NIXON NJT02C103 User manual

SIDE STEP
User Manual
2019-2023 Jeep Gladiator 4 Door
Model:
NJT02C103
Material:
Q235A
Product Dimensions:
82.6 x 6.3 x 3.5 inch
Package Dimensions:
85.4 x 10.6 x 9.4 inch
Product Weight:
68.67 lbs

※Thank you for purchasing the SIDE STEP. Please read this manual carefully and
keep it properly if you need to refer to it afterward. If you need any support or
assistance, please contact us with your product model number and order number,
and our support team will help you solve problems.
※This product is designed primarily to enhance the appearance of the vehicle. Do
not rely in any way on the components of this product to protect against injury or
death in the event of an accident. To reduce the risk of serious injury or property
damage, please read all safety messages and understand all instructions and
procedure notices before attempting to install or use this product.
※Properly torque and recheck fasteners and security of step tread after 250 miles
and inspect frequently. Do not use if damaged.
※Side Steps are heavy, and we strongly suggest the assistance of an able-bodied
assistant during the lifting and installation of your Side Step.

REQUIRED TOOLS
Socket
Ratchet
Wrench
Scissors
Masking tape
Safety Glasses
Parts Information
Parts NO.
Parts Name
Size
Line Graph
Qty
Color
/
Side Step
/
2
Black
/
Left/Right Bracket
/
6
Black
/
Left/Right Support
Bracket 1
/
4
Black
/
Left/Right Support
Bracket 2
/
2
Black
B20
Hex Bolts
M8x25-8.8
38
Dacro
Black
W16
Spring Washer
Φ8
38
Dacro
Black
W19
Flat Washer
Φ8x24x2
68
Dacro
Black
N22
Hex Nuts
M8
32
Dacro
Black
/
Ribbon
5x250
10
Black
*Note: spare parts such as B20, W16，W19, N22 are provided with 2PCS
each (included in the number of parts details).

Installation Instructions
※Note: This installation manual takes a single side as a sample, please repeat the
steps for the other side.
Step 1: Open the carton and take out the parts. Check whether the number of
components is complete.
Step 2: Install the bracket and support bracket.
①Left ②Left ③B22 ④W16 ⑤W19 ⑥N22
x1 x1 x1 x1 x2 x1
①
②
③
④
⑤
⑤
⑥
①Left ②Left ③B22 ④W16 ⑤W19 ⑥N22
x2 x1 x2 x2 x4 x2
①
②
③
④
⑤
⑤
⑥

Step 3: Remove the original side skirt and clean the surface of the rocker panel to
ensure it is free of dust, dirt, and debris.
Step 4: Install the brackets.
Front of the car
Mounting Holes
①Right ②Right ③B22
x2 x1 x9
④W16 ⑤W19 ⑥N22
x9 x9 x6
Front of the car

②
Car
①
①

Step 5: Install the Side Step.
②③④
① ②B22 ③W16 ④W19 ⑤N22
x1 x6 x6 x12 x6
①
bracket
①
Car
②③④⑤ x2

Step 6: Adjust the balance of the Side Step and the car side, and tighten the
corresponding bolts.
Step 7: Adjust the balance of the pedal to the ground and tighten the corresponding
bolts.
Tips: Use a stretch ruler to measure and balance the left and right sides of the pedal.
Please ensure that the pedal has the same distance to the ground on both sides.
Step 8: Connect the Bracket light wiring.
Step 9: Installation of a Side Step is complete. Please do periodic inspections of the
Side Step to make sure that all hardware is secure and tight.
④
④
bracket
①
①
bracket
⑤
②
③
