Advantech-DLoG DLT-V6210FL User manual

www.advantech.com
Manual
English
ADLoG MDevice DLT-V6210FL
Manual V1.41 (EN)

IMPORTANT:
Read this manual carefully.
Keep for future reference.
The software and hardware designations as well as the brand names used in this documentation are in most
cases also registered trademarks and are subject to the international law (trademark, brand and protection laws).
Windows®is a registered trademark of Microsoft Corporation in the United States (US) and other countries.
We recognize all national and international trademarks and product names.
We reserve the right to modify the contents of this document at any time and without prior notice.
Advantech assumes no liability for technical inaccuracies, typographic errors or faults in this documentation.
Advantech also assumes no liability for damages caused directly or indirectly by the delivery, performance or
usage of this material.
This documentation is protected by copyright. Duplication, in whole or in part, is not permitted without prior written
approval of Advantech.
Manual title: MDevice Manual
Manual completed on:
October 04, 2022
Manual version: V1.41
Software version described:
1.0.9 \ 1.0.12 \ V1.0.2.0 (WEC7)
Copyright 2016-2022
By Advantech Co., Ltd
All rights reserved
Advantech Co., Ltd
No. 1, Alley 20, Lane 26, Rueiguang Road,
Neihu District, Taipei 11491, Taiwan, R.O.C.
E-Mail: [e-mail]
Web: www.advantech.com

Content
ABOUT THIS MANUAL ..........................................................................................................................4
1.1. Target group / Qualifications.........................................................................................................................4
1.2. Software version described ..........................................................................................................................4
1.3. Current manuals ...........................................................................................................................................4
1.4. Area of applicability.......................................................................................................................................4
1.5. Design method in this manual ......................................................................................................................5
SAFETY INFORMATION ........................................................................................................................6
STARTING THE PROGRAM...................................................................................................................7
MAIN MENU: OVERVIEW OF FUNCTIONS...........................................................................................8
SYSTEM INFORMATION........................................................................................................................9
POWER SETTING...................................................................................................................................10
FUNCTION KEY SETTING .....................................................................................................................12
MODULE SETTING.................................................................................................................................13
ANTENNA SETTINGS ............................................................................................................................14
9.1. Safety information about radio wave emissions ...........................................................................................14
9.2. Antenna Settings Menu ................................................................................................................................15
9.3. WiFi Config Tool IGX ....................................................................................................................................15
BRIGHTNESS SETTING.........................................................................................................................16
NETWORK STARTUP ............................................................................................................................17
TOUCH SETTING....................................................................................................................................18
EXPORT \ IMPORT SETTINGS ..............................................................................................................19
TECHNICAL CUSTOMER SUPPORT ....................................................................................................21
LIST OF FIGURES ..................................................................................................................................22

About this manual
4 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
About this manual
1.1. Target group / Qualifications
NOTICE: Physical damage
MDevice contains important settings for your Advantech-DLoG Industrial PC. Only skilled
qualified persons are permitted to configure Industrial PCs with MDevice. If improper
changes of the MDevice settings are performed by the customer, this releases Advantech
from all liability for warranty claims.
1.2. Software version described
This manual describes the MDevice software versions 1.0.9 \ 1.0.12 and 1.0.2.0.
1.3. Current manuals
Current manuals can be found in our Download Center on the internet at:
www.advantech.com
1.4. Area of applicability
The MDevice settings described in this manual apply to the following Industrial PCs:
−DLT-V6210FL
NOTE
MDevice software automatically recognizes the computer model and the installed operating
system. MDevice differentiates the various systems and displays the configuration
dialogues according to the respective device. So the parameter settings in the configuration
dialogues can be different. Example: In the Module Settings menu you can enable/disable
WWAN also on DLT-V6210FL devices.

About this manual
Advantech Co., Ltd. MDevice Manual www.advantech.com 5 / 23
1.5. Design method in this manual
The following icons and keywords are used in this manual to indicate dangers, notices etc.
DANGER / WARNING / CAUTION
DANGER means that death or severe bodily injury will occur if this information is not
observed.
WARNING means that death or severe bodily injury can occur if this information is not
observed.
CAUTION means that slight bodily injury can occur if this information is not observed.
NOTICE: Physical damage
Information about possible physical damage
TIP / HINT
Tips, hints for using the product
Note about additional information in manuals

Safety information
6 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Safety information
NOTICE: Property damage
MDevice contains important settings for your Advantech-DLoG Industrial PC. Only skilled
qualified persons are permitted to configure Industrial PCs with MDevice. If improper
changes of the MDevice settings are performed by the customer, this releases Advantech
from all liability for warranty claims.

Starting the program
Advantech Co., Ltd. MDevice Manual www.advantech.com 7 / 23
Starting the program
System requirements
The following operating systems are supported:
−Microsoft Windows®7 Professional.
−Microsoft Windows®Embedded Standard 7 (WES7)
−Microsoft Windows®Embedded 8 Standard (WE8S)
−Microsoft Windows®8.1 Industry Professional
−Microsoft Windows® 10 IOT
−Microsoft Windows® Embedded Compact 7 (WEC7)
Starting the program
Start MDevice utility via the Windows Programs menu under Start.
If a password was entered in the MDevice Settings menu, this will be requested when starting
the program. The password is case-sensitive; the program terminates after three incorrect
entries.
The default password ex works is gold. Please change this in the Settings menu to suit your
requirements.

Main Menu: Overview of functions
8 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Main Menu: Overview of functions
NOTE
MDevice software automatically recognizes the computer model and the installed operating
system. MDevice differentiates the various systems and displays the configuration
dialogues according to the respective device.
DLT-V6210FL Main Menu
Figure 4.1: MDevice main menu on DLT-V6210FL

System Information
Advantech Co., Ltd. MDevice Manual www.advantech.com 9 / 23
System Information
In this menu, Industrial PC system information is displayed.
Examples:
−Device
−CPU
−EC firmware version
−LCD Type
−ADV S/N
−ADLoG S/N
−Hard switch Off Count
−Over Temperature Count
−Total Run Time
DLT-V6210FL System Information Menu
Figure 5.1: System information menu for DLT-V6210FL

Power Setting
10 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Power Setting
NOTE
MDevice automatically recognizes the computer model and the installed operating system.
MDevice differentiates the various systems and displays the configuration dialogues
according to the respective device. So the parameter settings in the configuration dialogues
can be different.
Parameter settings (full set)
Switch-On To configure which source is allowed to turn on the device.
Switch-Off To configure which source is allowed to turn off the device.
Screen Display To configure the behavior while receiving ignition off event.
Block input: While receiving ignition off event, all the inputs (ex.
touch, keyboard, mouse) will be blocked.
Show counter: While receiving ignition off event, utility will show a
count down dialog to notify the user.
Time Delay
Seconds
To configure the delay seconds.
Ignition Off Delay: The waiting time to trigger a OS shutdown event
while ignition off.
Hard Off Delay: The waiting time to trigger a power shutdown event
while ignition off.
Figure 6.4: Count down dialog
NOTE for WEC7 OS:
Due to quick shutdown time at WEC7 operating system it is highly
recommended to leave Hard Off Delay timeout at 1 second.
Increasing this value will cause system warm start followed by EC
switch off.

Power Setting
Advantech Co., Ltd. MDevice Manual www.advantech.com 11 / 23
Note:
This settings
are not
available
with
WEC7 OS.
Battery
Capacity
Threshold
To configure the percentage threshold of battery for
switch-on/off event.
Thermal
Protection
NOTE: FACTORY SETTING. Not customer
configurable.
Thermal protection per default is “ON” on ALL
terminals.
For your information:
Bootup: Defines the values the terminal can boot at
ambient temperatures in off state.
Shut down: Defines the values the terminal releases an
emergency shutdown, based on inside temperature.
Sensor
Temperature
Threshold
NOTE: FACTORY SETTING. Not customer
configurable.
For your information: The temperature threshold of each
sensor for switch-on/off event is defined.
DLT-V6210FL Power Setting Menu
Figure 6.1: Power setting menu for DLT-V6210FL

Function Key Setting
12 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Function Key Setting
NOTE
This option is not available at DLT-V6210FL.
Parameter settings (full set)
User can switch the type of function. There are 3 types of function user can set:
VK codes The function key which is set to this type will send virtual key codes
which supports max to 3 combinations of keys.
Program The function key which is set to this type will trigger an application.
Text The function key which is set to this type will send a plain text.

Module Setting
Advantech Co., Ltd. MDevice Manual www.advantech.com 13 / 23
Module Setting
NOTE
MDevice software automatically recognizes the computer model and the installed operating
system. MDevice differentiates the various systems and displays the configuration
dialogues according to the respective device. So the parameter settings in the configuration
dialogues can be different.
Settings parameters
WLAN / BT / WWAN /
GPS
Enable/Disable the respective wireless technology
DLT-V6210FL Module Setting Menu
Figure 8.1: Module Setting Menu for DLT-V6210FL
NOTE
Hardware based WLAN support is always enabled at DLT-V6210 in combination with
WEC7 and cannot be disabled using MDevice utility.
Using Windows CE “Control Panel – Network and Dial-up Connections” dialog allows
(enabling \ disabling) WLAN card instead.
WWAN option is only available at DLT-V6210FL.

Antenna Settings
14 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Antenna Settings
9.1. Safety information about radio wave emissions
CAUTION
Danger of radiation emission.
Industrial PCs with WLAN equipment emit high-frequency energy (abbreviation: HF). To
protect people from HF radiation and to comply with country-specific regulations:
Install the industrial PC in such a way that the minimum distance between individuals
and the PC antenna is 20 to 50 cm.
For the Wi-Fi configuration: Set the correct transmitting power and frequency.
Risks to health are possible due to excessive radio wave emission if the transmission power
and the frequency are set incorrectly during the Wi-Fi configuration.
Observe the applicable regulations for your deployment location/country with regard to
frequencies and the maximum permissible transmitting power. Responsibility for this
lies with the operator of the industrial PC. The regulatory authorities in the relevant
country can provide information on this.
Country-specific regulations
Example Germany:
In Germany according to regulations published in the Official Journal 89/2003 of the RegTP
(regulating body for telecommunications and mail, now: “Bundesnetzagentur”) - Federal
Network Agency for electricity, gas, telecommunications, post and railway - the maximum
permissible transmitting power, EIRP (Equivalent Isotropically Radiated Power), in the 2.4 GHz
frequency band is set at 20 dBm (100 mW).
Set the transmitting power of the Advantech-DLoG antenna so that the permitted EIRP limit
value is complied with.
Example worldwide:
Region Regulatory authority
EU EU Verification Notified Body V1.9.1 ETSI
China CNCA-07C-031
Japan Japan SDoC, Certificate
Taiwan Taiwan Certification
Canada Canada Certification Body
USA USA Certification

Antenna Settings
Advantech Co., Ltd. MDevice Manual www.advantech.com 15 / 23
9.2. Antenna Settings Menu
DLT-V6210FL Antenna Settings Menu
Figure 9.1: Antenna Settings Menu for DLT-V6210FL
User can select using internal antenna or external antenna or auto switch.
Other than that, WiFi Config Tool also can launch WiFi setting utility.
9.3. WiFi Config Tool IGX
Figure 9:2: WiFi Config Tool IGX for DLT-V6210FL

Brightness setting
16 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Brightness setting
NOTE
This setting is not available at DLT-V6210FL.

Network Startup
Advantech Co., Ltd. MDevice Manual www.advantech.com 17 / 23
Network Startup
Figure 11.1: Network Startup Menu
Network startup feature will check whether the device is connected with server at boot-up stage
and take action according to the check result.
Enable Network Startup Checked if user want to enable this feature
Programs for Startup It's for setting the startup program list, user can add program
by clicking Add program ... button, or remove program by
Removed program button.
Network Adapter To specify a network adapter for the network checking
event.
Server IP-address(PING) It's for setting the server IP.
Time Waiting for network It's for setting the waiting time for network, if devices cannot
connect to server within the time limit, the check result of
network is failed.
Validate adapter
availability at startup
Checked if user need to check the adapter as well.
Start programs even
without network
Checked, if user need to launch the startup programs which
list in Programs for Startup, even the checking result is
failed.
Show info dialog It is for setting the text information which will be shown
during checking network.

Touch setting
18 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Touch setting
For Touch Setting, please enter [MDevice] -> Select [Touch Setting].
Figure 12:1: Touch Setting for DLT-V6210FL
NOTE
Touch Mode allows Finger and Glove mode to be set to allow better touch interaction while
wearing gloves.

Export \ Import Settings
Advantech Co., Ltd. MDevice Manual www.advantech.com 19 / 23
Export \ Import Settings
To export and import done MDevice Settings use [Export Settings] and [Import Settings]
feature from main menu.
Figure 13:1: Export Settings for DLT-V6210FL
Figure 13:2: Export Settings Success message for DLT-V6210FL

Export \ Import Settings
20 / 23 MDevice Manual V1.41 Advantech Co., Ltd.
Figure 13:3: Import Settings for DLT-V6210FL
Figure 13:4: Import Settings Success message for DLT-V6210FL
