NGM Elvis User manual

Ver.1.0.20101125
Elvis

Elvis User Manual
2
Contents
1. For your Safety...............................5
2. Mobile Phone Profile .....................8
3. Preparation before Use................10
Install SIM Card................................................10
Install Memory card .........................................12
Install Battery ..................................................13
Charge Battery.................................................14
Notices on using the battery ............................15
PIN code...........................................................16
4. General Instructions.....................18
Dial key ............................................................18
Switch-on/off key /End key ..............................18
Standard keypad..............................................18
AM/FM function key ........................................19
Keypad lock......................................................20
Icons in Standby State......................................20
Language and Input Mode ...............................21
Services ............................................................21
Callers’ group...................................................22
5. Basic operation ............................22
Switch on .........................................................22
Switch off .........................................................23

Elvis User Manual
3
Dial a Call.........................................................23
Adjust Receiver Volume ...................................24
Answer a Call ...................................................24
Send DTMF Signal ............................................25
Dial Hold ..........................................................25
Fast Read SMS .................................................26
Missed Calls .....................................................26
Connect to Voice mail ......................................26
6. Use of Menu Functions ................27
Phonebook.......................................................27
Messaging .......................................................30
Call History.......................................................43
Fun & Games ...................................................46
Audio player.....................................................47
Multimedia ......................................................49
Services ............................................................60
Organizer .........................................................63
Settings............................................................69
7. Coffer Function ............................83
8. Editor Operation ..........................87
Basic letter input..............................................87
Number input...................................................87
Symbol input ....................................................87
9. Use of USB ...................................88
10. Maintenance & Safety................88

Elvis User Manual
4
After sales service ............................................88
Charger and Adapter Safety.............................89
Battery Information and Care ..........................89
General Notice .................................................89
Troubleshooting...............................................91
10. Abbreviations.............................94
11. Certifications..............................95

Elvis User Manual
5
1. For your Safety
For your safety and proper use of the
mobile phone, please read the following
guidelines carefully: Do not switch the mobile
phone on when close to chemical factory, gas
station or other explosive objects.
During driving, please use headset for safety
purpose; unless otherwise in emergency,
always stop the car on roadside to have a call
conversation.
Because the use of the mobile phone can
cause interference in the aircraft, never use
the mobile phone in aircraft. The use of the
mobile phone is dangerous and illegal; do
switch off the mobile phone before boarding.
Pay special attention to the use of the mobile
phone near heart pacemaker, deaf-aid and
some other medical equipments, because
the mobile phone can cause interference
with them.
None-original factory’s accessories and parts

Elvis User Manual
6
will lose guarantee.
Do not dismantle the mobile phone without
permission. In case of failure, please contact
the supplier as soon as possible.
Do not plug the charger into the mobile
phone and charge without battery. Always
power off the mobile phone when taking out
the battery; otherwise the memory of the
phone may be damaged.
When charging the mobile phone, always
keep it in the place with good ventilation,
heat sink and away from flammable and
explosive objects.
In order to avoid demagnetization, always
keep the mobile phone away from magnetic
objects such as CD, credit card etc.
Ensure the mobile phone not to contact any
liquid; once such case occurs, remove the
battery and contact the supplier
immediately.
Do not use the mobile phone in the
environment at too high or too low
temperature, never expose the mobile
phone under strong sunshine or too wet
environment. The suitable temperature for

Elvis User Manual
7
the phone and accessories is 0℃-40℃. The
height to use the phone shall be less than
2,000m.
Do not use liquid or wet cloth with strong
cleanser to clean the mobile phone.
This mobile phone has shooting, videoing
and audio recording functions, which shall be
used as per the related laws and regulations.
Always keep the mobile phone out of
children’s reach. Do not throw or vibrate the
mobile phone because violent treatment to
the mobile phone may damage the inner
circuits and precise structures.
Please do not discard the waste battery into
general household garbage. Please deal with
the waste battery according to provisions
where they are definitely made.
Warning: We will not be bear any responsibility
for any incompliance with the above guidelines
or improper use of the mobile phone. Our
company keeps the right to make modifications
to any of the content here in this user guide
without public announcement in advance. The
content of this manual may vary from the actual
content displayed in the mobile phone. In such

Elvis User Manual
8
case, the latter shall govern.
2. Mobile Phone Profile
The mobile phone single screen ，one
vibration motor, one charger/ data common
transmission port.
(Below is the front of the mobile phone).
1
2
3
5
6
7
8
9
10
11
4

Elvis User Manual
9
7
6
1.
Speaker
8.
Keypads
2.
LCD
9.
Next music
3.
Play key
10.
Retreat key
4.
Previous music
11.
End key
5.
SEND 1 (SIM-1)
12.
Speaker
6.
Main menu key
13
Camera
7.
SEND 2 (SIM-2)
9
12
13

Elvis User Manual
10
3. Preparation before Use
Install SIM Card
When registering mobile phone number,
you can apply for two different phone numbers,
two different mobile phone network service
providers and thus obtain two SIM (Subscriber
Identification Module) cards.
With these two SIM cards, you can use all
functions of your mobile phone. The SIM cards
save the parameters needed for communications
and personal data, including PIN (Personal
Identification Number) code, phonebook, short
message and other extra system services.
Warning: Do not distort or scratch the SIM card
nor let it contact static, dust or moisture. If it is
lost, please contact immediately your network
operator for help.
Before SIM card installation, please switch off
the mobile phone. The SIM card is installed on
the back of the mobile phone.
Follow the following diagram to install the
SIM card. Please insert the host SIM card into the

Elvis User Manual
11
SIM1 slot and the slave SIM card into the SIM2
slot.
Note: If SIM card is inserted only into the
SIM1 slot, then only the host works; likely, If SIM
card is inserted only into the SIM2 slot, then only
the slave works. When two SIM cards are
inserted into the SIM1 slot and SIM2 slot
respectively, you can choose work mode freely as
you wish.
Note: As the SIM card is small object, keep it out
of children’s touch or prevent children gulping it!
SIM 1
SIM 2

Elvis User Manual
12
Install Memory card
As the mobile phone does not have enough
storage space, to use some functions, you need
to install a memory card (This mobile phone use
T-FLASH card.)
Install T-FLASH card: Open the back cover to
take out the battery, release the T-Flash card lock,
insert the T-Flash card into its slot, and restore
the lock and the battery before restarting the
mobile phone.
Note: As the T-FLASH card is small object, keep it
T-flash
card

Elvis User Manual
13
out of children’s touch or prevent children
gulping it!
Install Battery
The mobile phone is suitable for original
battery and accessories. When the battery is idle,
it is recommended to put it into the protection
box.
Follow the following diagram to install the
battery.
Note: Do install the battery as per the diagram so
as prevent the battery contact patch being
damaged.
Battery

Elvis User Manual
14
Earphone
Charge Battery
The new battery cannot reach the optimal
efficiency unless it has undergone several
continuous complete charges and discharges.
When the battery is used up, charge it in
time. Over-discharge can damage the battery.
After the battery is charged full, cut off the
connection of charger with the AC power supply
and the connection with the mobile phone.
Follow the following diagram to connect the
charger.
During charging, the battery capacity icon
on the screen flickers from the right to the left.
After the battery is charged full, the icon is full of
bars. Slight heat during charging is normal.
Warning: When a travel charger and its
accessories are used to charge the battery, please
firstly check if they are original or recognized by
the original manufacturer. The use of other
accessories may damage your mobile phone and
cause risks! Always use them indoor and dry
Charger Port /USB

Elvis User Manual
15
places.
Notices on using the battery
The performance of the battery is affected
by many factors, including radio barrier network
settings, signal strength, signal strength, work
temperature, chosen and used functions or
settings as well as phone accessories, tone, data
or other applications.
For optimal performances, please follow the
rules below:
New battery or the battery having been idle
for long need charging for long. The standard
voltage scope for the battery is 3.6V-4.2V.
During charging, keep the battery at room
temperature or similar temperature.
With time passing by, the battery will
gradually be worn and thus need longer time
to charge. This is normal. However, after
normal charging, if call duration decreases
but charging time increases, you need to buy
another battery from the original
manufacturer or authorized by the original
manufacturer. The battery of interior quality
can damage your mobile phone and cause

Elvis User Manual
16
danger!
If the phone is overused at low battery when
charging, there might need a longer time for
the charge indicator to be shown on the
screen.
Note: Please dispose the battery according to the
local regulations. Try to recycle the battery as
possible. Do not treat the waste battery as
common waste.
Warning: Do not throw the battery into fire so as
to prevent fire. The broken battery may cause
explosion.
Warning
Charging the mobile phone by
improper means can cause to explosion.
Always refer to the related regulations for
the disposal of the battery.
PIN code
PIN1 Code: It is the personal identification
number used to enter SIM and able to prevent
others using SIM1 without permission. If the
mobile phone has activated the PIN1 code
protection, when the mobile phone is switched

Elvis User Manual
17
on, the screen will display “Input PIN”. In the
process of inputting PIN1 code, the screen will
use “*” to represent the input content. While
obtaining SIM, you can obtain its PIN1 code.
PIN2 Code: It is the personal identification
number used for some special functions such as
paid call etc.
PUK Code and PUK2 Code(8-digit)
To change the locked PIN code, you need to
use PUK (Personal Unblocking Key) code. To
change the locked PIN2 code, you need to use
PUK2 code. If these two codes are not provided
together with the SIM cards, ask the local service
provider for them.
Warning: If the PIN code is input wrongly for
successively three times, the SIM card will be
locked. Please contact the network operator
immediately for help. Attempt to unlock the code
may make the SIM card ineffective forever!

Elvis User Manual
18
4. General Instructions
Dial key
It is used to dial a call (with phone number
entered or in phonebook state) or receive an
incoming call. In standby state, press this key to
display the latest call register (SIM1 and SIM2
support respectively 20 call entries, including
received calls, missed calls and dialed calls). In
dual-SIM standby mode, press this key to have an
option menu on which you can choose to operate
via SIM1 or via SIM2.
Switch-on/off key /End key
In call state, it is used to interrupt a call; in
call conversation state, it is used to end a call or
exit from the current menu and back to the
standby state. Hold this key for 4~5s to switch
on/off the mobile phone.
Standard keypad
On the keypad, you can see 0-9（A-Z keys）
number keys, * key and # key, totally 12 keys.
Press these keys to input phone number,

Elvis User Manual
19
password, English letters, and symbols or choose
menus.
In different states or different functional
menus, “+” key and “Speaker“key have different
functions:
Press “SPEAKER” key long to start or exit
from the silence mode.
In music player state, “up” and “down” are
used to adjust volume.
AM/FM function key
OK key: In radio state, press the key to stop
In search state, press the left/right key to
search channels forward and backward,
press the OK key until you find an effective
channel. For FM, you can have a tuning of
0.1MHz downward or backward.
1-9 number keys: If they are pressed shortly,
you can switch to the corresponding
channels saved in the channel list; if they are
pressed long, you can save the current
frequency to the corresponding channel.
Up/ Down keys: Adjust volume.

Elvis User Manual
20
Keypad lock
When in standby interface, if the mobile
phone is idle for certain time, it will be locked
automatically. Press the “Send 1” key and
“Retreat”to release. After the mobile phone is
locked, the keypad cannot be activated easily; in
case of incoming call, likewise, press the answer
key to receive it; after that, the keypad will be
locked automatically.
Icons in Standby State
Indicates signal
strength
Indicate the
battery level
Alarm clock is
active
Keypad is locked
There is new
message(s)
Host line 1
There is missed
call(s)
Host line 2
In normal mode
Slave line 1
Vibrate then ring
Slave line 2
Ring
MMS
Vibrate
Inbox PUSH
