NHR SG-01-SK-HB User manual

ZigBee Wireless Fire Smoke Alarm
(Photoelectric detection type / Battery-powered / Voice alarm)
User Manual
※Compliant to local legal requirements
※For Indoor use
※Contain installation procedure
There are two ways of mounting the detector, wall-mounted and
ceiling-mounted.
Model: SG-01-SK-SB for stand-alone / SG-01-SK-HB for ZigBee
1. Safety Notice
使用前 Before installing the detector
Warning
Please make sure your personal safety in mounting the detector,
position in installing the detector is very important and should pay
high attention to avoid accidents.
Please make sure the screws have been fixed tightly on wall, any
fallen parts or detectors itself may cause damage of the detector.
Please strengthen the wall or ceiling with a supplement board in
softer wall or ceiling to avoid the damage cause from fallen parts
or detector.
Please make sure the screws or any wooden dust will not fall into
eyes during installation. Please clean the dust as soon as possible
if it happens and call doctor for careful check of health of installer.
2. Notice in use
3. Detector introduction
Warning
Fixture Smoke detection
chamber
Siren speaker
Test button/
Mute button
The detector Alert LED : Red
Wireless Link
Status button
(S1)
Wireless Link
LED : Green
What is included in the box
◤ Screws for wall/ceiling mount (3.5 x 25mm)…………………………2 pieces
◤ Screws cap for screws ………………………………………………2 pieces
◤ Battery (CR123A) …………………………………………………… 1 piece
◤ Manual ………………………………………………………………1 piece
Please make sure the battery is away from children, it will hurt
children if they accidentally swallow the battery.
4. Location of Installation
Bed room Baby room Kitchen
Hallway/
Corridor StairLiving room
Photoelectric Type Fire Smoke detector Heat
detection
type
5. Installation Position
Warning
Please install the detector as centered
as possible, false alarm could happen
frequently because of inappropriately
installing position.
Within
60 cm
Away from ventilation
over at least 1.5 meters
within
60cm
over
15cm
※Ceiling-mounted
◤ The detector should
be less than 60 cm from
the ridge beam.
◤ Installing position
should away from the
ridge beam or wall at
least 60 cm, and best
position it in the center
of the room.
◤ Installing the detector away
from the ventilation at least
1.5 meters to avoid the false
alarm caused from the air flow.
◤Please install the detector over 15 cm and within
60 cm from the ceiling in wall-mounted style.
※Wall-mounted
6. How to mount the detector
* Places where the photoelectric type detector should avoid installing:
(1) Cooking area with frequently smoke or steam generating; (2) Places where
the temperature goes sub-zero。 C/ 32。 F, or over 50。 C/ 122。 F in that it is easy
to damage the battery and end up causing false alarm or low battery;
(3) Outdoor is not allowed to be installed; (4) Bathroom or any places where
frequently wet or in high humidity places; (5) Places besides Lamp or lights
that may block fire smoke are not allowed to install the detector, please keep
those equipment at least for over 50 cm.
7. Procedure of installation - Preparation
1. Open the mounting bracket, and put in the battery.
2.
Please write down installing date on the detector in the position where agent
has suggested.
3. Please press Test Button one time and wait for a Beep to ensure the proper
detector setup.
4.
Please make sure the linking status for the wireless type. Green LED flashes
every 65 seconds in normal status.
SG01SK_U15AUG26
1/2
◤Thank you for choosing Nietzsche’s photoelectric type fire smoke detector.
◤Please read the manual carefully and use the detector properly.
◤
Please read every details in the manual and notice every “Warning”carefully.
To protect your safety , please note below safety notice. Please make
sure the Site of installation is safe during your installation, watch your
feet and position, danger could happen if you do not keep your eyes
on your environment.
Please keep tools, such as battery, screws and screw drivers away
from children. Children could accidentally swallow or hurt themselves
if they get those tools.
Please keep your ears a certain distance from the siren, it may hurt
your ability of hearing if you get too close to the siren while it is
activated at the time.
Suggested
Installation Location
Within
60 cm
Within
60 cm
Negative
pole
-
Positive pole +
Battery model: CR123A
Installed
on yy / mm
Detector
Type
◤ According to the law, customer must install the detector(s) in indoor and
--maintain/ manage the detector’s operation on their own.
◤ Please check if the detector still working properly every six months to make
--sure its functions.
◤ Please do not disassemble, modify, scratch, paint or shocking impact on the
--detector, it may cause damage of the detector.
◤ Please note the detector has self-detection and low-battery alarm, please be
-- aware of any indication from the detector no matter it is flash in LEDs or beep,
--and read manual to find out the meanings.
◤ Photoelectric type smoke detector alerts only for the smoke around it, the
--detector may not report event for another room.
◤ Please make sure user can hear the alarm when installing the detector in less
--used room.
◤ Please make sure the pesticide may effect the functions of the detector, please
-- withdraw or spread the pesticide in the place where it will not effect the detector.
◤ Please double check if the detector still works normally whenever you are
--back home after 7 days or more than 7 days trip.
◤ The sensing technology of this detector is photoelectric smoke detection.
◤
The detector reports possible fire alarm, but user should not expect there will
not be any fire event because installing the detector, please note Nietzsche
take no responsibility for any damages from any accident in any case.
◤
Please note sprinkling-type of pesticide will effect the function of the detector.

Method for verifying detector(s) operation normally :
Please verify detector function properly after installation, battery replacement,
and inspection.
Please press Test Button for 1 second for operation verification. Within 1 ~ 5
seconds, you will hear “Operations : Normal＂meaning the detector functions
normally; on the contrast you will hear Beep Beep meaning the detector function
abnormally and it needs to proceed further treatment(s). Please refer to below
Status and notification table indications :
When you hear “Danger! Evacuate!” from the detector(s) and see the red Led
flashing, please follow below SOP or local emergency SOP and act immediately :
Please confirm the exact location where fire smoke comes from and call the
Fire department after evacuate oneself. Except for fire smoke, siren could be
activated in following conditions. User can stop the alarming siren by means of
exchange fresh air about the detector(s).
•When the pesticide sprinkles on the detector directly.
•When the cigarette smoke gets into the detector.
•When the sanitizer sprinkles on detector.
•When the cooking smoke gets into the detector.
•When the smoke detector has condensed.
•When there is/are bug(s) or incent(s) get(s) into the detector chamber.
Warning
(1) Please mark the expected installing position on wall in advance
that is helpful for drilling holes
(2) Please make sure the Test / Mute button face down for best
manual operation.
7. Installation – installing procedure
…………… …
…………… …
1
2
3
1
66.8㎝
…………… ………
……………
2
3
4
2
66.8㎝
Please fix the detector with two screws on ceiling or wall.
1. Fix the mounting bracket with two screws.
2. Place the detector in the rail of mounting bracket.
3. Turn the detector clockwise until hear a sound “KA” meaning fixing
tightly.
………
1
1
Please fix the detector with two screws on ceiling or wall.
1. Drill 2 holes on expected mounting position for 5mm for diameter
and 25 mm in depth.
2. Fix the mounting bracket with two screws.
3. Place the detector in the rail of mounting bracket.
4. Turn the detector clockwise until hear a sound “KA” meaning fixing
tightly.
8. Operation Verification
Please verify operation normally when using Wireless Type Smoke Detector
9 When your hear the siren from the detector(s)
1. Please check the operation of detector every 6 months.
2.
Please check if there is dust or stink attached on the smoke detector chamber.
This will potentially cause false-alarm.
3. Method of maintaining the detector :
Please withdraw the detector from mounting bracket. And clean the ceiling
or wall around the detector. Please clean the whereabouts of the detector
after detaching the detector.
•Please clean the dust with wet and clean cloth.
•Please do NOT let the water of wet cloth leaks into the detector.
•Please do NOT use the volatile cleaner to clean the detector, it may cause
the damage on the surface of the detector.
10 When you hear the sound notification of power low
11. Maintain and inspection periodically
12. Waste of detector treatment
13. Trouble-shooting
Status Inspection Treatment
Siren keeps
activating
Or
No fire event,
but siren keeps
activating
Or
Press Test button
and keep
“Beep, Beep”
meaning
malfountion.
Is there any smoke from
cooking, pesticide,Cigarette,
and steam that gets In the
detector?
Please start the air
exchange in that space.
Is there dust covered
on the detector?
Please clean the dust
on the detector.
Is there any residual smoke
remains on the detector?
Please clean the smoke
in the detector
Is the test button has been
pressed accidentally?
Please adjust the test
button to avoid being
pressed.
Mute the siren,
but siren is
still on.
Is the battery or power
adaptor loosen?
Please make sure the
battery or power cord is
fixed tightly.
Is the battery run out of
power?
Please replace new
battery.
Wireless
disconnection
Is there is block between
detector and receiver? Please add router in
between
Is the battery is about to
power low?
Is there any powerful radio
radiation that Interrupts the
current wireless signal?
Please replace battery
Please remove the radio
radiation source, or add
router in between.
E：[e-mail]
W： www.shop-wifi.com
SG01SK_U15AUG26
2/2
尼采實業股份有限公司
Nietzsche Enterprise Co., Ltd.
Please contact your local dealer for battery information and replacement.
Please note the battery specification is CR123A
(Battery run time is less than one week before it starts warning about power low)
Disposed detector and battery should strictly follow laws of local waste
management.
Mounting on ceiling or wall
Mounting on concrete wall
Please remove the block
in between
---
---
Indication
---
---
---
---
---
--- Red & Green LED
lit-on for 1 sec
Status Action Voice and
Sound Green LED
Flash once per
15 second
Flash once per
65 seconds
Flash twice per
10 seconds
Flash 3 times
Flashing
Please press S1
on gateway
Please follow
Trouble-shooting
Press 3 times
on S1
Press S1 for
5 seconds
Not connected To
gateway
Connected to gateway
successfully
Normally connected
Disconnection
Leave network
Reset
---
Replace battery
Follow trouble-shooting
---
---
Flash twice
Flash 5 times
Indication
Status Action
Power On
Normal Detecting
Alarming
Low Power
“Beep”
---
“Danger! Evacuate!”
“Beep” per minute
“Operations: Normal”
Put in battery or plug
on DC adaptor
Follow local
emergency SOP
LED Flash
3 times
LED Flash per
minute
Flashing
continuously
Operation
Abnormally
Operation
Normally
“Beep, Beep”
per minute
Voice and Sound Red LED
