Nikro PS2009 User manual

PORTABLE
POLY AIR SCRUBBER
MODEL #PS2009
INSTRUCTION MANUAL

2
RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY
Unit must be electrically grounded.
Do not use an adapter.
Plug into matching three-pronged GFCI receptacle only.
Do not operate in standing water.
If electrical components become wet, allow to dry completely before using.
Unplug unit before performing any maintenance, filter changes or cleaning.
Inspect cord and plug for damage before use.
Do not touch cord with wet hands or while standing on wet surface.
Do not operate in flammable or explosive areas.
Do not clean unit while plugged in.’
This unit has been designed for indoor use only.
Do not use to exhaust hazardous or explosive materials or vapors
IMPORTANT SAFETY INSTRUCTIONS
a. “Do not operate any unit with a damaged cord or plug. Discard unit or return it to an authorized service
facility for examination and/or repair.”
b. “Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings.
c. Arrange cord away from traffic area and where it will not be tripped over.”
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
“READ AND SAVE THESE INSTRUCTIONS”
RISK OF ELECTRIC SHOCK CAN CAUSE
INJURY OR DEATH.
UNPLUG UNIT BEFORE SERVICING.
TO REDUCE THE RISK OF ELECTRIC SHOCK:
CONNECT TO A GFCI OUTLET, DO NOT USE
AN EXTENSION CORD.

3
All Nikro Industries Inc. products that have rated efficiencies of 99.97% @ 0.3 microns
and/or 99.99% @ 0.3 microns, have H.E.P.A. filters that have been individually tested to
meet these minimum efficiencies.
Although all the filters have been pre-tested, the possibility of leaks or filter failure due to
handling, transportation, punctures, loaded filters, moisture, wear and tear, etc., does
exist.
Therefore, when using this equipment in highly sensitive areas or where any release of
particles above and beyond the minimum efficiencies would be detrimental and harmful
to humans, plants or property; it is strongly recommended that the units be individually
tested prior to their use.
This is to assure that they are maintaining the efficiency levels, which they were designed
to filter out.
FAILURE TO DO SO COULD RESULT IN SERIOUS HARM TO HUMAN LIFE, PLANT
LIFE AND/OR PROPERTY.
BACKDRAFTING AND CARBON MONOXIDE FUMES
To prevent the backdrafting of deadly carbon monoxide, when using your portable air
scrubber to create a negative pressure in a containment area, turn off all open
combustion devices such as but not limited to fireplaces, hot water heaters, furnaces,
boilers etc.
1115 N. Ellsworth Ave., Villa Park, IL 60181
Telephone: [phone] FAX: [phone] Toll Free: 800-875-6457

4
Your #PS2009 Poly Air Scrubbing System has been thoroughly tested and inspected at the factory and is fully assembled
and ready for use. However, prior to plugging the unit in, inspect it for any damage that may have incurred during
shipping. Inspect and tighten the HEPA filter hold down nuts, which may have loosened during transportation.
ELECTRICAL RATING:
115V 10 Amps 60 HZ
FILTER SET-UP PROCEDURES
The Model #PS2009 Air Cleaning unit is equipped with three stages of filtration as follows:
#550047 1" Polyester Filter Pad (1ST Stage)
#550048 2" Pleated Filter (2nd Stage)
#550046 H.E.P.A. Filter (99.97% efficient @ 0.3 microns) (Final Stage)
The H.E.P.A. Filter is held in place by 4 nuts and 2 – hold down brackets.
Slide the brackets over the threaded mounting studs located on the inside
of the housing. Thread the nuts over the bracket and tighten securely with
a 7/16” wrench. Be sure these nuts & brackets are always tightened
securely on the frame of the HEPA filter to guarantee a tight seal with the
H.E.P.A. Filter and the filter frame of the unit. The air flow arrows on this
filter should always be directed towards the motor and blower assembly.
Always turn off and unplug unit when removing or replacing the H.E.P.A.
filter. (See Photo 1)
The 2" Pleated Filter should be set in front of the H.E.P.A. Filter. The air
flow arrows on this filter should always be directed towards the H.E.P.A.
Filter. (See Photo 2)
The 1" Polyester Filter Pad should be placed in the door frame of the unit.
Close the hinged door of the unit and snap the latches into the locked
position...Unit is ready for use. (See Photo 3 & 4)
An optional Carbon Filter can be used to help control odors.
Simply replace the #550048 – 2” Pleated Filter with #860887 – 2” Carbon
Filter (sold separately).
FILTER MAINTENANCE
When performing filter maintenance always wear proper personal protective equipment and clothing. Always follow safe
working practices including proper disposal and handling of used filters in accordance with all federal, state and local
regulations.
The model #PS2009 Air Cleaning unit is equipped with a Filter-Monitor gauge. This gauge is located on the control panel
of the unit. When gauge reads 1.75" or higher, filter maintenance is required and the following steps should be taken:
1. Change the 1" Polyester Filter pad (this filter cannot be cleaned or reused. Dispose of Properly)
2. Close cabinet door and turn unit on.. If gauge continues to read 1.75" or higher go to step #3
3. Change the 2" Pleated Filter (this filter cannot be cleaned or reused. Dispose of Properly)
4. Close cabinet door with all filters in proper position. Turn unit on. If gauge continues to read 1.75” or higher, the
H.E.P.A. Filter must be replaced. (This filter cannot be cleaned or reused. Dispose of Properly)
NOTE: FILTERS SHOULD BE REPLACED IMMEDIATELY IF TORN OR DAMAGED.
USE OF ANY OTHER FILTERS THAN ORIGINAL NIKRO REPLACEMENT PARTS VOIDS THE PRODUCT
WARRANTY AND PERFORMANCE CLAIMS
TO AVOID CROSS CONTAMINATION CHANGE ALL FILTERS AFTER EVERY REMEDIATION JOB AND CLEAN
ENTIRE UNIT THOROUGHLY BEFORE REMOVING IT FROM THE CONTAINMENT AREA.

5
BEFORE OPERATING THE UNIT
1. Inspect cord and plug for damage.
2. Visually inspect the HEPA Filter for damage, punctures or tears. If you are operating in or exhausting into a highly
sensitive area it is strongly recommended that this unit is independently tested to assure proper filtration
efficiencies.
3. Inspect and tighten HEPA the filter hold down nuts, which may have loosened during transportation of the unit.
TRANSPORTING AND STORING UNIT
1. Always handle this unit with care. Rough handling such as dropping, or tipping over the unit, bouncing around in a
vehicle, and impact from rolling over or off of curbs, stairs and other platforms, could cause serious damage to
this unit.
2. Always clean and decontaminate unit before storing it. Store this unit indoors in a dry location.
TROUBLE SHOOTING
PROBLEM
Machine will not start
Machine will not run
continuously
POSSBILE CAUSE
Power cord unplugged
Blown or tripped circuit breaker
Tripped thermal protector on
motor
Not enough amperage
Extension cord too long or
inappropriate gauge.
REMEDY
Plug cord into outlet
Replace/reset building fuse or
breaker
Turn off unit and let cool for
A
pproximately 20 minutes, then
back on.
Use a larger circuit or remove
other appliances from circuit
Use a 12 gauge extension cord
Maximum length 50’
CLEAN AIR EXHAUST DISCHARGE
This portable air scrubber allows the operator to connect a 12”
exhaust hose to the unit allowing for remote or controlled exhausting
and/or to create a controlled negative pressure in a contained area.
Simply connect a 12” hose (#860243) to the 12” exhaust flange
located on the back/exhaust end of unit and extend the hose to the
desired area you wish to exhaust to.

6
#PS2009 ASSEMBLY
#862599 BLOWER ASSEMBLY
PC NO PART NO PART NAME QTY
1 860726 STRIKE 2
2 862096 DOOR 1
3 862442 DOOR GASKET 1
4 550047 FILTER PAD 1
5 550048 PLEATED FILTER 1
6 862062 HEPA HOLD DOWN BRACKET 2
7 550046 HEPA FILTER 1
8 862599 BLOWER ASSEMBLY 1
9 860725 LATCH 2
10 860724 HANDLE 4
11 862243 FIXED WHEEL 2
12 862244 LOCKING CASTER 2
13 860941 CORD STRAIN RELIEF 1
14 520010 ELECTRICAL CORD 1
15 860402-PS CONTROL PANEL 1
16 861839 CABINET 1
PC NO PART NO PART NAME QTY
1 861837 MOTOR 1
2 862026 MOTOR BRACKET 1
3 862132 CAPACITOR BRACKET 1
4 861392 CAPACITOR 1
5 862131 BLOWER LEG LEFT 1
6 861296 BLOWER 1
7 862130 BLOWER LEG RIGHT 1
862599 BLOWER ASSEMBLY COMPLETE

7
CONTROL PANEL
#PS2009 WIRING DIAGRAM
PC
NO PART NO PART NAME QTY
1 861853 THREE WAY SWITCH 1
2 860699 FILTER MONITOR
GAUGE 1
3 861854 CIRCUIT BREAKER 1
4 860954 HOUR METER 1
5 860721 GAUGE RELIEF BARB 1

8
WARRANTY
Nikro Air Scrubbers are warranted for 1 year from the date delivered to the original end
user and may not be assigned or transferred.
Parts, which become defective due to faulty workmanship or materials during normal
use in this period will be repaired or exchanged at no charge if returned and approved
by an authorized Nikro service center. All replaced or repaired parts shall only be
warranted for the remainder of the original one year warranty period.
After the expiration of the one year warranty, all warranties on this unit including fitness
for a proposed usage or purpose will become void.
The end user shall be responsible for freight charges incurred to deliver warranted
product to an approved Nikro service center. Nikro shall be responsible for freight
charges incurred in returning unit to customer, but not to exceed the original freight
charges to customer.
It shall be wholly Nikro’s decision to repair, replace or refund the purchase price of any
such defective goods.
This warranty does not apply to normal wear and tear, neglect, misuse, abuse or
incorrect installation. If any other replacement parts, filters or attachments are used
other than original Nikro parts, this warranty will become void.
Nikro disclaims responsibility for loss of production, profits, goodwill or any other costs
that may indirectly occur due to the failure of this product.
H.E.P.A. FILTER STANDARDS AND CERTIFICATION
All Nikro H.E.P.A. filters are manufactured and individually tested using the MIL-STD
282 D.O.P. test, or the IEST-RP-CC-001.3 test method.
Each filter is tested and certified to have a minimum efficiency of 99.97% @ 0.3 micron
particles. All filters are then individually labeled and registered by the manufacturer.
All H.E.P.A. filters used in Nikro equipment meet, and in most cases, exceed the
minimum standard of 99.97% efficiency @ 0.3 micron particles, and comply with OSHA
and EPA standards for cleaning the air of toxic and nuisance dust such as mold, lead
and asbestos.
ELECTRICAL CERTIFICATION
ETL LISTED
CONFORMS TO UL STD 507
CERTIFIED TO CAN/CSA STD C22.2 NO. 113
