Next Level Racing FLIGHT SIMULATOR NLR-S018 User manual

Video Instruction: bit.ly/nlrbuild
INSTRUCTION MANUAL
TAKE IT TO THE SKIES
*ELECTRONICS NOT INCLUDED

2 3
YOUR
FLIGHT
JOURNEY
STARTS
HERE
We know you’re eager to start flying! Take your time with the
instructions and follow this guide to assemble your product.
You’ll be setting yourself up for success by following the
instruction booklet to fully optimize your product.
TAKE IT
TO THE SKIES
NEXTLEVELRACING.COM
@nextlevelracingOcial
@next_level_racing
@nextlvlracing
Next Level Racing
[e-mail]
ASSEMBLY
VIDEO

4 5
WARNING
• Please do not use power tools for assembly as over tightening can damage your frame.
• Lay out and build the cockpit on a level surface.
• Do not force parts together.
• Avoid cross threading bolts.
• If in doubt consult the installation video.
If you require any support with
your product please contact our friendly team at:
[e-mail]
PRE-FLIGHT
CHECKS IN THE BOX
WARNING
Small parts not for children under 3 years
or any individuals who have a tendency to place inedible objects
in their mouths.
ASSEMBLY
VIDEO
2 x SEAT FRAMES
1 x MOUSE PLATE
1 x PEDAL PLATE
1 x PEDAL FRAME
1 x CENTRE YOKE PLATE
1 x HOTAS OUTER POLE
1 x SEAT BOTTOM
1 x PEDAL ANGLE PLATE
1 x FLIGHT PLATE
1 x HOTAS INNER POLE
1 x SEAT BACKREST
1 x END PLATE
1 x HOTAS PLATE
1 x CENTRE INNER POLE
1 x SIDE ARM (LEFT)
1 x CROSS MEMBER
1 x CENTRE OUTER POLE
1 x SIDE ARM (RIGHT)
2 x SIDE PANELS
1 x KEYBOARD PLATE

6 7
[e-mail]
4 x 20mm KNOBS 1 x M8 70mm BOLT 6 x SQUARE WASHERS 10x M6 20mm
THREADED STUDS 1 x 13mm WRENCH (M8)
14 x M4 16mm BOLTS
26 x M6 16mm BOLTS
14 x M8 16mm BOLTS 40 x M8 55mm BOLTS 8 x M5 60mm BOLTS
14 x M4 FLANGE NUTS
8 x M5 FLANGE NUTS
34 x M6 FLANGE NUTS
40 x M8 FLANGE NUTS
14 x M4 WASHERS
8 x M5 WASHERS
26 x M6 WASHERS
55 x M8 WASHERS
4 x ALLEN KEYS 1 x M4/M6 WRENCH
1 x M5/M6 WRENCH 6 x ADJUSTABLE FEET 1 x BUTTKICKER POLE 1 x SEATBELT
1 x TURTLE BEACH ADAPTOR 6 x VELCRO CABLE TIES 1 x LUMBAR CUSHION 2 x TPR ADAPTORS
2 x FELT PADS
(30mm x 120mm) 1 x SUPPORT BRACKET 1 x SUPPORT BRACKET MOUNT 1 x 40mm BARREL SPACER 1 x CLAMP PLATE
1 x KEYBOARD ARM 10 x M8 16mm WASHERS 1 x KEYBOARD MAT 1 x MOUSE MAT
ANGLE HEIGHT DISTANCE
RUDDERS
YOKE
SEAT
THROTTLE
ADJUSTMENT POINTS
The Flight Simulator is a fully adjustable cockpit making it perfect for flight
enthusiasts of all sizes. Utilize the various adjustment poin ts to achieve the most
comfortable position.
M8
M6
M5
M4
1 x STRAIGHT SIDE ARM

PARTS:
•
• 1 x Pedal Frame
•
• 1 x Pedal Angle Plate
•
• 4 x M8 55mm Bolts
•
• 4 x Square Washers
•
• 4 x M8 Flange Nuts
PARTS:
•
• 1 x Pedal Plate
•
• 4 x M8 16mm Bolts
•
• 4 x M8 Washers
PARTS:
•
• 2 x Seat Frames
•
• 2 x M8 55mm Bolts
•
• 2 x M8 16mm Bolts
•
• 4 x M8 Washers
•
• 2 x M8 Flange Nuts
PARTS:
•
• 2 x Side Panels
•
• 4 x M8 55mm Bolts
•
• 4 x M8 Washers
•
• 4 x M8 Flange Nuts
PARTS:
•
• 1 x Cross Member
•
• 4 x M8 55mm Bolts
•
• 4 x M8 Washers
•
• 4 x M8 Flange Nuts
PARTS:
•
• 1 x End Plate
•
• 4 x M8 55mm Bolts
•
• 4 x M8 Washers
Align the mounting holes on the Pedal Angle Plate with the slots on the Pedal Frame.
Bolt through and secure with 4 x M8 Bolts, Square Washers and Flange Nuts.
Align the mounting slots on the Pedal Plate with the threaded inserts on the Pedal Angle Plate.
olt through and secure with 4 x M8 Bolts and Washers.
