Notes on Safety Operations
CAUTION
Do not disassemble
Touching the internal parts of the camera or lens could
result in injury. Repairs should be performed only by
qualified technicians. Should the camera or lens break
open as the result of a fall or other accident, take the
product to a Nikon-authorized service representative for
inspection after unplugging the product and/or removing
the battery.
Turn off immediately in the event of
malfunction
Should you notice smoke or an unusual smell coming
from the camera or lens, remove the battery immediately,
taking care to avoid burns. Continued operation could
result in injury.
After removing or disconnecting the power source, take
the product to a Nikon-authorized service representative
for inspection.
Do not use the camera or lens in the
presence of flammable gas
Operating electronic equipment in the presence of
flammable gas could result in an explosion or fire.
Do not look at the sun through the lens
or viewfinder
Viewing the sun or other strong light sources through the
lens or viewfinder could cause permanent visual
impairment.
Keep out of reach of children
Particular care should be taken to prevent infants from
putting the batteries or other small parts into their mouths.
Observe the following precautions when
handling the camera and lens
• Keep the camera and lens unit dry. Failure to do so
could result in fire or electric shock.
• Do not handle or touch the camera or lens unit with
wet hands. Failure to do so could result in electric
shock.
• When shooting with back-lighting, do not point the
lens at the sun or allow sunlight to pass directly down
the lens as this may cause the camera to overheat and
possibly cause a fire.
• When the lens will not be used for an extended period
of time, attach both front and rear lens caps and store
the lens away from direct sunlight. Failure to do so
could result in a fire, as the lens may focus sunlight
onto a flammable object.

15
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
A
B
Nomenclature
1Lens hood (P. 20)
2Lens hood setting index
(P. 20)
3Lens hood attachment
index (P. 20)
4Lens hood mounting index
(P. 20)
5Distance scale (P. 19)
6Distance index line
7Focus ring (P. 17)
8Zoom ring (P. 19)
9Focal length scale
0Focal length scale index line
!Mounting index
@Lens mount rubber gasket
(P. 21)
#CPU contacts (P. 21)
$Focus mode switch (P. 17)
%Vibration reduction ON/OFF
switch (P. 18)
( ): reference page

16
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
Usable cameras and available
functions
There may be some restrictions or limitation for available
functions. Refer to camera’s User’s Manual for details.
Cameras
Function Exposure mode
VR AF P*1 6$0
Nikon digital SLR (Nikon FX/DX format)
cameras, F6, F5, F100, F80-Series/
N80-Series*, F75-Series/N75-Series*,
F65-Series/N65-Series*
3 3 3333
Pronea 600i/6i*, Pronea S*2 —
3 3333
F4-Series, F90X/N90s*, F90-Series/N90*,
F70-Series/N70*
—
333
——
F60-Series/N60*, F55-Series/N55-Series*,
F50-Series/N50*, F-401x/N5005*,
F-401s/N4004s*, F-401/N4004*
——
3333
F-801s/N8008s*, F-801/N8008*,
F-601
M /N6000*
——
33
——
F3AF, F-601/N6006*, F-501/N2020**,
Nikon MF cameras (except F-601
M /N6000*)
— — ————
3: Possible — : Not possible
VR: Vibration reduction AF: Autofocus
*: Sold exclusively in the USA
**: Sold exclusively in the USA and Canada
*1: P includes AUTO and Vari-Program System.
*2: Manual (M) is not available.
Thank you for purchasing the AF-S NIKKOR 16-35mm f/4G ED VR lens. Before using this lens,
please read these instructions and refer to your camera's User's Manual.
Major features
• The Nano Crystal Coat deposited on some of the
lens elements ensures that fine, clear images can be
reproduced under various shooting conditions, from
the sunny outdoors to spotlighted interior scenes.
• By enabling vibration reduction ( VR Ⅱ ), slower
shutter speeds (approximately four stops*) can be
used, thus increasing the range of usable shutter
speeds and zoom positions, particularly when hand-
holding the camera. (*Based on results achieved
under Nikon measurement conditions. The effects of
vibration reduction may vary according to shooting
conditions and use.)
• Superior optical performance and rendering
characteristics are maximized with the use of three
aspherical lens elements and two extra-low
dispersion (ED) glass elements, which ensure
correction of chromatic aberration. In addition, the
rounded aperture produces soft and pleasing blur
characteristics in portions of pictures that are out-of-
focus.
Important
• When mounted on Nikon DX format digital SLR
cameras, such as the D300-Series and D90, the lens’
picture angle becomes 83°-44° and its 35mm
equivalent focal length is approx. 24-52.5 mm.

17
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
Focusing (Fig. A)
Set your camera’s focus-mode selector according
to the chart below:
Autofocus with manual override (M/A mode)
aSet the lens focus mode switch to M/A.
bAutofocus is enabled, but autofocus operation
can be overridden by rotating the separate
focus ring while pressing the shutter-release
button halfway, or by pressing the AF-ON
button on the camera body of cameras so
equipped.
cPress the shutter-release button halfway or the
AF-ON button once again to cancel manual
focus and resume autofocus.
Getting good results with autofocus
Refer to “Notes on using wide- or super wide-
angle AF NIKKOR lenses” (P. 23).
Cameras Camera
focus mode
Lens’ focus mode switch
M/A M
Nikon digital SLR (Nikon FX/DX format) cameras, F6, F5,
F4-Series, F100, F90X/N90s*, F90-Series/N90*, F80-Series/
N80-Series*, F75-Series/N75-Series*, F70-Series/N70*,
F65-Series/N65-Series*, Pronea 600i/6i*, Pronea S
AF (C/S) Autofocus with
manual override
Manual focus
(Electronic rangefinder
can be used.)
MF Manual focus
(Electronic rangefinder can be used.)
F60-Series/N60*, F55-Series/N55-Series*, F50-Series/N50*,
F-801s/N8008s*, F-801/N8008*, F-601M/N6000*,
F-401x/N5005*, F-401s/N4004s*, F-401/N4004*
AF (C/S)
MF
Manual focus
(Electronic rangefinder can be used,
except with the F-601M/N6000*)
* Sold exclusively in the USA

18
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
Vibration reduction mode (Fig. B)
Setting the vibration reduction ON/OFF
switch
ON: The effects of camera shake are reduced
while the shutter-release button is pressed
halfway and also at the instant the shutter is
released. Because vibration is reduced in the
viewfinder, auto/manual focusing and exact
framing of the subject are easier.
OFF: The effects of camera shake are not reduced.
Notes on using vibration reduction
• After pressing the shutter-release button halfway,
wait until the image in the viewfinder stabilizes
before pressing the shutter-release button the
rest of the way down.
• Due to the characteristics of the vibration
reduction mechanism, the image in the
viewfinder may be blurred after the shutter is
released. This is not a malfunction.
• If the camera is panned in a wide arc,
compensation for camera shake in the panning
direction is not performed. For example, only the
effects of vertical camera shake is reduced with
horizontal panning.
• Do not turn the camera off or remove the lens
from the camera while vibration reduction is
operating. Failure to observe this note could
result in the lens sounding and feeling as if an
internal component is loose or broken when it is
shaken. This is not a malfunction. Turn the
camera on again to correct this.
• With cameras featuring a built-in flash, vibration
reduction does not function while the built-in
flash is charging.
• With autofocus cameras featuring an AF-ON
button, vibration reduction does not function
when the AF-ON button is pressed.
• When the camera is mounted on a tripod, set the
vibration reduction ON/OFF switch to OFF.
However, it is recommended that the switch be
set to ON when using the camera on an
unsecured tripod head or with monopod.
• If this lens is used with cameras that do not have
the vibration reduction function (P.16), set the
vibration reduction ON/OFF switch to OFF. With
the Pronea 600i/6i camera, in particular, battery
power may become quickly depleted if this switch
is left ON.

19
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
The built-in flash and vignetting
• The built-in flash cannot be used over distances
of less than 0.6 m (2.0 ft.).
•
To prevent vignetting, do not use the lens hood.
• Vignetting is the darkening of the corners around
the image that occurs when the light emitted by
the flash is obstructed by the lens barrel.
Cameras Supported focal length/Shooting distance
D700 (FX format) • 28 mm/3 m (9.8 ft.) or greater
• 35 mm/1 m (3.3 ft.) or greater
D700 (DX format) • 20 mm/1.5 m (4.9 ft.) or greater
• 24 mm or longer/No restriction
D300-Series,
D200, D100
• 24 mm/2 m (6.6 ft.) or greater
• 28 mm/1 m (3.3 ft.) or greater
• 35 mm/No restriction
D90, D80, D5000,
D3000, D60, D50,
D40-Series
• 28 mm/1.5 m (4.9 ft.) or greater
• 35 mm/1 m (3.3 ft.) or greater
D70-Series • 28 mm/2 m (6.6 ft.) or greater
• 35 mm/1 m (3.3 ft.) or greater
Other cameras Vignetting occurs at any shooting
distance.
Focusing, zooming, and depth of
field
Before focusing, rotate the zoom ring to adjust the
focal length until the desired composition is
framed. If your camera has a depth-of-field
preview (stopdown) button or lever, depth of field
can be previewed through the camera viewfinder.
• This lens is equipped with the Internal Focusing
(IF) system. As the shooting distance decreases,
the focal length also decreases.
• The distance scale does not indicate the precise
distance between the subject and the camera.
Values are approximate and should be used only
as a general guide. When shooting distant
landscapes, depth of field may influence
operation and the subject may appear in focus
at a position that is closer than infinity.
• For more information, see p. 146.
Setting the aperture
Use the camera to adjust the aperture setting.

20
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
Using the lens hood
Lens hoods minimize stray light and protect the lens.
Attaching the hood
• Be sure that the lens
hood mounting
index ( ) is aligned
with the lens hood
setting index ( )
(3).
• To facilitate attachment or removal of the hood,
hold it by the base (near the lens hood attachment
index (
)) rather than its outer edge.
• If the lens hood is not correctly attached, vignetting
may occur.
• To store the lens hood, attach it in the reverse
position.
Recommended focusing screens
Various interchangeable focusing screens are
available for certain Nikon SLR cameras to suit any
picture-taking situation. The ones recommended
for use with this lens are:
Screen AB C E
EC-B
EC-E
G1
G2
G3
G4
JLMU
Camera
F6 ◎◎◎ ◎◎
F5+DP-30 ◎◎○◎◎ ◎◎
F5+DA-30 ◎◎ ○
(-0.5)
◎◎ ◎◎
Ⴟ
: Excellent focusing
Ⴜ
: Acceptable focusing
Slight vignetting or moiré patterns appear in
the viewfinder, but not on the film.
— :Not available
( ) : Indicates degree of exposure compensation
needed (center-weighted metering only). For
F6 cameras, compensate by selecting “Other
screen“ in Custom Setting “b6: Screen comp.“
and setting the EV level to -2.0 to +2.0 in 0.5
EV steps. When using screens other than type
B or E, “Other screen“ must be selected even
when the required compensation value is “0“
(no compensation required). For F5 cameras,

21
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
compensate using Custom Setting #18 on the
camera body.
See user’s manual of the camera body for more
details.
Blank box means not applicable. Since type M
screen can be used for both macrophotography at
a magnification ratio of 1:1 or above and for
photomicrography, it has different applications
than other screens.
Important
• For F5 cameras, only EC-B, EC-E, B, E, J, A, L
focusing screens are usable in Matrix Metering.
Lens care
• Be careful not to allow the CPU contacts to
become dirty or damaged.
• If the lens mount rubber gasket is damaged, be
sure to visit the nearest Nikon-authorized service
representative for repair.
•
Clean lens surfaces with a blower brush. To remove
dirt and smudges, use a soft, clean cotton cloth or
lens tissue moistened with ethanol (alcohol) or lens
cleaner. Wipe in a circular motion from the center
to outer edge, taking care not to leave traces or
touch other parts of the lens.
• Never use organic solvent such as thinner or
benzene to clean the lens.
• NC filters are available to protect the front lens
element. The lens hood also helps to protect the
front of the lens.
• When storing the lens in its flexible lens pouch,
attach both the front and rear lens caps.
• When the lens is mounted on a camera, do not
pick up or hold the camera and lens by the lens
hood.
• When the lens will not be used for an extended
period of time, store it in a cool, dry place to
prevent mold and rust. Be sure to store the lens
away from direct sunlight or chemicals such as
camphor or naphthalene.
• Do not get water on the lens or drop it in water
as this will cause it to rust and malfunction.
• Reinforced plastic is used for certain parts of the
lens. To avoid damage, never leave the lens in an
excessively hot place.
Standard accessories
• 77mm Snap-on Front Lens Cap LC-77
• Rear Lens Cap
• Bayonet Hood HB-23
• Flexible Lens Pouch CL-1120
Optional accessory
• 77mm screw-on filters

22
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
Specifications
Type of lens: G-type AF-S Zoom-NIKKOR lens
with built-in CPU and Nikon
bayonet mount
Focal length: 16-35mm
Maximum
aperture: f/4
Lens construction: 17 elements in 12 groups
(2 ED, 3 aspherical and some
Nano Crystal Coat-deposited
lens elements)
Picture angle: 107°-63° with 35mm (135)
format Nikon film SLR cameras
and Nikon FX format digital SLR
cameras
83°-44° with Nikon DX format
digital SLR cameras
94°-52° with IX240 system
cameras
Focal length scale: 16, 20, 24, 28, 35mm
Distance
information: Output to camera
Zoom control: Manually via separate zoom
ring
Focusing: Nikon Internal Focusing (IF)
system, autofocus using a Silent
Wave Motor; manually via
separate focus ring
Vibration
reduction:
Lens-shift method using voice
coil motors (VCMs)
Shooting
distance scale:
Graduated in meters and feet
from 0.28 m (1 ft) to infinity (෱)
Closest focusing
distance:
0.29 m (1.0 ft.) (at 16mm, 35mm)
0.28 m (0.9 ft.) (at 20-28mm)
No. of diaphragm
blades:
9 pcs. (rounded)
Diaphragm: Fully automatic
Aperture range: f/4 to f/22
Exposure
measurement: Via full-aperture method with
cameras with CPU interface
system
Attachment size: 77mm (P = 0.75 mm)
Dimensions: Approx. 82.5 mm dia. ×
125 mm extension from the
camera’s lens-mount flange
Weight: Approx. 680 g (24.0 oz)
Specifications and designs are subject to change without
any notice or obligation on the part of the manufacturer.

23
Jp
En
De
Fr
Es
Se
Ru
Nl
It
Cz
Sk
Ck
Ch
Kr
Notes on using wide- or super wide-angle AF NIKKOR lenses
In the following situations, autofocus may not perform as expected when shooting with wide- or super
wide-angle AF NIKKOR lenses.
1. When the main subject in the focus
brackets is relatively small
When a person standing in front of a distant
background is positioned within the focus
brackets, as shown in Fig. C, the background
may be in focus, while the subject is out of
focus.
2. When the main subject is a finely
patterned subject or scene
When the subject is finely patterned or of low
contrast, such as a field filled with flowers, as
shown in Fig. D, focus may be difficult to
acquire using autofocus.
Responses to these types of situations
(1) Focus on a different subject located at the same
distance from the camera, apply focus lock,
recompose, and shoot.
(2) Set the camera’s focus mode to manual focus
and focus manually on the subject.
Refer to “Getting Good Results with Autofocus” in
the camera’s User’s Manual.
CA person standing in front of
a distant background
DA field filled with flowers

146
Hloubka ostrosti Hĺbka ostrosti
yHloubka ostrosti
yHĺbka ostrosti
yMěřítko zobrazení
y
Reprodukčný pomer
• Distanza di ripresa • Shooting distance
• Vzdálenosti zaostření • Aufnahmedistanz
• Opnameafstand
• Distance de prise de vue
•拍摄距离• Distancia de disparo
•拍攝距離• Avstånd
• ㈖⫫#ᅚẖ • Расстояние съемки
• Vzdialenosť pri snímaní
f/4 f/5.6 f/8 f/11 f/16 f/22
[f=16mm]
0.28
0.27 — 0.29 0.27 — 0.30 0.26 — 0.30 0.26 — 0.32 0.25 — 0.34 0.24 — 0.38
1/8.2
0.35
0.33 — 0.38 0.32 — 0.39 0.31 — 0.41 0.30 — 0.44 0.29 — 0.51 0.27 — 0.70
1/12.5
0.5
0.44 — 0.58 0.43 — 0.62 0.41 — 0.71 0.38 — 0.89 0.35 — 1.53 0.32 — 
1/21.6

2.13 —  1.59 —  1.17 —  0.87 —  0.66 —  0.51 — 
1 / 
[f=20mm]
0.28
0.27 — 0.29 0.27 — 0.29 0.27 — 0.30 0.26 — 0.31 0.26 — 0.32 0.25 — 0.34
1/7.0
0.35
0.33 — 0.37 0.33 — 0.38 0.32 — 0.39 0.31 — 0.41 0.30 — 0.45 0.29 — 0.52
1/10.5
0.5
0.46 — 0.55 0.45 — 0.58 0.43 — 0.62 0.41 — 0.70 0.38 — 0.88 0.35 — 1.48
1/18.0

3.06 —  2.27 —  1.65 —  1.21 —  0.90 —  0.68 — 
1 / 

147
f/4 f/5.6 f/8 f/11 f/16 f/22
[f=24mm]
0.28
0.27 — 0.29 0.27 — 0.29 0.27 — 0.29 0.27 — 0.30 0.26 — 0.31 0.26 — 0.32
1/5.9
0.35
0.34 — 0.36 0.33 — 0.37 0.33 — 0.38 0.32 — 0.39 0.31 — 0.41 0.30 — 0.45
1/8.8
0.5
0.47 — 0.54 0.46 — 0.55 0.45 — 0.58 0.43 — 0.62 0.41 — 0.70 0.38 — 0.88
1/15.1

4.34 —  3.20 —  2.31 —  1.68 —  1.23 —  0.91 — 
1 / 
[f=28mm]
0.28
0.28 — 0.28 0.27 — 0.29 0.27 — 0.29 0.27 — 0.29 0.27 — 0.30 0.26 — 0.31
1/5.0
0.35
0.34 — 0.36 0.34 — 0.36 0.33 — 0.37 0.33 — 0.38 0.32 — 0.39 0.31 — 0.41
1/7.5
0.5
0.48 — 0.53 0.47 — 0.54 0.46 — 0.56 0.44 — 0.58 0.43 — 0.63 0.40 — 0.72
1/12.9

5.86 —  4.31 —  3.09 —  2.23 —  1.62 —  1.19 — 
1 / 
[f=35mm]
0.28
0.28 — 0.28 0.28 — 0.28 0.27 — 0.29 0.27 — 0.29 0.27 — 0.29 0.27 — 0.30
1/4.0
0.35
0.34 — 0.36 0.34 — 0.36 0.34 — 0.36 0.34 — 0.37 0.33 — 0.38 0.32 — 0.39
1/6.1
0.5
0.48 — 0.52 0.48 — 0.52 0.47 — 0.54 0.46 — 0.55 0.45 — 0.58 0.43 — 0.62
1/10.5

8.55 —  6.27 —  4.48 —  3.21 —  2.32 —  1.69 — 
1 / 

148
• IF（ニコン内焦）方式は、撮影距離が短くなるにしたがって焦点距離が短くなります。
• With the Nikon Internal Focusing (IF) system, as the shooting distance decreases, the focal length also
decreases.
• Beim System Internal Focusing (IF, interne Scharfeinstellung) von Nikon nimmt, wenn die
Aufnahmedistanz abnimmt, die Brennweite ebenfalls ab.
• Avec le système de mise au point interne Nikon (IF), si la distance de prise de vue diminue, la longueur
focale diminue également.
• Con el sistema de enfoque interno (IF) de Nikon, a medida que disminuye la distancia de disparo, lo
hace también la distancia focal.
• Med Nikons system för innerfokusering (IF), kommer även brännvidden att minska om
fotograferingsavståndet minskar.
•      (IF) Nikon,   
     .
• Met het Nikon Internal Focusing-systeem (IF) neemt de brandpuntafstand af naarmate de
opnameafstand afneemt.
• Con il sistema Nikon Internal Focusing (IF), la lunghezza focale diminuisce proporzionalmente alla
distanza di ripresa.
• U systému vnitřního ostření (IF) Nikon se při zmenšení vzdálenosti zaostření zmenší také ohnisková
vzdálenost.
• Vďaka systému vnútorného zaostrovania (IF) spoločnosti Nikon sa so znižovaním vzdialenosti snímania
zároveň znižuje aj ohnisková vzdialenosť.
• 内部对焦（IF）系统在近距离对焦时，焦距会稍微缩短。
• 內對焦（IF）系統隨著拍攝距離減小，焦距也會減小。
• ᘽ⌉G㊑⶙GⷹⶑOpmPG⡥⠭㛥ⳉG㊵⮊GᇹἵᆉG⽰⫍⽉´G㊑⶙Gᇹἵ᥍G⺍⬽᩶ᡑᡭU

149
Depth of field (ft.)
Shooting distance Depth of field Reproduction ratio
f/4 f/5.6 f/8 f/11 f/16 I
[f=16mm]
1
11-8/16 in.
—
1 ft. 10/16 in.
11-4/16 in.
—
1 ft. 13/16 in.
11-1/16 in.
—
1 ft. 1-5/16 in.
10-13/16 in.
—
1 ft. 2-1/16 in.
10-7/16 in.
—
1 ft. 3-8/16 in.
9-15/16 in.
—
1 ft. 6-6/16 in.
1/9.7
1.25
1 ft. 1-15/16 in.
—
1 ft. 4-5/16 in.
1 ft. 1-9/16 in.
—
1 ft. 5-1/16 in.
1 ft. 1-3/16 in.
—
1 ft. 6-2/16 in.
1 ft. 10/16 in.
—
1 ft. 8-3/16 in.
1 ft.
—
2 ft. 8/16 in.
11-3/16 in.
—
3 ft. 3 in.
1/14.3
2
1 ft. 8-6/16 in.
—
2 ft. 5-14/16 in.
1 ft. 7-7/16 in.
—
2 ft. 9-4/16 in.
1 ft. 6-2/16 in.
—
3 ft. 4-11/16 in.
1 ft. 4-11/16 in.
—
5 ft. 2-6/16 in.
1 ft. 3-4/16 in.
—
41 ft.
1 ft. 1-11/16 in.
—

1/28.2

6 ft. 11-14/16 in.
—

5 ft. 2-12/16 in.
—

3 ft. 10-1/16 in.
—

2 ft. 10-5/16 in.
—

2 ft. 2-1/16 in.
—

1 ft. 8-3/16 in.
—

1/ 
[f=20mm]
1
11-10/16 in.
—
1 ft. 8/16 in.
11-8/16 in.
—
1 ft. 10/16 in.
11-4/16 in.
—
1 ft. 15/16 in.
11-1/16 in.
—
1 ft. 1-7/16 in.
10-11/16 in.
—
1 ft. 2-3/16 in.
10-5/16 in.
—
1 ft. 3-10/16 in.
1/8.3
1.25
1 ft. 2-3/16 in.
—
1 ft. 3-15/16 in.
1 ft. 1-15/16 in.
—
1 ft. 4-5/16 in.
1 ft. 1-9/16 in.
—
1 ft. 5-1/16 in.
1 ft. 1- 1/16 in.
—
1 ft. 6-2/16 in.
1 ft. 10/16 in.
—
1 ft. 8-3/16 in.
11-14/16 in.
—
2 ft. 10/16 in.
1/12.1
2
1 ft. 9-6/16 in.
—
2 ft. 3-12/16 in.
1 ft. 8-8/16 in.
—
2 ft. 5-10/16 in.
1 ft. 7-7/16 in.
—
2 ft. 9-2/16 in.
1 ft. 6-4/16 in.
—
3 ft. 4-3/16 in.
1 ft. 4-13/16 in.
—
5 ft. 4/16 in.
1 ft. 3-4/16 in.
—
26 ft. 6-10/16 in.
1/23.5

10 ft. 8/16 in.
—

7 ft. 5-6/16 in.
—

5 ft. 4-15/16 in.
—

3 ft. 11-10/16 in.
—

2 ft. 11-6/16 in.
—

2 ft. 2-12/16 in.
—

1/ 

150
f/4 f/5.6 f/8 f/11 f/16 I
[f=24mm]
1
11-12/16 in.
—
1 ft. 6/16 in.
11-10/16 in.
—
1 ft. 8/16 in.
11-8/16 in.
—
1 ft. 10/16 in.
11-4/16 in.
—
1 ft. 15/16 in.
11-1/16 in.
—
1 ft. 1-7/16 in.
10-11/16 in.
—
1 ft. 2-4/16 in.
1/6.9
1.25
1 ft. 2-6/16 in.
—
1 ft. 3-10/16 in.
1 ft. 2-4/16 in.
—
1 ft. 3-15/16 in.
1 ft. 1-15/16 in.
—
1 ft. 4-5/16 in.
1 ft. 1- 9/16 in.
—
1 ft. 5-1/16 in.
1 ft. 1-1/16 in.
—
1 ft. 6-4/16 in.
1 ft. 10/16 in.
—
1 ft. 8-4/16in.
1/10.1
2
1 ft. 10-1/16 in.
—
2 ft. 2-8/16 in.
1 ft. 9-6/16 in.
—
2 ft. 3-10/16 in.
1 ft. 8-8/16 in.
—
2 ft. 5-8/16 in.
1 ft. 7-7/16 in.
—
2 ft. 9 in.
1 ft. 6-4/16 in.
—
3 ft. 4 -1/16 in.
1 ft. 4-13/16 in.
—
4 ft. 11-12/16in.
1/19.6

14 ft. 3 in.
—

10 ft. 6-2/16 in.
—

7 ft. 6-13/16 in.
—

5 ft. 6 in.
—

4 ft. 6/16 in.
—

2 ft. 11-14/16 in.
—

1/ 
[f=28mm]
1
11-12/16 in.
—
1 ft. 4/16 in.
11-12/16 in.
—
1 ft. 6/16 in.
11-10/16 in.
—
1 ft. 8/16 in.
11-6/16 in.
—
1 ft. 12/16 in.
11-4/16 in.
—
1 ft. 15/16 in.
11-1/16 in.
—
1 ft. 1-9/16 in.
1/5.9
1.25
1 ft. 2-8/16 in.
—
1 ft. 3-8/16 in.
1 ft. 2-6/16 in.
—
1 ft. 3-12/16 in.
1 ft. 2-3/16 in.
—
1 ft. 3-15/16 in.
1 ft. 1-15/16 in.
—
1 ft. 4-7/16 in.
1 ft. 1-9/16 in.
—
1 ft. 5-3/16 in.
1 ft. 1-1/16 in.
—
1 ft. 6-6/16in.
1/8.6
2
1 ft. 10-9/16 in.
—
2 ft. 1-13/16 in.
1 ft. 10-1/16 in.
—
2 ft. 2-8/16 in.
1 ft. 9-6/16 in.
—
2 ft. 3-13/16 in.
1 ft. 8-6/16 in.
—
2 ft. 5-14/16 in.
1 ft. 7-5/16 in.
—
2 ft. 9 -10/16 in.
1 ft. 6 in.
—
3 ft. 5-6/16in.
1/16.8

19 ft. 2-12/16 in.
—

14 ft. 1-11/16 in.
—

10 ft. 1-11/16 in.
—

7 ft. 3-13/16 in.
—

5 ft. 3-13/16 in.
—

3 ft. 10-15/16 in.
—

1/ 

151
f/4 f/5.6 f/8 f/11 f/16 I
[f=35mm]
1
11-14/16 in.
—
1 ft. 2/16 in.
11-12/16 in.
—
1 ft. 4/16 in.
11-12/16 in.
—
1 ft. 6/16 in.
11-10/16 in.
—
1 ft. 8/16 in.
11-8/16 in.
—
1 ft. 10/16 in.
11-4/16 in.
—
1 ft. 15/16 in.
1/4.7
1.25
1 ft. 2-12/16 in.
—
1 ft. 3-6/16 in.
1 ft. 2-10/16 in.
—
1 ft. 3-8/16 in.
1 ft. 2-6/16 in.
—
1 ft. 3-10/16 in.
1 ft. 2-4/16 in.
—
1 ft. 3-15/16 in.
1 ft. 1-15/16 in.
—
1 ft. 4-5/16 in.
1 ft. 1-9/16 in.
—
1 ft. 5-1/16in.
1/7
2
1 ft. 10-15/16 in.
—
2 ft. 1-3/16 in.
1 ft. 10-9/16 in.
—
2 ft. 1-11/16 in.
1 ft. 10-1/16 in.
—
2 ft. 2-6/16 in.
1 ft. 9-8/16 in.
—
2 ft. 3-10/16 in.
1 ft. 8-8/16 in.
—
2 ft. 5-8/16 in.
1 ft. 7-9/16 in.
—
2 ft. 9 in.
1/13.7

28 ft. 10/16 in.
—

20 ft. 6-13/16 in.
—

14 ft. 8-6/16 in.
—

10 ft. 6-10/16 in.
—

7 ft. 7-5/16 in.
—

5 ft. 6-6/16 in.
—

1/ 
• With the Nikon Internal Focusing (IF) system, as the shooting distance decreases, the focal length also
decreases.

Printed in Japan
© 2009 Nikon Corporation 7MAA63E3-03 SG01
TT0B03(E3)

CD
..
C
CD
"...
C0
~
..
CD
4)
en
C
~.=
-fi.
~
=
4)
Q.C
.. 0
=.
o
>
..
CD
..
en
.-
I:')
Q)
..
o
..
"'CS
u
en
•
..
C
..
=
..
CD
..
a::
=
• 0
0
...
o
CD
en
c:
Q)
cC
~I=
CD
~
C
CD
o>
I-
•
LL.
(I»
•
..
en
~
..
-
ca
--
0-
" 0 •
".c
u
ca
CD
en
..
-
-
e
o
1-
~
o
u
•
..
II)
1;)
1-
m
t»
o
..
Q.
I
...
'"
Q)
e
I-
e
o
..
Q)
...
en
••
m
Q)
II:

_lJwunl.l,lluaUUIJ; IlllMellASl_' I~_. l't!aOlASf.ll OOI'OT t~'HA.-.a;C1t .... "C£SOl''''''''''I>I<J ~"_
~""" ... M"""""IJ_("EMnood'-oII._ •• _" __ f.\lSQl IOd"-""~_I~""""~_
l"" _"WJ.J(lI);.f"" lnI UJIDOl S--",, __ ...,;n~. ILW .... EO.$T., _~ 11,:tIOl .. II .. ,.... UT f_
loI' _.I·,'· .......... .-_·_OIJ'-.lJ.COd<'...,""_"SIOOJlOOOO'.A...,Vrood .....
.. __ ......... 0 _ITlIIl.Il, DqL Th't. 0.-. CD 102".Jl)j, __ ._ .... _~JI,:tIOlood __ .. _ ...
_-..~ __ oc...,.-_.....-lat_ ....... __ A' __ ............. ..-_'I
llllI Odolo .. _olt,-d ...... __ .. _...,.,_llp<oo US _ .. _ •• _. EI>lS _
r-l)l_,_ .. _, .. _ ....... _lIodlol'otmfoeol .. "" _e.... ._ood
~_ .. .........,._-..4o)'> .. oouIIaooooo .. _l'""f"C"~ __ ,_If .... nf><lOfJ_,~ """' _ .... -..
_._ ....... ..- ..-_ ................. ~_Bl __ ·_, __ _
_ ~f .. _ "" .A~ _""..-.J .. OlS 10<_ ... "'_ .. ..,._--., ..
___ .. _ ... __ wiII _IOIoo _ ... ·__ Ioo_.,_"""" ......... ""
._ ... __ - '_ .. ooId)-....r.. .._ -... _Io< ""'" EMS "" ...... <o><I'<CI_ .. ........-
_~QIl .. _ .. _..., __ loI' .... fot __ ...... ·_..-.. "'oo,QXlOO~A..., \"1- .• 0 &10
l1J1 'l. 0..-. 00 .:l.lIT,JU'
,.
Mr.
,.
1 •.
TNR01-01
~lrst Na .... Inillrol l.a .. Name
..
Apl. No.
Clly Stalc ZU'Code
E·...,.U Add,.,.:
,'our dal~ Ql"blrlh:
Marital sIan ...:
I
Moolh
"""'"
Register ONLINE at
www.prodregister.comlnikon
I
Moolh Do,
I
Serial num~"
Modtl numbtr:
PItas. Indiealt l~ Nlkon ""Unt'nl lhls ~essory ,,'W be ustd ,,·ith.
Cam~n1 modtl:
(;amtno modtl:
llraltr natnC':
,vOl i~lud,·ng yourstlf • ..-halls Iht GENOER and ACt: (in
)'u.,) or child .. ," an<! other adulls H"lng in )'our housthold?
INo one tl'" In hou"'hold 2. 0Child under 1year
Male
t'tlnalt AlI:t Male .'emale AI:"
o.
,0
o. 2.
'0
yo.
0
,.
Co
,.
0
,B. ,B.
..
\Vhalls lour l~"tl otpholognlphk uptf"itna?
I. 0Resinner 3Advanced """'ltUr
2. Arnaleur 4. 0Profess,onal
Who or "hal W2i\lnnlltn«d lhi~ purehase?
I0Dealer 6. TV ad
2. A pofCSStOnal 7. 0Doaler/Slorc ad
3. 0FrielldIRel1ll"'e g. N.koo rnaga1Jnead
4. 0PrcVIOUSUpenencc 9MagWn<:artJck
wlNikoo LO. O<her
5. Nikon ...-pul8l1on
110"- "ill )'OU U'lt Ihls produ""? (chert ""I.I'Qlle}
ICommerclaU 4. 0Creallvelllobby
IndllsoriallGovemmenl 5. Famllyffn
... c:l
2. 0Scient,fic/Medical 6, 0SponIOutdoor-s
3. 0 1'1Io<0 JOUl'lUllism 7, O<.bcr
Whal ... lttr products do )'ou o..-n or Inl~nd 10 purehast?
CUfTf'ntly Inltnd 10
o..·n pureh .....
.00
s_
o.
2.
3.
..
3
6
S""~
,
,.
J
•,
3r
6
1
unloftdu""Ii(ln: {cliff! highe511nel compIeudJ
l. 0Complete<! High School
2. _Completed Calk:&<:
3 0 Completed Graduale School
Whl~h e"""il card>' do )'00...., f\'Jlularly?
I0AtntI'ican ExpreM. Di""rs Club
2. 0MasoerCard.
ViSll, Disco,'~r
3. Dop.>rtn\Cnl Slore. 011 Com!»"y. etc.
4. Do "'" uSC ~tl cards
For four primary rtSlden«, do )'00:
I. 0Own?
2. Renl~
l'ltase ItUllS ho .... many magaUr>eI)'our housf/lold:
A. 8. l'tareh_ al
Subscribes to SIO~t"SSlllnds
l. 01-3pcrmomh 1-3ptfmonth
2. 04+ pcr month 2. 4+ per month
Which or Ihe rollo,,'lng do )'OU plan to do wilhln Ihe nUl
6orI2""llllhs? l.fi 7-12
Monll<! MOfIlh$
OuylLeasc: a Ne..- Vehicle l.
8uy/l.case a Usc<l Veh.cle.. 2•
o.,cupallon: (cud wi rhal "1'pM VIMJ
Profess'ooaVTed"'ical ..
UJIP"r M"""gcmemlE.1ccuu,'c ..
Middle Managcmenl
SaI."..fM:rrI<e<ing .
Clc:ncI1lS<:rvicc Worker
Tradesman/Machin<: OpcratarlLabon:r..
Art )'00 or )'oor s~: \'ou
AHomcnlalcr? ..
Rctlred1.
A SIOOcnl? ..
SclfEmployedlBusintSS Owner" [
Warkln& from a
1·lonlC Office?..
In tit<: Military'.
AVe<eran'
WlU<:h group dts<:rlbQ )'our an"ual ramH)' llOWlIlt?
01 0Under$15.000 08. $75.00}-$99.m
02.
SI5.QOO-SI9.999 09 SJ/lO.ooo.SI24.999
03. 0$20.000.S29.999
10. 0$12'i.ooo.SI49.999
04. 0S3O.000.539.999 II 5150.000.5174.999
05. S40.Q00-S49,999
12. 517S.000.S199.999
06. 0 SSO.00}-$S9.999 13. 0$200.000.$249.999
07. $60.000-574.999
14 05250.000 &. mer
o
o
,.
2.
,.
•
,
6.
1
Mllilortltr
Catalos
shQ .... room
Via
the Intcmc:.
E1cctroni", SI<lfl:
""'"
O;gual Came" ..
Digtlal SLR Camel1l 0
Film SLR Camera ..
Compact Came".. 0
Film Scan"", ,.
Color l'rmler .. .. ..
Lens..
Prlct Ilald: (uciudinll<U) $
Whut..-"5 Ihls pro:>dl>tt purehastd?
I 0 Rt=ivedll5agifl 5. 0
2. CamerISIOfe 6. 'l
3. 0Discount SIOfe (leman. 7.
WaI·m.:lrt. tIC.) 8, 0
4. Dcpanmenl $IOfe 9.
