Next PARKER A13924 User manual

A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST
H180 x W88.5 x D39cm
Actual product size
Assembly instructions
IMPORTANT -
RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
Need Help ?
With: Assembly instruction
Missing or damaged parts
CALL: 0333 777 8999

Two people are required to assemble this item
Time to assemble : 30 minutes
PH2 X2
1
Produced in China for Next Retail Ltd.
Do's
We suggest you spend a short time reading through this leaflet before you start.
BEFORE YOU START
Don'ts
Do not drag or pull your furniture.
When you are ready to start, make sure that you have the right tools and plenty of space.
Unwrap all packaging materials and place the components on a clean surface to protect it from damage,
We recommend that the packaging is used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning assembly.
Due to the size of this product we recommend that it is assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all fixings fully tightened before use.
Wood will mellow and change colour over time, we recommend that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
Wipe occasionally with a soft cloth slightly dampened with water. Then buff with a dry clean soft cloth.
Tools required
Do not rub or scrub the surface when cleaning.
Do not use silicone based furniture polish. Silicone in furniture polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not place hot items (e.g. hot drinks) directly on to the wood surface. Please make sure you use a placemat or coaster.
Number of people required to assemble
Assembly instructions
not supplied
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

x 3
Assembly instructions
2
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
18
15
17
19
14
16
6
7
12
13
2
5
5
3
1
4
8
9
10
11
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

1 1
39x76.5cm 1
Assembly instructions
3
Components supplied. Please use this guide if you require replacement parts.
Produced in China for Next Retail Ltd.
Ref Dimensions Visual Qty Ctn Ref Dimensions Visual Qty Ctn
21
7.5x80cm 2
31
9.5x80cm 2
4 1
39x76.5cm 1
5 2
34x81cm 1
61
8.5x83.5cm 2
71
8.5x83.5cm 2
8 1
39x83.5cm 1
9 1
30.5x83.5cm 2
10 1
28.5x83.5cm 2
11 1
26.5x83.5cm 2
12 1
39x180cm 1
13 1
39x180cm 1
14 3
16.5x75.5cm 2
15 3
16.5x30cm 2
16 3
16.5x30cm 2
17 3
6x28.5cm 2
18 3
29x76cm 1
19 3
25x79.5cm 2
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

N/A
4
Ø15 x 10mm 2
N/A
Ø8 x 38mm 2
2N/A
N/A
D3 Ø6 x 30mm 2
N/A
D6 Ø8 x 30mm 2
2N/A
B8
B2
Fixtures and fittings supplied ( not to scale)
Ref Dimensions Visual Qty
Fixtures and fittings supplied ( not to scale)
Spare Qty
Produced in China for Next Retail Ltd.
Assembly instructions
10 20 30 40 50 60 70 80 90
100
110
120
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty Spare Qty
12
Ø15 x 12mm 2B3
Titus
Titus
B12 Ø7.5 x 33mm 12 2
S41 Ø4 x 16mm 21
41
Y8 Ø6 x 50mm
V53 Ø6 x 30mm 81
T4 N/A
N1 N/A
61
N/A
T38
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

5
Assembly instructions
1
Produced in China for Next Retail Ltd.
2
Packing Materials
1
3
2
4
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST
Unfinished side

4
6
3
Assembly instructions
Produced in China for Next Retail Ltd.
Finished side
Finished side
5
5
T4 N/A 2
Y8 Ø6 x 50mm 4
7
6
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

5
7
Assembly instructions
Produced in China for Next Retail Ltd.
6
8
2
2
12
B12 Ø7.5 x 33mm
not supplied
PH2
N1 N/A
S41 Ø4 x 16mm
not supplied
PH2
13
12
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

8
7
Assembly instructions
Produced in China for Next Retail Ltd.
2
4
6
not supplied
PH2
T4 N/A
B3 Ø15 x 12mm
Titus
V53 Ø6 x 30mm
12
9
10
11
4
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

9
8
Assembly instructions
Produced in China for Next Retail Ltd.
2
4
6
not supplied
PH2
T4 N/A
B3 Ø15 x 12mm
Titus
V53 Ø6 x 30mm
13
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

10
9
Assembly instructions
Produced in China for Next Retail Ltd.
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

11
Assembly instructions
Produced in China for Next Retail Ltd.
10 We recommend the use of the wall attachment bracket/strap provided for safety reasons.
Move unit into desired position.Secure the 2X"L" metal brackets to the wall with an
appropriate screw and wall plug for your wall type (not provided).
Warning: Always ensure intended wall area to be drilled is free from hidden electrical wires,
water and gas pipes.
NB:Wall fixings are not included-Please source suitable fixing for your wall type.
If in doubt please consult a qualified trades person.
WALL
SCREW
TOP
6
not supplied
PH2
N/A
T38
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

12
11
X 3
Assembly instructions
Produced in China for Next Retail Ltd.
12
Unfinished side
X 3
X 3
14
15
16
17
18
19
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

13
13
Assembly instructions
Produced in China for Next Retail Ltd.
WHEN LOOSENING THE CAM
TURN THE CAM IN A COUNTERCLOCKWISE DIRECTION
UNTIL THE ARROW POINTS IN THE POSITION SHOWN
IN THE DIAGRAMS BELOW
TURN UNLOCKED
MAXIMUM
LOCK TO UNLOCK
19
19
19
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

H180 x W88.5 x D39cm
Produced in China for Next Retail Ltd.
Actual product size
1800mm
884mm
390mm
246mm
266mm
284mm
390mm
251mm251mm251mm
796mm
753mm
284mm
148mm
833mm
256mm
284mm
256mm
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST

Produced in China for Next Retail Ltd.
Warnings
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well
away from construction area.
Please periodically check all fittings and re-tighten as necessary.
Home Customer Services
Next Retail Ltd.
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range please visit www.next.co.uk
Missing parts
If you are missing any fixtures and fittings for your product.
Please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
If you have a fault with your product, please contact our customer
service team on 0333 777 8999. If you have had the product for
28 days or less you may be offered a replacement,refund or for a
fully trained home service technician to visit your home to assess
the fault and repair the product where possible. If you have had
the product for more than 28 days we will send an independant
home service technician to review and repair the product where
possible and recommend further action.
You can write to us at
This product should only be used on firm level ground.
Please do not sit or stand on your furniture.
Unwrap all packaging materials and place the components on top
of the carton box or on a clean floor to protect it from damage
Avoid exposing the furniture to excessive heat or direct sunlight
as this can cause deterioration of the colour.
A13924
A13924-2021-V1.
PARKER 3 DRAWER LADDER CHEST
