Nikon D200 Operating instructions

INC
作成承認印 配布許可印
VBA13001-R.3677.A
VBA13001
Copyrigh ｃ2005 by Nikon Corporation.
All Rights Reserved.
無断転載を禁ず !!
Printed in Japan November 2005
Recycled paper
再生紙を使用しています
REPAIR MANUAL
Ｍ
サービス
計画課

INC
VBA13001-R.3677..A
- Ｍ1 ･ -
Q0220ｸﾞﾗﾌｨｯｸ用ロゴ
050808_デザイン部伊藤
Specications
Type Single-lens reex digital camera with interchangeable lenses
Effective pixels 10.2 million
LBCAST image sensor 23.6× 15.8 mm; total pixels: 10.92 million
Image size (pixels) 3872× 2592 (L), 2896× 1944 (M), 1936× 1296 (S)
Lens mount Nikon F mount (with AF coupling and AF contacts)
Compatible lenses
Type G or D AF Nikkor All functions supported (except IX Nikkor)
Micro Nikkor 85 mm F2.8D All functions supported except autofocus and some exposure modes
Other AF Nikkor All functions supported except 3D color matrix metering Ⅱand 3D multi-sensor
balanced ll-ash for digital SLR
AI-P Nikkor All functions supported except 3D color matrix metering Ⅱ, 3D multi-sensor
balanced ll-ash for digital SLR, and autofocus
Non-CPU Can be used in exposure modes A and M; electronic range nder can be used if
maximum aperture is f/5.6 or faster; color matrix metering, multi-sensor balanced
ll-ash for digital SLR, and aperture value display supported if user provides lens
data (Non-Ai lens cannot be used.)
Picture angle Equivalent in 35-mm format is approximately 1.5 times lens focal length
Viewnder Fixed eyelevel pentaprism
Diopter adjustment －2～＋ 1 m
－ 1
Eyepoint 19.5 mm (-1.0 m
－ 1
)
Focusing screen Type B BriteView clear matte screen Mark Ⅱ provided (Focus frame; grid line
display for composition）
Frame coverage Approximately 95% of lens (vertical and horizontal)
Magnication Approximately 0.94× (50-mm F1.4 lens at innity; -1.0 m
－ 1
)
Reex mirror Quick return
Lens aperture Instant return with depth-of-eld preview

INC
VBA13001-R.3677..A
- Ｍ2 ･ -
Q0220ｸﾞﾗﾌｨｯｸ用ロゴ
050808_デザイン部伊藤
Focus-area selection Normal frame (11 focus areas): Single area or group can be selected from 11 focus areas
Wide frame (7 focus areas): Single area can be selected from 7 focus areas
Lens servo Instant single-servo AF (S); continuous-servo AF (C); manual (M); predictive focus tracking
automatically activated according to subject status in continuous-servo AF (C)
Autofocus TTL phase detection by Nikon Multi-CAM2000 autofocus module
Detection range -1- +19 EV (ISO 100, room temperature 20 °C/68 °F)
AF-area mode Single-area AF, dynamic-area AF, group dynamic-AF, dynamic-area AF with closest subject
priority
Focus lock Focus can be locked by pressing shutter-release button half-way (single-servo AF) or by
pressing AE-L/AF-L button
Exposure
Metering Three-mode through-the-lens (TTL) exposure metering
Matrix 3D color matrix metering Ⅱsupported with type G and D lenses; color matrix metering Ⅱ
available with other CPU lenses; and color matrix metering available with non-CPU lenses if
user provides lens data
Center-weighted Weight of 75% given to 6, 8, 10, or 13-mm circle in center of frame, or weighting based on
average of entire frame
Spot Meters 3-mm circle (about 2% of frame); metered area linked to selected focus area (with
non-CPU lens, xed in center)
Range EV0 ～ 20 (3D color matrix or center weighted metering）
EV2 ～ 20 (spot metering）
（ISO 100 equivalent, f/1.4 lens, 20℃/68°F）
Exposure meter coupling Combined CPU and AI
Exposure modes Programmed auto with exible program; shutter-priority auto; aperture priority auto; manual
Exposure compensation ±5EV in increments of 1/3, 1/2, or 1 EV
Bracketing Exposure and/or ash bracketing (2-9 exposures in increments of 1/3, 1/2, 2/3, or 1EV)
WB (2-9 exposures in increments of 1- 3EV)
Exposure lock Luminosity locked at detected value with AE-L/AF-L button
Shutter Electronically-controlled vertical-travel focal-plane shutter
Speed 30- 1/8000 in steps of 1/3, 1/2, or 1EV, bulb
Sensitivity 100 -1600 (in steps of 1/3, 1/2, or 1EV), auto gain to ISO 1600 equivalent
White balance Auto (TTL white-balance control with 1,005 pixels RGB sensor), six manual modes with
ne-tuning, color temperature setting, preset, white balance bracketing
Built-in Speedlight Pop-up Speedlight with button release
Guide number (at 20°
C/68°F)
ISO 100: approximately 12 (Manual full-ash: approx. 13)

INC
VBA13001-R.3677..A
- Ｍ3 ･ -
Q0220ｸﾞﾗﾌｨｯｸ用ロゴ
050808_デザイン部伊藤
Flash
Sync contact X-contact only; ash synchronization at up to 1/250 s
Flash control TTL ash control by 1005-segment RGB sensor:
- i-TTL balanced ll-ash for digital SLR (built in Speedlight or SB-800/SB-600 with other
meterings than spot metering)
- Standard i-TTL balanced ll-ash for digital SLR (built in Speedlight or SB-800/SB-600
with spot metering)
(Can be set on speedlight when SB-800/SB-600 is used)
Auto aperture is available with CPU lenses and SB-800
Non-TTL auto is available with SB-800, SB-80DX,SB-28DX, SB-27, SB-22S, etc
Range-priority manual is available with SB-800
Sync modes Front curtain sync (normal), slow sync, rear-curtain sync, red-eye reduction, red-eye
reduction with slow sync
Flash-ready indicator Lights when B-800, SB-600, SB-80DX, SB-28DX, SB-50DX, SB-28, SB-27, B-22S, etc,
is fully charged; blinks for 3 sec. after ash is red at full output
Accessory shoe Standard ISO hot-she contact with safety lock
Creative Lighting System - with SB-800, SB-600, or SB-R200, supports Advanced Wireless Lighting (with SB-600
and SB-R200, remote only)
Setting Comand mode can control built-in Speedlight as Master ash
- Supports Auto FP High-Speed Sync, Flash Color Information Communication, modeling
illumination, and FV lock

INC
VBA13001-R.3677..A
- Ｍ4 ･ -
Q0220ｸﾞﾗﾌｨｯｸ用ロゴ
050808_デザイン部伊藤
Storage
Media Type I and II CompactFlash memory cards; Microdrives
File system Compliant with DCF2.0 (Design Rule for Camera File Systems) and DPOF (Digital Print
Order Format)
Compression - Compressed NEF (RAW): 12-bit (about 50％～ 60％) compression
- JPEG baseline-compliant (size priority, image priority can be selected)
Self-timer Electronically controlled timer with 2, 5, 10, and 20 sec. duration
Depth-of-eld preview Lens aperture stopped down when depth-of-eld preview button is pressed.
Stopped down up to set aperture value with A・M mode; up to control aperture value with P・S
mode.
Monitor 2.5”, 230,000-dot, low-temperature polysilicon TFT LCD with brightness adjustment
Video output Can be selected from NTSC and PAL
External interface USB 2.0 Hi-Speed
Tripod socket 1/4 (ISO 1222)
Firmware updates Can be updated by users
Language German, English, Spanish, French, Korean, Italian, Dutch, Portuguese, Russian, Swedish,
simplied Chinese, and Japanese
Power source - One rechargeable Nikon EN-EL3e lithium-ion battery
Voltage 7.4V DC［Quick charger MH-18a］is used
- MB-D200 multi-power battery pack (available separately) with one or two rechargeable
Nikon EN-EL3e lithium-ion batteries or six (LR6 (AA) alkaline, ZR6 nickel-manganese, or
HR6 nickel-metal-hydride) batteries
- EH-6 AC adapter (available separately)
Dimensions
（W× H×D）
Approximately 147×113× 74 mm
Weight Approximately 830g without battery, memory card, body cap, or LCD monitor cover
Operating environment
Temperature 0 ～ 40℃
Humidity Less than 85％ (no condensation)
● Unless otherwise stated, all gures are for a camera with a fully-charged battery operating at an ambient temperature of 20°C (68°
F).
● Nikon reserves the right to change the specications of the hardware and software described this manual at any time without prior
notice. Nikon will not be held liable for damages that may result from any mistakes that this manual may contain.

INC
- Ｄ1 ･ -
VBA13001-R.3677.A
Points to notice for Disassembly and Assembly
�
内部に高電圧部あり。カバーを外す時は感電に注意すること。
カバーを外した後は、修理指針の指示に従ってメインコンデン
サーの放電を必ず行うこと。
警告
Caution:
① In disassembly/(re)assembly, be sure to use conductive mat (J5033) and wrist strap (J5033-5), in
order to protect electric parts from static electricity.
② Before disassembling, be sure to remove batteries or AC power cord.
③ In disassembling, be sure to memorize the processing state of wires and FPC, screws to be xed and
their types, etc.
④ The low-pass lter of the image PCB is easily damaged. Handle it very carefully.
Points to notice for Lead-free solder products
・Lead-free solder is used for this product.
・For soldering work, the special solder and soldering iron are required.
・Do NOT mix up lead-free solder with traditional solder.
Caution:
When "Separation of Front body from Rear body", "Disassembly of CCD/FPC unit" and
"Disassembly of Bayonet" are performed, be sure to carry out "RESET AF-DEFOCUS
COMPENSATION" of the D200 adjustment software after assembly.
WARNING
Take extra care not to get an electric shock when detaching
covers.
After removing covers, be sure to discharge the main
condenser according to the instructions of repair manuals.

INC
- Ｄ2 ･ -
VBA13001-R.3677.A
Disassembly
1. Separate Front and Rear bodies
External rubber
WB
QUAR
ISO
#B60
#B447 #B61
#B63
･ Remove the external rubbers
(#B63,#B60,#B61,and #B447).
Bottom cover
･ Remove the battery lid (by tilting and pulling it).
･ Take out two screws (#1556), six screws (#1549) and two screws (#1547).
･ Remove the bottom cover. #1547
#1549×6
#1556
Bottom cover
#1556
#1547

INC
- Ｄ3 ･ -
VBA13001-R.3677.A
・ Remove the three TFT-PCB connection FPCs from the connector.
Rear cover
・ Take out two screws (#1552), two screws (#1547) and one screw (#1549).
・ Remove the rear cover.
#1552×2 #1547×2
#1549
・ Be careful NOT to cut the TFT-PCB connection
FPC that is at the lower side of the rear cover.

INC
- Ｄ4 ･ -
VBA13001-R.3677.A
Discharge of Main condenser
・ Discharge the main condenser .
�
内部に高電圧部あり。カバーを外す時は感電に注意すること。
カバーを外した後は、修理指針の指示に従ってメインコンデン
サーの放電を必ず行うこと。
警告
I/F cover
#1549×2
・ Take out two screws (#1549).
・ Remove the I/F cover unit.
#969
#969
#393
#395
#962×3
#965 #1643
#1642×2
#392
#394
WARNING
Take extra care not to get an electric shock when
detaching covers.
After removing covers, be sure to discharge the main
condenser according to the instructions of repair manuals.
２ＫΩ / ５Ｗ

INC
- Ｄ5 ･ -
VBA13001-R.3677.A
#426
#455
#467
#1538 × 2
#469
#468
#481
#474
#476
#986
#985
#924
#1631
#465
#1511 × 2
#1630
#479
#477
#478
#456
#1511 × 2
#1020
#1512 × 3
#422
#472
#473
#470
#430
#480
#RP00007
Disassemble Rear Cover

INC
- Ｄ6 ･ -
VBA13001-R.3677.A
#431
#433
#488
#489
#1629
#434 × 2
#435 × 2
#1057
#1626
#1633
#432
#487
#492 #484 #483 × 2
#485
#1546
#491
#1571
#987
#922
#441
#443
#923
#442
#1628 × 2
#424
#921
#425
#1518 × 2
#486
#440
#1632 × 2
#427
#445
#429
#423

INC
- Ｄ7 ･ -
VBA13001-R.3677.A
Soldering bridge
#1515
#1515
#1546×5
・ Take out ve screws (#1546) and two screws (#1515).
・ Remove the soldering bridge.
・ Remove the DG shield plate unit (#683, #696).
DG shield plate unit
DG-PCB unit
・ Remove the tape (#926).
・ Remove ve FPCs from the connector.
・ Remove the two harnesses from the
connector.
・ Unsolder the four wires.
・ Remove the DG-PCB unit (#B1017).
#B1017 DG-PCB unit
Harness
Harness
DG shield plate
#926
1040
#926

INC
- Ｄ8 ･ -
VBA13001-R.3677.A
・ Take out three screws (#1639) and remove the CCD/FPC unit (#B2032).
・ Take out three screws (#1543) and remove the CF card holder (#1018).
CCD/FPC unit
CF card holder
#1639×3
#B2032 CCD/FPC unit
#1543×3
#1018
CF card holder
・ Take out the screw (#1539) and remove the conductive plate (#691).
・ Take out four screws (#1539) and remove the conductive plates (#689, #690,and #688).
・ Remove the main connection FPC (#1035) from the connector of the power drive PCB (#1002).
#1543
Conductive plate
(#691)
Power drive PCB (#1002)
Conductive plate
(#689)
Conductive plate
(#690)
#1539
Conductive
plate (#688)
#1539
#1539
Ｍ
サービス
計画課
JUL.7.2006
Change page △×1
△(Addition）
#1539
△(Revice）
#1539

INC
- Ｄ9 ･ -
VBA13001-R.3677.A
・ Unsolder six wires.
・ Remove the harness of the back of the power drive PCB.
・ Take out two screws (#1541) and remove the power drive PCB.
Power drive PCB
#1075
Harness: DC/DC PCB
Power drive PCB (#1002)
Yellow: Main-PCB
Brown: Main-PCB
Blue:AF motor
Orange:AF motor
Red: Charge motor
Black: Charge motor
#1541
#1541

INC
- Ｄ10 ･ -
VBA13001-R.3677.A
DC/DC PCB unit
・ Unsolder six wires.
・ Take out four screws (#1541) of the DC/DC-PCB (#1047).
・ Remove the harness (#1074) from the DC/DC-PCB (#1047).
・ Remove the harness (#1075) from the DC/DC-PCB (#1047) and from the connector of the power drive PCB
(#1002).
Harness: DG-PCB
#1074
Harness: Power drive PCB
#1075
Ｍ
サービス
計画課
JUL.7.2006
Change page △×1
Black: Battery contact
Red: Battery contact
Yellow:SBDI-PCB
Brown: SBDI-PCB
Red: IF-PCB
Black: IF-PCB
#1541
#1541
#1541
#1541
△(Addition）
#1047

INC
- Ｄ11 ･ -
VBA13001-R.3677.A
Top cover
・ Remove the tape (#930).
・ Unsolder four wires.
・ Remove the top cover FPC (#1003) from the connector.
#1547
#1547
#1555
#1555
#1511
#1511
・ Remove the cover (#850). Take out the screw (#1622) , and
remove the diopter adjustment knob unit (#852, #857, #851).
・ Pop the SB up, and take out two screws (#1548).
・ Take out two screws (#1511), two screws (#1547) and two
screws (#1555).
・ Lift the top cover unit slowly not to cut the FPC.
#1548×2
Pop this up.
Tape (#930) Red: SB-PCB
Brown: SB-PCB
Yellow: SB-PCB
Black: SB-PCB
#1622
#852
#857
#851 #850
#1555
Ｍ
サービス
計画課
JUL.7.2006
Change page △×1
△(Addition）
#1003

INC
- Ｄ12 ･ -
VBA13001-R.3677.A
SB upper case
Disassembly of Top cover unit
・ Push the pop-up lever A-part of the top cover unit, and lift the built-in SB.
・ Take out two screws (#1623). (Fig.1)
・ Fold down #301 of the SB lower case on the top cover. Then while holding the hooks of the SB upper case
from both sides by hand, release them from the two holes by sliding/tilting, then remove #301. (Fig.2）
Pop-up lever A-part
Push
#1623×2
Fig.1
SB lower case unit
SB upper case
Fig.2
Holes
Hooks
#301
SB lock cover
#310
#312
#1565
#309
#917C
・ Remove the spring (#310).
・ #309 comes off.

INC
- Ｄ13 ･ -
VBA13001-R.3677.A
Removal of Top cover FPC / Wires / SB-PCB
・ Unsolder the three metering mode FPC lead wires.
・ Unsolder the accessory shoe contact at four locations.
・ Unsolder the seven lead wires of the SB-PCB.
・ Take out the screw (#1601).
・ Remove the FPC of SB-PCB (#B1013).
・ Take out the screw (#1511).
・ Take out the screw (#1535).
・ Take out the screw (#1541).
Metering mode FPC lead wire
Red×1, Brown×1, Black×1
Red, Brown, Black △(Revice）
Accessory shoe contact×4
#1541
#1535
#1511
FPC #B1013
#1601
SB(Black)
SB(Gray)
SB (Green)
SB(Red)
SB(White)
SB(Orange)
Sync terminal(Green)
Ｍ
サービス
計画課
JUL.7.2006
Change page △× 2
△(Addition）
・It demounts tapes.

INC
- Ｄ14 ･ -
VBA13001-R.3677.A
・ Pull each wire from the holes.
・ While releasing the two hooks of the collar (#308), remove #308.
・ Remove the rotation axes (#306 and #307).
・ Remove the SB lower case unit (#B302) from the top cover.
・ Remove the SB-up spring (#305) from the hooking part.
・ Take out the screw (#1601) and remove the SB-up spring (#305).
・ Remove #796, #322, and #325.
SB-up spring
SB lower case unit
#305
Hooking part
#796
#325
#322
#796
#306
#308
#307
#B302
Be careful of the direction of assembling.
Pull six wires out from the holes.
Hooks
#1601
#305
Ｍ
サービス
計画課
JUL.7.2006
Change page △× 1
△(Revise）
#796×2

INC
-
Ｄ15
･
-
VBA13001-R.3677.A
M/DFPC unit
・
Remove the FPC soldering bridges of #1025 and #1026.
・
Take out the screw (#1569).
・
Detach #1025 from the bosses.
・
Unsolder the lead wire (#1094).
・
Remove the solder of the lead wire (#1094).
・
Lift the FPC, and take out the screw (#1572).
・
Remove B502 and B504 (Trefoil button unit).
Soldering
bridge
#1026
#1569
#1569
Boss
#1025
#1094 Green
#1094 Green
Trefoil button unit
Screw (#1572)
Use the Hexagonal wrench
of 5-mm diameter
#B502
#509
#B505
#50
#B43
#1532
#1572
#46
#46
#1569
#513
#508
#510
#1544×2
QUAR
ISO
#1569
#1569
#B504
1026FPC
1025FPC
#514
#515
※
When removing the solder
on the synchro-terminal
unit, unsolder within 2 sec.
△ (Addition）
Changed page △×2
△ (Addition）
Ｍ
サービス
計画課
Aug.8.2006
