INSTRUCTION MANUAL FOR
NEXT LEVEL RACING MATTE BLACK
SIMULATOR COCKPIT
If you require any support with your product or have an issue,
please contact our friendly team at:
[e-mail]
for a prompt response.

Thank-you for purchasing a
If you require any support with your product or have
an issue, please contact our friendly team at:
[e-mail]
for a prompt response.
WARNING
-Please do not use power tools for assembly as over
tightening can damage your frame.
-During assembly please be sure to have a washer positioned
at the front of every bolt as pictured below.
Simulator Cockpit

F-GT SIMULATOR COCKPIT
For assistance please contact: [email protected]
www.nextlevelracing.com
What’s In The Box:
60MM BOLTS
50MM BOLTS
SCREWS FOR WHEEL
SHIFTER PEDALS
LUMBAR/ NECK CUSHION
SEAT BASE SEAT BACK

For assistance please contact: [email protected]
www.nextlevelracing.com
F-GT SIMULATOR COCKPIT
Step 1: FRAME ASSEMBLY
1 X 16MM BOLT
Repeat both sides
Step 2:
Step 3:
1 X 50MM BOLT.
Repeat both sides.
Install SUPPORT POST on third hole from front for GT and last hole for Formula
2 X 50MM BOLTS
Repeat both sides
SUPPORT POST
SIDE FRAMES
FLOOR POSTS
FRONT PLATE

F-GT SIMULATOR COCKPIT
For assistance please contact: [email protected]
www.nextlevelracing.com
Step 5:
4 X 16MM BOLTS.
Repeat both sides.
Step 4: SEAT ASSEMBLY
Attach ANGLE MOUNTS to SEAT BASE
Step 6:
Attach SEAT SIDE FRAMES to SEAT BASE
2 X 16MM BOLTS.
Repeat both sides.
3 X 16MM BOLTS.
Repeat both sides.
Attach SEAT BACK to ANGLE MOUNTS
Angle Mounts
SEAT SIDE FRAMES
PLEASE NOTE: DUAL NUT PLATE SITS
INSIDE SEAT SLIDER FRAME

For assistance please contact: [email protected]
www.nextlevelracing.com
F-GT SIMULATOR COCKPIT
Step 7: Formula ASSEMBLY
PEDAL PLATE
PEDAL ANGLE BAR
5. Attach PEDAL PLATE to the
PEDAL ANGLE BAR using 2 X
16MM BOLTS on each side.
Repeat both sides.
*For Formula- Recommend
attaching at bottom of PEDAL
PLATE as pictured
WHEEL PLATE
3.
2 X 50MM BOLTS.
Repeat both sides.
2. Insert WHEEL SUPPORT BARS.
Use the 2 X 16MM BOLTS on each side
to adjust height.
1.
2 X 60MM BOLTS.
Repeat both sides.
*Once you're happy with the
position, tighten as much as possible
to ensure wheel support is strong
and rigid.
4. Attach PEDAL ANGLE BAR using
2 X 60MM BOLTS.
Repeat both sides.
WARNING
DO NOT OVER TIGHTEN 2 X 60MM BOLTS FOR PEDAL PLATE
OR YOU CAN DAMAGE YOUR FRAME

F-GT SIMULATOR COCKPIT
For assistance please contact: [email protected]
www.nextlevelracing.com
Step 8: Formula ATTACHING SEAT
- PEDAL ANGLE BAR: This determines the distance of your pedals. If you are a shorter user attach
closer to the seat. Opposite for taller users.
- In Formula position, for extra comfort you may find the LUMBAR SUPPORT CUSHION provided
suitable to use for your neck or head.
1 X 60MM BOLT.
Repeat both sides.
1 X 60MM BOLT.
Repeat both sides.
Step 9: Formula TIPS

For assistance please contact: [email protected]
www.nextlevelracing.com
F-GT SIMULATOR COCKPIT
Step 10: GT ASSEMBLY
1.
2 X 60MM BOLTS.
Repeat both sides.
*Once you are happy with the position
tighten as much as possible to ensure wheel
support is strong and rigid
2. Insert Wheel Support Bars.
Use 2 X 16MM BOLTS on each side
to adjust height.
3. 2 X 50MM BOLTS.
Repeat both sides.
WHEEL PLATE
PEDAL PLATE
4. Attach GT SEAT
SUPPORTS to last holes
using 2 X 60MM BOLTS.
Repeat both sides.
5. Attach PEDAL PLATE to
frame using 1 X 16MM BOLT.
Repeat both sides.
WARNING
DO NOT OVER TIGHTEN 2 X 60MM BOLTS FOR PEDAL PLATE
OR YOU CAN DAMAGE YOUR FRAME
PEDAL ANGLE BAR

F-GT SIMULATOR COCKPIT
For assistance please contact: [email protected]
www.nextlevelracing.com
Step 11: GT SEAT ASSEMBLY
-In GT position for extra comfort you may find the LUMBAR SUPPORT CUSHION provided suitable
to use for your higher back or shoulders.
- Many GT users prefer pedals in Formula style position meaning no need to change pedal position.
2 X 60MM BOLTS.
Repeat both sides.
2 X 60MM BOLTS.
Repeat both sides.
Step 12: GT TIPS

For assistance please contact: [email protected]
www.nextlevelracing.com
F-GT SIMULATOR COCKPIT
Step 13: GEAR SHIFTER ASSEMBLY
Left hand side shifter
Step 14:
Right hand side shifter
SHIFTER ARM
SHIFTER BRACKET
2 X 50MM BOLTS
2 X 50MM BOLTS

F-GT SIMULATOR COCKPIT
For assistance please contact: [email protected]
www.nextlevelracing.com
Step 15: BUTTKICKER® GAMER 2 ADAPTOR
2 X 50MM BOLTS

For assistance please contact: [email protected]
www.nextlevelracing.com
F-GT SIMULATOR COCKPIT
Step 16: CHANGING FROM Formula TO GT
Step 17: CHANGING FROM GT TO Formula
.
.
4. Wheel Angle
May need adjustment
1. PEDAL PLATE
*Please note many GT users
prefer pedals in Formula style
position meaning no need for
change.
Remove the PEDAL PLATE
from the PEDAL ANGLE BAR
and mount the PEDAL PLATE
directly to the FRONT PLATE.
Please reverse the steps when changing from GT to Formula mode.
3. Seat Angle
May need
adjustment
2. GT SUPPORT
POSTS
Attach
GT SUPPORT POSTS
on each side to lift
seating position
5. Wheel Position
May need adjustment

F-GT SIMULATOR COCKPIT
For assistance please contact: [email protected]
www.nextlevelracing.com
Step 18 (OPTIONAL):
For maximum rigidity over adjustability, install optional FELT STRIPS in
WHEEL SUPPORT BARS. This means sliding holes in frame won't be eective to
change position
Step 19:
Attach HEIGHT ADJUSTABLE FEET to bottom of cockpit frame
