Nilfisk-ALTO ATTIX 961-01 Operating instructions

Repair manual.
ATTIX 961-01
ATTIX 965-21 SD XC

2
2
Nilfisk
ALTO Index
A. Saftey Issues 3-4
B. Technical data 5-7
C. Construction 8-11
D. Function 12-14
E. Trouble shooting 15-20
F. Spare parts 21-23
G.Tooles 24
H.Diagram 25-26

3
3
Nilfisk
ALTO A
Preface
In this manual you will find
the essentials you need
to know when repairing
wet and dry cleaners of
the Attix 9 series.
When carrying out repairs,
make sure you have a suitable
workbench or the like with the
necessary power supply
available.
If you determine an error
in operation, be sure to
refer the customer to the
user manual.
A fault in the equipment
can have a number of causes.
Chapter E Troubleshooting
will help you here.
Use the illustrated spare
parts lists for your repairs.
These show you the location
of the individual parts and the
sequence in which they are
assembled.
Read the technical informa-
tion sheets. These will tell you
about any technical modifica-
tions made after publication of
this repair manual.
Technical information
sheets are a supplement
to the spare parts list until
a follow-on publication.
Repair manuals and technical
information sheets
should be available at the
site where repairs are carried
out. Further repair
manuals of the Attix series
may be necessary for
repairs to the equipment.
It is not permitted to give
them to third parties.
Use original Nilfisk
ALTO spare parts only!
Safety instructions marked
with this symbol in
this manual must be ob-
served
to prevent danger to per-
sons.
This symbol is used to
mark safety instructions
that must be observed to
prevent damage to the
equipment and degradation
of performance.
This symbol indicates tips
and instructions to simplify
work and to ensure safe
operation
Symbols used to mark
instructions

4
4
Nilfisk
ALTO A
Safety Issues.
Observe national safety
directives and regulations
for the electrical engineer-
ing
trade, in particular:
IEC 60335-2-69
EN 60335-2-69
DIN VDE 105 part 1:
operation of electrical
power installations.
DIN VDE 0701/0702:
repair, modification and
testing of electrical installa-
tions.
Before starting the equip-
ment,
be sure to read the
accompanying service
manual, and keep it close
as ready reference.
The equipment should
only be used by persons
who have been instructed
in its use and are author-
ized to do so.
Repairs should only be
made by someone who
has received proper
instructions for the job
or who is a qualified elec-
trician.
For your own safety.
ESD (electrostatic discharge)
Observe the following ESD precautions before any
repair of or near electronic parts:
• Touch the protective conductor to discharge your own body.
• Possibly wear an anti-static wrist strap.
• Use a conducting floor or tabletop.
• Never touch a circuit board or electronic components,
always hold them by the plastic or insulation.
• Transport electronic parts in conductive packaging (e.g. special ESD packages).

5
5
Nilfisk
ALTO B
Technical Data.
Attix Attix 961-01 SD
National Variants EU EU
Voltage V 230 230
Frequency Hz 50/60
Fusing A 16
Power consumption PIEC W 2x1200
Connected load for appliance
socket W 1280
Total connected load W 2400 3680
Power cord lenght m 10
Power cord type H07RN-F3G1,5
Protection class I
Protection category IPX4
RFI suppression EN 55014-1
Width mm 580 615
Depth mm 600 690
Hight mm 970 990
Weight kg 30 45
Tank volume l 70 50
Air volume flow (max) l/min 2x3600
Static wate lift (max) Pa ???
Sound pressure level at 1m,
EN 60704-1 67
Noise level in working distance dB(A) ??

6
6
Nilfisk
ALTO B
Technical Data.
Attix ATTIX 965-21 SD XC
National Variants DK
Voltage V 230
Frequency Hz 50/60
Fusing A 13
Power consumption PIEC W 2x1000
Connected load for appliance
socket W 990
Total connected load W 2990
Power cord lenght m 10
Power cord type H07RN-F3G1,0
Protection class I
Protection category IPX4
RFI suppression EN 55014-1
Width mm 615
Depth mm 690
Hight mm 990
Weight kg 45
Tank volume l 50
Air volume flow (max) l/min 2x2900
Static wate lift (max) mbar 230
Sound pressure level at 1m,
EN 60704-1
Noise level in working distance dB(A) 67

7
7
Nilfisk
ALTO B
Technical Data.
Attix ATTIX 965-21 SD XC
National Variants EU
Voltage V 230
Frequency Hz 50/60
Fusing A 16
Power consumption PIEC W 2x1200
Connected load socket W
Total connected load W 2400
Power cord lenght m 10
Power cord type H07RN-F3G1,5
Protection class I
Protection category IPX4
RFI suppression EN 55014-1
Width mm 615
Depth mm 690
Hight mm 990
Weight kg 45
Tank volume l 50
Air volume flow (max) l/min 2x3600
Static wate lift (max) mBar 230
Sound pressure level at 1m,
EN 60704-1
Noise level in working distance dB(A) 67

8
8
Nilfisk
ALTO C
Construction.
ATTIX 961-01

9
9
Nilfisk
ALTO C
Construction.
ATTIX 965-21 SD XC

10
10
Nilfisk
ALTO C
Construction.
Suction turbines.
Attix 961-01 Attix 965-21 SD

11
11
Nilfisk
ALTO C
Construction.
Electrical components.
Attix 961-01
Attix 965-21 SD

12
12
Nilfisk
ALTO D
Function.
Yellow led
flashes
Red led
Green led
Yellow led
Magnetic valve
Servo plug
Magnetic
Motor connection
Motor connection
Attix 965-21 SD
Servo motor Magnetic valve

13
13
Nilfisk
ALTO D
Function.
Even with extremely fine dust the automatic filter cleaning function allows you to work constantly
with the same suction performance without having to manually clean the filter.
To make it possible to clean the filter during cleaning work, the filter has been divided into two
halves by means of two side seals on the filter holder. The cleaner sucks in dirt through
one side while the other side is being cleaned by a blast of air from the inside to the outside.
One solenoid valve (pos 1.) and the the servo motor (pos.2 ) control ( every 30 sec.) the suction
air stream and the blast of air to clean the filter.
Aut. Cleaning function.
Pos.1
Pos.2

14
14
Nilfisk
ALTO D
Function.
3. Sucking on both sides of the filterspliting.
4. Electromagnet valve piston is closed.
5. Servo motor is in neutral.
1. Right side will be closed.
3. Sucking on the left side of the filter.
2. Air push is claning the right side of the filter.
4. Electromagnet is opening to push hole.
5. Servo motor is closing the right side.
1. Left side will be closed.
3. Sucking on the right side of the filter.
2. Air push is claning the leftside of the filter.
4. Electromagnet is opening to push hole.
5. Servo motor is closing the left side.
2
1
3
33
1
2
3
4
4
4
Automatic filter cleaning.
5
5
5

15
15
Nilfisk
ALTO E
Trouble shooting
Removing/fitting grip with tensioning band
1. Take the cleaner head
with the adapter ring off
the container, and lift the
container out of the base
frame.
2. Mark (1) the position of
the grip (4) and the facing
stop (5) on the container.
3. Undo the screw (2) on
the tensioning band (3)
with a screwdriver, and remove
the grip (4) and tensioning
band (3).
4. Fit in the reverse order,
placing the grip (4) and
stop (5) between the markings
and lightly tightening
the screw (2) on the tensioning
band (3).
5. Set the container in the
base frame, and lock it in
place.
6. Align the grip (4) and
stop (5) on the container in
the base frame (7), and
firmly tighten the screw (2)
on the tensioning band (3)
Note:
The contact faces of the
contact spring (6) must be
clean and free of corrosion.
7
7
7
6
7
1
1
1
1
2 3 5
4

16
16
Nilfisk
ALTO E
Trouble shooting
Removing/fitting belt (all models)
1. Take the cleaner head
with the adapter ring off
the container, and lift the
container out of the base
frame.
2. Mark the position of the
belt on the container (1).
3. Remove the ring (8) on the coupling
Take out the coupling.
4. Thread a normal length
of cord (3) or the like (60-
80 cm) through one of the
Loops (4) of the tensioning
device, and pull the loop
(4) back over the catch
(6). Detach the second
loop (4) in the same way,
and take off the belt (7).
5. Fit in the reverse order,
making sure the belt (7) is
correctly positioned.
7
3
4
6
4
46
6
1
8

17
17
Nilfisk
ALTO E
Trouble shooting
Remove the filter.
Remove 4 screws. in top. Remove 2 screws in the handle.
Punch out the wire
nail with a mandrel.
Fig. Fig.
Fig. 3 Fig. 4
Fig. 5
Release by pulling.
Removing/fitting grip
Attix 961-01
Attix 965-21 SD XC

18
18
Nilfisk
ALTO E
Trouble shooting
Voltage applied to switch ?
Do electronics work?
Does motor work?
Conduct
saefty
check
Does cleaner work?
Repair or replace motor.
Replace electronics.
Check plug and power
c o r d , r e p l a c e i f
necessary.
Start:
line voltage must be present
and plug must be plugged in.
- Touch the protective
coductor to discharge static
from your own body.
- Possibly wear an antistatic
wrist strap.
- Use a conductive floor ta-
bletop.
- Never touch a circuit
board or electronic compo-
nents, always hold
them by the plastic or insula-
tion.
- Transport electronic
parts in conductive packag-
ing (e.g. Special
ESD packages).
ESD (electrostatic discharge)
Observe the following
ESD precautions before
any repairs to electronic
circuitry:

Unit will not work
(all units with brush motor)
Troubleshooting on unit
Yes
No
No
No
No
Yes
Yes
Yes

19
19
Nilfisk
ALTO E
Trouble shooting
Is LED no.1 (operating )illuminates
Magnetic valve.
Is LED no.2 (operating) illuminates
Servo.
Check plugs for Servo (3) and
Magnetic valve (4) on PC board
Are they OK !
Replace electronic PC board.
Replace Servo or Magnetic valve.
Replace Servo or Magnetic valve.
Machine does not clean the Filter.
Replace electronic PC board.
No.2
Green led
Servo.
No.1.
Yellow led
Magnetic valve.
No.3
Servo plug.
No.4
Magnetic
Valve plug.
No
No
No
Aut. Filter cleaning
Yes
Yes
Yes

20
20
Nilfisk
ALTO F
Spare parts
Attix 961-01
