Jetson JBEAM User manual

BEAM
ELECTRIC FOLDING SCOOTER
MODEL#: JBEAM | VERSION: 082017
-MANUAL-

2
TABLE OF CONTENTS
A. Introduction 3
B. Features And Specs 4
C. Safety Warnings 5
D. Included In The Box 7
E. Opening and Unfolding 7
F. Turning the Jetson Beam On/Off 9
G. Turning Headlight On/Off 9
H. LCD Display 9
I. Bluetooth Function 10
Connecting to Bluetooth
Connecting to the Ride Jetson App
Mode Setting in the Ride Jetson App
J. Pulsing Beam Light 11
K. Rear Wheel Light 11
L. How to Use 13
M. Folding 14
N. Operation 15
Battery
Charging
O. Care and Maintenance 17
P. Warranty 18
Q. Product Registration 19

3
INTRODUCTION
Congratulations on your new Jetson Beam! The Jetson Beam is an innovative
and fun personal transportation device, ready to take on everyday use. Before
your rst ride, check whether the wheels are damaged, or parts are loose. If
there are any abnormalities, please contact Jetson Customer Support at 1-(888)
976-9904, or email [email protected] immediately.
This product manual can help you understand, use, and maintain your Jetson
Beam. In order to avoid danger caused by collisions, falls, and loss of control,
please use caution and learn how to ride the Jetson Beam safely. Jetson and
authorized dealers cannot be held liable for injury or damage caused from
riding the Jetson Beam. Falling, losing control, and collisions (including failure
to obey the Jetson Beam manual) may cause injury. In order to minimize the
risk, ensure you read the Jetson Beam manual carefully. Users ride at their own
risk.
The user is responsible for consequences caused by violating warnings or
improper operations.
If for any reason you want to return this product, please email us at
[email protected] or call us at [phone] before returning
it to the store.

4
FEATURES & SPECS
MOTOR: 250W
MOTOR TYPE: HUB
BATTERY: 24v, 4.3Ah (LG BATTERY)
CHARGING TIME: UP TO 3 HOURS
MAX RANGE: 14 MILES
MAX SPEED: 12 MPH
BLUE TOOTH: VERSION 4.0
WEIGHT LIMIT: 250 LBS
PRODUCT WEIGHT: 25.15 LBS
BRAKE: FRONT: ELECTRIC BRAKE. REAR: FOOT BRAKE
WHEEL SIZE: FRONT: 8”
REAR: 8” INFLATABLE
LIGHTS: LED HEADLIGHT & STEM
THROTTLE TYPE: THUMB
DISPLAY: INTEGRATED LCD
CLIMBING ANGLE: 10 DEGREES
CHARGER: UL LISTED. 100V - 240V
RECOMMENDED AGE: 13+
UL 2272 Certied: YES
USE TEMPERATURE: -10°C - 40°C
CHARGING TEMPERATURE: 0°C - 40°C
DIMENSIONS: FOLDED: 36.25” L x 13.8” H x 6.5“ W
UNFOLDED: 36.25” L x 44.5” H x 17” W
IN THE BOX FOLDING SCOOTER, CHARGER, MANUAL

5
FOR YOUR SAFETY...
• This product is intended for ages 13+. Always drive defensively, and watch
out for potential obstacles that may catch your wheel or cause you to swerve
suddenly.
• Always check any local laws or regulations which may affect where the Jetson
Beam can be used. This product is intended to be used on private property.
• Ride at your own risk and use common sense. Any rider that is unable to t
comfortably on the vehicle should not attempt to ride it. All decisions on who
can ride the Jetson Beam should be made based on their maturity, skill, and
ability to follow the rules.
• Keep this product away from small children. It is intended for use by people
who are, at a minimum, comfortable and competent when operating the Jetson
Beam.
• The Jetson Beam is designed for one rider. Never carry passengers, and do
not attach the Jetson Beam to other objects.
• This product was manufactured for performance and durability, but is not im-
pervious to damage. Aggressive riding can over-stress and damage the Jetson
Beam. The rider assumes all responsibility and risk associated with high-stress
activity.
• Keep your ngers and other body parts away from the wheels and all other
moving components when operating the Jetson Beam. Only activate the speed
control when you are on the Jetson Beam and in a safe environment suitable
for riding.
• Do not wear headphones or use a cell phone while operating the Jetson
Beam.
• Do not operate the Jetson Beam in wet or icy weather, and never immerse
the product in water. The components can be damaged by water and create
other unsafe conditions.
• Avoid excessive speeds when riding downhill, as it increases the risk of acci-
dent and injury. Avoid wet, slick, bumpy, uneven or rough surfaces while using
the Jetson Beam. Never risk damaging surfaces such as carpet and ooring by
using the product indoors.
• Do not ride at night, or when visibility is limited.
• Always wear proper protective equipment, such as a helmet, elbow pads, and
knee pads. Athletic shoes with rubber soles are best for riding the Jetson
Beam.
• Never operate the product barefooted or in sandals, and keep shoelaces tied
and out of the wheels, motor, and drive system.
• Riding with improperly adjusted brakes or worn brake pads is dangerous and
can result in serious injury or death.
• Applying brakes too hard or too suddenly can lock up a wheel, which could
WARNINGS & GENERAL INFORMATION

6
cause you to lose control and fall. Sudden or excessive application of the front
brake may pitch the rider over the handlebars, which may result in injury or
death.
UNBOXING
After opening the box, please carefully remove the scooter and all the acces-
sories slowly to avoid scratching the frame. Please check the carton for loose
parts before discarding.
With its stylish and futuristic appearance, and powerful lithium battery, the
Jetson Beam is created to give you a wonderful riding experience.
NOTE: Actual product may differ from images shown in manual.
LED Headlight
Pulsing
Beam
Light
Folding
Lock
Lever
Throttle button
Easy Grip Handles
Folding
Handlebars
Folding T-bar Latch
LCD Display For Speed
And Battery Life
10” Expandable
Handlebar
Handlebar Stem
Electric Brake
Kickstand Charging PortRear Hub LED Lights
Rear Foot Brake Release Button
Throttle Sensor Deck
Brushless
Motor Hub
6
INCLUDED IN THE BOX
Auxiliary wheels

7
OPENING AND UNFOLDING YOUR JETSON BEAM
Step 1 Open the Folding Lock Lever, then press the Release Button while
gently lifting the handlebar away from the deck. Once you hear a “click” sound,
lock the Folding Lock Lever. The handlebar stem should now be secure.
Press Release Button
And Lift Handlebar
Away From Deck
After Click Sound,
Lock Folding Lock Lever
Press Release Button
And Lift Handlebar
Away From Deck
After Click Sound,
Lock Folding Lock Lever

8
Step 2 Open Folding T-bar Latch by lifting upwards, and unfold one handlebar
at a time. Once unfolded, push handlebars in, and bring Folding T-bar Latch
back to its original position by pushing down. Make sure handlebars and Fold-
ing T-bar Latch are secure before continuing.
Open Folding T-bar Latch Bring Folding T-bar Latch
Back to Original Position
Push Handlebar In Push Handlebar In
Unfold Handlebar Unfold Handlebar
Step 3 Open Handlebar Quick Release Lever and pull handlebar up to adjust
height. Once adjusted, lock Handlebar Quick Release Lever by pushing back
in.
Step 4 Check to make sure everything is secure and locked before continuing.

9
TURNING YOUR JETSON BEAM SCOOTER ON AND OFF
To turn your Jetson Beam Scooter on, place one foot on scooter and kick off
with your other foot to put it in motion, while simultaneously holding down the
thumb throttle (on right side of handlebar) for 5 seconds.
To turn your Jetson Beam Scooter off, make sure scooter is not in motion, then
press the thumb throttle and electric brake (on left side of handlebar) down
simultaneously.
TURNING HEADLIGHT ON/OFF
When parking your Jetson Beam, press and hold e-brake down for 3 seconds.
This will turn your headlight off. Pressing and holding the e-brake for 3 seconds
can turn your headlight back on.
Hold e-brake down
for 3 seconds to turn
headlight on and off
Press e-brake and thumb throttle
simultaneously to power off
DISPLAY SCREEN
The LCD display screen is an interface that shows the battery life, speed, and
Bluetooth connectivity of your Jetson Beam while in operation.
OVERVIEW

10
14mph
Battery life indicator
Bluetooth 4.0 onnects to Ride Jetson App
Your Jetson Beam is Bluetooth 4.0 enabled, so you can pair it with Jetson’s
Ride Jetson app on your personal Bluetooth enabled device. It can be paired
with Androids and iPhones.
The Ride Jetson app is available for download from the App Store and the
Google Play Store, and unlocks extra features on your Jetson Beam. Simply
install the app (it’s free!) and connect to your Jetson Beam via Bluetooth (as
detailed on the next page).
Extra features available through the app:
- Turn your Beam light on/off, increase or decrease light’s intensity, choose the
light pattern (solid or pulsing)
- Turn your headlight on/off, and increase or decrease light’s intensity
- Lock and unlock your scooter remotely, for added safety

11
To pair your Jetson Beam with your Bluetooth enabled device, follow these
steps:
1. Turn on the Jetson Beam so that it will become discoverable on your device.
2. Make sure the Bluetooth function in your handheld device and in the Jetson
Beam is turned on.
3. Open the Ride Jetson app in your device, and locate the Bluetooth icon in
the top left corner.
4. Tap on the Bluetooth icon, and from the device list, select your Jetson Beam.
5. You will be prompted to enter a password. Default password is “000000”
6. Your Ride Jetson app should now be paired with your Jetson Beam, and
ready to use.
NOTE: When your app is not connected via Bluetooth, the Bluetooth logo in
the app will be white. When your app is connected via Bluetooth, the Bluetooth
logo in the app will turn green.
Pulsing Beam Light
Once your Jetson Beam Scooter is in motion, the pulsing beam light located
on the handlebar stem will automatically turn on. The throttle sensor on deck
senses when you step off – once you step off, the pulsing beam light will auto-
matically shut off after 60 seconds.
Rear Wheel
Rear wheel LED lights will change from color (matching your Jetson Beam
model) when in motion, to red when braking.

12
HOW TO ATTACH AUXILIARY WHEELS
Your Jetson Beam comes with auxiliary wheels you can attach, which provide a
more practical and comfortable way of carrying your Beam. To attach:
1. Lay your Beam on its side, and locate 4 screws (2 on each side) that are
towards the front wheel, close to the bottom of the deck.
2. Unscrew the 4 screws.
3. Line up the holes on the platform attached to the auxiliary wheels, with the
holes on the Beam where the screws were. Make sure the auxiliary wheels are
closest to the front end of your Beam.
4. Place a screw in each hole and tighten to secure the auxiliary wheels to your
Beam.
Once properly attached, you can use the auxiliary wheels to roll your
Jetson Beam when it’s not in use. Simply fold up the Beam and lift it up by
the handlebar (in a position where the wheels are on the bottom and the
handlebar is on top), with the auxiliary wheels being the only wheels that
should be touching the ground. Pull it behind you for easy transporting. Adjust
the handlebar to a height that’s comfortable for you.
Screws

13
HOW TO USE YOUR JETSON BEAM
RIDING THE JETSON BEAM
SAFETY GEAR
Helmet Most serious injuries that occur while riding are head injuries. This
could be prevented by wearing a helmet.
Elbow and Knee Pads For added protection, always wear elbow and knee pads
when riding your Jetson Beam, to prevent any serious injuries.
DRIVING TECHNIQUE
Foot Position - before riding put your foot as close as possible to the front
section of the scooter, and your other foot on the ground. Make sure that your
driving route is clear.
To start riding, boost yourself forwards (as on non-motorized scooters) with
your foot that is on the ground. Please do not push the thumb throttle all the
way down, get accustomed to the acceleration of the throttle.
Immediately after boosting yourself forward, slowly press the thumb throttle
downwards, tilt your body forwards so you shouldn’t fall backwards during
acceleration. The Jetson Beam will be in motion.
Avoid putting your body pressure on the handlebars in acceleration and
deceleration! Keep one foot behind the other, (it’s more comfortable to place
one foot forward and the other one turned backwards at 70-90°, like on skate/
surfboard). It will help you gain more stability.
NOTICE: Riding, like most sports, involves risk of injury and damage. By
choosing to ride the Jetson Beam the responsibility and all inherent risk is on
you. It is crucial that you know, understand and act according to safety rules.
Turns - The turns on the Jetson Beam are commanded by the direction you
turn the handlebar/front wheel in, and leaning your body in the direction you
are turning. Before turning look at the approaching direction and make sure
turning is safe.
Braking – You have two options to brake: e-brake and foot brake. To use the
e-brake, the Jetson Beam must be powered on. Press the e-brake while on the
scooter to make it stop (being careful not to press too fast, as it may cause too
sudden of a stop/jerking motion).
To use the foot brake, tilt your weight backwards so that the brake action will
come through the feet and not trough the handlebar and steering system. Lift
your back foot and step down on the back wheel cover. It is best to learn how
to adjust your center of gravity when braking, otherwise, you could fall forward.

14
Your Jetson Beam Scooter folds up conveniently to store away easily in the
trunk of a car, in a closet, or to carry with you onto a train or bus!
Step 1 Open the Quick Release Lever and slide the expandable handlebar all
the way down. Once it’s completely stored away, lock the Quick Release Lever.
Step 2 Pull the Folding T-bar Latch out, and pull the handlebars out to the side.
Push one handlebar down at a time, and press in until they are fully stored.
Once both handlebars are folded down, bring the Folding T-bar Latch back to
its original position.
Step 3 Open the Folding Lock Lever and press the Release Button. Fold the
handlebar down towards the rear wheel until you hear a “click.” Once it’s fully
folded, close the Folding Lock Lever to secure.
Press Release Button
Fold Handlebar Down Towards Rear Wheel.
Listen For “Click” Sound.
Close Folding Lock Lever.
Open Folding Lock Lever
FOLDING YOUR JETSON BEAM
SAFE DRIVING
1. Get to know the Jetson Beam before driving it. Test your control over it.
Make your turns slowly and cautiously, and give yourself stopping distance.
2. Your driving capability - to gain control over your scooter, practice your rst
ride on the Jetson Beam in an open space with no obstacles to disturb you.
3. Recommended tires pressure in back tire: 28 psi
PLEASE NOTE: Make sure to ll the tire with air before your rst ride. Riding on
a partially lled tire will cause it go at and it will need to be replaced.

15
MECHANICAL SAFETY TESTS
Before using the Jetson Beam: Perform a visual inspection that all screws and
nuts are tight and in place. Tires and wheels: check the tires for signs of wear.
To do this- spin them to make sure that they are not yet in the need of replac-
ing. Make sure that the wheels are freely rotating from the brakes. If not, take
the Jetson Beam to the authorized distributor. Before each ride, always check
your brakes and mechanical function.
BATTERY
• Do not operate the motor while charging
• Battery level indicator in the LCD display is intended for general
knowledge (full/empty) only, and does not give a precise indication to
the battery status.
• If storing the Jetson Beam for long periods of time, make sure you
store it with a fully charged battery, and make sure to charge it once a
month.
DO NOT USE THE BATTERY IF THE SCOOTER
• Is broken
• Emits an unusual odor or excessive heat
• Presents any leakage
Avoid contact with any substance oozing from the battery. Keep the battery
away from children and pets. Exposure to the battery voltage can cause death
or serious injury.
The use, storage or charging of the Jetson Beam battery outside specied
limits may result in the annulment of the warranty, battery damage, and an inef-
fective battery charging.
CHARGING AND BATTERY
Your Jetson Beam has a charging port located at the front of the deck.
OPERATION

16
Connect the charger’s electric cable to an electrical outlet. Open the cover to
the charging port in your scooter (note: be sure to keep any liquids away from
charging port and cable), and then connect the charging cable to the scooter’s
charging port under the footboard, on the right side at the front. Always plug
the charger into the wall rst before the device. The charger offers a charging
status on the top of the charger:
Charging Light Red Battery is charging.
Charging Light Blue Charging is complete.
Once the charger is plugged into the wall and then the charging port, the
charging light should turn red, indicating that it is charging. If it does not turn
red, either the battery is full or the charger is not properly connected to the
Beam. Once the light has turned blue and charging is complete, unplug the
cable from the charging port, as overcharging your scooter can affect the ser-
vice life of the batteries.
(Please note: Always plug the charger into the wall rst before the device. If
the wall outlet doesn’t have power and you plug the charger into the unit, it
will light blue, even if the battery is not full. So always plug into the wall rst to
make sure there is power.)
Average charge time is 3 hours. Charge the battery only using tools approved
for the Jetson Beam.
To maximize your scooter’s battery performance, fully charge it for 3 hours,
once a month, or after each use of twelve hours. It is dangerous to use the
Jetson Beam when plugged into an AC outlet. Electrical shock can cause seri-
ous injury and damage the scooter. Do not attempt to open the battery. Do not
insert anything in the battery and do not attempt to open its case with any tool.
Charging Port

17
STORAGE
If you plan on storing your Jetson Beam for a substantial amount of time,
please do the following:
• If the ambient temperature of your storage area is below 32 degrees
Farenheit, please do not charge. You should bring the scooter into a warm
environment (above 50 degrees Farenheit) for charging.
• To prevent dust, cover the Jetson Beam when storing.
• Store the Jetson Beam indoors, in a dry and suitable temperature.
• Do not leave the Jetson Beam plugged into the charger for long periods of
time.
MAINTENANCE
The Jetson Beam was assembled by professional technicians. Any attempt to
independently x or change the Jetson Beam or parts of it in any way, can
cause damage to the Jetson Beam folding electric scooter, and can cancel the
manufacturer warranty given upon delivery. Please contact your authorized
Jetson dealer, or Jetson’s customer service for any maintenance needs.
Inserting an object into openings or in the battery can cause electrical shock,
injury, burns or re. Any attempt to open the battery case will damage it and
cause release of dangerous toxic substances. Unplug the Jetson Beam from
the outlet before performing any maintenance. Carry the Jetson Beam accord-
ing to all applicable local and national requirements.
PROTECTION AGAINST OVER-DISCHARGING
The Jetson Beam has a built-in smart over-discharging protection system that
will actively cut off the power when the scooter is in a locked or shutdown state
and battery power is too low. Once the scooter goes into the over-discharging
protection mode, it needs to be awakened by charging. If the scooter remains
un-awakened after 30 minutes of charging, please contact the authorized
dealer of the Jetson Beam, or Jetson’s customer service.
JETSON BEAM CARE AND MAINTENANCE

18
TO QUALIFY FOR WARRANTY SERVICE
1. You must present a copy of the sales receipt from an approved retail partner
within 90 days of purchase.
2. This product can not be used for rental or commercial use.
3. This product can not be used for competition.
LIMITATIONS OF LIABILITY
• This Limited 1 Year Warranty is non-transferable after the Product’s initial sale.
• No unapproved modications can be made to the Product, its performance
or otherwise, in order for this Limited 1 Year Warranty to remain in effect.
• No reimbursement is provided for towing, loss of time, loss of use,
inconvenience, incidental or consequential damages.
• Warranty is void if weather related water damage is determined. Owner is
responsible for storage and protection from weather.
• Jetson®makes no warranty with respect to products or trade accessories
not made by Jetson®, including, but not limited to, motors, tires, wheels and
batteries, such products or trade accessories, such items being subject to the
original manufacturer’s warranty, if any.
• This Limited 1 Year Warranty does not cover minor surface blemishes, rips,
tears, or other cosmetic damages due to normal use, or other intentional or
unintentional damage to the Product.
• This Limited 1 Year Warranty will not cover any damage which results from the
application of improper cleaners, solvents or chemicals to the Product, water
damage, smoke or soot, or from exposure to salt-water, sea breeze or salt.
• This Limited 1 Year Warranty will not cover any damage which results from
aging, such as fading of paint, deterioration of plated surfaces, deterioration of
rubber or plastics, or rusting.
• This Limited 1 Year Warranty does not cover improper repair or misdiagnosis
of problem.
• This Limited 1 Year Warranty covers only parts and labor due to manufacturer
defect.
• Damage due to misuse or neglect, use other than as specied in the Owner’s
Manual, or use under abnormal conditions are not covered by this Limited 1
Year Warranty.
OWNER’S WARRANTY RESPONSIBILITIES
As the vehicle owner, you are responsible for the performance of the required
maintenance. You should maintain a record of all maintenance performed
your vehicle and retain all receipts covering maintenance on your vehicle. You
may be denied a warranty claim solely because of your failure to ensure the
performance of all scheduled maintenance or lack of maintenance records or
receipts. As the vehicle owner, you should be aware that you may be denied
your warranty coverage if your vehicle or a part has failed due to abuse,
neglect, improper maintenance, or unapproved modications. For any issue
regarding your Jetson®product, call toll free [phone].
LIMITED 1 YEAR WARRANTY

19
PRODUCT REGISTRATION
Please complete and mail this card within 10 days of purchase or go to
https://www.ridejetson.com/product-registration.
Name: _____________________________________________________________________________
Address: ____________________________________________________________________________
City
, State,
Zip: ______________________________________________________________________
Email: ______________________________________________________________________________
Home Phone: ___________________________ Gender: _____________________________
Pu
rchase Date: _________________________ Purchased Fr
om: __________________________
Serial Number: ______________________________________________________________________
Is this your first
Jetson pr
oduct? ______________________________________________________
Other similar pr
oduct owned befor
e: _________________________________________________
How did you hear about the Beam? ______________________________________________
_____________________________________________________________________________________
Co
mplete this form and mail it to:
Attention: Product Registration
Jetson Electric Bikes
1 Rewe Street
Brooklyn, NY 11211
Why did you buy this pr
oduct?: For myself
For my child
For my grandchild
Gift for someone else (adult)
Gift for someone else (child)
