NGX Technologies BlueBoard-RL78/G13/G14_64pin Operating and maintenance instructions

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 1
BlueBoard-RL78/G13/G14_64pin
Fig. 1
User Manual for BlueBoard-RL78/G13/G14_64pin:
For CubeSuite+ with E1 Emulator: Click here
For Renesas Flash Programmer with E1 Emulator: Click here
Sample projects for BlueBoard-RL78/G13_64pin:
For CubeSuite+: Click here
Sample projects for BlueBoard-RL78/G14_64pin:
For CubeSuite+: Click here
Schematic for BlueBoard-RL78/G13/G14_64pin:
Click here to download Schematic.

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 2
About NGX Technologies
NGX Technologies is a leader in embedded microcontroller product development. We supply reference
designs and evaluation modules to silicon companies. Our customers include industry leaders like NXP
and RENESAS. Our core business is in helping our customers realize their embedded products.
Contact Information:
NGX Technologies Pvt. Ltd.
#12, 20th Cross, Malagala, Nagarabhavi 2nd Stage
Bengaluru - 560091
Phone- [phone] / 23188306
email:[e-mail]

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 3
Table of Contents
1.0 INTRODUCTION ................................................................................................................................4
1.1 Possible Debuggers and IDEs that can be used ................................................................................4
2.0 BLUEBOARD-RL78/G13/G14_64pin OVERVIEW ..........................................................................5
2.1 INTRODUCTION.............................................................................................................................5
2.2 Board Features ..................................................................................................................................5
2.3 Block Diagram..................................................................................................................................6
2.4 MCU Features...................................................................................................................................7
3.0 BLUEBOARD-RL78/G13/G14_64pin Hardware Description ............................................................8
3.1 Introduction.......................................................................................................................................8
3.2 Board Image with pointer to each peripheral & connectors .............................................................8
4.0 BLUEBOARD-RL78/G13/G14_64pin hardware verification .............................................................9
4.1 Board connections.............................................................................................................................9
4.2 Powering the Board.........................................................................................................................10
4.3 Verifying all the peripherals of the board .......................................................................................10
4.3.1 LED..............................................................................................................................................10
4.3.2 BUZZER ......................................................................................................................................10
4.3.3 User Switch..................................................................................................................................10
4.3.4 Character LCD .............................................................................................................................10
4.3.5 RTC..............................................................................................................................................11
4.3.6 ADC............................................................................................................................................11
4.3.7 UART1 & UART2.......................................................................................................................11
4.3.8 Supply Voltage Adjustment Pot..............................................................................................12
5.0 CHANGE HISTORY..........................................................................................................................13
5.1 Change History................................................................................................................................13
6.0 REFERENCES....................................................................................................................................13

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 4
1.0 INTRODUCTION
This document is the Quick Start Guide for the BLUEBOARD-RL78/G13/G14_64pin, a low cost
RENESAS’s RL78/G13/G14_64pin based board by NGX Technologies. This document reflects its
contents which include MCU features, hardware description, and hardware verification. This document
provides detailed information on board features and hardware verification and possible debuggers and
IDEs that can be used with this board.
.
1.1 Possible Debuggers and IDEs that can be used
E1 Emulator with CubeSuite+
1.2 E1 Emulator and CuibeSuite+
Board has 14 pin emulator connector, connect the one end of 14 pin cable to E1 emulator and other end to
the 14 pin connector on the board, connect usb cable to E1 emulator and PC and connect the power supply
to the board as shown in the below image
Note: E1 Emulator, 14 pin cable and USB cable are not a part of the BB-RL78/G13/G14_64pin board
package.
Fig. 2

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 5
2.0 BLUEBOARD-RL78/G13/G14_64pin OVERVIEW
2.1 INTRODUCTION
The NGX BLUEBOARD-RL78/G13/G14_64pin is a compact and versatile evaluation platform for the
RENESAS's RL78/G13/G14_64pin MCU. RENESAS's evaluation platforms are generally tied up to
CubeSuite+ and High Performance Workshop compiler/IDE and E1 Emulator. For our development we
use E1 Emulator and CubeSuite+ as the debugger and compiler/IDE respectively. The board is supported
by extensive sample examples allowing you to focus on the application development.
2.2 Board Features
Following are the salient features of the board
Dimensions: 110mm X 120mm
Two layer PCB (FR-4 material)
Power: DC 6.5V with power LED On-board linear regulators generate +3.3V/500mA
14 pin CORTEX debug connector for Emulator connection
User Switch and reset switch
12.0000 MHz crystal for MCU
Extension headers for all MCU pins
Test LED
Character LCD
Two RS232 connectors
10K pot for ADC
Buzzer

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 6
2.3 Block Diagram
Fig. 3

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 7
2.4 MCU Features
•Minimum instruction execution time can be changed from high speed (0.03125µs: @ 32 MHz
operation with high-speed on-chip oscillator) to ultra low-speed (30.5µs: @ 32.768 kHz operation
with subsystem clock)
•General-purpose register: 8 bits × 32 registers (8 bits × 8 registers × 4 banks)
•ROM: 64 KB, RAM: RL78/G13 4 KB, RL78/G14 5.5 KB, Data flash memory: 4 KB
•On-chip high-speed on-chip oscillator
•Select from (for RL78/G14 only 64 MHz (TYP.), 48 MHz (TYP.)), 32 MHz (TYP.), 24 MHz
(TYP.), 16 MHz (TYP.), 12 MHz (TYP.), 8 MHz (TYP.), 4 MHz (TYP.), and 1MHz (TYP.)
•On-chip single-power-supply flash memory (with prohibition of block erase/writing function)
Self-programming (with boot swap function/flash shield window function) On-chip debug
function
•On-chip power-on-reset (POR) circuit and voltage detector (LVD)
•On-chip watchdog timer (operable with the dedicated low-speed on-chip oscillator)
•On-chip multiplier and divider/multiply-accumulator
•16 bits × 16 bits = 32 bits (Unsigned or signed)
•32 bits ÷ 32 bits = 32 bits (Unsigned)
•16 bits × 16 bits + 32 bits = 32 bits (Unsigned or signed)
•On-chip key interrupt function
•On-chip clock output/buzzer output controller
•On-chip BCD adjustment
•I/O ports: 16 to 120 (N-ch open drain: 0 to 4)
•Timer
•16-bit timer: 8 to 16 channels
•Watchdog timer: 1 channel
•Real-time clock: 1 channel (Correction clock output)
•Interval timer: 1 channel
•Serial interface
•CSI
•UART/UART (LIN-bus supported)
•I2C/Simplified I2C communication
•Different potential interface: Can connect to a 2.5/3 V device when operating at 4.0 V to 5.5 V
•8/10-bit resolution A/D converter (VDD = EVDD =1.6 to 5.5 V): 6 to 26 channels
•Standby function: HALT, STOP, SNOOZE mode
•Power supply voltage: VDD = 1.6 to 5.5 V
•Operating ambient temperature: TA = -40 to +85°C
For the most updated information on the MCU please refer to RENESAS's website.

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 8
3.0 BLUEBOARD-RL78/G13/G14_64pin Hardware Description
3.1 Introduction
The NGX BLUEBOARD-RL78/G13/G14_64pin is based on RL78/G13/G14_64pin microcontroller
from RENESAS. RL78/G13/G14_64pin offers 64-KB Flash memory, 32-MHz operation, ADC: Up to
20 channels, 10-bit resolution, 2.1µs conversion time, D/A converter: 2 channels, 8-bit resolution,
Onchip temperature sensor and wide range of peripherals. Refer to the RL78/G12/G13/G14 data sheet
for complete device details.
BLUEBOARD-RL78/G13/G14_64pin microcontroller is factory-programmed with a quick start demo
program. The quick start program resides in RL78/G13/G14_64pin on-chip Flash memory and runs each
time power is applied, unless the quick start has been replaced with a user program.
3.2 Board Image with pointer to each peripheral & connectors
Fig 4

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 9
4.0 BLUEBOARD-RL78/G13/G14_64pin hardware verification
NGX's BlueBoard-RL78/G13/G14_64pin board evaluation platforms ship witha factory-programmed test
firmware that verifies the board peripherals. It is highly recommended that you verify the board, before
you start programming. Also this exercise helps you get acclimatized with the board quickly.
To run the tests you will need the following:
BLUEBOARD-RL78/G13/G14_64pin
Power: DC 6.5V Supply
PC
Serial RS232 cable
4.1 Board connections
BlueBoard Peripheral
Schematic labels
MCU pins
User LED
LED
21
Buzzer
BUZZER
64
User Switch
INTP1
33
Reset Switch
NRST
6
Character LCD
LCD_D0
LCD_D1
LCD_D2
LCD_D3
LCD_D4
LCD_D5
LCD_D6
LCD_D7
LCD_RS
LCD_R/W
LCD_EN
LED+
29
28
27
26
25
24
23
22
17
18
19
20
ADC
ANI2
54
UART1
RXD1
TXD1
59
60
UART2
RXD2
TXD2
42
43
E1 Emulator
TOOL0
NRST
5
6
Power Supply
Vdd_MCU
15
Table.1

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 10
4.2 Powering the Board
The BLUEBOARD-RL78/G13/G14_64pin requires DC supply of 6.5V.1A rating to power it up,
alternatively the board could be powered through Emulator.
4.3 Verifying all the peripherals of the board
The following section focusses on the verification of all the peripherals supported on the board. The order
of the tests is mentioned in the same manners as the flow of the test firmware. We highly recommend that
you follow the order of the test. The test firmware is designed in a manner that the user needs to spend as
minimum time as possible to verify all the peripherals.
Note: It is highly recommended that the user tests all the peripherals as soon as the board is received.
Power up the board and we are all set to verify the board peripherals. The order of the peripherals that are
verified by the firmware are as follows:
4.3.1 LED
Test setup and verification:
As soon as the board is turned ON or reset; the test LED (D1) go ON & OFF for a couple of times, this
simple test validates the LED.
4.3.2 BUZZER
Test setup and verification:
When the board is turned ON or reset you will hear a beep after few seconds. This confirms the status of
the Buzzer.
4.3.3 User Switch
Test setup and verification:
When you press the User Switch, LED (D1) toggles.
4.3.4 Character LCD
Test setup and verification:
A message “WELCOME TO NGX TECHNOLOGIES” should be displayed on the Character LCD.

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 11
4.3.5 RTC
Test setup and verification:
Next, the firmware validates the internal RTC. The RTC value is read and displayed on the character LCD.
4.3.6 ADC
Test setup and verification:
The ADC pin is connected to a potentiometer. To test the ADC rotate the wheel of the potentiometer, as
The position varies the ADC value sensed is displayed on the LCD display.
Note: Since the RL78G13/G14 has a 10-bit ADC, the values of the ADC reading will range from 0x0000
to 0x1023.
4.3.7 UART1 & UART2
Note: The UART1 and UART2 test is not there in the factory-programmed test firmware , user need to
load the UART1 and UART2 sample firmware separately then follow the below steps. To load the
firmware follows the steps in section 3.2 in the user manual.
Test setup and verification:
Open the hyper terminal as shown in the below image. To test the UART1& UART 2 open the hyper
terminal with settings 9600bps 8N1, i.e.
Baud Rate: 9600 bps
Bits: 8
Parity: None
Stop bits: 1
Flow Control: None
Fig 5
A ‘Connect To’ window opens where you have to select the COM port. In this example it is
COM26.Click OK. A ‘COM26 Properties’ window appears. Set the values as shown below. Click OK.

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 12
Note: Please check for your machines COM port number. The COM port number can be different.
Fig 6 Fig 7
Next a ‘Hyper Terminal’ window opens as shown.
Fig 8
4.3.8 Supply Voltage Adjustment Pot
Test setup and verification: This pot demonstrates the MCU can work for variable voltages i.e 1.6 V to
5.5 V. We have verified user LED (D1) blinky at voltage 1.8V.
Adjust the pot to set the voltage between the specified ranges and test the user LED (D1) blinky, LED
(D1) should toggle.

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 13
5.0 CHANGE HISTORY
5.1 Change History
6.0 REFERENCES
In addition to this document, the following references are included on the NGX
BLUEBOARDRL78/G13/G14_64pin product and can also be downloaded from
www.ngxtechnologies.com:
▪NGX BLUEBOARD-RL78/G13/G14_64pin schematic for the Development board.
Additional references include:
▪Information on development tool being used:
-CubeSuite+, http://sg.renesas.com/products/tools/ide/ide_cubesuite_plus/
About this document:
Revision History
Version: V1.1 author: Vivek Aggarwal & Sandeep
Company Terms & Conditions
Legal
NGX Technologies Pvt. Ltd. provides the enclosed product(s) under the following conditions:
This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT,
DEMONSTRATION, and EDUCATION OR EVALUATION PURPOSES ONLY and is not considered
by NGX Technologies Pvt. Ltd to be a finished end-product fit for general consumer use. Persons handling
the product(s) must have electronics training and observe good engineering practice standards. As such,
the goods being provided are not intended to be complete in terms of required design-, marketing-, and/or
manufacturing-related protective considerations, including product safety and environmental measures
typically found in end products that incorporate such semiconductor components or circuit boards. This
evaluation board/kit does not fall within the scope of the European Union directives regarding
electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC, CE or UL and
therefore may not meet the technical requirements of these directives or other related directives.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the
user indemnifies NGX Technologies from all claims arising from the handling or use of the goods. Due
to the open construction of the product, it is the user’s responsibility to take any and all appropriate
precautions with regard to electrostatic discharge.
13

Quick Start Guide: BLUEBOARD-RL78/G13/G14_64pin
Page | 14
EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL
BE LIABLE TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES.
NGX Technologies currently deals with a variety of customers for products, and therefore our arrangement
with the user is not exclusive. NGX Technologies assumes no liability for applications assistance,
customer product design, software performance, or infringement of patents or services described herein.
Please read the User’s Guide and, specifically, the Warnings and Restrictions notice in the User’s Guide
prior to handling the product. This notice contains important safety information about temperatures and
voltages.
No license is granted under any patent right or other intellectual property right of NGX Technologies
covering or relating to any machine, process, or combination in which such NGX Technologies products
or services might be or are used.
Disclaimers
Information in this document is believed to be reliable and accurate. However, NGX Technologies does
not give any representations or warranties, expressed or implied, as to the completeness or accuracy of
such information and shall have no liability for the consequences of use of such information.
NGX Technologies reserves the right to make changes to information published in this document, at any
time and without notice, including without limitation specifications and product descriptions. This
document replaces and supersedes all information supplied prior to the publication hereof.
Trademarks
All referenced trademarks, product names, brands and service names are the property of their respective
owners.
