NFL Helmet User manual

!
!
WARNING
!
IMPROPER USE OF THIS HEATER COULD RESULT IN FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS
!
WARNING
ANY REQUIRED SERVICE OTHER THAN FILTER MAINTE-
NANCE SHOULD ONLY BE PERFORMED BY AN AUTHORIZED
SERVICE REPRESENTATIVE
CAUTION : RISK OF ELECTRICAL SHOCK DO NOT OPEN
NO USER-SERVICEABLE PARTS INSIDE CAUTION
DO NOT COVER
!

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

CONGRATULATIONS ON THE PURCHASE OF YOUR VERY
OWN HELMET HEATER!
!
What Is Infrared Heat and How Does It Work?
Instead of just heating the air around you, infrared heat is very
efficient and will warm any object with which it comes in contact,
including your body. Infrared heat scientifically uses a shorter
wave length and is able to more efficiently heat an area without
drawing moisture out of the air. The result is a lower cost, safer
and warmer heat source.
Comfort Levels and Therapeutic Benefits of Infrared Heat
The Helmet Heater is a true infrared heating system with four
scientifically designed infrared heating elements. An infrared
heater will heat a room evenly from floor to ceiling. This eliminates
the need for ceiling fans as warm air is distributed equally
throughout the space. Even rooms with high ceilings are not a
problem because the room is being heated evenly.
There are many other advantages of infrared heat. Foremost,
infrared heat warms the body faster than other forms of heating.
Infrared heat penetrates the body and energy that flows into the
body is absorbed quicker. A 68 degree room heated with infrared
heat will feel more like 72 degrees. This allows you to achieve
energy savings by turning down your thermostat while maintaining
the same comfort level.
An infrared heater also sterilizes the air that passes through it.
This is especially key for those who suffer from allergies. As air enters
the back of your infrared heater the air is heated to a temperature
of 180 to 200 degrees. This high temperature eliminates germs and
other airborne pests. Since your infrared heater doesn’t have any
ductwork there isn’t any place for bacteria, mold or dust pollen
to accumulate. Most homes have heating and air conditioning
sharing the same ducts. As a result, dust, bacteria, mold, germs
and other contaminants collect in these ducts and can cause
allergies and respiratory problems if not properly maintained.
Energy Saving Benefits and Other Amenities
Infrared heat waves are transferred rapidly throughout the
room due to their shorter wave length. The results are impressive
because it requires less energy to heat a room evenly with infrared
heat than with conventional radiant heating sources. This makes
the Helmet Heater one of the most cost effective and energy
efficient supplemental heat sources on the market.
!

The infrared heating elements are designed to last about
20,000 hours. Using your heater only during the winter months,
the elements should last 4 to 6 years. (Call our toll-free number for
questions and concerns. The internal electronic thermostat
maintains an accurate temperature at all times. Simply set your
heater control to the desired comfort level and sit back and enjoy
a warm, comfortable, cozy environment regardless of the
temperature outside.
The great look of the Helmet Heater allows you to add its
aesthetic design to any room or background. With a wide range
designs and logos your Helmet Heater is a welcome addition in any
space. Your Infrared Helmet Heater is manufactured to meet all
ISO9000 standards
!

WARNING
Improper use of this heater could result
in fire, electric shock, or injury
!
WARNING
Any required service other than
maintenance should only be performed by
an authorized service representative.
Caution : Risk of electrical shock do not
open
No user-serviceable parts inside: Caution
Do not cover
READ ALL INSTRUCTIONS BEFORE USING THE HEATER.
Extreme caution is necessary when the heater is used near children, invalids or when
heater is left operating and unattended.
Always unplug the heater when not in use.
DO NOT plug heater into any other cord-connected device, such as power strip, surge
protector, multiple outlet adapter, grounding adapter, outlet-type air fresheners or
extension cords. Plug into a 3-prong, 120V, 15 amp or higher grounded circuit only.
DO NOT plug the heater into a loose fitting or broken outlet.
DO NOT alter the heater’s design; doing so will VOID the warranty. DO NOT block the
front or rear of the heater.
DO NOT place anything directly in front of the heater.
DO NOT cover the unit as this may block airflow and cause the heater to malfunction.
DO NOT use the heater outdoors or for heating construction sites.
This heater is not intended for use in laundry areas or similar damp or humid indoor
locations. Never locate heater where it may fall into a bathtub or water.
DO NOT force the filter to dry using alternative methods; doing so could damage the
filter.
DO NOT run the cord under carpeting or cover cord with throw rugs, runners or
similar
coverings. Arrange cord away from high traffic areas.
DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening, as
this may cause an electric shock or fire or damage the heater.
Heater has hot parts; DO NOT use in areas where gasoline, paint or flammable
liquids are used or stored.
Heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces.
Use handle when moving heater.
DO NOT operate any heater with a damaged cord or plug or if the heater has been
dropped or damaged in any manner. Return heater to an authorized service facility
for
for examination, electrical or mechanical adjustment, or repair.
To disconnect heater, turn controls to off, then remove plug from outlet. Connect to
properly grounded outlets only.
Use this heater only as described in this manual. Any other use is not recommended by
the manufacturer and may cause fire, electrical shock, or injury.
DO NOT locate this heater below a socket outlet.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS
!

SUGGESTIONS FOR BEST PERFORMANCE
To use the heater most efficiently, a minimum of 30% relative
humidity should be maintained. In most homes that is fairly stan-
dard.
NOTE: If you are unsure of the humidity or do not have a humid-
ifier, bring a pot of water to a boil and allow most of the water to
evaporate into the air. The added humidity that is introduced to
the room will allow your Helmet Heater to more effectively heat
your home.
If you are using your heater in a room with unfinished concrete
floors position your heater no less than three (3) feet above the
floor for the best results. Always make sure your heater is in a safe
location where it will not fall or tip over. Place the heater in a room
where the most time is spent during non-sleep hours, such as a
family room, den or an office. Set the comfort level dial on the
back of the heater to the desired setting.
If you are using your Helmet Heater in a large open area, it is
better to have the heater close to the center of the room. Using
the heater in a dusty or dirty environment, the filter on the bottom
of the heater should be cleaned more often than recommended.
Your filter should be cleaned once per month or every two (2)
weeks during high use. For best results, do not place your heater in
rooms that are high air exchange. For example, if a door to the
outside is opened
20 times per day and it is cold outside, place
the heater in another room.
!

MAINTENANCE INSTRUCTIONS
The most important maintenance required for your heater is to
clean the filter once a month. Clean more often in dirty or dusty
places.
!
CLEANING THE ELECTROSTATIC FILTER
1. Turn off the power by pressing the power switch to OFF.
2. When the heater’s fan stops (the heater will become
completely silent) unplug the heater.
3. To remove the filter from the heater, turn the bottom side up
and slide the filter out of the heater. (fig 1)
4. Clean the filter by vacuuming or rinse it with warm water.
!

DETAILED OPERATING INSTRUCTIONS
TURNING POWER ON
1.
Press for POWER (fig1). Adjust thermostat knob (fig3).
The heater and fan begin to operate.
TURNING POWER OFF
2.
Press to POWER OFF (fig1).
SETTING THE POWER
3.
Press 1200W(HI) or 600W(LOW) to adjust high & low heat
setting (fig2).
FIG 1
FIG 2
SETTING THE TEMPERATURE
FIG 3
!

FREQUENTLY ASKED QUESTIONS
Q: Why does my heater run after I shut it off?
A: The heater fan will continue to run after the unit is turned off
for approximately 4 minutes in order to cool down the inside of
the heater. The heating elements heat to between 180 and 200
degrees so it is important to let your heater cool down after use.
Q: Will the heater heat more than one room at a time?
A: Heating will vary depending on the floor plan and size of
your rooms. Placing the heater close to the center of the largest
room will help improve heat efficiency and movement.
Q: May I use my heater in moist or damp rooms?
A: The heater will work effectively in places such as bathrooms
and pool rooms. The heater is designed to work with natural
humidity. Using your heater in areas with excessive moisture should
be avoided.
Q: Will my heater work if my room is not well insulated?
A: The heater will work in places like basements and garages. The
better a room is insulated, the more effective the heater will be.
Remember, the heater will heat objects in the room and not the
air itself. An uninsulated room wall may absorb much of the heat
making the heater less effective.
Q: Can I use more than one heater in a room?
A: Yes. If you are heating a large area more than one heater may
be used. Each heater is rated at 10 AMPS so each heater must be
plugged in to an independent outlet on 15 AMP or greater circuit.
Q: Why is my heater not blowing as hard as before?
A: Make sure the filter on the bottom of the heater is clean and
free of debris. Make sure the heater is not too close to a wall or
furniture that would obstruct airflow.
!

HEATER SPECIFICATIONS
Weight: 10.6 lbs
Dimensions:
Power Required: 120 Volt AC 1200 Watt
Power Cord: 6 Foot
Safety Cutoff: Yes
Pre-Filter: Lifetime Electrostatic
Heat Type: Quartz Infrared Heat
Chamber: Copper-ion
Heating Elements: Quartz Infrared Emitters
Emitter Life Expectancy: 20,000 hours (approx. 10 -12 years)
Fan System: Single high output scroll fan that provides a much
quieter operation by eliminating vibration and ELF electromagnetic
emissions caused by AC axial fan motors.
Noise Level: 47-49 dB (Comparatively quiet)
Warranty: 3 Year
!
!!

WARRANTY AND SERVICE INFORMATION
THREE-YEAR LIMITED WARRANTY
!
Helmet Heater / parent company warrants this product to be
free from defects in materials and workmanship, to the original
purchaser, and under normal operating conditions, for a period of
one year.
For an additional two years, Helmet Heater will warrant the heater
fully, except for the fan motor and infrared heating elements,
against defects in workmanship or materials under normal use and
service.
All replacement parts will be shipped via USPS or UPS at the
customers expense.
The customer shall be responsible for shipping costs in the event
that the unit needs repairs or requires replacement parts.
LIMITATIONS
!
ALL WARRANTIES IMPLIED BY LAW, INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE EXPRESSLY LIMITED TO THE DURATION OF THE
WARRANTY SET FORTH ABOVE.
Note: Some jurisdictions do not allow limitations on the length of
the implied warranty, so the above limitation may not apply to you.
In no event shall Helmet Heater / its affiliates / parent company be
liable for any incidental or consequential damages caused by the
misuse or malfunction of the product. Helmet Heater / its affiliates
/ parent company will not be held responsible for loss of use,
medical expenses or other problems caused by defect or failure.
Note: Some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
Helmet Heater / its af liates / parent company will not be responsible
for damages or losses due to misuse, neglect, abuse or failure to
follow directions or improper storage.
!

WARRANTY AND SERVICE INFORMATION (CONTINUED)
!
Helmet Heater / its responsible
for statements made that are published, written or spoken that are
not consistent with the written warranty. Helmet Heater / its
affiliates / parent companywill not be responsible for statements
made that are misleading or inconsistent with this owner’s manual.
Warranty Restriction: Removing the serial number or changing the
design or performance of the heater will void the manufacturer
warranty.
To file a warranty claim, please contact the dealer where you
purchased your Helmet Heater. All other issues for service, warranty,
or problems with your heater should be addressed with the dealer
where you purchased your heater.
The Helmet Heater comes with a 30-day, money-back guarantee.
After the initial 30 days and up to 90 days, a 30% restocking fee will
apply. (No returns are allowed after 90 days.)
SERVICE, WARRANTY, AND SALES [phone]
!
