NexTraq VT-4226 User manual

NexTraq VT-4226 Driver ID
Quick Install Guide

2
Notice This installation guide is published and copyrighted by
NexTraq. Information and specifications contained in this document are
subject to change without notice and do not represent commitments on
the part of NexTraq. Under copyright laws, no part of this
installation guide may be reproduced or transmitted in any form or by
any means, electronic or mechanical, including photocopying and
recording, for any purpose, without the express written permission of
NexTraq. This installation guide does not constitute a warranty as to
any product or service, except to the extent expressly provided in the
agreement under which such a product or service was provided.
Trademarks
NexTraq is trademarked. All other trademarks and service marks
contained within this document are the property of their respective
owners.
Disclaimer
The complete terms and conditions under which NexTraq provides
hardware and services are contained in separate agreements. None of
the information in this document is intended to create additional or
separate warranties or guarantees.
© 2011 NexTraq. All Rights Reserved.

3
Figure 1: The VT-4226

4
Figure 2: VT-4226 power harness
Figure 3: VT-4226 and power harness

5
Figure 4: Driver ID button
Figure 5: 2-pin driver ID connection to harness

6
Figure 6: Driver ID alarm
Figure 7: 3-pin alarm connection to harness

7
Figure 8: The VT-4226 combo antenna
Figure 9: Unit connected to antenna. Top: comm; Bottom: GPS.

8
Figure 10: VT-4226 electrical wiring from power harness. Red: constant power; white:
ignition; black: ground

9
Figure 11: Button inserted into a dummy panel. White washer on button side, black
washer on lock side.
Figure 12: Close-up of black washer/wire side of dummy panel.

10
Figure 13: Close-up of white washer/button side of dummy panel.

11
Figure 14: Button installed into dummy panel. This should be located as close to the
ignition as possible.
Figure 15: Alarm mounted in vehicle.

12
Figure 16: Key fob. Alarm will sound while ignition is on until driver logs in with
fob. Fob and button must make contact. Customer will need to record which key fob is
assigned to which driver.

13
Appendix A –Technical Specifications
Communication Specifications
GSM/GPRS Quad-Band
850/900/1800/1900 MHz
GSM/GPRS Output Power
850: 2 Watts (Class 4)
900: 2 Watts (Class 4)
1800: 1 Watt (Class 1)
1900: 1 Watt (Class 1)
CDMA Dual-Band
800/1900 MHz
CDMA Output Power
800: +24 dBm
800: +24 dBm
Data Support
SMS, GPRS, or CDMA 1xRTT packet data
Electrical Specifications
Operating Voltage
6-32 VDC
Power Consumption
<3mA @ 12V (Deep Sleep)
<10mA @ 12V (Sleep on Network with SMS)
<20mA @ 12V (Sleep on Network with GPRS)
<70mA @ 12 V (Active Tracking)
Physical Specifications
Dimensions
2.0 x 4.0 x 0.85 inches (51 x 102 x 22 mm)
Weight
74g (external), 85g (internal)
Certifications
Fully certified FCC, CE, IC, PTCRB, Cellular Carriers

14
Appendix B –Installation Notes
The first choice for power connections should always be at the
ignition column. An industry standard poke-tape-tie-wrap method should
be used to secure connections. If column is unobtainable or there is
too many other devices wired to the column, then going to the input
wires behind the fuse box can be a valid alternative. If connections
must be made to fuses at the fuse box, then using a fuse tap pictured
below is acceptable, but should be a “last resort.”
Antenna placement is optimal underneath a removable plastic cover near
the windshield on the top of the dashboard. If no removable cover is
present, then removing the front dash bezel, the radio or instrument
cluster to gain access to under the dashboard is good. Behind the
plastic A pillar cover also works well, but should be a second choice.
If the dashboard is metal and/or not enough clearance is present
behind the A pillar, then mount the antenna at either top center of
the windshield behind the rear view mirror, or at the top right corner
of the windshield.
