niu UQiGT Series User manual

USER MANUAL
V 1.0

CONTENTS
Attach the
SN Code here
The SN Code of your scooter.
Please see P.4 for detailed information.
General Notice
Precautions
Safety Notice
Download APP and Register
Installation Guide
Parts Info
Operation Guide
Battery Use and Maintenance
DOs and DON'Ts while Riding
Maintenance and Repair
Troubleshooting List
Technical Parameters
Maintenance Record
01
02
03
04
05
07
12
16
22
23
28
32
35

General Notice Precautions
Please read this User Manual carefully for proper operation before riding the scooter.
For your safety, please check whether the parts are in good condition according to this User
Manual before riding. Contact your dealer in time in case of any problems.
Please follow the traffic laws. Slow down on slippery roads in bad weather to allow greater
braking distance for your safety.
Please pay attention to deep water. It may cause rusting or failure of the motor, battery, or
other parts if water level reaches wheel axle.
Do not dismantle the scooter on your own. Please contact your dealer for replacement or
purchase of original parts.
Do not lend your UQi GT scooter to those who can’t operate a scooter for others' safety and
preventing unnecessary damage to your scooter.
Please keep the User Manual properly.The final explanation of this User Manual belongs to
the manufacturer and is subject to change without notice.
For more product information or maintenance need,
please visit our website: www.niu.com/en
Rider and Passenger
This scooter is not designed for a ride of more than 2 persons.
Riding Conditions
UQi GT scooter is not designed for off-road use.
This User Manual should be deemed as a permanent document of UQi GT scooter. If this
scooter is transferred to others, this User Manual should also be handed over to the
new owner.
Reproduction or reprint of any part of this User Manual is strictly prohibited.
WARNING: Do not exceed speed limit and apply brakes cautionsly. Always use side stand
when parking.
0201
ATTENTION: Failure to follow the instructions herein may lead to serious casualties,
personal injury, or scooter damage.

Safety Notice
Using a safety helmet and protective goggles is strongly advised.
You are advised to take proper training or exercise before using on open roads.
Please follow the Operation Guide (P.12) to fully understand how to properly operate the
scooter.
It should be noted that the braking distance in bad weather will be much longer. Please avoid
braking on paint markers, manhole covers, and oil stains to prevent slipping. Pay extra
attention when riding through railway crossings, junctions, tunnels, and bridges. Slow down
if road conditions are unclear.
Do not use high beam indiscriminately. Continuous use of high beam may disturb the vision
of other drivers and pedestrians.
Do not use mobile phones or other electronic devices which may draw your attention while
riding.
Do not change the lane without signaling. Changing the lane at will is one of the major
causes for accidents. When you need to change the lane, remember to switch on the Turn
Signal Indicator first. Always check the vehicles approaching from behind before changing
the lane.
0403
Downloading the APP
Step 1
Step 2
Step 3
Functions such as checking battery level, locating, and management can be implemented on the
electric scooter through the app.
NOTE:
The mobile phone system is required to be at least Android 4.0 or iOS 8. Make sure that the
mobile phone has been connected to the Internet when running the app (Wi-Fi / 2G / 3G / 4G).
Scan the QR code below to download the APP
titled Niu E-Scooter.
Run Setup after downloading and register.
Please scan the QR code on the inside of cover
page for app registration.

Installation Guide
Step 1
Step 2
Step 3
0605
Open the Accessories Box to take the tools.
Install the rearview mirrors into the mounting holes on dashboard and turn it
clockwise. The bolt shall be screwed in for more than 15mm.
Adjust the rearview mirror to an appropriate position and then tighten nuts on the
rearview mirror with a spanner. Properly set the dust cover.
Step 4
Step 5
Take out the foot rests and assemble the top and holder together with screws for both
sides with M6 screws.
Install the foot rests on two sides of the scooter frame with M6 screws.

0807
Parts Info
Side Stand Central Stand
Taillight
Left
Combination
Switch
Saddle
Rearview
Mirrors
Turn Signal
Indicators
Headlight
Handlebar
Lock
Reflector
Handrail
Right
Combination
Switch

1009
GSM Signal
Dashboard Display Info
Time
Riding Mode
Cruise Mode
Diagnostic Code
Charging
Percentage
Speed
GPS Signal
Economic Mode
Battery Bar
Charging
Energy Recycling
Left Turn Indicator
Left Turn Indicator The Left Turn Indicator is on.
The Right Turn Indicator is on.
The High Beam is on.
Right Turn Indicator
Right Turn Indicator
Ready Indicator
Ready Indicator In Riding Mode.
Battery level less than 10%.
Now is 10:00
Ideal energy consumption status.
The scooter is in Cruise Mode.
Energy is being recycled from braking.
The Diagnostic Code is 30.
Please see the “Troubleshooting List”
No flashing: Signal strong.
Bars are falshing: Signal weak.
Entire icon flashing: No signal.
Low Battery Indicator
Low Battery Indicator
Time
Economic Mode
GPS Signal
GSM Signal
Cruise Mode
Diagnostic Code
Energy Recycling Status
High Beam
High Beam
Distance TravelledBattery Percentage&
Remaining Charging Time
Instant Electric Current Battery Bar Current battery level is 80~89%.

1211
Operation Guide
USB Port
Hook
Handlebar Lock
Front Storage Area
1
2
3
Start the Scooter
Unlock Button
Power Button
Lock Button
Key Remote Controller
1
3
2
Current battery level is 85%.
The remaining charging time is 3.2 h
(using scooter charging port).
Battery Percentage (Small)
Battery is being charged.
Distance Travelled is 802 miles.
Indicates instant power output.
Current speed is 26 mph.
Current battery charging progress is 13%
(using scooter charging port).
Charging
Distance Travelled
Instant Electric Current
Riding Mode Mode 2 is selected.
Speed
Charging Percentage (Large)
Remaining Charging Time

1413
Press the Unlock Button of the remote controller to disable the alarm. Insert the key into the
keyhole of the handlebar lock, push inward, and turn clockwise to unlock the steering
handlebar.
Unlocking the Scooter
Press the Power Button again to turn off the scooter. Turn the steering handlebar to the left,
then Insert the key into the keyhole of the handlebar lock and turn counter-clockwise to lock
steering handlebar. Press the Lock Button on the Remote Controller within an effective
distance to turn on the alarm. The Turn Signal Indicators will stay on for 2 seconds after the
scooter is properly locked.
Locking the scooter
Step 1
Step 2
Press the Power Button of the scooter or the remote controller to turn on the scooter.
Press and hold the Start Button on the right handlebar for 2 seconds, on Dashboard
will light on. You are ready to go.
High/Low Beam Light: Press the upper part to switch to high
beam; press the lower part to switch to low beam.
Turn Signal Indicator: Push the button left to turn on the Left
Turn Signal Indicator; push the button right to turn on the
Right Turn Signal Indicator. Press the button to turn off.
Cruising Mode: Push the button to cruise at current speed.
Press again or brake to turn it off.
1
2
3 4
High/Low Beam Light
Turn Signal Indicator
Horn
Cruise Mode switch
Left Combination Switch
1
2
3
4
Overtaking Light Button
5
Low Beam
High Beam
PRESS
5
Overtaking Light Button: To signal overtaking with flashing
light, the rider may press and release the Overtaking Light
Button repeatedly.

1615
Mode Selector: Press right part to switch up the mode. Press
left part to switch down the mode.
Start/Stop Button: Press and hold the button for 2 seconds to
set the scooter in the riding mode. The indicator on the
dashboard will light up and you are ready to go. Press the
button again to turn it off.
Hazard Light Switch: Push the switch left to
turn on the HazardLight; push the switch
right to turn it off.
Mode Selector
Hazard Light Switch
Start/Stop Button
Right Combination Switch
1
2
3
1
2
3
Switch down Switch up
Turn on the Hazard Light Turn off the Hazard Light
When the Indicator Button is pressed, the Indicator will light up to show the percentage
of the battery. The indicator has 5 sections. Each presents 20% of the battery level.
If the battery level is less than 20%, the Indicator will flash 3 times.
When charging, the indicator will flash to show the charging progress. They will stop
flashing when the battery is fully charged.
If all 5 sections flash, it means the battery has fault. Please contact your dealer for
consultation.
Battery Use and Maintenance
Battery Level Indicator
Indicator
Button
Indicator
Charging Port
Handle

1817
In order to prevent possible leakage, overheat, smoking, fire or explosion, please follow these
instructions:
The battery should be used at the temperature of -10°C to 45°C.
Do not expose to water, beverages or corrosive liquids.
Keep away from heat source, open fire, inflammable and explosive gases and liquids.
Please keep metal parts away from the battery compartment.
In case of undesirable odor, overheat or deformation of the battery, please disuse the
battery immediately, keep away from the battery and contact your dealer.
WARNING: The M+ battery is NOT a repairable part by the user. In case of battery fault,
please contact your dealer. Users dismantling the battery may lead to leakage, overheat,
smoking, fire or explosion. Do not attempt to open or repair the battery, as any attempt to
do so will render the warranty invalid.
Battery Use and Maintenance
Using Environment
The battery should be charged at the temperature of 0°C to 35°C. The charging time should not
exceed 24 hours. Overcharging will shorten the battery life.
Charging Environment
ATTENTION: Do not charge the battery below 0°C.
WARNING: Using non-original battery chargers may lead to leakage, overheat, smoking,
fire or explosion.
1
2
3
Battery Connector/Charging Port
Battery
Battery Lock
1
2
3

2019
All operation should be strictly conform to the user manual. If not, result will be
assumed by user.
Must use original charger.
Pay attention to the type of battery and applied voltage. Mixture use is forbidden.
Charging should be in ventilated environment. DO NOT charge in closed space or under
high temperature. DO NOT put charger into trunk or tail box while charging.
While charging, connect battery with charger before connect with electric supply. After
full charged, cut off the electric supply before cut off the battery plug.
When the green light turns on, please cut off the power in time. Avoid long time
connection between charger and AC power supply while not charging.
While charging, if the signal light is abnormal, has different smell or the charger is over
temperature, please stop charging immediately and check or change the charger in
time.
When using and storing the charger, please avoid foreign matter, especially water or
other liquid in case of internal short circuit.
DO NOT bring charger within scooter, if have to, please make sure of damping.
DO NOT disassemble or change the parts in charger by yourself.
WARNING
Charging Methods
Charging on the Scooter
Open the saddle, open the cover of the
connector, and plug the charger into
the charging socket.
Charging the Battery
Remove the battery from the
scooter. Connect the charger with
battery and socket.
Charging Pot

2221
If the battery can not be fully charged after 12 hours, please stop charging and contact
your dealer.
To maximize the battery life, please keep the battery percentage within 20% to 80%.
For storage, please keep the battery under 40°C to prevent irreversible capacity loss of
the battery.
UQi GT battery will lose more capacity in lower temperature conditions. To be more
specific, the usable capacity at -10°C is 70%, 85% at 0°C and 100% at 25°C.
The best battery capacity performance for storage is 50%. Storing battery with less than
10% or more than 90% over a long period of time will cause irreversible capacity loss to
the battery.
The battery needs to take out from the scooter for storage longer than one week. In this
condition, please keep the battery at the temperature of 0°C to 20°C with capacity of
30%-70%. It's advised to have at least one cycle of charge and discharge every 2 months
to minimize battery capacity loss during storage.
If the battery failure is due to misuse or lack of proper maintenance as instructed, its
warranty will be invalidated.
Falling may cause uncontrollable internal damage to the battery and may cause
leakage, overheat, smoking, fire or explosion.
ATTENTION
DOs and DON'Ts while Riding
Please check the following details before riding.
Before Riding
Check Point Description
Steering Handlebar
Braking
Tyres
Battery
Lights
Horn
Braking lever has 5 to 9mm idle travel.
Adequate for planned distance to travel.
Check whether the horn can work.
Check all the lights—High Beam, Low Beam, Brake Light,
Turn Signal Indicator, etc.
(1) The air pressure range of both tires is 25 to 34psi.
(2) Proper tyre tread depth
(3) No cracks or openings
(4) Minimum load-capacity index: front 17, rear 43.
(5) Minimum-speed category: B.
(1) Steadiness
(2) Steering flexibility
(3) No axial displacement or loosening

2423
Adjust the scooter upright before applying brakes.
If the tyres are locked and the scooter loses steering ability resulting from excessive braking
force, loosen the grip on the braking lever and the tyres will be working again and the scooter
will be stabilized.
Try to maintain a 1:1 ratio of front and rear braking force on slippery roads.
ATTENTION: Inexperienced riders tend to use the rear brake only, which will accelerate
the wear of the brake and result in a longer braking distance.
WARNING: Using the front brake or rear brake only is dangerous because of possible
grip or control loss. Pay extra attention and use the brakes gently when riding on damp,
slippery roads and around corners. Otherwise, riders will be exposed to great danger.
Braking Precautions
Users are advised to have the scooter checked and maintained on a regular basis, even for the
scooters that are not used for a long time.
Maintenance and Repair
Users are advised to have their scooters checked 2 months after purchased or with 500 km
travelled distance. Overall check and maintenance is advised to be conducted every 6 months
or 3000 km thereafter.
Regular Maintenance
If any problem occurs during checks, please look through the Home Repair Instructions or send
the scooter to the dealer’s for checks and maintenance.
Daily Maintenance
Please use neutral detergent and water to wash the scooter. Use soft cloth to wipe the scooter
after washing to prevent scratching.
Scooter Washing

25 26
If the scooter is frequently used in overload, high-speed, bumpy or up/downhill riding
conditions, the maintenance cycle should be shortened.
For more guaranteed quality and longer service life, please use original parts, which are
under normal warranty.
ATTENTION
If incapable of repair or adjustment on his/her own, the scooter owner is advised to send
the scooter to the dealer’s for maintenance and adjustment for the sake of safety.
Always choose a smooth surface road for repair and adjustment. If it’s necessary to repair
the scooter during a ride, please mind the traffic.
WARNING
Do not use pressure washer to wash the scooter, especially around the battery
compartment. Do not flush the rear inner mudguard, where the charger, controller and
other parts are installed behind. If the charging port on the scooter is wetted, please do not
charge before the charger dries off. Contacting your dealer is recommended.
WARNING
WARNING: Please take out the battery from the scooter when long-term storage.
Keep the scooter in flat, steady, well-ventilated and dry area.
Charge the battery to 50% full before storage to maximize battery life.
Avoid exposure under sunlight and rain to reduce damage or aging.
Short-term Storage
Remember to have a cycle of charge and a discharge at least every 2 months and charge the
battery to 50% full before storage to maximize battery life.
Charge the battery to 100% full after long-term storage.
Check all the parts carefully to make sure that there is no problem before riding it. If there's
any problem, take the scooter to your dealer for maintenance or repair.
Long-term Storage
Storage Method

2827
Regular Maintenance Checklist
Regular Safety and
Performance Check
Structural Check
Major Parts
Brakes
Lights
Horn
Electric Parts
Tyres
Lubrication
Wheel Bearing
Vibration Damper
Side Stand/Central Stand
Steering Bearing
Battery
Main Wiring Harness
Control System
No output when
switched on
1. Dead battery
2. Batery not connected
3. Alarm failure
1. Charge the battery.
2. Check if it’s properly connected.
3. Replace Alarm.
Troubleshooting List
Malfunction
Description Causes Troubleshooting
1. Battery voltage is low
2. The power off switch is enabled
when pulling the brake lever
3. The Parking Mode has not been
turned off yet
1. Not properly connected
2. Battery temperature is too high
or too low
1. Low battery level
2. Under-inflation of tyres
3. Frequent braking and overload
4. Battery aging or normal capacity
loss
5. Low battery capacity resulting
from low temperature
1. Check whether the plug is
loosened.
2. Wait for it to achieve normal
temperature.
Motor failure when
turning the twist grip
after switched on
Battery charge failure
Dropping speed or
range
1. Charge the battery.
2. Do not pull the brake lever when
twisting the twist grip.
3. Check “Start the Scooter” section.
Check if the side stand is on.
1. Charge the battery and check if
the plug is properly plugged in
and whether the charger is damaged.
2. Check the tyre inflation every time.
3. Develop good riding habits.
4. Replace the battery.
5. Normal situaiton.

3029
Identify the fault causes in reference to the meter panel fault codes.
Dead battery
Communication failure
or Dashboard failure
FOC Controller locked rotor Stop the scooter and restart later.
1. Disconnect the battery and reconnect it
after 30 seconds.
2. Check whether the wires are loosened.
3. Contact your dealer for professional checks.
Charge the battery.
Sudden stop
during a ride
00 displayed
10 displayed
FOC Controller overcurrent
Motor overtemperature
Contact your dealer for professional checks.
Stop the scooter and restart when cooled down.
12 displayed
FOC Controller
overtemperature
Disconnect the battery and cool it down
before reuse.
13 displayed
20 displayed
Battery overcharged30 displayed
FOC Controller
undervoltage/overvoltage Stop the scooter and restart later.11 displayed
Troubleshooting List
Malfunction
Description Causes Troubleshooting
Turn on the headlight and hazard light to
discharge until the code disappear.
Charging overcurrent31 displayed Stop charging the battery and check if the
charger is failed.
Charging at low temperature
SIM card identification failure
GPS module failure
GPS antenna short circuit
GPS antenna open circuit
ECU SN missing/incorrect
SIM card unpaid/inactivated/
low signal strength
Contact your dealer for professional checks.
32 displayed
60 displayed
62 displayed
63 displayed
64 displayed
65 displayed
67 displayed
99 displayed
110 displayed
111 displayed
120 displayed
130 displayed
131 displayed
FOC Controller failure
Motor failure
Battery overdischarged
Over-current discharging
1. The scooter is locked 2. FOC
Controller verification failure
Electronic components
communication failure
Troubleshooting List
Malfunction
Description Causes Troubleshooting
Take the battery indoor until back to normal
operating temperature.
1. Press unlock button on the Remote.
2. Contact your dealer for professional checks.
Contact your dealer for professional checks.
Charge the battery.
Stop the scooter and restart later.

3231
Technical Parameters
1910 mm 740 mm
1128 mm
Battery overtemperature
Battery undertemperature
Twist grip failure
The scooter is locked by
remote command
Controller communication
failure
Contact your dealer for professional checks.
132 displayed
133 displayed
140 displayed
161 displayed
190 displayed
191 displayed BMS communication failure
Troubleshooting List
Malfunction
Description Causes Troubleshooting
Stop riding and let battery cool down.
Charge the battery after it reaches the
operating temperature range.
Please check the wires of the twist grip or
contact your dealer for professional checks.

3433
Frame
Front/Rear Damper
Front Tyre Specification
Rear Tyre Specification
Front Brake Mode
Rear Tyre Pressure
Minimum Ground Clearance
Seat Height
Oil Damping Direct Acting Shock Absorber
90/90 - 14 Rim : 2.15 x 14
100/80 - 14 Rim : 2.50 x 14
220 mm Hydraulic Disk Brake
180 mm Hydraulic Disk Brake
180 mm
845 mm
UQi GT Pro UQi GT Sport
Features
Battery System
Diamension
Product Weigh(battery included)
Maximum Load
Designed Capacity
Gradeability
Voltage
Standard Charging Current
Maximum Discharging Current
Capacity
Max.Speed
1910 x 740 x 1128 mm
77kg
227 kg
2 Person
48 V
45 km/h
5.2 A
40 A
42 Ah 31 Ah
Power System
Motor Control Mode
FOC Controller Max. Current
Motor Rated Power
Max. Motor Continuous Power
FOC Vector Control
40 A
1200 W
1500 W
Electrical System Central Control Unit
USB Charging
Headlight/Turn/Indicator
Taillight/Brake/Light
Meter Panel
12V LED
12 V
5V/1A
Dynamic: ~11°
~50km/h ~40km/h
Range

Maintenance Record
Date
Notes：
Dealer：
Mileage
Maintenance Record
Date
Notes：
Dealer：
Mileage
3635
