Flat Head Screw Long Fei:F#6-32x8 F#6-32x8 Trox 10 NI+ Nylok 1

4 50311F0315X00 Round Head Screw Long Fei:P6#32T T10 Nylok P6#32T Outer Teeth Washer T10 Nylok 1

5 50311F0326X00 Flat Head Screw Long Fei:F3x5 Nylok NI+Heat Treatment F3x5 Nylok NI+Heat Treatment 8

6 50311F0330X00 Round Head Screw Long Fei:P2x3 ISO+Nylon P2x3 NI Nylok 4

7 50311P0014X00 P Head Screw Kang Yang:M3-5 5.5x2.1x5mm Plastics 1

8 5044440090X00 Thermal Pad APUS:3A2015001001500 15x10x1.5mm XR-PE 1

9 5061600106X00 Washer Kang Yang:WS6-3.2-1A D6.0mm T=1.0mm 2

10 5061600245X00 Washer Kang Yang:TW-320-01 10.4x6.4mm T=1mm Nylon Black 4

11 60177B0364X00 NISE 3800E Quick Reference Guide VER:B SIZE:A4 Kramer 1

12 6029900037X00 Dow Corning 340 Silicone Heat Sink Compound (3g) 1
