Next AMELIA CABIN BED 178779 User manual

Actual product size
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
Need Help?
CALL: 0333 777 8999
With: Assembly instructions
Missing or damages parts
H127.1 x W199.7 x D109.5cm

1
Do’s
We suggest you spend a short time reading through this leaflet before you start
When you are ready to start, make sure that you have the right tools and plenty of space
Unwrap all packaging materials and place the components on a clean surface to protect it from damage,
we recommend that the packaging is used to protect the surfaces during assembly
Carefully check that you have all the parts before beginning assembly
Due to the size of the product we recommend that it is assembled in the room intended for use
Ensure the product is fully assembled as illustrated and all fixings fully tightened before use
Wipe occasionally with a soft cloth slightly dampened with water. Then buff with a dry clean soft cloth
Wood will mellow and change colour over time, we recommend that ornaments and items placed on the surface are
moved regularly for the first few months to prevent uneven mellowing
Don’ts
Do not drag or pull your furniture
Do not rub or scrub the surface when cleaning
Do not use silicone based furniture polish. Silicone in furniture polishes can break down the finish
Never allow any kind of liquid to remain on your furniture. Absorption can cause wood to warp or finishes to de-laminate
Do not place hot items (e.g. hot drinks) directly on to the wood surface. Please make sure you use a placemat or coaster
BEFORE YOU START
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
PH2
30min
Number of people required to assemble
Time to assemble
Tools required
Two people are required to assemble this item
WARNING: “High beds and the upper bed of bunk beds
are not suitable for children under six years due to the risk
of injury from falls”.
WARNING: “Bunk beds and high beds can present a
serious risk of injury from strangulation if not used correctly.
Never attach or hang items to any part of the bunk bed that
are not designed to be used with the bed, for example, but
not limited to ropes, strings, cords, hooks, belts and bags”.
WARNING: “Children can become trapped between the
bed and the wall. A roof pitch, the ceilling. adjoining pieces
of furniture (e.g.cupboards) and the like. To avoid risk of
serious injury the distance between the top safety barrier
and the wall shall not exceed 75mm or shall be more than
230mm”
WARNING: Do not use the bunk bed/high bed if any
structural part is broken or missing.
· Always follow the manufacturer’s instructions.
· Recommended use only mattress which is L190 x W90 x
17cm or less in thickness on upper bunk bed.
· The ventilation of the room is necessary in order to keep
the humidity low and to prevent mould in and around the
bed.
· A statement to check regularly that all assembly
fastenings are properly tightened.

2
1
2
5
4
12
3
6 9
9
8
7
15
15
15
15
14
13
13
16
12
11
11
10
10
GETTING TO KNOW YOUR PRODUCT
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779

3
Ref Dimensions Visual Qty
1
Ctn
2
3
4
5
6
191.8 x 92cm
192 x 35.5cm
192 x 40cm
192 x 17.8cm
127.1 x 99.1cm
127.1 x 99.1cm
78 x 56.4cm
78 x 56.4cm
11
7
8
1 3
1 1
1 1
3
1
1
1
1 2
1 2
38.5 x 52.6cm
92 2
74.2 x 53.1cm
10
74.2 x 52.7cm
11
78 x 74.2cm
12
2 2
2 2
2 2
Ref Dimensions Visual Qty
13
Ctn
14
15
16
74.2 x 5cm
105.7 x 43.6cm
34 x 36.6cm
39.9 x 11cm
12
1 3
4 1
21
Components supplied. Please use this guide if you require replacement parts.
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779

4
12Ø6 x 65mm 2a
4Ø5 x 65mm 1a1
8
6
N/A
Ø5 x 50mm 1a2
Ø4 x 40 mmb
N/AØ8 x 40mm
1
Ø8 x 38 mmc 2
2
d
N/AØ6 x 30mm 2
d1
N/AØ15 x 9.5mm 2f
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty Spare
Qty
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
Fixtures and fittings supplied (not to scale)
Ref Dimensions Qty Visual
Spare
Qty
N/A N/Ah 4
N/A N/A
N/A
p 8
N/Aq 4
N/A N/Av 1
x 2

5
TURN THE CAM IN A CLOCKWISE DIRECTION
PUSH THE TWO PANELS TOGETHER ALLOWING THE
DOWEL TO ALIGN WITH THE HOLE
WHEN TIGHTENING THE CAM
TURN THE CAM IN A CLOCKWISE DIRECTION UNTIL THE
ARROW POINTS IN THE POSITIONS SHOWN IN THE
DIAGRAMS BELOW
START MAXIMUM
LOCK
With edge banding
x 2
x 2
10
13
9
11
1
2
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779

6
x 2
10
11
12
9
10
11
8
12
3
4
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779

7
PH2 a1 x 4
5 x 65mm PH2 a2 x 4 5 x 50mm
12 11
7
10
9
2
7
8
9
16
a2
a1
a1
a1
a1
a2
6
5
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
With Edge Banding

a x 4
6 x 65mm
v x 1
a
av
v
aa
3
2
5
12
8
7
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779

a x 8
6 x 65mm
v x 1
v
a
a
av
a
a
a
a
a
5
4
3
12
2
6
11
9
8
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
Without Edge Banding

2
7
8
14
a2
a2a2
a2
10
9
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
PH2 a2 x 4
5 x 50mm

cam lock
PH2 b x 6
4 x 40mm
cam lock
b
b
b b
b
b
b
6
5
12
11
10
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779

x 4
5
2
8
6
10
10
15
15
15
15
15
p
p
12
11
12
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
PH2 p x 8
x 2

Note :
Lock the hinge
after adjustment !
15
15
15
15
h
h
h
h
q
q
13
13
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
PH2 h x 4 q x 4
Door hinge adjustment instructions
A. Side to side adjustment by
clockwise or anticlockwise
adjustment .
B. Up and down adjustment by
adjusting mounting plate slot.
C. Front to back adjustment by
rotating screw clockwise or
anticlockwise.

Actual product size
H127.1x W199.7 x D109.5cm
14Produced in Indonesia for Next Retail Ltd.
178779-2017-V1
AMELIA CABIN BED
178779
1920mm
290mm
1271mm
355mm
335mm
118mm
340mm
920mm
581mm
991mm
366mm
329mm
399mm
742mm
