Next BRONX T45556 User manual

H75 x W105x D30cm
Actual product size
Assembly instructions
IMPORTANT - RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
Need Help ?
With: Assembly instruction
Missing or damaged parts
CALL: 0333 777 8999
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD

Two people are required to assemble this item
Time to assemble : 30 minutes
1
Produced in China for Next Retail Ltd.
Do's
We suggest you spend a short time reading through this leaflet before you start.
BEFORE YOU START
Don'ts
Do not drag or pull your furniture.
When you are ready to start, make sure that you have the right tools and plenty of space.
Unwrap all packaging materials and place the components on a clean surface to protect it from damage,
We recommend that the packaging is used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning assembly.
Due to the size of this product we recommend that it is assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all fixings fully tightened before use.
Wood will mellow and change colour over time, we recommend that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
Wipe occasionally with a soft cloth slightly dampened with water. Then buff with a dry clean soft cloth.
Do not rub or scrub the surface when cleaning.
Do not use silicone based furniture polish. Silicone in furniture polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not place hot items (e.g. hot drinks) directly on to the wood surface. Please make sure you use a placemat or coaster.
Number of people required to assemble
Assembly instructions
PH2 X2
Tools required
not supplied
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD

13
Assembly instructions
2
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
17
19
18
10`
10
9
9
11
12
6
8
712
13
15
16
16
14
5
2
3
1
4

1 1
33x60cm
1
Assembly instructions
3
Components supplied. Please use this guide if you require replacement parts.
Produced in China for Next Retail Ltd.
Ref Dimensions Visual Qty Ctn Ref Dimensions Visual Qty Ctn
211
3
18x33.5cm
11 11
12 2 1
13x25cm
13x25cm
1 1
424x29cm 1 1 35x60cm
13 2 1
30x105cm
14 11
13x28.5cm
5
28x59cm
6
1 1
1 1
11.5x29cm
15 1 1
30x96cm
16 2 1
8x34cm
71 1
28x59cm
8 1 1
33x58.5cm
17 1 1
33x40cm
18 1 1
30x105cm
9 2 1
30x59cm
10 2 1
33x58.5cm
19 1 1
26x32cm
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD

Push connector into housing
to be jointed..
Make sure there is no gap
between the panels.
next FITTNGS ASSEMBLE INSTRUCTIONS
Connector
1
Housing
2
3
Next Retail Ltd, Desford Road, Enderby, Leicester, LE19 4AT

4
Produced in China for Next Retail Ltd.
Assembly instructions
2
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
Fixtures and fittings supplied ( not to scale)
Ref Dimensions Visual Qty
Fixtures and fittings supplied ( not to scale)
Spare Qty
10 20 30 40 50 60 70 80 90
100
110
120
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty Spare Qty
6 N/A
N/A
Ø5 x 16mm
P3
12
8
C11
Ø4.5 x 15mm
N/A
4
E39 N/A
U139
1
1
2
2
T39
T1
N/A
N/A
N/A
N/A
S41 Ø4 x 16mm 2
V36 Ø6 x 14mm 4
V68 Ø6 x 40mm 8
1
1
1
9
T38 N/A

5
Assembly instructions
1
Produced in China for Next Retail Ltd.
2
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
1
2
3
4
SLOTS ALIGNED

6
3
Assembly instructions
Produced in China for Next Retail Ltd.
4
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
5
Note: Drawer will be permanently
assembled once panel 5 is fitted.
90°

5
7
Assembly instructions
Produced in China for Next Retail Ltd.
6
6
Finished side
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
6
7
8
E39 N/A 1

8
7
Assembly instructions
Produced in China for Next Retail Ltd.
8
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
9
10
10
9
V36 Ø6x14mm 4
11
V68 Ø6x40mm 8

9
9
Assembly instructions
Produced in China for Next Retail Ltd.
10
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
T1 N/A 2

10
11
Assembly instructions
Produced in China for Next Retail Ltd.
12
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
12
6
8
12
13
14 13
SLOTS ALIGNED
11

13
11
Assembly instructions
Produced in China for Next Retail Ltd.
14
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
15
A=B
A
B

15
12
Assembly instructions
Produced in China for Next Retail Ltd.
T45556 / A79660
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
not supplied PH29
T38 N/A
T45556 / A79660-2022-V1.

16
13
Assembly instructions
Produced in China for Next Retail Ltd.
not supplied
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
We recommend the use of the wall attachment bracket/strap provided for safety reasons.
Secure the strap to the wall with an appropriate screw and wall plug for your wall type (not provided).
To hide the strap behind the unit ,drill the hole lower than the top of unit.
Attach the other end of the strap to the underside of the top panel with screw.
Warning: Always ensure intended wall area to be drilled is free from hidden electrical wires,water and gas pipes.
NB:Wall fixings are not included-Please source suitable fixing for your wall type.
If in doubt please consult a qualified trades person.
Please ensure you secure your product to the wall for your and your family's safety before you use it.
2
WALL
WALL
STRAP
SCREW
STRAP
TOP
SCREW
T39 N/A
2
S41 Ø4x 16mm

17
14
Assembly instructions
Produced in China for Next Retail Ltd.
18
C11 N/A 6
12
U139
U139 Ø4.5 x 15mm
PH2 X2
not supplied
17
19
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
16
16
Finished side
Finished side
P3 Ø5 x 16mm 8
18

19
15
Assembly instructions
Produced in China for Next Retail Ltd.
20
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
Adjust Hinge Position
LATEEAL
VERTICAL
Renmove hinge
Install hinge
FRONT-TO-BACK
17
19
PH2 X2
not supplied
E39 N/A 3
17 18
19
18

21
16
Assembly instructions
Produced in China for Next Retail Ltd.
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
Right side
Left side
5

To disassemble:
17
22
Produced in China for Next Retail Ltd.
23
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
Step1: Remove the plastic wedges (T38)
from the back panels and screws
from the rear of the base panel (11);
Step2: Press down all the back panels so
they are clear of the top panel slot;
Slide the top panel back to unlock, then lift off.Follow the same
sequence to remove the other panels;

Produced in China for Next Retail Ltd.
T45556 / A79660
T45556 / A79660-2022-V1.
BRONX / BRONX LIGHT COMPACT LARGE SIDEBOARD
Actual product size
H75 x W105 x D30cm
109 mm
333 mm
179 mm
1048 mm
300 mm
333 mm
585 mm
333 mm
403 mm
749 mm
