1.0 INTRODUCTION
This document is the User Manual for LPC1788/LPC4088 Xplorer++; a cost effective evaluation platform
for NXP’s LPC1788 MCU. This document reflects its contents which include system setup, debugging,
and software components. This document provides detailed information on the overall design and usage
of the board from a systems perspective.
Before proceeding further please refer the Quick Start Guide for LPC1788/LPC4088 Xplorer++ features,
unboxing and verification. Kindly refer to the product page for LPC1788 and product page for LPC4088
for the latest information.
(Note: LPC1788 and LPC4088 Micro-controllers are pins compatible. This User Manual is also
applicable to LPC4088 Xplorer++ board. The LPC1788 sample example works with LPC4088.)
Note: To restore the Factory Default for ‘LPC1788/LPC4088 Xplorer++ Board’ kindly refer to section
6.0

User Manual: LPC1788/LPC4088 Xplorer++
Page | 5
2.0 LPC1788/LPC4088 Xplorer++ Development Tool Setup
2.1 ULINK2/ME and KEIL
NGX’s MCU evaluation platforms are not coupled tightly with any one particular combination of IDE and
debugger. The following sections will explain the setup for KEIL and ULINK2/ME as the IDE and
debugger respectively.
2.2 Installation & Configuration of KEIL software
The Installation of KEIL (MDK-ARM V4.54) software is explained below:
Step 1: Open the KEIL setup
Fig.1

User Manual: LPC1788/LPC4088 Xplorer++
Page | 6
Step 2: Click on Next.
Fig.2
Step 3: To accept the agreement, click the check box and click Next.
Fig.3

User Manual: LPC1788/LPC4088 Xplorer++
Page | 7
Step 4: Provide the destination path and click on Next
Fig.4
Step 5: Fill your personal information and click on Next
Fig.5

User Manual: LPC1788/LPC4088 Xplorer++
Page | 8
Step 6: Click on Next
Fig.6
Step 7: Keil µVision 4.54 Setup is completed, click Finish.
Fig.7

User Manual: LPC1788/LPC4088 Xplorer++
Page | 9
2.3 Configuration of ULINK2/ME Debugger
The configuration flow of ULINK2/ME Debugger is explained below:
Step 1: Open the KEIL blinky project downloaded from the website and click on the ‘Target Options’.
Fig.8
Step 2: The window opens as shown in the following image. Next click on Debug and then select the
‘ULINK2/ME Cortex Debugger’ as shown in the following image.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 10
Fig.9
Step 3: Next click on the ‘Settings Option’, the ‘Cortex-M Target Driver Setup’ window opens then select
SW port. After selection of the SW port the ULINK2/ME detected is as shown in the following image.
Fig.10
Click OK to complete the ‘ULINK2/ME Debugger configuration’.
(Note: The Cortex M3 can be programed using SW or JTAG).
2.4 Configuring Internal Flash
Step 1: Open the KEIL blinky project, and then click on the ‘Target Options’.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 11
Fig.11
10
Step 2: The window opens as shown in the following image, click on Utilities and select ‘ULINK2/ME
Cortex Debugger’.
Fig.12
Step 2: Select ‘Update Target before Debugging’ check box, click on ‘Settings Options’ and in ‘CortexM
Target Driver setup’ click Add and select ‘LPC17xx IAP 512kB Flash programing algorithm’ and click
add.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 12
Fig.13
Click OK to complete the ‘ULINK2/ME Debugger and Internal Flash configuration’.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 13
2.5 Setup for ULINK2/ME and LPC1788/LPC4088 Xplorer++ Board
Option A: With ULINK-ME debugger
To run the KEIL examples you will need the following and the image shows the each components:
•ULINK-ME
•10-pin ribbon cable
•LPC1788/LPC4088 Xplorer++ Board
•USB AM to Micro B cable
Fig.14
Steps to setup the ULINK-ME and LPC1788/LPC4088 Xplorer++ Board:
(Note: Please refer keil knowledgebase article for connecting ULINK2/ME 10-pin ribbon cable to NGX
Xplorer++)
Step 1: Connect one end of 10-pin ribbon cable to ‘ULINK-ME 10-pin box header’ as show in the
following image.
Fig.15

User Manual: LPC1788/LPC4088 Xplorer++
Page | 14
Step 2: Connect other end of 10-pin ribbon cable to ‘10-pin box header’ of the LPC1788/LPC4088
Xplorer++ board as shown in the following image.
Fig.16
Step 4: Connect one end of ‘USB AM to Micro B’ cable to LPC1788/LPC4088 Xplorer++ board and other
end to computer and connect one end of ‘USB AM to Micro B’ to ULINK-ME and other end to computer
as shown in the following image.
Fig.17

User Manual: LPC1788/LPC4088 Xplorer++
Page | 15
Step 5: The setup is now ready to be used for development with KEIL IDE and ULINK-ME.
Option B: With ULINK2 debugger
The LPC1788/LPC4088 Xplorer++ board has on board ‘10-pin SWD/JTAG box header’; ensure that the
ULINK2/ME must have ‘10-pin SWD/JTAG’ support for development. The ULINK2 debugger, ‘20-pin
to 10-pin adapter’ and 10-pin ribbon cable are not a part of the LPC1788/LPC4088 Xplorer++ package,
the user needs to buy separately.
To run the KEIL examples you will need the following and the image shows the each components:
•ULINK2
•ARM JTAG to Cortex JTAG Adapter (20-pin to 10-pin Adaptor)
•10-pin ribbon cable
•LPC1788/LPC4088 Xplorer++ Board
•One USB AM to Micro B cable
Fig.18
Steps to setup the ULINK2 and LPC1788/LPC4088 Xplorer++ Board:
(Note: Please refer keil knowledgebase article for connecting ULINK2/ME 10-pin ribbon cable to NGX
Xplorer)
Step 1: Connect the one of 10-pin ribbon cable to ‘20-pin to 10-pin adapter’ as shown in the following
image.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 16
Fig.19
Step 2: Connect other end of 10-pin ribbon cable to ‘10-pin box header’ of the LPC788-Xplorer++ board
as shown in the following image.
Fig.20
Step 3: Now connect the ‘ULINK2 20-pin’ cable to ‘20-pin to 10-pin adapter’ as shown in the following
image.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 17
Fig.21
Step 4: Connect one end of ‘USB AM to Micro B’ cable to LPC1788/LPC4088 Xplorer++ board and other
end to computer, connect one end of ‘USB type B’ to ULINK2 and other end to computer as shown in the
following image.
Fig.22

User Manual: LPC1788/LPC4088 Xplorer++
Page | 18
Step 5: The setup is now ready to be used for development with KEIL IDE and ULINK2.
3.0 LPC1788/LPC4088 Xplorer++ firmware Development
3.1 Creating the sample (Blinky) project in KEIL
Steps to create the sample (Blinky) project:
Step 1: Open a KEIL IDE.
Fig.23
Step 2: Click on Project->New uVision Project… as show below.
Fig.24

User Manual: LPC1788/LPC4088 Xplorer++
Page | 19
Step 3: Create a new folder in downloaded sample example folder and rename to Blinky_test and select
Blinky_test folder click Open.
Fig.25
Step 4: Give a project name, example: ‘Blinky_test’ and click Save.

User Manual: LPC1788/LPC4088 Xplorer++
Page | 20
Fig.26
Step 5: Select the NXP (found by Philips) and search for the controller.
Fig.27
Step 6: Select LPC1788 controller and click OK.
