ezee Sprint User manual

eZee Kinetics Technology Co. LtdAll Rights Reserved. 2013
Simply Moving
User Manual

Simply Moving
Dear Customer,
Thank you for your purchase of your eZeebike. You’re a step closer
to a great way of greating around thats fast, fun and friendly to the
environment.
Using a technology called Pulse Wave Modulation control, our
brushless hub motors do not wear out like regular DC motors.
Planetary reduction gears itted in the hub gives our motor a
powerful torque. Combined with your pedalling, eZeebikes latten out
those hills and overcome headwinds with a breeze.
Under normal cruising conditions (15 km/h), the motor draws
~5 amps at 150W, a torque of 5 Nm and an eiciency of ~ 83%. At
20 km/h, its power consumption is 1 kwH for 100 kms. Your ride is
eicient and lots of fun!
While our pledge to quality means our components are high value
and reliable. It’s your part to understand the safety implications and
the possible risks of cycling. So take some time and read this manual.
It explains the bike in detail, how to take care of it, so that you can
enjoy using the bike for years to come.
WW Ching
Chief eZee Oicer
2

Table of Contents
2 Introduction
4Legal regulations
5Technical data
6Warranty conditions
7Assembly
8Checklist
9Battery charging
11 Display console
12 How eZeebike works
13 Maintenance
14 Afterword
A PartsIdentication
BReference / Serial No. Registration
3

EU regulations state that your vehicle is an Electric Powered Assist Cycle (EPAC) when the following conditions are met, and is now governed by the latest European regulation
EN15194:2009 for EU. [ EU directive 2002/24/EC Chapter 1 Article 1 1(h) ]
“Cycles with pedal assistance which are equipped with an auxiliary electric motor having a maximum continuous rated power of 0.25 kW, of which the output is progressively
reduced and inally cut o as the vehicle reaches a speed of 25 km/h or if the cyclist stops pedaling.”
Conforming to EN reg., the power assist of an eZeebike only functions while the rider is pedalling. The means of controlling the power level of the assistance adjusted by the power
setting from the console or throttle.
Legal Regulations
In USA it is governed by Consumer Product Safety Commission 16 CFR Part 1512 requirements for low speed electric bicycles.
USA regulations allow an ebike throttled maximum speed of 20 mph. eZee bike made for the USA has a motor nominally rated at 500 watts.
For markets that are not subject to EN reg. the bike comes with default mode that allows PAS or ebike mode simultaneously.
Electric bicycles does not require a license or moped certiicate, there is no age limit and you can take cycling paths. It conforms to regulations of normal bicycles. Legal
requirements concerning insurance of your bicycle may dier, so do ind out about the rules and regulations in your country.
4

EC Declaration of conformity 2013
(Only applicable to models requiring registration)
The manufacturer Shanghai eZee Kinetics Technology Co. Ltd
259 Feng Yong Road, Feng Xian,
Shanghai, People’s Republic of China
Telephone [phone]
herby declares that the following products:
Product name: eZee electric bike
Type names: Sprint, Bolt, Forza, Torq, Cadence, Street, Quando, Expedir, Carro
Year of manufacture: 2013 / 2014
are in accordance with:
EN 15194: Electrically Power Assist Cycles (EPAC), with the inclusion of conformity for
Electro Magnetic Compatibility.
EN 14764: City and Trekking cycles - Safety requirement and test methods.
EC and UL certiied charger.
Technical documentation is available upon request.
On behalf of Shanghai eZee Kinetics Technology Co. Ltd:

Technical Data
Motor DC brushless hub motor with planetary reduction gears
Nominally Rated - 250W (EU)
Nominally Rated - 500W (US)
Battery Lithium Ion with battery management circuit
36V 11Ah (370 Wh)
36V 15Ah (540 Wh)
36V 21Ah (756 Wh)
36V 28Ah (1000 Wh)
Low voltage protection 28 V
Discharge temperature limit -15°C to +55°C
Controller PWM
LED self diagnostic system
Overload protection 20 amps
Thermal protection
Short circuit protection
Charger 4 amps
Charge time 4 hrs for 15Ah
Charging temperature +5°C +35°C
Interface Forward magnetic motion sensor 12 pole and dual hall
5 levels Power and speeds settings and or throttle application.
5 levels battery gauge
Fuse 30 amps
Ching Wai Won
CEO, Managing Director
5

The following guarantee conditions complement your legal rights.
How the guarantee applies:
We guarantee against material or construction defects under the following conditions.




How the guarantee does not apply







How the guarantee covers



Warranty Conditions
6

7
Unpack
Carefully remove the bicycle by lifting it straight out of
the box (beware of the carton staples.) Remove packing
material around the bike and stand the bike on a clean
lat surface. Be sure to keep any part packages. Discard
box and packaging material only.
Dispose responsibly, recycle when possible.
Checklist
This box should contain....the eZeebike!
An accessory box containing.
a. 3 Ignition keys
b. 1 Pair of pedals
c. 1 Battery charger
d. 1 Power cord
e. 2 Fuses (30 amps)
f. Nylon ties
g. Heat shrink tubes (assorted pre-cut sizes)
h. 1 Hex Key #5
i. 1 Hex Key #3
j. 1 eZeebike User manual
k. Bike component manuals
j. 1 Battery
Tools required
Tools are the irst step to proper assembly, you will need
Allen / Hex key metric set
Philips head screwdriver
Open-end lat wrenches metric measurements 6mm -
17mm
Assembly
Front wheel
Insert the hub motor wheel into the fork, ensure it is
snugly itted in the dropout slots. Tighten nuts on both
sides till the wheel is secured. Tightening torque 35
Nm
Seat post
Insert into the seat tube and align. Tighten clamps and
ensure seat is irmly fastened. Tightening torque 16 Nm
Do not adjust the seat post beyond its maximum
extension mark.
Front Mudguard
The supports are attached to the sides and top of the
front fork, the mudguards are made of polycarbonate
and should not rattle when securely fastened.
Brakes
One of the most important safety features on the bicycle.
To minimize the risk of injury, ensure they are corrected
adjusted.
Ensure that the brakes are centered and that the wheel
spins freely when brakes are not applied.
If you have little experience with bicycle maintenance.
We recommend you get this done with your local bike
shop.
Accessories
Install any optional accessories you have purchased with
your bike. Read the manufacturer’s manual provided.
Battery
Insert key into keyhole located by the controller box and
turn key counter clockwise while pressing it in, so that it
arrives in the open position. Release the catch located
at the underside of the saddle to lip it over. Locate
the battery langes in their slots in the battery holder;
then push the battery irmly into the holder until the
connecting pins are irmly in the battery sockets.
The it can be tight when new, so it may be required to
apply gentle pressure. Once the battery is in position,
lock into place by turning the key one click clockwise
to the “OFF” position. Ensure that the key is in “OFF”
position until you are ready to ride.
Do not use excessive force to it the battery, which could
result in damaging the connection sockets or pins.
If there is an A/C outlet near to where your bicycle is
parked. It may not be necessary to remove the battery
from the bicycle to charge.
Tyres
Ensure that the tyres are inlated to the correct pressure
of 45~ 60 psi. Well inlated tyres enhances the comfort,
safety and eiciency of your ride. Do not make max.
inlation of 75 psi, it makes an unfortable ride. Check
reommended inlation pressure as marked on the tyres.

8
Usage
The eZeebike is best described as a city / trekking bike and is best suited for usage
in urban environment and roads. While cycling, it is your responsbility to be attentive
of your environment and traic rules, as this concerns the safety of all who share the
paths, especially you.
Wear shoes that stay on your feet and grip irmly to the pedals. No barefoot or
sandles.
Dress to be visible on the road and avoid loose clothes that will tangle with moving
parts of the bicycle.
Keep your speed at levels appropriate to road conditions
Be aware of wet weather conditions, as these aect braking distance.
Brake earlier than you normally would on dry roads.
Familiarise with the traic rules in the country you are riding in.
Avoid cycling in poor weather and visibility conditions such as fog, night, heavy rain
and snow. Keep your lights on in such conditions.
Familiarise yourself with the usage of the bike and how to maintain it.
Checklist
Inspect
Before every ride, make a quick inspection of your bike’s mechanical and electronic
features. Be safe, not sorry.
Frame & fork
Visually check for damage, do not ride if bent or fractured.
Wheels and Tyres
Check for missing or damage spokes. Feel spokes to ensure tightness. wheels should
be true (straight) and tyres inlated to its correct pressure.
Handlebar and stem
Tightened irmly in the ‘face forward’ positions, the handlebars will rotate the front
fork and wheel, ensure that the grips are also irmly seated.
Brakes
Check brake functions on both front and rear brakes.
Brake cables should remain unobstructed by other cables or accessories.
Chain
Turn crank arms to ensure chain runs smoothly. Keep the chain lubricated and clean.
Chain tension may need adjustment or tightening if it is without suicient tension.

9
a. Male charging plug
b. Charging cord
c. Charger speciications
d. Charger serial no.

1. Fuse / Fuse holder (30 amps)
2. Battery grip
3. Charging socket
4. Battery slot guides
5. Battery lock slot
6. Serial number / information
Battery Charging
a.
b.
c. d. e. f. g. h. i. j. k. l.
e. Cooling fan
f. Fuse 10 Amps
g. Charger ‘ON’ LED
h. Charging status LED
i. Warning label
j. Power switch
k. A/C voltage switch
l. Power cord socket
Before your irst ride, the battery needs charging. Bring it to a wall socket. (220V - 230V AC EU / 115V AC US)
Insert charging plug into socket on battery and connect charger power cord to A/C outlet. Turn on A/C outlet. Turn the ‘1’ switch on the charger.
Do not remove the plug by pulling the cord, always grip the charging port by its metal body.
Check the indicator lights on the front of the charger.
RED indicates that the charger is connected and running from an A/C outlet.
YELLOW indicates that the battery is charging
GREEN indicates that the battery is fully charged
It will take 4 hours to fully charge a 14Ah battery. You may interrupt the charging at any time.

10
As Li Ion batteries do not suer from memory eect, it is not required for the battery to be empty to commence a recharge.
Top-up charging everytime you’ve completed your cycle ride is recommended.
Kept in good condition Li Ion battery will perform at least 350 full charge cycles, with a retention of 70% from its original capacity.
Please use only the Li ion charger as provided.
Sometimes after temporary disconnection, the charging status light may give a false green reading. To verify that your battery is fully charged, switch the charger o, wait for the
charger lights to go out and switch it back on again. When the battery is fully charged, the charging status light should quickly return from amber to green,
The battery may be also charged on the bicycle, do make sure that the bicycle is switched o when charging.
If the battery refuses to accept a charge, refer to your eZee dealer for more information.
Battery charging is automatically regulated, there is no danger of overcharging. However, we strongly advise that you disconnect the battery and switch the charger o when the
charging process is completed, and not to leave it on unattended.
Do not charge the battery in wet conditions.
Never allow children to play with the battery or charger.
Do not leave your battery in a fully discharge state for long periods of time. The battery will continue to self-discharge, resulting in damage.
Battery Charging

11
Power On
When the electric bike is switched on, the display will boot, lighting all the LED lights for 2 seconds before entering normal operation.
Basic Operation
Power level in blue LED shows the level of electric assistance in pedelec or power assist mode.
There are 5 levels of assistance and power o when all the blue LED lights are o.
At least one blue LED must be on to have any power on (e.g. activating the throttle)
Display console

b. Power Assist Level / Mode Selection Indicator (5 Blue)
c. “Up” button
d. “Down” button
Battery
Power
c.a.
d.b.
Setup Menu
Hold the button for 5 seconds to enter setup menu.
Use or button to select the appropriate settings. In menu setup, hold the ‘Down’ button for about 3
seconds to save.
Mode Selection
Mode 1: (Default) Pedelec / EBike (US): Power Led Bar shows the assist power level. When throttling, it
switches to EBike mode.
Mode 2: Pedelec (EU): Power Led Bar shows the assist power level. Throttling will be in 6km EBike mode.
Mode 3: Option for BB torque sensor with proportional 5 power levels.
Mode 4: Pedelec: Responds to throttle / assist level. Power LED Bar shows the current (amps) level.
Mode 5: EBike (Cruise): Responds to throttle (from gauge). Power LED Bar shows the current (amps) level.
‘Up’ button set cruise. EBrakes deactive cruise.
The bike will come set up with the mode according to your country legal requirement. Any changes are
made may aect the legal status of your bike.

12
How eZeebike works
Your irst ride
Before you wheel your bike out into the world, we recommend you practice handling the bike in a safe area away from obstructions and traic. The motor may look small, but it’s
powerful ! You’ll be riding faster than you think.
Turn the key to the ‘ON’ position. A red LED will illuminate below the key socket. If the light lashes, read the Troubleshooting section of this manual. If it shines steadily, you’re ready
for the next step.
EPAC / Pedelec
As you pedal, rotation on the crank is picked up by a sensor in the bottom bracket. This allows the drive system to be engaged.There are 5 levels of speed/power selection on the
console.
EBike
The motor runs as soon as you turn the throttle. Ensure that you are seated and ready to ride o before you use the throttle
In E-bike mode, the range of your bike will be approximately 40 kms (25 miles) with a 10ah battery. The hillier the terrain, the less you pedal, shortens your range. While EPAC,
judicious use of gears, power assistance all contributes to increasing the mileage you can get out of your ride to about 60 kms (40 miles).
You can always choose to ride your bicycle as an ordinary push bicycle.
Battery power consumption
With a fully charged bicycle, the battery level gauge shows ‘green’. As you cycle, the battery power drops and the gauge will show the state of charge remaining. When it remains
on ‘amber’ and dips into ‘red’, you have approximately 20% of the charge left. Best to recharge the battery soon.
Continued use of an empty battery by ‘pulsing’ will cause deep discharge, this is detrimental to the battery and reduces its lifespan.
Lighting system
Front and rear LED lights are powered by the main battery
Lock
Turning the key to the ‘OFF’ position and removing it will shut the system o and lock the battery in place. Use a chain lock to further secure your bicycle
Central support stand
This stand supports your bike straight up. Use your feet to depress the stand downwards and pull the bike in reverse. Do not sit on the bike with the stand parked.
Luggage rack
If you plan to carry luggage on the rear, make sure everything is securely fastened and clear from the rear wheel. Do however, take note that the load limit is 25 kgs.

13
Maintenance
Maintaining your bicycle ensures you’ll get the most out of every ride and out of the entire life of your eZee bike. How much of your bike’s maintenance you can do yourself will
depend on your knowledge, skill, experience and whether you have the necessary tools for the job.
Learning from available cycling literature and joining cycling communities can be an enjoyable way of improving your skill and knowledge about maintaining bicycles. Beyond this
manual, it is good to consult your LBS and eZee dealer for advice regularly.
Before every ride
Mechanical safety checks, use a fully charged battery, visual inspection for damages.
Every 150kms (100 miles)
Clean the bike, incl. chain rings and sprocket. Clean and lightly oil the chain and gears.
Every 20 - 30 hours of riding
Squeeze the brakes and rock the bike to check for any looseness with each forward of backward movement. If the headset is loose, have your dealer check it.
Lift the front wheel and rotate handlebars to check for tightness of steering, it may be necessary to lubricate ball bearings.
Check and recalibrate the brakes, replace if worn out.
Every 20 - 30 hours of riding (continued)
Squeeze spokes in adjoining pairs between your thumb and index inger. They all should have the same tension. Have your dealer respoke or true the wheel if necessary.
Check cables for rust, kinks and fraying, have your dealer replace them if necessary.
Repairing a punctured tyre.
If you have a punctured tyre, we recommend that you get a specialist to carry out the repairs. You can always of course consult a specialist and carry out the repairs on your own.
Changing Tyres on hub motor wheel
With the hub motor wheel, there are additional steps in the case you require the entire wheel to be removed from the bike. A philips head screwdriver will be required to open
the cable housing (shown on left) to irst unplug the wires than run from the motor to controller.. Unplug these before proceeding to remove the front wheel. Be mindful of the
tightening assembly sequence of washers, nuts and spacers.
Hub motor and general inspection
After 5,000 kms (3,000 miles) of cycling. We recommend you arrange to have a thorough inspection of your bicycle by an eZee dealer.

14
Afterword
At eZee, our mission is simple - continue to make the best
electric bikes and oer exceptional service. We’re constantly on the
lookout for ways to improve our bikes and apply solutions to our
bikes to enrich lives everywhere.
We would like to invite you to join our eZeebike community
to discover the latest news and happenings in the world of electric
bikes. Participate in our events and competitions and help spread the
word on the street that the new cycling revolution has arrived.
We want to get to know and thank everyone of you. If you
have anything to ask, to comment or suggest; perhaps you have an
idea, a project to discuss, or simply would like share your stories and
photos with us. Contact us directly, we want to hear from you!
Here’s wishing you, safe, happy and eZee riding!
www.ezeebike.com
http://www.facebook.com/Ezeebikes

Customer Name :
Contact Details :
Motor s/no. :
Charger s/no. :
Controller s/no. :
Battery serial no. :
Frame no. :
Ignition key no. :
Reference
Proof of purchase
Keep your proof of purchase with vendor’s receipt,
with the date of purchase clearly marked.
3 Ignition / lock keys comes with the bike, please
keep 2 keys in a place where you could remember
where it is. Use only one key at a time.
Serial Numbers
Record the serial numbers found on your motor,
frame, controller, charger and battery here for
reference. These are important data for us to
understand and troubleshoot your eZeebike.
Dealer Copy
Dealer Information
B
Customer Name :
Contact Details :
Motor s/no. :
Charger s/no. :
Controller s/no. :
Battery serial no. :
Frame no. :
Ignition key no. :
