1)OEL=Occupational Exposure Limit, *) Optional accessories / Option depending on model
Original instruction
1
Quick reference guide
Operating elements:
1. Handle
2. Accessory positions
3. Latch
4. Castor
5. Container
6. Inlet fitting
7. Switch
8. Toolbox*)
9. Appliance socket*)
10. Filter cleaning button Push&Clean
11. Inlet cap*)
12. Wire/hose storage
The pictorial quick reference guide
The pictorial quick reference guide is designed for
helping you when starting up, operating and storing
the unit. The guide are subdivided into 4 sections,
which are represented by symbols:
A
Before starting
DO READ OPERATING INSTRUCTIONS BEFORE USE!
1A - Unpack accessories
2A - Filter bag installation
3A - Hose insert & operations
4A - Tube fixed
5A - Accessories placement
B
Control/Operation
1B - Flow rate and filter warning
2B - Push&Clean filter cleaning system
C
Connecting electrical appliances
1C - Power tool adaption
D
Maintenance:
1D - Filter bag replacement
2D - Filter replacement Dust Class M & H
Contents
1 Safety instructions .................................... 2
1.1 Symbols used to mark instructions ............ 2
1.2 Instructions for use .................................... 2
1.3 Purpose and intended use......................... 2
1.4 Electrical connection.................................. 3
1.5 Extension lead ........................................... 3
1.6 Guarantee.................................................. 3
1.7 Important warnings .................................... 3
2 Risks .......................................................... 4
2.1 Electrical components................................ 4
2.2 Hazardous dust.......................................... 5
2.3 Spare parts and accessories ..................... 5
2.4 In explosive or inflammable atmosphere ... 5
3 Control / Operation .................................... 5
3.1 Starting and operating of the machine....... 6
3.2 Auto-On/Off socket outlet for power tools*) 6
3.3 Push&Clean............................................... 6
3.4 Flow rate warning ...................................... 6
3.5 Antistatic connection*) ................................ 6
3.6 Wet pick-up................................................ 6
3.7 Dry pick-up................................................. 7
3.8 Emptying after dry pick-up ......................... 7
4 After using the machine ........................... 7
4.1 After use .................................................... 7
4.2 Transport.................................................... 7
4.3 Storage ...................................................... 7
4.4 Recycling the machine............................... 7
5 Maintenance ............................................... 7
5.1 Regular servicing and inspection............... 7
5.2 Maintenance .............................................. 8
6 Further Informationen ............................... 9
6.1 Specifications............................................. 9
Declaration of conformity .................................. 282
