Next D65922 User manual

D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK
H60xW60xD32cm
Actual productsize
Assemblyinstructions
IMPORTANT-
RETAINFORFUTUREREFERENCE
Produced in China forNext Retail Ltd.
NeedHelp?
With:Assemblyinstruction
Missingordamagedparts
CALL:0333777 8999

1
Produced in China forNext Retail Ltd.
Assemblyinstructions
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

Assemblyinstructions
2
GETTINGTOKNOWYOURPRODUCT
Produced in China forNext Retail Ltd.
6
7
8
5
9
9
3
42
1
10
11
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

1 1
29x57cm 1
21
32x60cm 1
3 1
32x50.5cm 1
32x50.5cm
71
16.5x53cm 1
32x60cm
Assemblyinstructions
3
Componentssupplied.Pleaseusethisguideifyourequirereplacementparts.
Produced in China forNext Retail Ltd.
Ref Dimensions Visual Qty Ctn
81
16.5x53cm 1
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

12
4
15 x 12mm 2
12
8x38mm 2
P3 11
12
D6 8x30mm 2
U139 4.5x 15mm 4
B8
B3
Fixturesandfittingssupplied(nottoscale)
Ref Dimensions Visual Qty
Fixturesandfittingssupplied(nottoscale)
Spare Qty
5x16mm 2
14
S6 3x16mm
1
2
E39 N/A
V53 6x30mm 1
T4 N/A 2
O1 21mm 12
S41 4x16mm 1
T39 2
Produced in China forNext Retail Ltd.
Assemblyinstructions
10 20 30 40 50 60 70 80 90
100
Ref Dimensions Qty SpareQty
Fixturesandfittingssupplied(actual size)
preassembled
preassembled
preassembled
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

5
Assemblyinstructions
1
Produced in China forNext Retail Ltd.
2
V53 6x30mm
2
1
T4 N/A 2
3
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

3
6
4
Assemblyinstructions
Produced in China forNext Retail Ltd.
4
5
Unfinishedside
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

7
5
Assemblyinstructions
Produced in China forNext Retail Ltd.
14
S6 3x16mm
6
6
8
7
O1 21mm 12
Pleaseapplythestickersprovided
tocoverthecamlocks asshownon
the diagram as an example.
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

8
7
Assemblyinstructions
Produced in China forNext Retail Ltd.
8
U139 4.5x 15mm 4
P3 5x16mm
9
9
10
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

9
9
Assemblyinstructions
Produced in China forNext Retail Ltd.
P3 5x16mm
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

10
10
Assemblyinstructions
Produced in China forNext Retail Ltd.
Adjust Hinge Position
10
To align the door, please adjust
the hinges as shownbelow.
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

11
11
Assemblyinstructions
Produced in China forNext Retail Ltd.
notsupplied
PH2
E39 N/A 1
10
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

12
12 We recommend the useof the wall attachment bracket/strap provided for safetyreasons.
Securethe other end of the strap tothe wall withan appropriate screwand wall plug
for your wall type (not provided).
To hide the strap behind the unit ,drill the hole lower than the top of unit.
Warning: Always ensureintended wall area tobe drilled is free fromhidden electrical wires,water and gaspipes.
NB:Wall fixings arenot included-Please sourcesuitable fixing for your wall type.
If in doubt pleaseconsult aqualified tradesperson.
Assemblyinstructions
Produced in China forNext Retail Ltd.
WHENLOOSENINGTHE CAM
TURNTHECAMIN ACOUNTERCLOCKWISEDIRECTION
UNTILTHEARROWPOINTSINTHEPOSITIONSHOWN
IN THEDIAGRAMSBELOW
TURN UNLOCKED
MAXIMUM
LOCK TO UNLOCK
Please ensureyou secureyour product tothe wall for your and your family'ssafetybefore you use it.
TOP
WALL
STRAP
SCREW
WASHER
2
S41 4x16mm
T39 2
D65922
D65922-2023-V1.
NEWGREY BRONX UNDER SINK

H60xW60xD32cm
Produced in China forNext Retail Ltd.
Actual productsize
