Nexcom Ndis b322 User manual

NEXCOM International Co., Ltd.

Published January 2013 www.nexcom.com

Multi-Media Solutions

Digital Signage Platform

NDiS B322

User Manual

Content

Contents

Preface

Disclaimer.............................................................................................. iii

Acknowledgements ............................................................................... iii

Regulatory Compliance Statements........................................................ iii

Declaration of Conformity...................................................................... iii

RoHS Compliance .................................................................................. iv

Warranty and RMA ................................................................................. v

Safety Information .................................................................................vii

Installation Recommendations................................................................vii

Safety Precautions.................................................................................viii

Technical Support and Assistance........................................................... ix

Conventions Used in this Manual........................................................... ix

Global Service Contact Information......................................................... x

Package Contents..................................................................................xii

Ordering Information ............................................................................xiii

Chapter 1: Product Introduction

Overview ................................................................................................1

Key Features ...........................................................................................1

Hardware Specifications..........................................................................2

Mechanical Dimensions...........................................................................3

Chapter 2: Hardware Functionality

Front Panel .............................................................................................4

Rear Panel...............................................................................................4

Chapter 3: System Setup

Removing the Chassis Cover ...................................................................5

Installing a DIMM....................................................................................6

Installing a SATA Hard Drive ....................................................................8

Installing a Wireless LAN Module ..........................................................12

Installing the Wallmount Brackets .........................................................16

Chapter 4: BIOS Setup

About BIOS Setup ................................................................................17

When to Configure the BIOS ................................................................17

Default Configuration...........................................................................18

Entering Setup .....................................................................................18

Legends................................................................................................18

BIOS Setup Utility..................................................................................19

Main .................................................................................................19

Advanced..........................................................................................20

Power................................................................................................25

Security .............................................................................................27

Boot..................................................................................................28

Exit....................................................................................................31

Preface

This publication, including all photographs, illustrations and software, is

part of this manual may be reproduced, copied, translated or transmitted in

any form or by any means without the prior written consent from NEXCOM

International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and

does not represent commitment from NEXCOM International Co., Ltd. However,

users may update their knowledge of any product in use by constantly checking

its manual posted on our website: http://www.nexcom.com. NEXCOM shall

not be liable for direct, indirect, special, incidental, or consequential damages

arising out of the use of any product, nor for any infringements upon the rights

of third parties, which may result from such use. Any implied warranties of

merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

NDiS B322 is a trademark of NEXCOM International Co., Ltd. All other

product names mentioned herein are registered trademarks of their

respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and

describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for

a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference

to radio communications. Operation of this equipment in a residential area

(domestic environment) is likely to cause harmful interference, in which

case the user will be required to correct the interference (take adequate

measures) at their own expense.

The product(s) described in this manual complies with all applicable

European Union (CE) directives if it has a CE marking. For computer systems

to remain CE compliant, only CE-compliant parts may be used. Maintaining

CE compliance also requires proper cable and cabling techniques.

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status

Update

NEXCOM is a global citizen for building the digital

infrastructure. We are committed to providing green

products and services, which are compliant with

European Union RoHS (Restriction on Use of Hazardous Substance in

Electronic Equipment) directive 2011/65/EU, to be your trusted green

partner and to protect our environment.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%

or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium

(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or

1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established

an engineering and manufacturing task force to implement the introduction

of green products. The task force will ensure that we follow the standard

NEXCOM development procedure and that all the new RoHS components

and new manufacturing processes maintain the highest industry quality

levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and

suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the

suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2013 will be RoHS compliant.

They will use the usual NEXCOM naming convention.

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in

accordance with industry standard. NEXCOM warrants that products will

be free from defect in material and workmanship for 2 years, beginning on

the date of invoice by NEXCOM. HCP series products (Blade Server) which

are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen

messages, and describe the problems on the “NEXCOM RMA Service

Form” for the RMA number apply process.

▪Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU

and RAM. If the components were suspected as part of the problems,

please note clearly which components are included. Otherwise, NEXCOM

is not responsible for the devices/parts.

▪Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage

and deterioration during transportation. In case of damages occurred

during transportation, the repair is treated as “Out of Warranty.”

▪Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is

basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is

basic diagnostic fee and another is component (product) fee.

System Level

▪Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free,

ex: resistor, capacitor.

▪Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪Replace with 3rd party products if needed.

▪If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free,

ex: resistors, capacitors.

▪If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and

the documentation supplied with the chassis, power supply, and accessory

modules. If the instructions for the chassis and power supply are inconsistent

with these instructions or the instructions for accessory modules, contact

the supplier to find out how you can ensure that your computer meets

safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the

described procedures only at an ESD workstation. If no such station is

available, you can provide some ESD protection by wearing an antistatic

wrist strap and attaching it to a metal part of the computer chassis.

Preface

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get

into components and cause a malfunction. Use containers to keep small

components separated.

Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow

require only a few simple tools, including the following:

▪A Philips screwdriver

▪A flat-tipped screwdriver

▪A grounding strap

▪An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended

that you do not use needle-nose pliers to disconnect connections as these

can damage the soft metal or plastic parts of the connectors.

Safety Information

Before installing and using the device, note the following precautions:

▪Read all instructions carefully.

▪Do not place the unit on an unstable surface, cart, or stand.

▪Follow all warnings and cautions in this manual.

▪When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪Avoid using the system near water, in direct sunlight, or near a heating

device.

▪The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly

necessary in order to provide balance stability.

▪The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace

only with the same or equivalent type recommended by the manufacturer.

Discard used batteries according to the manufacturer’s instructions.

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been

approved for use with the product and that it matches the voltage and

current marked on the product’s electrical range label. The voltage and

current rating of the cord must be greater than the voltage and current

rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the

power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical

shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by

service personnel:

a. The power cord or plug is damaged.

b.Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d.The equipment does not work well, or you cannot get it to work

according to the user’s manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third

pin to ground the unit and prevent electric shock. Do not defeat the

purpose of this pin. If your outlet does not support this kind of plug,

contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Preface

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s

website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or

sales representative, please have the following information ready before

calling:

– Product name and serial number

– Detailed information of the peripheral devices

– Detailed information of the installed software (operating system,

version, application software, etc.)

– A complete description of the problem

– The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products

or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a

CompactFlash storage card.

Conventions Used in this Manual

Warning:

Information about certain situations, which if not observed,

can cause personal injury. This will prevent injury to yourself

when performing a task.

CAUTION!

CAUTION!CAUTION! Caution:

Information to avoid damaging components or losing data.

Note:

Provides additional information to complete a task easily.

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe

District, New Taipei City, 23586, Taiwan,

R.O.C.

Tel: +886-2-8226-7786

Fax: +886-2-8226-7782

www.nexcom.com.tw

America

USA

NEXCOM USA

2883 Bayview Drive,

Fremont CA 94538, USA

Tel: +1-510-656-2248

Fax: +1-510-656-2158

Email: [email protected]

www.nexcom.com

Asia

Taiwan

Taichung Office

16F, No.250, Sec. 2,

Chongde Rd., Beitun Dist.,

Taichung City 406, R.O.C.

Tel: +886-4-2249-1179

Fax: +886-4-2249-1172

www.nexcom.com.tw Japan

NEXCOM Japan

9F, Tamachi Hara Bldg.,4-11-5, Shiba

Minato-ku,

Tokyo, 108-0014, Japan

Tel: +81-3-5419-7830

Fax: +81-3-5419-7832

Email: [email protected]

www.nexcom-jp.com

China

NEXCOM China

2F, Block 4, Venus Plaza, Building 21,

ZhongGuanCun Software Park, No.8,

Dongbeiwang West Road, Haidian District,

Beijing, 100193, China

Tel: +86-10-8282-5880

Fax: +86-10-8282-5955

Email: [email protected]

www.nexcom.cn

Shanghai Office

Room 1505, Greenland He Chuang Bldg.,

No. 450 Caoyang Rd.,

Shanghai, 200062, China

Tel: +86-21-6150-8008

Fax: +86-21-3251-6358

Email: [email protected]

www.nexcom.cn

Nanjing Office

Hall C, Block 17, Tian Xing Cui Lang Bldg.,

No. 49 Yunnan North Rd.,

Nanjing, 210018, China

Tel: +86-25-8315-3486

Fax: +86-25-8315-3489

Email: [email protected]

www.nexcom.cn

Shenzhen Office

Western Room 708, Block 210,

Tairan Industry & Trading Place, Futian Area,

Shenzhen, 518040, China

Tel: +86-755-833 7203

Fax: +86-755-833 7213

Email: [email protected]

www.nexcom.cn

Wuhan Office

1-C1804/1805,Mingze Liwan, No.519

South Luoshi Rd,Hongshan District,

Wuhan,430070,China

Tel: +86-27-8722-7400

Fax: +86-27-8722-7400

Email: [email protected]

www.nexcom.cn

Preface

Chengdu Office

9F, Shuxiangxie, Xuefu Garden,

No.12 Section 1, South Yihuan Rd.,

Chengdu, 610061, China

Tel: +86-28-8523-0186

Fax: +86-28-8523-0186

Email: [email protected]

www.nexcom.cn

Europe

France

NEXCOM France

La Grande Arche-Paroi Nord

92044 Paris La Défense

France

Tel: +33 (0) 1 40 90 33 35

Fax: +33 (0) 1 40 90 31 01

Email: [email protected]

www.nexcom.eu

Germany

NEXCOM GmbH

Leopoldstraße Business Centre,

Leopoldstraße 244,

80807 Munich, Germany

Tel: +49-89-208039-278

Fax: +49-89-208039-279

Email: [email protected]

www.nexcom.eu

Italy

NEXCOM ITALIA S.r.l

Via Gaudenzio Ferrari 29,

21047 Saronno (VA), Italia

Tel: +39 02 9628 0333

Fax: +39 02 9286 9215

Email: [email protected]

www.nexcomitalia.it

United Kingdom

NEXCOM EUROPE

10 Vincent Avenue,

Crownhill Business Centre,

Milton Keynes, Buckinghamshire

MK8 0AB, United Kingdom

Tel: +44-1908-267121

Fax: +44-1908-262042

Email: [email protected]

www.nexcom.eu

Preface

Package Contents

Before continuing, verify that the NDiS B322 package that you received is complete. Your NDiS B322 package should have all the items listed in the following

table.

Item Part Number Name Qty

1 50222A0435X00 NDiS166 Wall-Mount-Bracket VER:A CHYUAN-JYH 2

2 50311F0019X00 (H)Flat Head Screw Long FEI:F3x4 iso NI 4

3 50311F0102X00 (H)Round Head Screw Long FEI:P6#32Tx 1/4/SW7*0.8 4

4 50311F0122X00 (H)I Head Screw Long FEI:I 2*6ISO 4

5 5043330394X00 NDiS125-L HDD Bracket-R VER:A CHYUAN-JYH 1

6 5043330395X00 NDiS125-L HDD Bracket-L VER:A CHYUAN-JYH 1

7 5044440031X00 Rubber Foot KANG YANG:RF20-5-4P 4

8 602DCD0590X00 (N)NDiS B322 DVD Driver Manual VER:1.0 1

9 7400065011X00 Power Adapter DELTA:ADP-65JH DB 1

Preface

Ordering Information

The following information below provides ordering information for NDiS B322.

NDiS B322 (P/N: 10W00B32200X0)

Intel® Celeron® Processor 847, Dual-Core, 1.1G, 17W

Chapter 1: Product Introduction

Key Features

▪Intel® Celeron® processors 847

▪Low power consumption

▪Compact and fanless

▪Intel® HD Graphics

▪USB3.0 support

Overview

handle very rich multimedia contents. With Intel® Celeron® processor low

power consumption feature, NDiS B322 supports display output by VGA

and HDMI ports. NDiS B322 is ideal as entry level digital signage player for

advertising, hospitality and brand promotion application.

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪Intel® Celeron® Processor 847, Dual-Core, 1.1G, 17W

Chipset

▪Intel® NM70 Express Chipset

Graphics

▪Intel® HD Graphics

Main Memory

▪1x 204-pin SO-DIMM sockets, Supports DDR3 1333/1066/800MHz

non-ECC, un-buffered memory up to 8GB

I/O Interface-Front

▪1x USB3.0

▪1x USB2.0

I/O Interface-Rear

▪19V DC Power in

▪1x VGA

▪2x USB 2.0

▪1x RJ45 with LEDs for 10/100/1000Mbps Ethernet

▪1x Audio-out

▪1x HDMI

▪1x Mic-in

Storage Device

▪1 x 2.5” SATA HDD Bay

Dimensions

▪250 mm (W) x 194 mm (D) x 40 mm(H)

(9.9” x 7.6” x 1.6”) w/o mounting bracket

Power Supply

▪1x External 65W AC/ DC power adapter

Expansion

▪1x Half Mini PCI-E interface 802.11 b/g/n WLAN module (optional)

Environment

▪Operating temperature: 0°C to +40°C

▪Storage temperature: -20°C to +80°C

▪Humidity: 10 to 90% (non-condensing)

Certification

▪CE approval

▪FCC Class A

Operating System

▪Windows 7/ Windows 8/ XP/ WES7/ WES2009/ Linux

Chapter 1: Product Introduction

Mechanical Dimensions

250.00

284.40

40.00

46.60

194.20

Chapter 2: Hardware Functionality

Front Panel Rear Panel

USB 2.0

Line-outLAN

Input

HDMIVGA

USB 2.0

USB 3.0

Power

Switch Line-in

TV Tuner

Antenna

WiFi

Antenna

Chapter 3: System Setup

Removing the Chassis Cover

Prior to removing the chassis cover, make sure the unit’s power is

off and disconnected from the power source to prevent electric

shock or system damage.

1. The screws on the bottom of cover are used to secure the cover to the

chassis. Remove these screws and put them in a safe place for later use.

CAUTION!

CAUTION!CAUTION!

Chapter 3: System Setup

Installing a DIMM

1. Locate for the DIMM socket on the board.

DIMM

sockets

2. Push the ejector tabs which are at the ends of the socket outward. This

indicates that the socket is unlocked.

Ejector tabEjector tab

Chapter 3: System Setup

3. Note how the module is keyed to the socket. Grasping the module by

its edges, align the module with the socket so that the “notch” on the

module is aligned with the “key” on the socket. The key ensures the

module can be plugged into the socket in only one direction.

Notch

Key

4. Insert the module into the socket. Apply firm even pressure to each end

of the module until it slips down into the socket. The contact fingers

on the edge of the module will almost completely disappear inside the

socket.

The ejector tabs at the ends of the socket will automatically snap into

the locked position to hold the module in place.

Table of contents

Popular Digital Signage manuals by other brands

LG 55XE3C quick start guide

All Traffic Solutions

All Traffic Solutions Shield quick start guide

LG 75XE3C owner's manual

Smart-M

Smart-M SignWare2 user guide

LG 43UL3G installation guide

ALTAI

ALTAI G009BE manual

LG 55EG5SD Easy setup guide

LG 110UM5J-B.AUSQ user guide

LG 75UL3E owner's manual

LG LAEC015 Service manual

Quanmax

Quanmax OPS-2000 Series user guide

Nightlife

Nightlife crowdDJ installation guide

Samsung

Samsung QMR-T Series manual

LG 55EW5G-V.AWM installation guide

Mvix

Mvix DLite user manual

Advantech

Advantech DSA-3400 user manual

NSE

NSE P2 Series user manual

LG 55VM5B-A.AAU owner's manual

Nexcom NDiS B322 User manual

Popular Digital Signage manuals by other brands
