ASSEMBLY & OPERATING INSTRUCTIONS
MODEL# 720-0319 FOR OUTDOOR USE ONLY
PLEASE CONTACT 1-866-984-7455 FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE

MESSAGE TO OUR CONSUMERS
Thank you for selecting our stainless steel gas grill.
Because this appliance contains features which may not found on other grill, we recommend that
you read this entire booklet before your first use. Keep it in handy place as it has answers to
questions that may occur during future use.
Read this booklet carefully and be sure your gas grill is properly assembled, installed and maintained.
Failure to follow these instructions could result in serious bodily injury and/or property damage. This gas grill
in intended for outdoor use only and is not intended to be installed in or on recreational vehicles or boats.
NOTE TO INSTALLER: Leave these instructions with the consumer after installation.
NOTE TO CONSUMER: Retain for future reference.
TABLE of CONTENTS
SECTION ONE
Precaution ……………………………...1
Placement of the grill ………………… 3
SECTION TWO
Assembly instructions ………………...4
Battery Assemble………………………10
Liquid propane Cylinder Retention…..11
Propane Tank Assemble………………11
SECTION THREE
Gas hook-up …………………………. 12
Leak testing ……….………………..... 13
Operation Instructions...………………14
Grill lighting instruction …………….. ..15
SECTION FOUR
Using the side burner ………………... 16
SECTION FIVE
Care and maintenance ………………….16
Lighting Illustration……………………….17
To match light the grill……………………18
Troubleshooting ………………………… 19
SECTION SIX
Exploded view…………………………….20
Parts list ………………………………… .21
Ordering parts ……………………………22
Grill hints ………………………………….22
SECTION SEVEN
Grill Cooking Chart ………………………23
SECTION EIGHT
Grill recipe suggestions …………………25
SECTION NINE
Warranty ………………………………….28

PRECAUTIONS
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, immediately call
your gas supplier or your fire
department
WARNING
Do not try to light this appliance without first
reading the “LIGHTING INSTRUCTIONS”
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance..
TESTED IN ACCORDANCE WITH ANSI
Z21.58b-2005 STANDARD FOR OUTDOOR
COOKING GAS APPLIANCES. THIS GRILL IS
FOR OUTDOOR USE ONLY.
Check your local building codes for the proper
method of installation. In the absence of local
codes, this unit should be installed in accordance
with the National Fuel Gas Code No.
Z223.1-1988 and the National Electrical Code
ANSI/NFPA No. 70-1990.
SAFETY PRACTICES TO AVOID PERSONAL
INJURY
When properly cared for, your stainless steel grill will
give safe, reliable service for many years. However,
extreme care must be used since the grill produces
intense heat and that can increase accident potential.
When using this appliance basic safety practices must
be followed, including the following:
Read this Care and Use Manual carefully and
completely before using your grill to reduce the risk of
fire, burn hazard or other injury.
Do not repair or replace any part of the grill unless
specifically recommended in this manual. All other
service should be referred to a qualified technician.
CHILDREN SHOULD NOT BE LEFT ALONE OR
UNATTENDED IN AN AREA WHERE THE GRILL IS
BEING USED. NEVER ALLOW THEM TO SIT, STAND
OR PLAY ON OR AROUND THE GRILL AT ANY TIME.
The Installation of this appliance must conform
with local codes or, in the absence of local codes, with
the national fuel gas code, ANSI Z223. 1a-1988.
Installation in Canada must be in accordance with the
Standard CAN/CGA-B149.1, Natural Gas Installation
Code or CAN/CGA-B149.2, Propane Installation
Code and local codes.
FOR YOUR SAFETY
-Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
CALIFORNIA PROPOSITION 65-WARNING
The burning of gas fuel generates some byproducts,
which are on the list of substances that are known by
the State of California to cause cancer or reproductive
harm. California law requires businesses to warn
customers of potential exposure to such substances.
To minimize exposure to these substances, always
operate this unit according to the use and care
manual, ensuring you provide good ventilation when
cooking with gas.
1

PRECAUTIONS
DO NOT STORE ITEMS OF INTEREST TO
CHILDREN AROUND OR BELOW THE GRILL
OR IN THE CART. NEVER ALLOW CHILDREN
TO CRAWL INSIDE OF THE CART.
Never let clothing, pot holders or other flammable
materials come in contact with or too close to any
grate, burner or hot surface until it has cooled.
Fabric may ignite and result in personal injury.
For personal safety, wear proper apparel. Loose
fitting garments or sleeves should never be worn
while using this appliance. Some synthetic fabrics
are highly flammable and should not be worn
while cooking.
Only certain types of glass, heat-proof glass
ceramic, earthenware, or other glazed utensils
are suitable for grill use. Theses types of
materials may break with sudden temperature
changes. Use only on low or medium heat
settings according to the manufacturer’s
directions.
Do not heat unopened food containers as a
build-up of pressure may cause the container to
burst.
Use a covered hand when opening the grill lid.
Never lean over an open grill.
WHEN LIGHTING A BURNER, ALWAYS PAY
CLOSE ATTENTION TO WHAT YOU ARE
DOING. BE CERTAIN YOU ARE TURNING THE
IGNITER LABELED FOR THE BURNER YOU
INTEND ON USING.
When using the grill, do not touch the grill rack,
burner grate or immediate surroundings as these
areas become extremely hot and could cause
burns. Use only dry potholders.
Moist or damp potholders on hot surfaces may
cause burns from steam. Do not use a towel or
bulky cloth in place or potholders. Do not let
potholders touch hot portions of the grill rack.
Grease is flammable. Let hot grease cool before
attempting to handle it. Avoid letting excess
grease deposits collect in the grease tray at the
bottom of the grill’s firebox. Clean often.
DO NOT USE ALUMINUM FOIL TO LINE THE
GRILL RACKS OR GRILL BOTTOM. This can
severely upset combustion air flow or trap
excessive heat in the control area.
For proper lighting and performance of the burners
keep the burner ports clean. It is necessary to
clean them periodically for optimum performance.
The burners will only operate in one position and
must be mounted correctly for safe operation.
Clean the grill with caution. Avoid steam burns; do
not use a wet sponge or cloth to clean the grill
while it is hot. Some cleaners produce noxious
fumes or can ignite if applied to a hot surface.
Keep the cover of the grill closed during preheat
period
INSECT WARNING!!! Spiders and insects can
nest in the burners of this and any other grill, and
cause the gas to flow improperly. This is a very
dangerous condition which can cause a fire to
occur behind the value panel, thereby damaging
the grill and making it unsafe to operate. Inspect
the grill twice a year.
Be sure all grill controls are turned off and the grill
is cool before using any type of aerosol cleaner on
or around the grill. The chemical that produces the
spraying action could, in the presence of heat,
ignite or cause metal parts to corrode.
2

PRECAUTIONS
Do not use the grill for cooking excessively fatty
meats or products which promote flare-ups. Do
not operate the grill under unprotected
combustible construction. Use only in well
ventilated areas. Do not use in buildings,
garages, sheds, breezeways or other such
enclosed areas. THIS UNIT IS FOR OUTDOOR
USE ONLY.
Keep the area surrounding the grill free from
combustible materials, trash, or combustible
fluids and vapors such as gasoline or charcoal
lighter fluid. A minimum of 24” clearance away
from combustible material. Do not obstruct the
flow of combustion and ventilation air. If the unit is
stored indoors ensure that it is cool. If propane is
used, the cylinder must be unhooked and the
propane cylinder stored outside in a well
ventilated area, out of the reach of children.
DO NOT USE BRIQUETTES OF ANY KIND IN
THE GRILL.
This stainless steel grill is designed for optimum
performance without the use of briquettes. Do not
place briquettes on the radiant as this will block off the
area for the grill burners to vent. Adding briquettes
can damage ignition components and knobs, and
void the warranty.
Keep the back of the cart free and clear from debris.
Keep any electrical supply cord, or the rotisserie
motor cord away from the heated areas of the grill.
Never use the grill in extremely windy conditions. If
located in a consistently windy area (oceanfront,
mountaintop, etc.) a windbreak will be required (see
below). Always adhere to the specified clearance.
NEVER USE A DENTED OR RUSTY PROPANE
TANK.
PLACEMENT OF THE GRILL
Locate the grill only in a well-ventilated area. Never
locate the grill in a building, garage, breezeway, shed
or other such enclosed areas without an approved
ventilation system. During heavy use, the grill will
produce a lot of smoke. Lock the wheels after the grill
is placed in a suitable position according to the sticker
located beneath the right door. Keep any electrical
supply cord and the fuel supply hose away from any
heated surfaces. Storage of an outdoor gas cooking
appliance indoor is permissible only if the cylinder is
disconnected and removed from the appliance.
This outdoor cooking gas appliance shall be used
only outdoor and shall not be used in a building,
garage or any other enclosed area. This appliance
is not intended to be installed on or on recreational
vehicles and/or boats
CLEARANCE
To Non-Combustible Construction
A minimum of 3” clearance from the back of the
grill to non-combustible construction is required
for the lid to open fully.
DO NOT INSTALL THIS UNIT INTO
COMBUSTIBLE ENCLOSURES!
LOCATION
When determining a suitable location take into
account concerns such as exposure to wind,
proximity to traffic paths and keeping any gas
supply lines as short as possible.
3

ASSEMBLE INSTRUCTIONS
PLEASE READ THE INSTURCTION CAREFULLY AND FOLLOW STEP BY STEP
¾Propane Tank is not included
¾Philips head Screwdriver (not provided)
¾The following hardware is provided
4

STEP 1:
Attach and secure the casters with brake (A) using the provided truss head and lock washer.
Attached wheels (B) Left cart panel leg by removing the hex nut screw first and assembling both wheels as shown
below.
A.
B.
STEP 2:
Attach the wire shelf to stand-up shelf to bottom panel use 4 (¼” by 15mm) truss head screws and 4 pieces of split
washer.
5

STEP 3:
Attach both left & right panel legs to bottom panel with 8 (1/4” x 40mm) truss head screws & split lock washers as
shown in diagram.
STEP 4:
Attach front panel to front legs of side panels use 4(1/4” x 8mm) truss head screws & split lock washers.
6

STEP 5:
Attached and secure the cart frame cross bar to the top back of both side panels by using 4(1/4” x 15 mm) truss
head screws & lock washers.
STEP 6:
Place the upper portion of grill on to the assembled cart.
Caution: To avoid injury, we strongly recommend 2 or more persons for this step.
7

STEP 7:
Secure head unit to cart with 4 (1/4” x 15mm) truss head screws & split lock washers as shown in diagram.
(Note: remove the cooking grids before this step)
STEP 8:
Place and secure the left and right side shelf bracket to side panel legs use 8 truss head screw (1/4” x 15 mm) and
split lock.
8
