User’s Guide for Nokia 1600

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product
RH-64 is in conformity with the provisions of the following Council Directive:
1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright ©2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
US Patent No 5818437 and other pending patents. T9 text input software Copyright
©1997-2005. Tegic Communications, Inc. All rights reserved.
Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trademarks or registered
trademarks of Nokia Corporation. Other product and company names mentioned
herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document
without prior notice.
Copyright
©
2005 Nokia. All rights reserved. i

Under no circumstances shall Nokia be responsible for any loss of data or income or
any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable
law, no warranties of any kind, either express or implied, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose, are
made in relation to the accuracy, reliability or contents of this document. Nokia
reserves the right to revise this document or withdraw it at any time without prior
notice.
The availability of particular products may vary by region. Please check with the Nokia
dealer nearest to you.
THIS DEVICE MAY CONTAIN COMMODITIES, TECHNOLOGY OR SOFTWARE SUBJECT TO
EXPORT LAWS AND REGULATIONS FROM THE US AND OTHER COUNTRIES. DIVERSION
CONTRARY TO LAW IS PROHIBITED.
Issue 1
ii Copyright
©
2005 Nokia. All rights reserved.

Contents
For your safety............................ v
General information .................. ix
Access codes...................................... ix
Shared memory.................................. x
1. Getting started ...................... 1
How to get started ........................... 1
Insert a SIM card and battery ....... 2
Charge the battery............................ 3
Switch on or off ................................ 4
Change the covers ............................ 5
Demo mode......................................... 6
Shortcuts in the standby mode..... 6
Lock the keypad................................. 7
2. Call functions......................... 8
Make a call.......................................... 8
Make a conference call........................ 8
Redial a number..................................... 9
Speed dial ................................................ 9
Answer a call...................................... 9
Loudspeaker..................................... 10
Voice messages (Network
service).............................................. 10
3. Write text............................. 11
4. Menu functions ................... 14
Messages........................................... 14
Create message.................................... 14
Read a text message (Inbox)............ 15
Drafts and Sent items........................ 16
Chat (Network service)...................... 16
Picture messages (Network
service)................................................... 17
Distribution lists.................................. 17
Screened messages............................. 18
Delete messages.................................. 18
Message counter................................. 18
Message settings................................. 18
Service com. editor (Network
service)................................................... 20
Contacts ............................................ 20
Search for a name and phone
number................................................... 20
Settings for Contacts......................... 21
Call register ...................................... 22
Recent call lists ................................... 23
Call timers............................................. 23
Message counter................................. 23
Copyright
©
2005 Nokia. All rights reserved. iii

Settings............................................. 24
Tone settings......................................... 24
Display settings.................................... 25
Profiles.................................................... 26
Time settings......................................... 26
Call settings .......................................... 27
Phone settings...................................... 28
Cost settings ......................................... 29
Enhancement settings........................ 30
Security settings.................................. 31
Right navigation key setting............ 32
Restore factory settings .................... 33
Clock .................................................. 33
Reminders......................................... 34
Games................................................ 34
Extras................................................. 34
Calculator .............................................. 34
Converter ............................................... 35
Countdown timer ................................ 35
Stopwatch ............................................. 36
Composer............................................... 36
Demo mode ........................................... 37
SIM services..................................... 37
5. Battery information............. 38
Charging and discharging ............ 38
Nokia battery authentication
guidelines.......................................... 39
6. Genuine Enhancements....... 43
Power ................................................. 44
Standard Charger (ACP-7)................ 44
Travel Charger (ACP-12) ................... 45
Audio .................................................. 45
Headset HDC-5.................................... 45
7. Care and maintenance......... 46
8. Additional safety
information ............................... 48
Index .......................................... 54
iv Copyright
©
2005 Nokia. All rights reserved.

For your safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle
while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in
aircraft.
SWITCH OFF WHEN REFUELLING
Do not use the phone at a refuelling point. Do not use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the phone where blasting is in
progress.
Copyright
©
2005 Nokia. All rights reserved. v

USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the end key as many
times as needed to clear the display and return to the start screen. Enter
the emergency number, then press the call key. Give your location. Do not
end the call until given permission to do so.
vi Copyright
©
2005 Nokia. All rights reserved.

■About your device
The wireless device described in this guide is approved for use on the EGSM 900/1800
networks. Contact your service provider for more information about networks.
When using the features in this device, obey all laws and respect privacy and
legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock, the
device must be switched on. Do not switch the device on when wireless
device use may cause interference or danger.
■Network services
To use the phone you must have service from a wireless service provider. Many of the
features in this device depend on features in the wireless network to function. These
network services may not be available on all networks or you may have to make
specific arrangements with your service provider before you can utilize network
services. Your service provider may need to give you additional instructions for their
use and explain what charges will apply. Some networks may have limitations that
affect how you can use network services. For instance, some networks may not
support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, they will not appear on your device menu. Your device
may also have been specially configured. This configuration may include changes in
menu names, menu order and icons. Contact your service provider for more
information.
Copyright
©
2005 Nokia. All rights reserved. vii

■Chargers and enhancements
Always switch the device off and disconnect the charger before removing the battery.
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from the ACP-7 and ACP-12 chargers.
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When you
disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.
viii Copyright
©
2005 Nokia. All rights reserved.

General information
■Access codes
For details about access codes and their operations, see "Security settings"
on page 31.
•Security code: This code, supplied with the phone, helps to protect your
phone against unauthorised use. The preset code is 12345.
•PIN code: This code, supplied with the SIM card, helps to protect the card
against unauthorised use.
To set your phone to request PIN code each time it is switched on, in the
standby mode, select Menu > Settings > Security settings > PIN code
request, enter the PIN code, and select On.
If you enter the PIN code incorrectly three times in succession, the SIM
card is blocked. You must enter the PUK code to unblock the SIM card
and set a new PIN code.
•PIN2 code: This code is supplied with some SIM cards and is required to
access certain services, such as call cost settings. If you enter the PIN2
code incorrectly three times in succession, PIN2 code blocked appears on
the display, and you will be asked for the PUK2 code.
Change the security code, PIN code and PIN2 code in Change access
codes in the Security settings menu (see "Security settings" on page 31).
Keep the new codes secret and in a safe place separate from your phone.
Copyright
©
2005 Nokia. All rights reserved. ix

•PUK and PUK2 code: These codes may be supplied with the SIM card. If
this is not the case, contact your local service provider.
■Shared memory
The following features in this device may share memory: Messages,
Contacts, and Composer. Use of one or more of these features may reduce
the memory available for the remaining features sharing memory. For
example, saving many text messages may use all of the available memory.
Your device may display a message that the memory is full when you try to
use a shared memory feature. In this case, delete some of the information or
entries stored in the shared memory features before continuing. Some of the
features, such as Contacts may have a certain amount of memory specially
allotted to them in addition to the memory shared with other features.
xCopyright
©
2005 Nokia. All rights reserved.

Getting started
Copyright
©
2005 Nokia. All rights reserved. 1
1. Getting started
■How to get started
The display indicators described below are shown when the phone is ready
for use and no characters have been keyed in. This state is called the standby
mode.
• Signal intensity of the cellular
network (1)
• Battery bar indicating battery charge
level (2)
• Current function of the two selection
keys (3)
• Selection keys (4)
The function of the selection keys
depends on the text shown on the
display above them.
• Scroll keys (5)
• Call key (6)
• Dials a phone number.
• Answers a call.

Getting started
2Copyright
©
2005 Nokia. All rights reserved.
• End key (7)
A long press switches the phone on or off.
A brief press ends an active call or exits from any function.
• Keypad (8)
■Insert a SIM card and battery
Keep all SIM cards out of the reach of small children.
For availability and information on using SIM card services, contact your
SIM card vendor. This may be the service provider, network operator, or other
vendor.
This phone is intended for use with BL-5C battery.
1. Press the back cover release
button (1), open the back cover,
and remove it (2, 3).
2. Lift the battery from the finger
grip, and remove it (4). Carefully
lift the SIM card holder from the
finger grip of the phone (5).

Getting started
Copyright
©
2005 Nokia. All rights reserved. 3
3. Insert the SIM card, ensuring
that the bevelled corner is on
the upper right side and that
the golden contact is facing
downward (6).
4. Close the SIM card holder (7),
and press it to lock it into place.
5. Insert the battery (8, 9).
■Charge the battery
1. Connect the charger to an ac wall outlet.
2. Connect the plug from the charger to the base
of the phone. The battery indicator bar starts
scrolling.
If Not charging is displayed, wait for a while,
disconnect the charger, plug it in again, and
retry. If charging still fails, contact your dealer.
3. When the battery is fully charged, the bar stops scrolling. Disconnect the
charger from the phone and the ac outlet.

Getting started
4Copyright
©
2005 Nokia. All rights reserved.
■Switch on or off
Press and hold the end key for a few seconds.
Warning! Do not switch on the phone when wireless phone use is
prohibited or when it may cause interference or danger.
Use the phone only in its normal operating
position.
Your device has an internal antenna.
Note: As with any other radio
transmitting device, do not touch
the antenna unnecessarily when the
device is switched on. Contact with the antenna affects call quality
and may cause the device to operate at a higher power level than
otherwise needed. Avoiding contact with the antenna area when
operating the device optimizes the antenna performance and the
battery life.
Note: Avoid touching this connector as
it is sensitive to electrostatic discharge.

Getting started
Copyright
©
2005 Nokia. All rights reserved. 5
■Change the covers
Note: Always switch off the power and disconnect the charger and
any other device before removing the cover. Avoid touching
electronic components while changing the cover. Always store and
use the device with the cover attached.
1. Press the back cover release
button (1), open the back
cover, and remove it (2, 3).
2. Take off the front cover
carefully (4).
3. Insert the keymat in the new front cover (5).

Getting started
6Copyright
©
2005 Nokia. All rights reserved.
4. Align the top of the front cover to the top of the phone, and
press the front cover to lock it into place (6,7).
■Demo mode
You may view how to use certain features of your phone. To access the
demo, use one of the two ways:
• If the SIM card is not installed, select Demo.
•Basics—To view the demo of Make a call, Answer a call, Send text
msg., or Set an alarm
•More—To view the demo of Speaking clock, Ringing tones, or Themes
•Games—To play the games in your phone
• If the SIM card is installed, select Menu > Extras > Demo > Basics or
More; or, you can access the demo mode by scrolling right in the standby
mode.
■Shortcuts in the standby mode
Scroll up to access Call register.
Scroll down to access the names and numbers saved in Contacts.
Scroll left to write a message.

Getting started
Copyright
©
2005 Nokia. All rights reserved. 7
Scroll right to access the demo mode.
Press and hold *to activate the speaking clock.
Press the call key once to access the list of dialled numbers. Scroll to the
name or number that you want, and to call the number, press the call key.
■Lock the keypad
The keypad lock helps to prevent keys from being pressed
accidentally.
To lock the keypad, in the standby mode, select Menu, and
press *quickly; to unlock, select Unlock, and press *quickly.
To automatically turn on the keylock, see "Phone settings"
on page 28.
When the keypad lock is on, calls may be possible to the official emergency
number programmed into your device.
Enter the emergency number, and press the call key. The emergency number
you have entered may not be displayed on the screen.

Call functions
8Copyright
©
2005 Nokia. All rights reserved.
2. Call functions
■Make a call
1. Enter the phone number and the area code if necessary.
To make international phone calls, press *twice quickly, add the country
(or region) code then the area code (delete the leading 0 if necessary).
To delete the last digit entered, select Clear.
2. Press the call key to call the number. Scroll right to increase or scroll left
to decrease the volume of the earpiece or headset during the phone call.
3. Press the end key to end the call (or to cancel the call attempt).
Make a conference call
Conference call (Network service) allows up to five people to participate in
the same call.
1. To make a call to a new participant, select Options > New call; select
Clear to clear the screen if necessary. Enter the number you want, and
press the call key.
2. When the new call is answered, add it to the conference call by selecting
Options > Conference.

Call functions
Copyright
©
2005 Nokia. All rights reserved. 9
Redial a number
To redial one of the last twenty phone numbers that you have called or
attempted to call, press the call key once in the standby mode, scroll to the
phone number or name that you want, and press the call key.
Speed dial
In the standby mode, select Menu > Contacts > Speed dials and one of the
following options:
•On or Off to set speed dial on or off
•Edit to edit the speed dial list
Scroll to select the number key you want (2 to 9), and select Assign;
choose if you want to assign to call or to SMS, and select the name you
want.
To dial a number using speed dial, press and hold the relevant assigned
number key in the standby mode.
■Answer a call
When there is an incoming call, press the call key to answer. To reject the
call without answering, press the end key.
