ntroduction
The present operation manual serves for the studying and correct using the pH-
meter Industrial 4122.P (hereinafter – pH-meter)
The manual contains the purpose, principle of operation, design, technical
characteristics, presents data on the sequence of operation and monitoring of the
technical condition.
PH-meters are engineered for the sphere of state regulation ensuring the uniformity
of measurements are subject to checking.
PH-meters which are not engineered for the sphere of state regulation ensuring the
uniformity of measurements are subject to calibration.
Checking (calibration) is performed in accordance with the procedure set in the
instruction «pH-meters industrial 41. Calibration procedure. АВДП.414332.001 МП»
pH-meters are manufactured in compliance with spec. ТУ 4215-085-10474265-
2006.
1 Purpose
1.1 pH-meters industrial are designed for the index activity measurement of the
hydrogen ion (pH) and temperature (T) of the analyzed liquid.
pH-4122.P can measure an oxidation-reduction potential (ORP), and a flow rate (F).
1.2 pH-4122.P has two galvanically isolated measurement channels. Each channel
has two measuring inputs: pH (or ORP) and T. Additionally the pH-meter has an input
for the fluid flow sensor connection (F). The pH-meter in the wall-mounted design has an
outlet for the output digital signals external unit БВД-8.2 connecting for alarm system. If
БВД-8.2 unit is not provided, the pH meter can have one discrete output. The pH-meter
of a panel performance has built-in digital outputs (relay).
pH meter provides a digital display of the measured values (pH and temperature
T), converting them to the proportional values of DC current analog outputs, data
exchange via RS-485 digital interface, signaling the overranging of the measured
parameters, as well as archiving and graphically display of the the measurement results.
pH meter pH-4122.P (transmitter) has a monoblock design.
1.3 Applications: thermal power, chemical, petrochemical and other industries.
1.4 Climatic execution as per GOST 15150-69*, kind of execution - УХЛ 4.2*,
but at a temperature from 5 to 50 ° C.
Climatic modification group as per GOST R 52931-2008 B4.
pH meter service conditions:
- ambient air temperature: (5... 50) ºС;
- ambient air relative humidity: 80 %;
- atmospheric pressure (84... 106) кПа.
Note: GOS * - Russian state standard for NPP
Instruction manual PH-ME ER Industrial 4122.P 5

2 Technical data
2.1 nput
2.1.1 Number of measurement channels: 2.
2.1.2 Measuring range pН: (0… 14,00) рH.
2.1.3 Measuring range ORP: ±2000 мВ.
2.1.4 Max temperature of the analyzed environment 95 ºС.
2.1.5 Nominal static characteristic (NSH) of the resistance temperature detectors (TD)
Pt (W100 = 1,3850).
Notes
1 NSH type and a TR resistance at 0 ° C (R0) within the range of (2000 ... 50) oh s, is set
progra atically.
2 Max te perature of the analyzed environ ent is deter ined by the para eters of pH electrodes.
2.1.6 The flow measuring range (with a sensor FCH-M) (0,9... 48) l/h.
2.2 The electrode system
The electrode system can be applied in one of the following variant:
- combined pH electrode, for example ASP type (measuring and auxiliary electrodes in
the same case), with the built-in temperature sensor;
- combined pH electrode, for example ID type (measuring and auxiliary electrodes in the
same case), with a single temperature sensor;
- individual measuring and auxiliary electrodes, for example ЭС-1 и ЭВЛ-1М3.1 type
with a single temperature sensor;
- combined ORP electrode type SZ275 or ASR2811.
2.3 Analog output
2.2.1 Number of analog outputs 2.
2.2.2 Output unified DC signal (is set programmatically):
– (0… 5) mA at the load resistance (0... 2) kilohm;
– (0... 20) mA at the load resistance (0... 500) ohm;
– (4... 20) mA at the load resistance (0... 500) ohm.
2.4 Discrete outputs
2.4.1 Number of signals in the analyzer of a panel design 4.
Type - relay switching "dry contact", ~ 240 V, 3 А.
2.4.2 Number of signals in the wall-mounted analyzer with an unit БВД-8.2 8.
Type - relay switching "dry contact", ~ 240 V, 3 А.
2.4.3 Number of signals in the wall-mounted analyzer without an unit БВД-8.2 1.
Type - optorelay normally opened = 100 V, 150 mA (dial-signal parameters can be
changed due customer's request).
2.5 Digital nterface
2.5.1 Physical layer RS-485.
2.5.2 Data link layer Modbus RTU Protocol.
Instruction manual PH-ME ER Industrial 4122.P 6

2.5.3 Data rate from 1,2 up to 115,2 kbaud.
Selecting the device address, data rate and other interface parameters are set
programmatically.
2.5.4 The frequency of the updating registers "measurement result" (LAN) 5 Hz.
2.6 ndication
2.6.1 Indication of the measured parameters is performed with a graphical LCD display
(display) in absolute terms.
2.6.2 Single LED indicators:
– four red LEDs for display the light alarm modes;
– two-color display for the interface communication.
2.6.3 Display update rate 2 Hz.
2.7 Control
2.7.1 Manual control is carried out by means of four buttons and a LCD display using
the menu.
2.7.2 Control of the upper level system is performed via the Modbus network
2.8 Power
2.8.1 Power supply voltage of 50 Hz (100... 244) V.
2.8.2 Power consumption 15 VA.
2.9 Structural specification
2.9.1 Dust and water protection of the wall-mounted pH meter is per GOST 14254-96
IP65.
2.9.2 The packed pH-meters are resistant to the vibration effects per GOST Р 52931-
2008 group F3.
2.9.3 Overall dimension (H×W×D) (96×96×124) мм.
2.10 Reliability index
2.10.1 The device is designed for twenty-four hour operation. Warm-up time after the
switching on is more than 15 min
2.10.2 Probability of no-failure operation 0,9
2.10.3 Average time between failures 20 000 h
2.10.4 Average lifetime 10 years
3 Specifications
3.1 The limit of the allowable value of the absolute error in pH measurement:
- with the electrodes 102010, ASP, ID ± 0,05 pН;
- with the electrodes ЭСК-1, ЭС-71, SZ ± 0,1 pН.
3.2 The limit of the allowable value of the absolute error in the analyzed environment
temperature measurement ± 0,5 ºС.
3.3 The limit of the allowable value of the complementary absolute error in pH
measurement caused by the variation in the analyzed environment temperature for every
25 °С (in a ATK mode) relatively 0 ºС within the temperature range:
Instruction manual PH-ME ER Industrial 4122.P 7

(0… 50) ºС ± 0,05 рН.
3.4 The limit of the allowable value of the complementary absolute error in pH
measurement caused by the variation in the analyzed environment temperature for every
10 °С within the temperature range:
(5… 50) ºС, ± 0,05 рН.
3.5 The limit of the allowable value of the complementary absolute error in pH
measurement caused by the variation in a measurement electrode resistance from 0 till
1000 Mom, not exceeding ± 0,05 рН.
3.6 The limit of the allowable value of the complementary absolute error in pH
measurement caused by the variation in a subsidiary electrode resistance from 0 till 20
Kilohm, not exceeding ± 0,05 рН.
3.7 The limit of the allowable value of the basic absolute error in ORP measurement, not
exceeding ±3 мВ.
3.8 Converting the measured pH (or ORP, temperature, T, flow rate V) to a standardized
current output is calculated by the formula:
Ioutput=Imin+Irange
pH measured −pH min
pH max−pH min
,
where, pH measured – the measured pH;
pH min, pH max – the minimum and maximum pH values for conversion into
the current output signal (set in the "Settings", "Output signal" menu);
I range – the range of the current output of 5 mA, 20 mA and 16 mA for ranges
(0 ... 5) mA (0 ... 20) and mA (4 ... 20 mA), respectively;
I min – the minimum output current value of 0 mA, 0 mA or 4 mA for ranges
(0 ...5) mA (0 ... 20 mA) and (4 ... 20 mA), respectively.
Note - For the values of ORP [ V], T [° C] and V [l / h] this for ula looks si ilar.
3.9 The limit of the allowable value of the basic reducial error in the converting the
measured value into an output current ±0,25 %.
4 Completeness
The set of the pH meter delivery is illustrated in Table 1:
Table 1 - Delivery set
№ Specification Qty. Note
1 pН meter industrial рН-4122.I (transmitter) 1
2 pН meter industrial рН-4122.I. Instruction manual 1
3 pН meter industrial рН-4122.I. Communications
interface. Application manual
1
4 pН meter industrial рН-4122.I. Passport 1
5 Combined pH electrode with the in-built temperature
sensor
optionally
6 pH measuring electrode optionally
7 pH subsidiary electrode optionally
Instruction manual PH-ME ER Industrial 4122.P 8

8 Combined ORP electrode optionally
9 Temperature sensor optionally
10 Hydropanel HP-4122 optionally
11 Hydropanel HP-4122. Instruction manual
12 Discrete signal output unit БВД-8.2 optionally
13 Discrete signal output unit БВД-8.2. Instruction manual optionally
14 Discrete signal output unit БВД-8.2. Passport optionally
15 pН meters industrial рН-41. Test procedure 1
16 pН meters industrial рН-41. Calibration procedure 1 optionally with
ORP measuring
Example of the order:
« рН-4122. — pH meter industrial dual channel». Additionally is indicated the
number of the measurement channels (one or two), the specific measurements ranges, the
output signals ranges, the types of pH electrodes.
5 Arrangement and principle of operation
5.1 Arrangement of transmitter
5.1.1 The pH meter transmitter is an electronic unit placed in the housing.
5.1.2 The electronic unit consists of two printed circuit boards: display board and the
main board, connected to each other by means of a flat cable.
5.1.3 The main board has a power supply and sensors connectors, analog outputs and a
measuring part galvanically isolated from the supply line on.
5.1.4 The display board has a power voltage converter, display and digital interface
controls.
5.1.5 The front panel (Appendix B) has the following elements:
– graphic LCD display with LED-backlit display of the measured value and the set
parameters;
– two-color LED single interface indicator (RS);
– LED single red indicator to inform about the selected alarm settings (1, 2, 3, 4);
–{- left, return, cancel;
–я- up, right to the figures positions;
–ч- down, and number increase;
–}- right, selection and left with the fixation.
5.1.6 The meter is a microcontroller device. The first microcontroller processes a signal
from the sensors providing analog-to-digital conversion. The second microcontroller
provides a keyboard control, indicators and data exchange over a local network.
5.1.7 In the presence of the interface it is possible to read the measurement results and
device control over the local Modbus network. The meter display has a priority in
control device.
5.1.8 To prevent an unauthorized adjustment or tampering impairing the measurement
results the analyzer body cover may be sealed.
Instruction manual PH-ME ER Industrial 4122.P 9

5.2 Principle of operation
5.2.1 The oprinciple of the pH meter operating is based on the direct potentiometric
method for the activity determination of hydrogen ions in the test liquid while the
measuring the electromotive force (EMF) of the electrode system (ES), formed by the
measuring electrode and reference electrode immersed in a tested liquid.
The pH meter provides the measurement of the analyzed liquid temperature (T) by
applying the converting the thermometer resistance to a temperature resistance according
to the nominal static characteristic (NSCH).
The pH meter allows to provide the measurement of the liquid flow rate (V) by
applying the converting the frequency pulse signal of the flow sensor.
In the calculation of pH the influence of temperature on the pH-electrode
sensitivity is considered.
In general, the pH of the tested environment is calculated by by the formula:
pH =− E−EИ
0,1984×S
100 %×(273,15+to)
+pH И
,
where рН – the measured pH value of the analyzed environment;
Е– EMF value on the ES output, mV;
tº – the measured temperature value (by the resistance thermometer
automatically (ATC)) or specified manually (RTC)°С;
рНи– the coordinate of the isopotential point of the pH electrode;
Еи– the coordinate of the isopotential point of the pH electrode, mV;
S– the slope of pH electrode, %
The compensation of pH temperature dependence of the ultrapure water (UPW) is
carried out according to the procedure МУ 34-70-114-85.
5.2.2 EMF measuring between the ES electrodes is produced by the differential
switching circuit. In this scheme, the analyzed liquid should be grounded (Appendix C).
5.2.3 ORP measuring, in millivolts, is made with a pH meter, as a high-resistance
millivoltmeter, in a direct voltage mode measurement - "ORP mode."
In general, the ORP of the tested environment is calculated by by the formula:
where ORP – ORP measured value of the analyzed environment, mV;
Е– EMF value on the ES output, mV;
ЕСМ – the displacement of ES characteristics of the ORP electrode, mV;
S– the slope of ORP electrode, %
5.2.4 For the measuring the redox potential (ORP) the electrode system is used,
consisting of a redoxometric (platinum or gold) measuring electrode and a silver chloride
reference electrode.
5.2.5 The temperature by the measurement of ORP is not considered.
Instruction manual PH-ME ER Industrial 4122.P
10
ORP=(E+EСМ )∗100 %
S

6 Directions related to the safety measures
6.1 The pH meter degree of protection against the electric shock is class I according to
GOST 12.2.007.0-75.
6.2 Only persons specially trained for a manual operation, familiar with general safety
regulations for operation of the electrical equipment having voltage of up to 1000 V,
passed the examination for a group of electrical safety not less than III, and having a
certificate of the established sample are allowed to install and maintain the pH meter.
6.3 The pH meter must be grounded.
6.4 The pH meter connection must be made in accordance with the marking with supply
voltage de-energized..
6.5 When operation and maintenance of pH-meter it is necessary to follow the
requirements of the following documents:
- "Rules of the technical operation of electrical consumers";
- "Safety regulations for the operation of electrical consumers."
7 Preparation for operation and operation procedure
7.1 Outer inspection
After unpacking it is necessary to check the following conformities:
– the pH meter must be completed in conformity with the certificate;
– the serial number must correspond to that specified in the certificate;
– the analyzer must be free of mechanical damages.
7.2 Operation procedure
7.2.1 Connecting the electrode system
ES Connection is performed according with the external connections diagram
(Appendix C).
7.2.2 Mounting of the pH meter transducer (MT)
When installing a pH meter it is necessary to provide the following conditions:
– The location should be easily accessible for the maintenance;
– over the place of installation should be no cranes, flanges and piping to avoid
the dripping of aggressive solutions;
– combined electrode should be always immersed into the tested liquid, the
electrode should be in a dry condition not more than 10 minutes.
Connect the ground wire to the corresponding terminal of the the analyzer.
Connect the power supply and warm the analyzer for 15 minutes.
7.3 Transmitter preparation
7.3.1 The pH meter is supplied configured in accordance with the order. Factory settings
are indicated in the passport.
7.3.2 Calibration on the standard solutions
Appendix D contains a calibration procedure of the pH meter. Calibration of two
buffer solutions (two-point) is required for initial and periodic analyzer calibration during
Instruction manual PH-ME ER Industrial 4122.P 11

operation (once a month during a continuous measurement of pH (ORP) of the analyzed
liquid), and after replacing the used ES on a new one.
7.3.2.1 ES calibration is performed by the pH buffers according to GOST 8.135-2004 or
ORP solutions as per GOST R 8.702-2010.
8 Operating modes of pH meter
8.1 When power the pH meter switches to the mode "Measurement" automatically and
operates on the previously set parameters.
8.2 "Measurement" mode
8.2.1 Buttons appointment in the " Measurement " mode:
–{ - entrance to the select menu of display type in the "Measurement" mode;
–я - entrance to the calibration menu of pH (ORP) input channel 1;
–ч - entrance to the calibration menu of pH (ORP) input channel 2;
–} - entrance to the "MAIN MENU".
8.2.2 Selecting the data type presentation in the measurement mode:
– Channel 1 , Channel 2 and Channels 1 и 2 - a digital displaying of the measured
data (see figure):
Instruction manual PH-ME ER Industrial 4122.P
12
MAIN MENU
Settings
Archive
Restoring of factory
settings
Software version
Diagnostic
CALIBRATION channel 1
1
one point calibration
two point calibration
CALIBRATION channel 2
one point calibration
two point calibration
[
[
MEASUREMENT
Channel 1
Channel 2
Channels 1 and 2
Graphics channel 1
Graphics channel 2
Graphics channels 1 and 2
{}
Measurement
mode

– Graphics channel 1 , Graphics channel 2 and Graphics channels 1 and 2 - display-
ing of the measured data in a graph (see figure):
8.3 MA N MENU
8.3.1 Entrance to the "MAIN MENU" is performed by pressing the button } (See
section 8.2).
Instruction manual PH-ME ER Industrial 4122.P 13
14.01.13 09:33 2,5 /ч
Кана 1 Та 23,8 oС
pН
ОЧВ
>> 9.00
Correction ОЧВ
is activated
Measured
value
MEASUREMENT
Channel 1
Channel 2
Channels 1 and 2
Graphics channel 1
Graphics channel 2
Graphics channels 1 and 2
14.01.13 09:33 2,5 /ч
Кана 2 Тр 0,0 oС
ОВП
мВ 70
Measured
value
14.01.13 09:33 2,5 /ч
Кана 1 Та 23,8 oС
pН
ОЧВ
Кана 2 Тр 00,0 oС
ОВП
мВ
9.00
70
Measured
value
Correction ОЧВ
is activated Measured
value
14.01.13 09:33 Exx 2,5 /ч
Кана 1 Та 23,8 oС
pН
ОЧВ
>> 9.00
Rate
Date Time
Measurement error
If yes – flashing
If not - blank
MEASUREMENT
Channel 1
Channel 2
Channels 1 and 2
Graphics channel 1
Graphics channel 2
Graphics channels 1 and 2
( 9.00)xx ( 23.8)xx
8.56 9.70
22.5 25.4
08:56:10 11.11.13 08:58:00
Measurement
parameter unit
Current parameter
value on the
continuous graph
Time of the first
data point
Current parameter
value on the
dotted graph
Current (added)
time of data point
Date
( 9.00)pH ( 23.8)oC
8.56 9.70
22.5 25.4
08:56:10 11.11.13 08:58:00
Minimum
of the dotted
graph
( 1.60)pH ( 55.4)oC
1.06 1.91
50.5 61.4
08:56:10 11.11.13 08:58:00
( 9.00)pH ( 1.60)pH
8.56 9.70
1.06 1.91
08:56:10 11.11.13 08:58:00
Maximum
of the continuous
graph
Minimum
of the continuous
graph
Maximum
of the dotted
graph

8.3.2 SETT NGS sub-menu
8.3.2.1 nputs
In this mode, the measuring input pH or ORP parameters (Channels 1 and 2) and the
temperature (channels 1 and 2) are set.
Inputs → рН channel 1 - the pH measurement parameters channel №1 are re-
viewed and adjusted:
– Averaging time of a low signal and Averaging time of a high signal - review and
adjusting of the averaging time of low and high signal, in seconds.
– Limit of a high signal - review and adjusting the changeover limit from the low sig-
nal filtering to a high, in pH.
– Ei (mV) - review and adjusting the pH electrode parameter Ei, in millivolts.
– Slope - review and adjusting the pH electrode parameter S, in percent.
– pНi (pH) - review and adjusting the pH electrode parameter pHi, in units pH.
– ОЧВ correction - turning on (On.) or off (Off) the temperature compensation for
the ultrapure water for the first channel.
–Input mode — switching on the device to the pH or ORP measurement mode.
Inputs → ORP Channel 2 - ORP measurement parameters channel №2 are re-
viewed and adjusted:
– Averaging time of a low signal и Averaging time of a high signal - review and ad-
justing of the averaging time of low and high signal, in seconds.
– Limit of a high signal - review and adjusting the changeover limit from the low sig-
Instruction manual PH-ME ER Industrial 4122.P
14
MAIN MENU
Settings
Archive
Restoring of factory
settings
Software version
Diagnostic
} SETTINGS
Inputs
Temperature
compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
}
SETTINGS
Inputs
Temperature
compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
}
Averaging time of a low signal
Averaging time of a high signal
Limit of a high signal
Ei (mV)
Slope
pHi (pH)
Correction OCHV
Input mode
Input mode
Averaging time
Thermometer NSH type
Resistance at 0 ° C
Manual temperature
Temperature correction
Averaging time of a low signal
Averaging time of a high signal
Limit of a high signal
E offset value (mV)
Slope
Input mode

nal
– filtering to a high, in mV.
– E offset (mV) - review and adjusting the pH electrode parameters E offset, in milli-
volts.
– Slope - review and adjusting the pH electrode parameter S, in percent.
–Input mode — switching on the pH meter to the the pH or ORP measurement mode.
Inputs → Temperature channel 1 - the temperature measurement parameters
channel №1 are reviewed and corrected.
– Averaging time - viewing and adjusting the averaging time in seconds by the tem-
perature measurement.
– НСХ type thermometer - selecting the НСХ type of the used temperature sensor.
– Resistance at 0 ° C - selecting the temperature sensor resistance at zero degrees
Celsius.
– Manual temperature - setting the temperature values for a temperature compensa-
tion manual mode (or in the absence of the temperature sensor).
– Temperature correction - correction of the temperature when two-wire connection
of the temperature sensor in degrees.
Inputs → Temperature channel 2 - the temperature measurement parameters
channel №2 are reviewed and corrected. The correction of the temperature measurement
parameters channel 2 is performed similarly to the correction of the temperature mea-
surement parameters channel 1.
When ORP measuring the temperature measurement is not considered.
8.3.2.2 Temperature compensation
The temperature compensation modes for each channel are set.
Temperature compensation
– TC mode channel 1 - the temperature compensation mode for the first channel is
selecting:
– automatic or manual. If auto atic temperature compensation while the pH calculating
the temperature sensor of the first channel as a source of the temperature value will be
taken. When anual temperature compensation while the pH calculating the collected
temperature value for the first channel will be taken (see p. 8.3.2.1).
– TC mode Channel 2 - the temperature compensation mode for the second channel
is selecting: automatic or manual. When auto atic temperature compensation while
the pH calculating temperature sensor of the second channel as a source of the temper-
ature value will be taken. When anual temperature compensation while pH calculat-
ing the collected temperature value for the first channel will be taken (see p. 8.3.2.1).
– The second channel is additionally provided with an automatic temperature compen-
Instruction manual PH-ME ER Industrial 4122.P 15
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Temperature compensation
TC mode channel 1
TC mode channel 2
}TC mode
Automatic
Manual
TC mode
Automatic
Manual
Temperature channel 1

sation mode using the temperature sensor of the first channel as a source of a temper-
ature value ( Temperature channel 1).
–Notes
–1 Set point value of a anual te perature is using with the pH eter auto atically
–when breaking or short-circuit of a te perature sensor.
2 A built-in the pH electrode te perature sensor is used as a te perature sensor or another
single sensor.
8.3.2.3 Graph
In this mode, the zoom parameters for each measurement parameter are selected: pH
channel 1, OPR channel 2, temperature channel 1 and channel 2. For each parameter the
minimum and maximum limits for displaying the trend are set. When selecting Auto
zoom mode the minimum and maximum limits are determined automatically.
8.3.2.4 Discrete outputs
For each digital output such parameters as: binding to a parameter, response value,
hysteresis, on and off delay and response function are set.
Notes
1 Each output can be set to the generalized easure ent error alar . To do this, select the ode:
Binding to the para eter, easure ent error (paragraph 8.3.6.).
2 Each output can be configured to the power supply absence signaling supplied to the analyzer. To
do this, select the ode: Binding to a para eter, power supply availability.
8.3.2.4.1 Setting the digital outputs in the wall-mounted pH-meter with block БВД-8.2.
Here are eight digital outputs with switching options ~ 240 V, 3 A available (see Figure
C.2).
8.3.2.4.2 Setting the digital outputs in the wall-mounted pH-meter with one digital out-
put.
Instruction manual PH-ME ER Industrial 4122.P
16
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
}
Minimal limit
Maximum limit
Scaling
}
SETTINGS
Inputs
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
БВД-8
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output 7
Output 8
}
Binding to the parameter
Response value
Hysteresis
On delay
Off delay
Response function
БВД-8 is off
1 – БВД-8 is on
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
Flow rate
Measurement error
Power supply availability
Relay is off
Overrun response
Reduction response

Herewith is only one digital output with switching settings = 100 V, 150 mA available
(see Figure C.3).
8.3.2.4.3 Setting the digital outputs to a panel pH meter.
Herewith are four digital outputs with switching parameters ~240 V, 3 A available (see
Figure C.1).
8.3.2.5 LEDs
In this mode, for each of the four LEDs on the front panel of the analyzer the following
functions are set: response value, response function and binding to the parameter. For the
mounted pH-meter the binding to the parameter "Relay condition" is off.
Note - Each LED can be set to the easure ent error alar . To do this, select the ode: Binding
to the para eter, easure ent error (paragraph 8.3.6.). In this case the LED is flashing.
8.3.2.6 Current outputs
Instruction manual PH-ME ER Industrial 4122.P 17
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Led 1
Led 2
Led 3
Led 4
}
Binding to the parameter
Response value
Response function
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
Flow rate
Measurement error
Relay condition
Off
Activate if < limit
Activate if > limit
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Output 1
Output 2
Output 3
Output 4
}
Binding to the parameter
Response value
Hysteresis
On delay
Off delay
Response function
SEC channel 1
SEC channel 2
Temperature channel 1
Temperature channel 2
Flow rate
Measurement error
Power supply availability
Relay is off
Overrun response
Reduction response
}
SETTINGS
Inputs
Graph
Temperature compensation
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Binding to the parameter
Response value
Hysteresis
On delay
Off delay
Response function
SEC channel 1
SEC channel 2
Temperature channel 1
Temperature channel 2
Flow rate
Measurement error
Power supply availability
Relay is off
Overrun response
Reduction response

In this mode, the parameters of two current outputs are set.
Current outputs → Output 1 - setting the parameters of the first current output:
– Binding to the parameter - in this mode one of the five measured parameters,
which will be on the output current signal, is selected (See figure);
– Lower measurement limit - the lower limit value of the selected parameter is set.
– Upper measurement limit - the upper limit value of the selected parameter is set.
– Current output range - one of the options of the current output range is selected:
(0 ... 5) mA (0 ... 20 mA) or (4 ... 20 mA).
Current outputs → Exit 2 - setting the parameters of the second current output.
The parameters of the second current output are configured similarly to the setting the
parameters of the first current output.
8.3.2.7 nterface
In this mode, the interface parameters are set: network address, transfer rate and a parity
check.
8.3.2.8 Date and time
In this mode, the current year, month, day, hour and minute for the integrated real-time
clock are set.
8.3.2.9 Sound signaling
Instruction manual PH-ME ER Industrial 4122.P
18
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Output 1
Output 2
}Binding to the parameter
Lower range limit
Upper range limit
Current output range
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
Flow rate
(0 - 5) мА
(0 - 20) мА
(4 - 20) мА
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Year
Month
Day
Hours
Minutes
Seconds
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
Network address
Transfer rate
Parity check

In this mode, the sound alarm is set:
– On the button pressing - when this mode is on the beeps are audible by pressing
the buttons on the front panel of the pH meter.
– On errors (alarm) - when this mode is on, the sound signal is activated (intermittent
audible alarm), if a diagnosed pH meter error appears.
8.3.3 ARCH VE sub-menu
In this mode the viewing and configuration of the archive display is made. (See section
8.2).
– View Archive - in this mode the archive is displayed. Right button } allows to
switch the control cursor mode: я and ч or a time discrete interval will be changed
or cursor indicating the time of viewing and the values of the measured parameters at
this time moves (See Figure 1).
– Trend line N1 - in this mode a parameter with a continuous line will be displayed.
– Trend line N2 - in this mode a parameter with a broken line will be displayed.
Instruction manual PH-ME ER Industrial 4122.P 19
}
SETTINGS
Inputs
Temperature compensation
Graph
Discrete outputs
LEDs
Current output
Interface
Date and time
Sound signaling
On the button pressing
On errors (alarm)

– Scaling - in this mode, for each measured parameter the minimum and maximum
limits for the trend displaying are set. When scaling mode selection, the minimum and
maximum limits are determined automatically - sub-menu structure "Archive".
Instruction manual PH-ME ER Industrial 4122.P
20
}
View archive
Trend line 1
Trend line 2
Scaling
}pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
Not display
MAIN MENU
Settings
Archive
Restoring of factory
settings
Software version
Diagnostic
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
Minimal limit
Maximum limit
Scaling
pH channel 1
ORP channel 2
Temperature channel 1
Temperature channel 2
9.00 15:49:12 23.8
8.56 9.70
22.5 25.4
121113 15:48:07 121113 15:49:58
Esc < 1c > -+

Figure 1 - Description of the control elements and data display
in the "View Archive" sub-menu
8.3.4 Restoring the factory settings. In this mode, you can restore the pH meter
settings installed at the manufacturing plant.
8.3.5 Software version
In this mode, you can view the software version of "PH" set in this pH meter:
8.3.6 D AGNOST CS. In this mode it is possible to read the errors diagnosed with a
pH meter:
- Internal error 1;
- Internal error 2;
- No connection to БВД8 (for wall design only);
- defective temperature sensor. 1 (2).
If no error the message will be displayed: No errors were detected
8.3.7 First channel calibration
Pressing я-key the pH meter switches to the electrode system calibration mode
connected to the first channel of the pH meter. Calibration is performed on pH (ORP)
buffer solutions.
Figure 2 – pH channel 1 calibration
Instruction manual PH-ME ER Industrial 4122.P 21
pH-meter
pH-4122P V01.02.01
compilation date:
27.01.2015 15:36
Channel 1 Calibration
1-point calibration
2-point calibration
[
Mode
“Measurement”
121113 15:48:07 121113 15:49:58
Esc < 1c > -+
Date and time
of the first point
the archival graph
ДДММГГ ЧЧ:ММ:СС ДДММГГ ЧЧ:ММ:СС
Date and time
of graph last point
the archival graph
9.00 15:49:12 23.8
8.56 9.70
22.5 25.4
121113 15:48:07 121113 15:49:58
Esc < 1c > -+
Trend line N1
parameter value
at the cursor position
Trend line N2
parameter value
at the cursor position
Trend line N2
maximum
Trend line N2
minimum
Time
in the cursor
position
Esc - 1c + <>
Перемещение
маркера по
оси времени
Изменение масштаба
времени
Time scale change
Date line
Help line of the
key functions
date line
Trend line N1
maximum
Trend line N1
minimum
Switching movements
on the time axis
Switching time
scale change
Axis scale
(1 pixel =)
1s, 5s, 10s, 30s,
1m, 5m, 10m, 30m,
1h, 3h, 6h,12h,
1 day
Cursor
movements
on the time axis
