1
ASSEMBLY & OPERATING INSTRUCTIONS
Model: 720-0600
FOR PROPANE GAS USE ONLY
FOR OUTDOOR USE ONLY
This instructions manual contains important information necessary for the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the appliance
Follow all warnings and instructions when using the appliance
Keep this manual for future reference
800
700
600
500
400
300
200
100
K20Y07P-1

2
DANGER
Ifyousmell gas:
1Shutoff gas totheappliance.
2Extinguishanyopenflame.
3Openlid
4Ifodorcontinues, keepawayfromthe
appliance andimmediatelycall yougas
supplieroryourfiredepartment.
WARNING
1.Donotstoreoruse gasolineorother
flammableliquidsorvaporsinthevicinity
ofthisoranyotherappliance.
2.AnLPcylindernotconnectedforuse
shall notbestoredinthevicinityofthisor
anyotherappliance.
Failuretocomplywiththeseinstructionscouldresultinafireorexplosionthatcouldcauseseriousbodily
injury, death, orpropertydamage.
Combustionbyproductsproduced when using thisproductcontainchemicalsknowntotheStatesof
Californiatocausecancer, birthdefects, orotherreproductiveharm
Yourgrillwillbeveryhot. Neverleanoverthecookingarea whileusingyourgrill.Do nottouchcooking
surfaces, grillhousing,lidoranyothergrill partswhilethegrillisinoperation, oruntilthegasgrillhas
cooled downafteruse.
TableofContents
SafetyInstruction
SafetyInstruction... ....... ..... ......
AssemblyInstruction... ....... ..... ...
GasHook Up.... ....... ..... .......
InstallerFinalCheck List. ...... ..... ...
LeakTesting..... ....... ..... ...... .
OperatingInstruction ..... ..... ....... .
GrillLightingInstruction .... ...... ......
LightingIllustration .... ..... ....... ....
ToMatchtheLight Grill. ...... . ………….
MotorInstruction.... ...... ...... ......
ConvertingtoNatural Gas. . ....... ..... .
InstructionsforConvertingtoNaturalgas. . .....
GasConversion ..... ..... ....... ..... ....
Careand Maintenance... ...... ...... ......
TroubleShooting . ...... ...... ...... .......
Exploded View..... ....... ..... ....... ...
PartList. ...... ...... ...... ...... ...... ..
OrderingParts... ....... ..... ....... ..... .
GrillHints.. ....... ..... ....... ..... ......
GrillCookingChart. ..... ....... ..... ......
GrillRecipe Suggestion .... ...... ...... .....
LimitedWarranty...... ...... ...... ...... .
2-7
8-12
13-14
14
15-16
17
18-19
20
21
22
23-24
25
26-32
33-34
35-38
39
40-41
42
42
43-44
45-47
48

3
WARNING
ELECTRICALGROUNDINGINSTRUCTIONS Thisappliance(rotisseriemotor)isequippedwithaplug
and shouldbe pluggeddirectlyintoaproperlygroundedreceptacle.Wheninstalled, must beelectricallygrounded
inaccordancewithlocalcodesorintheabsenceoflocalcodes,withtheNationalElectrical Code,ANSI/NFPA 70
ortheCanadian ElectricalCode, CSAC22.1DO NOTcut orremovethegroundingprong fromthisplug.
1.Toprotect against electricshock,donotimmersecordorplugsinwaterorotherliquid.
2.Unplug fromtheoutlet when notinuseandbeforecleaning.Allowtocool beforeputtingon ortakingoff
parts.
3.Do notoperateanyoutdoorcooking gasappliancewithadamagedcord, plug, oraftertheappliance
malfunctionsorhasbeendamaged inanymanner.Contactthemanufacturerforrepair.
4.Do notletthecordhang overthe edge ofatable oftouchhotsurface.
5.Do notusean outdoorcookinggasapplianceforpurposesotherthanintended.
6.When connecting,firstconnect plugtothe outdoorcooking gasappliancethenplug applianceintotheoutlet.
7.UseonlyaGround FaultInterrupt(GFI)protected circuit withthisoutdoorcookinggasappliance.
8.Neverremovethegroundingplugorusewithanadapterof 2prongs.
9.Useonlyextensioncordswitha3prong groundingplug, rated forthepoweroftheequipments,and
approved foroutdoorusewithaW-Amarking.
SafetyInstructioncontinued

4
SafetyInstructioncontinued
WARNING
Donottrylightingthisappliancewithoutreadingthe
“LIGHTING INSTRUCTIONS”sectionof thismanual.
TESTEDINACCORDANCEWITHANS
Z21.58 CSA1.6-2007STANDARDFOR
OUTDOORCOOKING GASAPPLIANCE.
THISGRILLISFOROUTDOORUSE
ONLY.
CAUTION:BewareofFlashback
Grill Installation Codes
Check yourlocalbuildingcodesforthepropermethodof
installation. intheabsenceoflocalcodes,thisunit
shouldbeinstalledinaccordancewiththeNationalFuel
GasCode,ANSIZ223.1/NFPA54,Storageand Handling
of LiquefiedPetroleumGases, ANSI/NFPAB149.2or
CSA B149.1NaturalGasandPropaneInstallation Code,
and theNationalElectricalCode,ANSI/NFPA 70.
CorrectLPGasTankUse
LPgasgrillmodelsaredesignedfor usewithastandard
20 lb.Liquid PropaneGastank,not includedwithgrill.
Never connectyourgasgrilltoanLPgastankthat
exceedsthiscapacity.
Ifanexternalelectricalsourceisutilized: Theoutdoor
cooking gasappliance,wheninstalled,mustbe
electricallygroundedinaccordancewithlocalcodesor,
intheabsenceoflocalcodes,withtheNationalElectrical
Code,ANSI/NFPA70,ortheCanadianElectricalCode,
CSA C22.1.
WARNING
Keepanyelectricalsupplycordandthefuelsupplyhose
awayfromanyheatedsurfaces.
NOTE:Thenormalflowof gasthroughtheregulatorand
hoseassemblycancreateahumming noise. Alow
volumeofnoiseisperfectlynormalandwillnotinterfere
withoperationofthegrill.If hummingnoiseisloud and
excessiveyou mayneedtopurgeairfromthegaslineor
reset theregulatorexcess gasflowdevice. Thispurging
procedureshouldbedoneeverytimeanewLPgastank
isconnectedtoyourgrill.
CAUTION: Spidersandsmallinsectsoccasionally
spinwebsormakenestinthegrill
burnertubesduringtransitand
warehousing.Thesewebscan lead
togasflowobstruction,whichcould
resultinafireinandaroundburner
tubes.Thistypeoffireisknownas
“FLASH-BACK”andcancauseseriousdamageto
yourgrillandcreatean unsafeoperatingcondition for
theuser.
Althoughanobstructedburnertubeisnot theonly
causeof “FLASH-BACK”,itisthemostcommon
cause.
Toreducethechanceof “FLASH-BACK”, you must
clean theburnertubesbeforeassemblingyourgrill,
and atleastonceamonthinlatesummerorearlyfall
whenspidersaremostactive.Alsoperformthis
burnertubecleaningprocedureifyourgrillhasnot
beenusedforan extendedperiod oftime.Aclogged
tubecanlead toafirebeneaththegrill.
Visuallycheck theburnerflamespriortoeachuse.
Theflamesshouldlooklikethispicture.Iftheydo not,
refertotheburnermaintenancypartofthismanual.

5
LP-GasSupplySystem
§Iftheinformation isnotfollowedexactly,afireresultingindeathor
seriousinjurycouldoccur.
§A20lbtankofapproximately12inchesindiameterby18-1/4inches
highisthemaximumsizeLPgastanktouse.
§Thissafetyfeaturepreventsthetankfrombeingoverfilled,which
can causemalfunctionof theLPgastank,regulatorand/orgrill.
§TheLPgassupplycylindertobeusedmustbeconstructedand
markedinaccordancewiththespecificationsforLP Gascylinderof
theU.S. Departmentof Transportation(DOT)ortheNational
StandardofCanada,CAN/CSA B339, Cylinders, Spheresand
TubesforTransportationof DangerousGoodsandCommission .
§TheLPgastankmusthaveashutoff valveterminating inanLP
valveoutletthat iscompatiblewithaType1. LPgassupplycylinder
must haveashutoff valveterminatinginavalveoutlet specifiedfor
connection typeQCC1inthestandardforcompressedgascylinder
valveoutlet andinlet connectionANSI/CGA-V-1asapplicable. LP
gassupplycylindermust befittedwithanOverfillProtectionDevice
(O.P.D)TheLPgastankmustalsohaveasafetyrelief devicethat
hasadirectconnectionwiththevaporspaceofthetank.
§Thetanksupplysystemmust bearrangedforvaporwithdrawal.
§TheLPgastankusedmust haveacollartoprotectthetankvalve
§Placedustcaponcylindervalveoutlet wheneverthecylinderisnot
inuse.Onlyinstallthetypeofdustcaponthecylindervalveoutlet
that isprovidedwitthecylindervalve. Othertypesofcaporplugs
mayresultinleakageofpropane
§Never connectanunregulatedLPgastanktoyourgasgrill.
§Thisoutdoorcookinggasapplianceisequippedwithahigh capacity
hose/regulatorassemblyforconnection toastandard20lb.Liquid
propanecylinder.
§HaveyourLPgastankfilledbyareputablepropanegas
dealerand visuallyinspectedand re-qualifiedateachfilling.
§Donot storeaspareLPgascylinderunderornearthis
appliance.
§Neverfill thecylinderbeyond 80percentfull.
§AlwayskeepLPgastanksinan uprightposition.
§Donot storeorusegasolineorotherflammablevaporsandliquids
inthevicinityofthisoranyotherappliance.
§Storageofanoutdoorcooking gasapplianceindoorsispermissible
onlyifthecylinderisdisconnectedandremovedfromtheoutdoor
cooking gasappliance..
§When yourgasgrill isnotinusethegasmust beturnedoffatLP
gastank.
•Thegasmustbeturnedoff at thesupplycylinderwhentheoutdoor
cooking gasapplianceisnotinuse.
•LPgastankmustbestoredoutdoorsinawell-ventilatedareaand
outofreachofchildren.DisconnectedLPgastanksmustnotbe
storedinabuilding,garageoranyotherenclosedarea.
PROPERPLACEMENTAND CLEARANCEOF
GRILL
•Neveruseyourgasgrill inagarage,porch,shed,
breezewayoranyotherenclosed area.Yourgasgrill is
tobeusedoutdoorsonly.
•DoNot install thisunit intocombustibleenclosures.
•Minimumclearancefromsidesand backofunitto
combustibleconstruction,24inches(61cm)fromsides
and 24inches(61cm)fromback.
•DO NOT usethisapplianceunderoverhead
combustiblesurfaces. Thisoutdoorscookinggas
applianceisnotintend tobeinstalledinoron
recreationalvehiclesand/orboats.
•DoNotobstructtheflowofventilationairaroundthe
gasgrillhousing.Onlyusetheregulatorandthehose
assemblysuppliedwithyourgasgrill.Replacement
regulatorsandhoseassembliesmustbethosespecified
inthismanual.
•Theregulatorandhoseassemblymustbeinspected
beforeeachuseofthegrill.Ifthereisexcessive
abrasionorwearorifthehoseiscut, it must be
replacedpriortothegrillbeing put intooperation. The
replacement hoseassemblyshallbethatspecifiedby
themanufacturer.
•Pressureregulatorand hoseassemblysuppliedwith
theoutdoorcooking gasappliancemustbeused.Never
substituteothertypesofregulator.Contactcustomer
serviceformanufacturerspecifiedreplacementparts.
•Thisoutdoorcookinggasapplianceisequippedwitha
pressureregulatorcomplywiththestandardfor
PressureRegulatingValvesforLPGasANSI/ UL144.
•Donot usebriquettesofanykindinthegrill.
•Thegrillisdesignedforoptimumperformancewithout
theuseofbriquettes.Donotplacebriquettesonthe
radiantasthiswill blockofftheareaforthegrillburners
tovent.Addingbriquettescandamageignition
componentsand knobs,andvoidthewarranty.
•Keepthebackandsidecartfree and clearfromdebris.
Keepanyelectricalsupplycord,ortherotisseriemotor
cordawayfromtheheatedareasof thegrill.
•Neverusethegrillinextremelywindyconditions.If
locatedinaconsistentlywindyarea(oceanfront,
mountaintop,etc.)awindbreakwill berequired. Always
adheretothespecifiedclearance.
•Neveruseadentedorrustypropanetank.
•Keepanyelectricalsupplycordandthefuelsupply
hoseawayfromanyheatedsurface
•Whilelighting, keepyourfaceandhandsasfaraway
fromthegrillaspossible.
•Burneradjustmentshouldonlybeperformed afterthe
burnerhavecooled.
SafetyInstructioncontinued

6
WARNING
Yourgrillwillget veryhot.Neverleanoverthe
cookingareawhileusingyourgrill.Do nottouch
cookingsurfaces, grill housing,lidoranyothergrill
hot surfacewhilethegrillisinoperation,oruntil the
gasgrillhascooleddownafteruse.
Failuretocomplywiththese instructionsmay
resultin seriousbodilyinjury.
WARNING
Keep aspraybottleof soapywaternearthegas
supplyvalveand check theconnectionsbeforeeach
use.
DO NOT USEALUMINUMFOILTO LINETHE
GRILLRACKSORGRILL BOTTOM.
Thiscanseverelyupset combustionairflowortrap
excessiveheatinthecontrolarea.
DO NOT LEAVETHEGRILL UNATTENDED
WHILECOOKING.
ROTISSERIEDRIVEMOTOR
USE ONLYFOROUTDOORS,DONOTEXPOSE
TORAIN.
CAUTION: TO ENSURECONTINUED
PROTECTIONAGAINSTRISKOFELECTRIC
SHOCK, CONNECTTOPROPERLYGROUNDED
OUTLETSONLY.TO REDUCETHERISKOF
ELECTRICSHOCK,KEEPEXTENSIONCORD
CONNECTIONDRYAND OFFTHEGROUND.
INSECT WARNING:
Spidersandinsectscannestintheburnersof this
and anyothergrill,andcausethegastoflow
improperly.Thisisaverydangerouscondition, which
can causeafiretooccurbehindandbeneaththe
valvepanel,therebydamagingthe grilland making it
unsafetooperate.Inspectthe grill atleast twicea
year.
SAFETYPRACTICESTOAVOIDPERSONAL
INJURY
When properlycaredfor, yourgrill willprovide safe,
reliableserviceformanyyears. However, extreme
caremust beused asthegrillproducesintenseheat
thatcanincreaseaccidentpotential. Whenusing this
appliancebasicsafetypracticesmust befollowed,
includingthe following:
Do notrepairorreplaceanypartofthe grillunless
specificallyrecommendedinthismanual.All other
serviceshouldbe referred toaqualifiedtechnician.
Thisgrill isnotintendedtobe installedinoron
recreational vehiclesorboats
Childrenshouldnotbeleftaloneorunattended inan
area wherethegrillisbeingused.Donotallowthemto
sit, standorplayinoraroundthegrillatanytime.
Do notstoreitemsofinteresttochildren around or
belowthe grill.
Do notpermitclothing,pot holdersorotherflammable
materialstocomeincontact withortooclosetoany
grate,burnerorhot surfaceuntilit hascooled.The
fabriccouldigniteandcausepersonal injury.
Forpersonal safety, wearproperapparel.Loosefitting
garmentsorsleevesshouldneverbe wornwhileusing
thisappliance.Somesyntheticfabricsarehighly
flammableandshouldnotbe wornwhilecooking.
Onlycertaintypesof glass, heat-proof glass ceramic,
earthenware, orotherglazed utensilsaresuitablefor
grilluse. Thesematerialsmaybreakwithsudden
temperaturechanges. Useonlyonlowormediumheat
settingsin accordancewiththe manufacturer’s
guidelines.
SafetyInstructioncontinued

7
WARNING
Thisoutdoorcookinggasappliance isnot
intendedtobeinstalledinoronboats.For
otherthanRVgrills, astatementthatthis
applianceisnotintendedtobeinstalledinor
onrecreationalvehicles.
Do notheatunopened foodcontainers.Abuild-upof
pressuremaycausethe containerstoburst.
Useacovered hand when opening thegrilllid.
Neverleanoveranopen grill.
When lighting aburner, paycloseattention towhat
you aredoing.Makecertainyou areawareof which
burneryouarelighting, soyourbodyand clothing
remainclearof openflames.
When usingthegrill,donot touchthegrillrack,burner
grateorimmediatesurroundingsastheseareas
becomeextremelyhotandcould causeburns.Use
onlydry potholders. Moist ordamppotholdersonhot
surfacesmaycausesteamburns.Do not useatowel
orbulky clothinplaceorpotholders.Do not allow
potholderstotouchhot portionsof thegrillrack.
Greaseisflammable. Lethotgreasecoolbefore
attempting tohandle it. Donotallowgreasedeposits
tocollect inthe greasetrayatthe bottomofthegrill’s
firebox.Cleanthegreasetrayoften.
Do notusealuminumfoiltoline thegrillracksorgrill
bottom.Thiscan severelyupsetcombustion airflowor
trap excessiveheatinthe controlarea.
Forproperlightingandperformanceof theburners
keep the burnerportsclean.Itisnecessary toclean
themperiodicallyforoptimumperformance.The
burnerswill onlyoperateinonepositionandmust be
mountedcorrectlyforsafeoperation.
Clean the grillwithcaution.Toavoidsteamburns, do
not useawet sponge orclothtoclean the grillwhileit
ishot.Somecleanersproducetoxicfumesorcan
igniteif applied toahotsurface.
Turnoff grillcontrolsand makecertainthegrilliscool
beforeusinganytype of aerosolcleaneron oraround
the grill.The chemical thatproducesthe spraying
actioncould,inthepresenceof heat, igniteorcause
metal partstocorrode.
Do notusethegrilltocookexcessivelyfattymeatsor
otherproductswhichpromoteflare ups.
Do notoperatethe grillunderunprotectedcombustible
constructions. Useonlyinwellventilated areas.Do
not useinbuildings, garages,sheds, breezewaysor
othersuchenclosed areas.
Keep the area surroundingthe grill freefrom
combustiblematerialsincludingfluids,trash, and
vaporssuchasgasoline orcharcoallighterfluid. Do
not obstructtheflowofcombustionandairventilation.
SafetyInstructioncontinued

8
PLEASE READ THEINSTRUCTIONSCAREFULLYAND FOLLOWSTEP BY
STEP.
TOOLSREQUIRED:
(1) PHILIPS HEAD SCREWDRIVER NOTPROVIDED
STEP 1:
A.The screwsusedtoattachthesideshelf are alreadyscrewedintotheleft
panel(seethe figurebelow).Removethe screwsfromthe left panel,align
withtheholesinthe side shelf, and thenre-screwintothe holeson the left
panelof thegrill.
B. The screwsusedtoattachthesideburner are alreadyscrewedintotheright
panel(seethe figurebelow).Removethe screwsfromthe rightpanel, align
withtheholesinthe side burner, and then re-screwintotheholesonthe right
panelof thegrill.
Screwsize:1/4x10mm
Washer size:1/4
800
700
600
500
400
300
200
100
AssemblyInstruction

9
C. Pushvalveintoside burner controlpanel. Insert screwsfromthe front sideof
controlpaneland tighten.
100
200
300400500
600
700
800
800 700
600
500
400
300
200
100
100
200
300400500
600
700
800
B. Pushthe side burner controlknob intothe valvesteamandtightenit using
the AllenWrench.
A.Insert valveventuriintothe side burner andtighten securelyusing an
adjustablewrench.
D. Connect ignitionwirewithvalve, keepthe igniter3-6mm awayfromthe
side burnerring.
800 700
600
500
400
300
200
100
STEP 2: Side BurnerAssembly
AssemblyInstruction continued

10
800
700
600
500
400
300
200
100
STEP 3: Batteryisinserted for the rotisserieburner. Toinstall the battery, turn the
ignitionbutton cap counterclockwiseandremoveit. Replacethe ignitionbuttoncap
after the batteryisinstalled.
800 700
600
500
400300
200
100
STEP 4: Attachthebarbarriertopre-drilled holeonbackpaneland bottom
panel,secure withscrews.
AssemblyInstruction continued

11
STEP 5: Attachpropanegastanktoregulatorinlet fittingbyturning the regulator
clockwiseasshowninfigurebelow.LPgascylindermust befittedwithalisted
overfill preventiondevice(OPD). Openthe door and pull out thetray, placethe
gastankcylinderinthe tanktray, then useretention kit thatshowed asbelow
diagramtosecure the tankcylinder. Makesure tankisleveled withbottompanel
for propervapor withdrawal.
g
OPEN
CLOSE
CYLINDERTANK FIXED
800
700
600
500
400300
200
100
AssemblyInstruction continued

12
STEP 6: The screwsforrotisseriedrivemotor bracket areattachedtothe motor
bracket. Removethescrewsand installthe rotisseriemotorbracket asshownin
the figure below. Assemblethe rotisserieskewer asshowninthefigurebelow.
AssemblyInstruction continued

13
NEVERCONNECTANUNREGULATEDGASSUPPLY
LINETOTHEAPPLIANCE.USETHE
REGULATOR/HOSEASSEMBLYSUPPLIED.
Thisisaliquidpropane configuredgrill.Do notattempt
touseanaturalgassupplyunless the grillhasbeen
reconfigured fornaturalgasuse.
Totalgasconsumption(perhour) ofthisstainless steel
gasgrillwithallburnerson “HI”:
Mainburner30,000Btu/hr
Side burner12,000Btu/hr
SearBurner15,000 Btu/hr
Rearburner10,000 Btu/hr
Total67,000 Btu/hr
L.P.TANK REQUIREMENT
Adented orrustyL.P.tankmaybehazardousand
shouldbe checkedbyyourL.P. supplier. Neverusea
cylinderwithadamagedvalve.TheL.P. gascylinder
mustbe constructedand marked inaccordancewiththe
specificationsforL.P.gascylindersoftheU.S.
DepartmentofTransportation (DOT)ortheNational
Standardof Canada, CAN/CSA-B339, Cylinders,
Spheresand TubesforTransportationof Dangerous
Goods; andCommission, asapplicable.Overfilling
prevention device(OPD)shallbe providedoncylinder&
QCCIconnectiononthecylindervalve,ANSI/CGA-V-1.
The cylindersupplysystemmustbe arrangedforvapor
withdrawal. Thecylindermustincludeacollartoprotect
the cylindervalve.The cylindermust beprovidedwitha
shut off valveterminatinginanL.P. gassupplycylinder
valveoutlet specified,asapplicable,forconnectiontype
QCC1 inthe standardforcompressed gascylinder
valveoutlet andinletconnectionANSI/CGA-V-1.
Manifoldpressure: 11”(27.94cm) watercolumn(W.C.).
L.P.GASHOOK-UP
Ensurethatthe blackplasticgrommetson the LP
cylindervalveareinplaceand that the hosedoesnot
comeintocontact withthegreasetrayorthegrillhead.
CONNECTION
Yourstainless steelgrill isequippedwithgassupply
orificesforuseonlywithliquidpropane gas. It isalso
equippedwithahigh capacityhose/regulatorassembly
forconnectiontoastandard20lb.L.P. cylinder(18-1/4”
(46.35cm)high,12-1/4”(31cm)diameter).Toconnect
the L.P. gassupplycylinder,pleasefollowthesteps
below:
1.Makesuretankvalveisfullyinoff position(turn
clockwisetostop)
2.Check tankvalvetoassureithasproperexternal
malethreads(type 1connection perANSIZ21.81)
3.Makesureall burnervalvesareinthe off position.
4.Inspectvalveconnections, port,andregulator
assembly.Lookforanydamageordebris. Remove
anydebris. Inspect hosefordamage.Never
attempttousedamagedorobstructedequipment.
See yourlocal L.P. gasdealerforrepair.
Gas Hook-Up

14
5.When connectingregulatorassemblytothe valve,
hand tighten thequick coupling nutclockwisetoa
completestop. Donotuseawrenchtotighten. Use
ofawrenchmaydamage thequick couplingnutand
resultinahazardouscondition.
6.Open thetankvalvefully(counterclockwise). Apply
the soap solutionwithacleanbrushtoallgas
connections.See below.If growing bubblesappearin
the solutionthe connectionsarenotproperlysealed.
Check eachfitting and tightenorrepairasnecessary.
7.If youhaveagasconnectionleakyoucannotrepair,
turngasOFF at supplytank, disconnect fuelline
fromyourgrilland call1-800-913-8999oryourgas
supplierforrepairassistance.
8.Alsoapplysoapysolutiontothetankseams. See
below. If growingbubblesappear,shuttankOFF
and do notuseormoveit!Contact anLPgas
supplieroryourfiredepartmentforassistance.
TodisconnectL.P.gascylinder:
1.Turnthe burnervalvesoff.
2.Turnthe tankvalveoff fully(turnclockwisetostop).
3.Detachtheregulatorassemblyfromthetankvalve
byturningthequickcouplingnut counterclockwise.
üSpecified clearancemaintained 24”(61cm)from
combustibles.
üAll internalpackaging removed.
üKnobsturn freely.
üBurners aretightand sittingproperlyonorifices.
üPressure regulatorconnectedand set.Gas
connectionstogrillusinghose &regulator
assemblyprovided(pre-setfor11.0”water
column).
üUnittestedandfreeofleaks.
üUser informedofgassupplyshutoff valve
location
USER,PLEASE RETAINTHISMANUAL FOR
FUTUREREFERENCE.
PROPANECYLINDERCAUTIONS
a)Do Notstoreaspare LP-gas cylinder underor
near thisappliance.
b)NEVERfill thecylinder beyond80 percentfull.
c)Iftheinformationin “a”and “b”isnot
followedexactly,afire orexplosioncausing
deathorseriousinjury mayoccur.
Gas Hook Upcontinued
InstallerFinalCheck List

15
Onlythosepartsrecommended bythe manufacturer
shouldbe used onthe grill.
Substitution will void the warranty. Do notusethegrill
untilallconnectionshavebeenchecked anddonot
leak.
GASFLOWCHECK
Eachgrillburneristestedandadjustedatthe factory
priortoshipment; however, variationsinthelocalgas
supplymaymakeit necessary toadjustthe burners.
The flamesoftheburnersshouldbevisuallychecked.
Flamesshouldbe blueandstablewithnoyellowtips,
excessivenoiseorlifting.If anyoftheseconditions
exist,checktosee if theairshutterorburnerports
areblocked bydirt, debris,spiderwebs, etc.If you
haveanyquestionsregardingflamestability, please
callcustomerservice
1-866-984-7455
Check allgassupplyfittingsforleaks beforeeach
use.Itishandytokeep aspraybottleofsoapy
water near theshut-off valveofthegassupplyline.
Spray all thefittings. Bubblesindicateleaks.
ALWAYS CHECK FORLEAKSAFTEREVERYL.P.
TANK CHANGE
GENERAL
Althoughallgasconnectionsonthegrillareleaktested
atthe factory priortoshipment,acompletegas
tightness check mustbe performedatthe installation
siteduetopossiblemishandlinginshipment,or
excessivepressureunknowinglybeing applied tothe
unit.Periodicallycheckthewholesystemforleaks
following the procedureslisted below.If thesmellof gas
isdetectedatanytimeyoushouldimmediatelycheck the
entiresystemforleaks.
BEFORETESTING
Makesurethatallpacking material isremoved fromthe
grillincluding tie-downstraps.
DO NOT SMOKEWHILELEAKTESTING.
NEVERPERFORMLEAKTEST WITHANOPEN
FLAME.
Makeasoap solution ofone partliquiddetergent and
one partwater.Youwillneedaspraybottle, brush,or
rag toapplythesolution tothefittings.Forthe initialleak
test, makesurethe L.P.cylinderis80%full.
TO TEST
1. Makesurethe controlvalvesareinthe “OFF”position,
and turnonthegassupply.
2. CheckallconnectionsfromtheLPgasregulatorand
supplyvalveuptoandincludingthe connectiontothe
manifoldpipe assembly(the pipethatgoestothe
burners). Soapbubbleswillappearwherealeakis
present.
3.If aleakispresent, immediatelyturnoff thegas
supplyandtightenthe leakyfittings.
4.Turnthegasback on andrecheck.
5.Should the gascontinue toleakfromanyofthe
fittings,turnoff the gassupplyandcontact customer
serviceat1-866-984-7455.
Leak Testing

16
Yourgrillisreadytouse!
CAUTIONS
Place dustcaponcylindervalveoutletwhenthecylinderisnotinuse. Onlyinstall the
typeofdustcaponthecylindervalveoutletthatisprovidedwiththecylindervalve.
Othertypes ofcapsorplugsmayresultinleakageofpropane.
Thegas mustbeturnedoff atthesupplycylinderwhentheunitisnotinuse.
Iftheappliance isstoredindoorsthecylindermustbedisconnectedandremovedfrom
theappliance. Cylindersmustbestoredoutdoorsinawell-ventilatedareaoutofthe
reachofchildren.
LeakTesting continued
800 700
600
500
400
300
200
100

17
DO NOT LEAVETHEGRILL UNATTENDED
WHILECOOKING.
WARNING:IMPORTANT!
USING THESIDEBURNER:
Inspectthe gassupplyhosepriortoturning thegas
“ON”.Ifthereisevidenceof cuts, wearorabrasion, it
mustbe replacedpriortouse.Do not usethe side
burneriftheodorof gasispresent.
USINGROTISSERIEBURNER
Yourgrilliscapableof performingbackburner
rotisseriecooking. Lightthe rearburnerasdescribed in
the lightingIllustration.Seepage20 Oncelit,the
rotisserieburnerwillreachcooking temperaturesin
about 1minute.
OperatingInstruction
GENERAL USEOF THEGRILL AND ROTISSERIE
Eachmainburnerisratedat 14,000Btu/hr.Themain
grillburnersencompass the entirecookingareaand
areside ported tominimizeblockagefromfalling
greaseand debris. Theigniterknobsarelocatedon
the lowercenterportionof the valvepanel.Each
rotary igniterislabeled onthe controlpanel.
USING THEGRILL
Grillingrequireshighheatforsearingandproper
browning. Mostfoodsarecookedatthe “HI”heat
settingfortheentirecookingtime. However, when
grilling largepiecesofmeatorpoultry, it maybe
necessary toturntheheattothelowersettingafter
the initial browning.Thiscooksthe foodthrough
without burningtheoutside.Foodscooked foralong
timeorfoodsbastedwithasugary marinade may
need thelowerheatsetting nearthe endofthe
cookingtime.
NOTE:Thisgrillisdesignedtogrill efficientlywithout
the useoflavarocksorbriquettesof anykind. Heatis
radiatedbytheflametamerspositionedaboveeach
burner.
NOTE:Thehotgrillsearsthefood, sealinginthe
juices. Themorethoroughlythegrillispreheated,the
fasterthe meatbrownsand the darkerthe grillmarks.
CAUTION:PLEASE TAKEOFF THEWARMING
RACK WHENUSINGTHEROTISSIERIEBURNER.
THEHIGHHEAT COMINGFROMTHEROTIS
BURNERMAYCAUSE THEWARMING RACKTO
WARP.

18
WARNING:IMPORTANT!
BEFORELIGHTING…
Inspectthe gassupplyhosepriortoturning thegas
“ON”.Ifthereisevidenceof cuts, wear, orabrasion,it
mustbe replacedpriortouse.Do not usethe grillif
the odorof gasispresent. Onlythepressure
regulatorandhoseassemblysupplied withtheunit
shouldbe used.
TOLIGHTTHEMAINBURNER:
Neversubstituteregulatorsand hoseassemblyfor
thosesuppliedwiththegrill.If areplacementis
necessary, contactthe manufacturer forproper
replacement.The replacement must bethat specified
inthe manual.
Screwthe regulator(typeQCC1)ontothetank.Leak
check the hoseand regulatorconnectionswithasoap
and watersolutionbeforeoperatingthe grill.
TOLIGHTTHEGRILLBURNER:
Makesureall knobsare “OFF”thenturnonthegas
supplyfromthe LPtank.Alwayskeep yourfaceand
bodyasfarfromthe grillaspossiblewhen lighting.
Yourgrillhasan exclusivepatentedbuilt-inignition.
The igniterisbuiltintothe valve.Toigniteeachburner
simplypushandturnthe controlknobstotheHIsetting,
you willhearthevalveclickasitsendsaspark tothe
pilotflame. If theburnerdoesnotlight wait5minutes
foranyexcess gastodissipateand thenretry.
WARNING:Alwayskeep yourfaceandbodyasfar
away fromtheburner aspossiblewhenlighting.
TOLIGHTTHESIDEBURNER
Tolightthe sideburner, removeanycookingutensils
fromthe burnergrate.Pushandturnthecontrolknob
counter-clockwisetothe “IGNITE/HI”position.Ifthe
burnerdoesnot light, turnthe controlknob to “OFF”.If
the smellofgasisdetectedandtheigniterisnot
functioning,immediatelyturnthe controlknob “OFF”.
Allow5minutesforanyaccumulatedgastodissipate.
If theside burnerigniterisnotfunctioning, see the
following section formatchlighting.
TOMATCH LIGHTTHEGRILL
If theburnerwillnotlightafterseveral attemptsthenthe
burnercanbe matchlit.
Matchlightextension rodislocatedon theinsidepanelof
the door.
If you’vejust attemptedtolighttheburnerwiththe
igniter, allow5minutesforanyaccumulated
gastodissipate.Keepyourfaceandhandsas
farawayfromthe grill aspossible.
1)Insert alit matchattachedtothelighting rod
through thecookinggridstothe burner(see
next page)
2)Press the controlknoband rotateleft tothe
HI/Lightsetting,continue topress the knob
untiltheburnerignites. Burnershouldlight
immediately.
3)Ifthe burnerdoesnotlightin 4secondsturn
the knob off,wait5minutesandtryagain.
TOMATCH LIGHTTHESIDEBURNER
Holdalit extendedmatchnearthe sideburnerports,
turnthe controlknob counterclockwiseto “IGNITE/HI”.
Moveyourhandimmediatelyoncetheburnerislit.
Rotatethecontrol knobtothe desired setting.
Keep aspraybottleofsoapywaternearthegas
supplyvalveandchecktheconnectionsbefore
eachuse.
Do notattempttolightthegrillifodorofgas is
present. Call forservice
1-866-984-7455
Grill Lighting Instruction

19
Eachburner isadjustedpriortoshipment;
however,variationsin thelocalgassupply
may take minoradjustmentsnecessary.
Visuallychecktheburnerflamespriortoeachuse.
The flamesshouldlooklikethispicture.If theydo
not,refertothe burnermaintenancepartofthis
manual.
GrillLighting Instruction continued
FLAME CHARACTERISTICS
Check forproperburnerflamecharacteristics.
Burnerflamesshouldbeblueandstablewithno yellowtips,excessivenoise, orlifting.If anyofthese
conditionsexist callourcustomerserviceline.Iftheflameisyellow, itindicatesinsufficientair.Ifthe
flameisnoisyandtendstolift awayfromthe burner,itindicatestomuchair
Approximate11/2 Flame
Height

20
Main&SideBurnerLightingIllustration
Step 1.
MakesuretheLidisopen
Step 2.
PushandturnmainorSideBurnerknobsto
“IGNITE/HI”position. Pilot torchwilllight. Holdfor
3-4secondsuntilburnerislit.
Step 3.
You mayneed totry3or4timestolight theburner.
Afterthe burnerislit, adjust the knob asdesired.
RotisserieBurnerorSearing
BurnerLightingIllustration
SteptolighttheRotisserieBurner:
Pushand turnthe RotisserieBurner
Knob to “IGNITE/ON”positionand
holdfor3-4secondsthenpush
electronicignition button atthesame
time,untilburnerislit.
SteptolighttheSearingBurner:
Pushand turnthe Searing Burner
Knob to “IGNITE/HI”positionand
holdfor3-4secondsand push
electronicignition button at same
time,untilburnerislit. Onceitislit,
releaseelectronicignitionbutton,
and holdthe Searing knob for
another15 secondstobe surethe
burnerstaylit.
LightingIllustration
