Fig. 1 EV-SCM Sounder Notification Module
© 2009 Nittan UK © 2009 Nittan UK
INTRODUCTION
The EV-SCM Sounder Control Module is designed to
provide an output, in response to a command
signalled from a controller, to activate a number of
polarised and suppressed sounders. The sounders
are powered from an independent power supply
and the module is capable of passing up to a
maximum of 2A.
FEATURES
Use an EN54 approved PSU, to supply the source
power for EV-SCM dc applications:
•EV-SCM can switch up to 2A
•EV-SCM supervises power supply.
•EV-SCM monitors the wiring to signalling
devices and will not switch on (even if
commanded to do so), if a short circuit occurs.
This prevents a single short circuit condition
from disabling more than the output that
contains the short-circuit.
An LED reports EV-SCM status to the user. The
LED lights when the EV-SCM has been commanded
to activate.
TECHNICAL SPECIFICATION
Type Identification Value: 65
System Compatibility: Use only with Evolution
Fire Alarm Panels which
support this product
Environment: Indoor Application only
Operating Temperature: -25ºC to +70ºC
Storage Temperature: -40ºC to +80ºC
Operating Humidity: Up to 95%
non-condensing
Dimensions (HWD): 87 x 148 x 14mm
Mounting Requirements: One MK backbox
surface mount
Wire Size: Min 1.5mm2
Max 2.5mm2
Battery Requirements:
Standby current: 0.75mA max
Alarm current: 4.5mA max
Addressable Device Conditions:
• Normal
• Short Circuit wiring fault
• Open Circuit wiring fault
• Input Power fault
• Device Type invalid
• Device No Response
Notification Circuit:
Max. Circuit Voltage Drop: 3.0V dc
Notification Circuit EOL: 27k ohms, 0.5 watt
Output Current: 2A max @ 24V dc
ELECTROMAGNETIC COMPATIBILITY
The EV-SCM complies with the following:
Product family standard EN50130-4 in respect of
Conducted Disturbances, Radiated Immunity,
Electrostatic Discharge, Fast Transients and
Slow High Energy
EN50081-1 for Emissions
Fig. 4 Simplified Wiring Diagram
showing Sounders wired in
a Spur Configuration
CIE
www.acornfiresecurity.com
www.acornfiresecurity.com

23
EV-SCM
Installation Leaflet EV-SCM Issue 1
EV-SCM
Installation Leaflet EV-SCM Issue 1
WIRING NOTES
The following notes apply:
1) There are no user-required settings (such as
switches or headers) on EV-SCM.
2) All wiring must conform to the current edition
of IEE Wiring Regulations and BS5839 part 1.
3) All conductors to be free of earths.
4) All Notification appliances must be polarised
and suppressed.
5) Verify the correct polarity of wiring before
connecting the EV-SCM to the addressable
loop circuit.
6) For EV-SCM typical wiring configurations
(see Figures 4 and 5).
© 2009 Nittan UK © 2009 Nittan UK
ADDRESS SETTINGS
The EV-SCM must be set to the loop address of the
device using the EV-AD2 Address Programing Tool.
The EV-SCM may be programmed with the address
prior to being installed by using the internal
programming port (see Fig. 2) or after being installed
by using the programming port on the front cover
(see Fig. 3).
Note: Once the address has been programmed, take
note of the device location and address
number, to include on site drawings.
CABLING
Cables are to be selected in accordance with the
requirements of the current issue of BS5839. A
maximum of one 1.5m2or one 2.5m2cable may be
connected at any one terminal.
CABLING
The module fits onto a standard dual-gang MK box.
The module may drive a EV-SBM Sounder Booster
Module.
CABLING
EV-SCM Sounder Control Module F16N82026
