CDA ECH Series Quick start guide

n
ECH
Standard chimney extractors
Installation, use and maintenance

2 | Instruction Manual
Contents
3. Important
4. Declaration of Conformity & product disposal
5. Notes
6. Using your extractor
7. Care and maintenance
Removing and cleaning the grease filters
8. Changing a charcoal filter
9. Extractor lighting
Notes on operating modes
10. Mains electrical connection
11. Electrical information
Troubleshooting
12. Determining the position of your extractor
13. Fixings provided
Product dimensions
14. Installation steps
15. Cont.
16. Ducting and ventilation
17. Energy Efficiency Information (product fiche)
18. Notes page

Instruction Manual | 3
Important
The CDA Group Ltd cannot be held responsible for
injuries or losses caused by incorrect use or installation
of this product. Please note that CDA reserves the right
to invalidate the guarantee supplied with this product
following incorrect installation or misuse of the
appliance or use in a commercial environment.
This appliance is not designed to be used by people
(including children) with reduced physical, sensory or
mental capacity, or who lack experience or knowledge
about it, unless they have had supervision or instructions on
how to use the appliance by someone who is responsible
for their safety.
Under no circumstances should any external covers be
removed for servicing or maintenance except by suitably
qualified personnel.
Appliance information
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance warranty.
Appliance model
Serial number

4 | Instruction Manual
EU Declarations of Conformity
This appliance has been designed and manufactured to comply with
all applicable UK and EU legislation,
Low voltage Directive, 2014/35/EU
Electromagnetic compatibility Directive, 2014/30/EU
ErP Directive, 2009/125/EC
RoHS Directive, 2011/65/EU
and has been marked with the following symbols
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection site, or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.

Instruction Manual | 5
Please note
Under no circumstances should the extractor be
connected to any gas ventilation system, flue system
or hot air ducting system.
Do not vent the extractor into an attic or loft space.
Only house the extractor in rooms with adequate
ventilation. Remember that the extractor is powerful and
whatever air is extracted needs to be replaced.
Do not tile the extractor in. It should be removable
for service or maintenance.
Do not use silicone sealant to secure the hood to the wall.
You must be able to isolate the extractor from the
mains electrical supply after installation.
This extractor has been designed to be used in a
room with a volume of less than 36m3.
Steam cleaners must not be used when cleaning
this appliance.
The performance of your extractor will vary depending
on several factors. These include type of extraction,
length of ducting, room volume, ventilation available and
cleanliness of the filters.
The extractor should be cleaned regularly to prevent
build-up of grease. We recommend cleaning both inside
and outside the appliance monthly. Failure to observe
the requirements specified in this manual can result in a
fire risk.

6 | Instruction Manual
Using your extractor
For best performance, you should switch on the extractor 15 minutes
before starting to cook and leave it to run for approximately 15
minutes after the end of cooking.
Control Panel
To switch the extractor light on or off
Press the “Lamp” indicator button.
To switch on the extractor or to change the speed at any time
when the extractor is running
Press the relevant button for the “Low”, “Mid” or “Max” speed
level as required.
To switch the extractor off
Press the “Off” button.
IMPORTANT: THE LIGHTS ON YOUR EXTRACTOR ARE TO BE
USED ONLY FOR THE DURATION OF COOKING. THEY ARE NOT
FOR USE AS AMBIENT LIGHTING.
Lamp Max Mid Low Off
Fig 1.

Instruction Manual | 7
IMPORTANT: DO NOT PERFORM MAINTENANCE OR CLEANING
OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE
ELECTRICITY SUPPLY.
Cleaning
You should use a non-abrasive cleaner. Any abrasive cleaner
(including Cif) will scratch the surface and could erase the control panel
markings. You can clean your extractor effectively by simply using a
dilute solution of water and mild detergent and drying to a shine with a
clean cloth. Ensure that the extractor is dry after cleaning.
Removing the grease filter
Cleaning the grease filter
The grease filter should be kept clean to minimise the risk of fire. At
least once a month you should remove and clean the grease filter with
hot soapy water. You can also wash the grease filter in a dishwasher,
ensuring that you place it in an upright position to prevent damage from
other items in the dishwasher. After rinsing and drying, replace the filter.
Fig 2.
To remove the grease filter,
pushing the button on the handle
and then pull down on the filter
at the front, as shown in figure 2.
Once released at the front it can
be pulled completely away.

8 | Instruction Manual
Please note that cleaning the grease filter(s) in a dishwasher may
cause the filters to discolour. This is normal and does not constitute a
fault with the appliance.
Changing the charcoal filter
To ensure the best performance of your extractor, you should replace
the charcoal filter every three to six months, depending on the frequency
of use and the style of cooking. To attach new charcoal filters, first
remove the grease filter(s) as described on the previous page. Offer up
the charcoal filters to the sides of the motor as shown in figure 3, turning
it clockwise until it locks in place.
Please note that charcoal filters are only required when the extractor
is being used in recirculation mode. Charcoal filters are not supplied and
are available to purchase from our Customer Care team
Fig 3.

Instruction Manual | 9
Extractor lighting
The lighting on your extractor uses energy efficient LED technology
and is designed to last the lifetime of the product. If the LED system
malfunctions, please contact CDA Customer Care.
Operating modes
Your extractor can be used in either of two modes - recirculation or
extraction. The choice often depends on the specific installation
requirements. Your installer will be able to advise which is best for you.
Note that when used in recirculation mode, the extractor will only
remove grease and odours from cooking. It will not remove steam.
The LED units must only be replaced by a
competent appliance service engineer.
Fig 4.
Fig 5.
Filter
Extraction mode
(ducted outside)
Recirculation mode
(no ducting)

10 | Instruction Manual
Mains electricity connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY
BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE
POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A
3A FUSE.
We recommend that the appliance is
connected by a qualified electrician,
who is a member of the N.I.C.E.I.C. and
who will comply with the I.E.T. and local
regulations.
The wires in the mains lead of this
appliance are coloured in accordance
with the following code:
BLUE = NEUTRAL, BROWN = LIVE, GREEN & YELLOW = EARTH
As the colours of the wires in the mains lead for the appliance may
not correspond with the coloured markings identifying the terminals
connecting to the fused spur, proceed as follows:
The wire which is coloured green & yellow must be connected to the
terminal marked E (Earth) or coloured green.
The wire which is coloured blue must be connected to the terminal
marked N (Neutral) or coloured black or blue.
The wire which is coloured brown must be connected to the terminal
marked L (Live) or coloured red or brown.
Fig 6.

Instruction Manual | 11
If the mains cable of this appliance is damaged, it must only be
replaced by a CDA approved service engineer, agent, or other
suitably qualified person.
IMPORTANT – ONLY USE A 3 AMP FUSE
The use of a 13A fuse can cause internal wiring damage which will not
be covered under the CDA warranty.
Do not mount the electrical isolation switch behind the chimney section.
It is a requirement that you must be able to isolate the extractor from
the mains electrical supply after installation.
Electrical Information
Rated voltage (mains electrical voltage): 230 – 240Vac, 50Hz
Rated input (rated power consumption): 158W
Motor input: 150W
Lamp power: 2 x 4W
Troubleshooting
If your extractor is not working
1. Check that the mains electrical supply has not been switched off.
2. Check that the fuse in the spur has not blown.
3. Contact CDA Customer Care.

12 | Instruction Manual
Determining the position of your extractor
When the extractor is to be
mounted above an electric hob,
the distance between the hob
and the extractor must be
greater than 550mm (600mm is
recommended). When the
extractor is to be mounted
above a gas hob, the distance
between the hob and extractor
must be greater than 650mm.
If the instructions provided with your gas hob dictate that the required
distance between hob and extractor must be greater than 650mm
then that is the distance that should be observed; this is a legal
requirement and failure to comply with the regulations may lead to
your hob being disconnected from the mains gas supply, and the
installation reported to RIDDOR. Any heights measured are from the
top of the gas burners.
In the absence of any instructions supplied with the gas hob, the
minimum distance between the hob and extractor must be at least
760mm. The width of any hob must not be greater than the width
of the extractor.
h = min 550mm
Fig 7.
h = min 650mm

Instruction Manual | 13
Installation
Fixings provided
We have provided a set of fixings that are suitable for most walls.
However, please ensure that the fixings you use to secure the
extractor to the wall are appropriate for the type of wall in your
kitchen.
Product dimensions
Model A (mm)
ECH63 600
ECH73 700
ECH93 900
ECH103 1000
Fig 8.

14 | Instruction Manual
Installation steps
1. Using the template supplied, mark out
the positions of the mounting holes
required. Make sure that the extractor
height above the hob will be greater
or equal to the height required for
your hob (figure 7).
2. Next, drill the fixing holes and insert
suitable wall plugs. Please make sure
you use fixings suitable for your wall.
Seek advice if you are unsure.
3. Secure the main wall hanging bracket
to the wall using the provided screws.
Lift the extractor on to the bracket,
ensuring it is properly hooked in place.
4. Attach the chimney support bracket to
the wall, making sure it is central to the
extractor body.
Fig 9.
Fig 10.
Fig 11.
Fig 12.

Instruction Manual | 15
5. Fit the extractor duct pipe and secure
to the extractor using duct tape, cable
tie or other clamping means.
6. Lift the chimney section on to the body
of your extractor, taking care not to
scratch the two parts.
7. Adjust the chimney sections to the
correct height and secure to the top
bracket using the two supplied
screws.
8. Finally, remove the grease filter and
secure the extractor body to the wall
using the two screws provided.
Fig 13.
Fig 14.
Fig 16.
Fig 15.
Fig 16.

16 | Instruction Manual
Ducting and ventilation
For best performance and quietest operation, we recommend the use
of 150mm ducting and for the extractor to be used in extraction mode
(as shown in figure 4). 125mm ducting may be used but this will reduce
the performance and increase the noise of the extractor when in use.
The use of 100mm ducting is not recommended.
Wherever possible, utilize rigid circular or rectangular section pipe
which has a smooth interior, rather than the expanding concertina type
ducting. The lengths of ducting with minimal effect on performance are
as follows:
4 metres with 1 x 90obend
3 metres with 2 x 90obends
2 metres with 3 x 90obends
Longer ducting can be used, but this will reduce the performance and
efficiency of your extractor. Ducting should be sealed to the vent outlet
using suitable securing means. Note that ducting components and
ducting kits are optional accessories and must be purchased separately.
Installation for recirculation
When installing this extractor for recirculating the air within your kitchen,
we recommend the use of optional charcoal filters to help remove
cooking odours. You should change these every three to six months,
depending on use.

Instruction Manual | 17
Product fiche (Technical information)
To determine the results, and in accordance with the requirements in relation to
the labelling of energy-related products and regarding the eco-design requirements,
the following calculations and measurement methods were applied:
Directive 2010/30/EU, REGULATION NO 65/2014.
Directive 2009/125/EC, REGULATION NO 66/2014.
EN 50564 — Electrical and electronic household and office equipment,
measurement of low power consumption.
EN 60704-2-13 — Test methods for the determination of airborne acoustical
noise, particular requirements for range hoods.
EN 61591 — Household range hoods and other cooking fume extractors –
methods for measuring performance.
Model identification, Symbol Units ECH63 ECH73 ECH93 ECH103
Annual Energy Consumption, AEC hood kWh/yr 71 63 67.7 65
Energy Efficiency Index, EEI
hood
C
Fluid Dynamic Efficiency, FDE
hood
14.3 20.6 15.4 20.8
Fluid Dynamic Efficiency Class D C D C
Lighting Efficiency, LE
hood
Lux/W 76 65
Lighting Efficiency Class A
Airflow rate, min m3/h 280 298 270 291
Airflow rate, max m3/h 475 498 468 498
Grease Filter Efficiency, GFE
hood
% 78 80
Grease Filter Efficiency Class C
Power consumption in standby, P
s
W 0
Power consumption off mode, PO
W 0
Noise level at min / max, L
WA
dBA 53 / 64
Noise level on boost -

18 | Instruction Manual
Notes

Instruction Manual | 19
This page is intentionally left blank

The CDA Group
Harby Road
Langar
Nottinghamshire
NG13 9HY
Sales Department
Phone: [phone]
Email: [e-mail]
Customer Care
Phone: [phone]
Email: [email protected]
