SPECIFICATIONS SHEET
VCS100R
VOLUME CONTROL SYSTEMS
• Includes Decora®and Standard faceplates
• Packaged for retail display
Stereo volume control with
selectable impedance magnification

VOLUME CONTROL SYSTEMS
FEATURES
■Power handling: 100 watts per channel RMS; 200 watts peak
■Selectable impedance magnifying: 1X, 2X, 4X, 8X
■12 step control, 54 dB maximum attenuation
■Removable screwless connectors accommodate up to 14-gauge wire
■Pop-free switching between all steps
■Removable knob and Decora®snap-in color inserts for quick and easy color changes
■Recommended for use with Niles VCS HUB8 speaker distribution hub
■UL listed to comply with local building codes
SPECIFICATIONS
■Dimensions: 1-5/8" wide x 2-5/8" high x 2-9/16" deep
■Requires 1-gang electrical box at least 3" deep
Warranty: Ten-year limited
High Power Stereo Volume Control
VCS100R
Color Stock Number
White FG00956
Bone FG00957
Almond FG00958
Black FG00959
Brown FG00960
