Nicopure Labs TRACER TWIST User manual

TRACER
TWIST BATTERY

INTRODUCTION
Thank you for purchasing the TRACER TWIST battery. Please
read this manual carefully before using to ensure optimal
lifespan and performance.
The TRACER TWIST battery offers a massive 2300 mAh
battery cell that will keep you powered all day long. With
its user-friendly and stealth-like design, the TRACER TWIST
battery is equipped with variable output capability ranging
from 5-30W and a bypass mode.
This system is manufactured to the highest quality standards
and, when coupled with our line of premium e-liquids, oers an
exceptional vaping experience.

GETTING STARTED
TRACER TWIST batteries must be turned “on” before using for
the rst time.
To turn on your TRACER TWIST battery, click the ring button
on the side of the battery ve times in rapid succession. The
button’s backlight will blink ve times to indicate the TRACER
has been successfully turned “on.”
In order to begin using the TRACER TWIST, rst conrm the
battery is “on” and the tank is lled with the appropriate amount
of e-liquid. Once ready, place your lips around the mouthpiece
and slowly inhale while holding down the ring button. Release
the button at the end of each drag and repeat as desired.

GETTING STARTED
It is important to turn “o” this device when storing.
There is no harm in leaving your TRACER TWIST battery “on,” as
the battery life will not be consumed unless the ring button
is pressed. However, it is important to turn the battery “o”
before placing it in drawers, pockets, or purses to ensure the
button is not pressed inadvertently.
To turn the TRACER TWIST battery “o,” follow the same steps used
to turn the battery “on.” Simply press the ring button ve times
in rapid succession. Once successful, the backlight on the ring
button will blink ve times and the device will turn “o.” To resume
use, you will need to turn the TRACER TWIST battery back “on.”

COMPONENT’S FRONT
1 : Firing Button
2 : Backlight
3 : 2300 mAh Battery
4 : USB Charging Port
5 : Charge Indicator
6 : Variable Wattage
Twist Ring
5W
10W
30W
BY PASS
TRACER TWIST
5W
10W
30W
BY PASS
TRACER TWIST

MODES
Bypass Mode
Direct output voltage is applied in this mode. The higher the
battery level, the higher the voltage yielded.
Variable Wattage Mode
User has the ability to select the desired wattage level between
5-30W. To adjust the wattage, simply rotate the bottom ring.
Shift Between Modes
To shift between Bypass Mode (orange light) and Variable
Wattage Mode (white light), simply rotate the bottom ring to
the desired mode.

BATTERY FEATURES
Automatic Cuto
If the ring button is pressed for more than 15 seconds at a time,
the TRACER TWIST battery will automatically cut o power to
the tank and the backlight will ash ten times. This cut o time
protects against potential safety hazards should the ring
button be accidentally pressed for an extended period.
Low Voltage Protection
If the available voltage of your TRACER TWIST battery drops
below 3.3 volts, the ring button’s backlight will ash four times
and the device will power o. Once the battery is recharged and
is capable of producing more than 3.65 volts, the battery will
perform again as intended.

BATTERY FEATURES
Short Circuit Protection
The TRACER TWIST is equipped with short circuit protection to
ensure your battery is not damaged by faulty tanks. Should a short
circuit occur before the TRACER TWIST is in use, the ring button’s
backlight will ash ve times, then power o. Should the short
circuit occur while the unit is in use, the ring button’s backlight
will ash three times before resetting. Replace the tank’s coil head,
and your TRACER TWIST battery will perform again as intended.
Important Note:
The TRACER TWIST battery is designed to work with coil heads
having a resistance of .2 ohms or above. Using coil heads below
.2 ohms will create a potentially unsafe situation.

BATTERY CHARGING
When to Recharge
The TRACER TWIST ring button’s backlight will display the amount
of battery life remaining. The battery can be charged at any time,
regardless of the remaining charge. If the battery is completely
drained, it will need to be charged before continuing use.
The TRACER TWIST battery takes approximately three and a half
hours to charge from its fully drained state.
Battery Life
60-100%
30-59%
10-29%
0-9%
Backlight
Stays Lit
Flashes Slowly
Flashes Moderately
Flashes Quickly

BATTERY CHARGING
How to Recharge
Attach the small connector of the USB cable into the charging port
of the TRACER TWIST battery. The larger end of the cable should
then be inserted into a computer or other USB compatible power
source, or can be used in conjunction with the TRACER TWIST wall
charger. Once connected to a power source, the charge indicator
at the bottom of the unit will glow red. When the unit is fully
charged, the red light will blink ve times and then go out.
Important Note:
It’s important to use only the TRACER TWIST USB cable and wall
charger. Components from other manufacturers may cause
irreversible damage to your TRACER TWIST battery.

WARNINGS
Storage: This device should be kept out of reach of children and
pets, and stored safely in a dry environment. Do not store in
high temperature areas, as this will cause irreversible damage
to batteries and other components.
Overheating: If the TRACER TWIST vaporizes continuously or
shows any signs of overheating, stop usage immediately and
unscrew all parts.
Charging: Do not use the charger in damp areas or near a high
temperature heat source. If the power supply emits any heat or
odor, is discolored, or experiences any unexpected issues while
charging, unplug it immediately.

WARNINGS
Coil Resistance: The TRACER TWIST battery is designed to work
with coils having a resistance of .2 ohms or above. Using coil-
heads below .2 ohms will create a potentially unsafe situation.
Improper Usage: The use of any third-party accessories may
lead to malfunction and/or damage of this product.
Guarantee: The TRACER TWIST oers a 30-day satisfaction
guarantee on all hardware. However, e-liquids and coil
assemblies are consumable items and will not be refunded.
Warranty: Claims for products damaged by improper usage
will not be accepted. This includes, but is not limited to, the use
of third-party hardware and/or improper handling.

110 452

Nicopure Labs, LLC.
5909 NW 18th Drive, Gainesville, FL 32653
nicopure.com
