Nikon UT-1 User manual

Communication Unit
User’s Manual Version 2
En
Users of D4-series, D800, D800E, D7100, D7000
cameras should instead refer to one of the
following manuals.
D4-Series, D7000
Communication Unit UT-1
User's Manual (supplied with
the UT-1)
D7100
Communication Unit UT-1
Manual for Users of D7100
Digital Cameras *
D800, D800E
Communication Unit UT-1
Manual for Users of D800/
D800E Digital Cameras *
* Available for download from the websites
listed on page xiii.

ii
What the UT-1 Can Do for You
What the UT-1 Can Do for You
This manual describes how to connect to a network and upload
pictures to a computer or ftp server or control the camera
remotely using Camera Control Pro 2. Use the UT-1 to connect to
Ethernet networks, or connect to wireless networks by attaching a
WT-5 to the UT-1.
Before connecting the UT-1, confirm the firmware for the camera and
UT-1 have been updated to the latest version. For more information,
visit the websites listed on page xiii.
Before using the UT-1 network function, connect the camera to a
network.
Ethernet Networks
For information on connecting to a computer, see page 15.
For information on connecting to an ftp server, see page 57.
Wireless Networks
Connect to wireless networks using a WT-5 wireless transmitter (06).
For information on connecting to a computer, see page 23.
For information on connecting to an ftp server, see page 64.

iii
What the UT-1 Can Do for You
Once a network connection has been established, you can:
Upload existing photos and movies
Take or browse photos remotely
Image transfer (035) FTP upload (075)
Computer ftp server
Camera control (040) HTTP server (043)
Camera Control Pro 2
iPhone
Computer

iv
What the UT-1 Can Do for You
