SPECIFICATIONS SHEET
MVC100
VOLUME CONTROL SYSTEMS
• Includes Decora®snap-in color insert and knob; faceplate not included
• Individually boxed
Automatic Muting Stereo Volume Control with
Selectable Impedance Magnification

VOLUME CONTROL SYSTEMS
FEATURES
■Programmable automatic muting circuit
■Built-in speaker relay
■Power handling: 100 watts per channel RMS; 200 watts peak
■Selectable impedance magnifying: 1X, 2X, 4X, 8X
■12 step control, 54 dB maximum attenuation
■Removable screwless connectors accommodate up to 14-gauge wire
■Pop-free switching between all steps
■Removable knob and Decora®snap-in color inserts for quick and easy color changes
■Recommended for use with Niles VCS HUB8 speaker distribution hub
■UL listed to comply with local building codes
SPECIFICATIONS
■Dimensions: 1-5/8" wide x 2-5/8" high x 2-9/16" deep
■Requires 1-gang electrical box at least 3" deep
Warranty: Ten-year limited
Automatic Muting Volume Control
MVC100
Color Stock Number
White FG00972
Bone FG00973
Almond FG00974
