Nokia 2710 User manual

Nokia 2710 User Guide
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Issue 1.2

Contents
Safety 5
Support 7
Get started 8
Insert SIM card and
battery 8
Insert a microSD
card 9
Remove the microSD
card 10
Charge the battery 11
GSM antenna 12
Headset 13
Connect a USB data
cable 14
Magnets and
magnetic fields 15
Keys and parts 16
Access codes 18
Switch on and off 19
Home screen 19
Keypad lock 20
Functions without a
SIM card 21
Applications running
in background 21
Calls 22
Make and answer a
call 22
Loudspeaker 22
Dialling shortcuts 23
Write text 24
Text modes 24
Traditional text
input 25
Predictive text
input 25
Navigate the
menus 26
Messaging 27
2Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Text and multimedia
messages 27
Flash messages 30
Nokia Xpress audio
messages 31
Voice messages 31
Message settings 32
Contacts 33
Call log 35
Settings 35
Profiles 35
Tones 36
Display 36
Date and time 36
Shortcuts 37
Synchronisation and
backup 38
Connectivity 38
Call and phone 43
Accessories 44
Configuration 44
Restore factory
settings 45
Operator menu 46
Gallery 46
Applications 46
Alarm clock 46
Calendar and to-do
list 47
Extras 49
Camera and video 50
FM radio 51
Voice recorder 53
Media player 54
Dictionary 55
Maps 56
About Maps 56
Introduction 58
Navigate to your
destination 61
Contents 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Web or Internet 67
Connect to a web
service 68
SIM services 68
Nokia original
accessories 69
Practical rules about
accessories 70
Battery 70
Green tips 71
Save energy 71
Recycle 72
Learn more 72
Product and safety
information 73
Index 112
4Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Safety
Read these simple guidelines. Not following them
may be dangerous or illegal. Read the complete user
guide for further information.
SWITCH ON SAFELY
Do not switch the device on when
wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your
hands free to operate the vehicle while
driving. Your first consideration while
driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect
performance.
Safety 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device
off in aircraft, near medical equipment,
fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or
repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it
dry.
6Safety
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, see the user guide or see the support pages
at www.nokia.com/support or your local Nokia
website, or with a mobile device, www.nokia.mobi/
support.
If this does not resolve your issue, do one of the
following:
•Restart the device: switch off the device, and
remove the battery. After about a minute,
replace the battery, and switch on the device.
•Restore the original factory settings as
explained in the user guide.
•Update your device software regularly for
optimum performance and possible new
features, as explained in the user guide.
If your issue remains unsolved, contact Nokia for
repair options. See www.nokia.com.hk/repair.
Before sending your device for repair, always back
up the data in your device.
Support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Get started
Insert SIM card and battery
Safe removal. Always switch the device off and
disconnect the charger before removing the battery.
The SIM card and its contacts can be easily damaged
by scratches or bending, so be careful when
handling, inserting, or removing the card.
1 Slide the back cover downwards, and remove it
(1).
2 Remove the battery (2).
3 Insert the SIM card. Ensure the contact surface
area is facing down and the bevelled corner of
the SIM card is facing the bottom of the device
(3, 4, 5).
8Getstarted
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

4 Replace the battery and the back cover (6, 7).
Insert a microSD card
Use only compatible microSD cards approved by
Nokia for use with this device. Nokia uses approved
industry standards for memory cards, but some
brands may not be fully compatible with this device.
Incompatible cards may damage the card and the
device and corrupt data stored on the card.
Your phone supports microSD cards with a capacity
A compatible memory card may be supplied with the
device, and may already be inserted in the device. If
not, do the following:
Get started 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
of up to 16 GB.
© 2010 Nokia. All rights reserved.

1 Open the cover of the memory card slot.
2 Insert the card into the memory card slot with
the contact surface facing up, and press until it
locks into place.
3 Close the cover of the memory card slot.
Remove the microSD card
Important: Do not remove the memory card during
an operation when the card is being accessed. Doing
so may damage the memory card and the device,
and corrupt data stored on the card.
10 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

You can remove or replace the memory card during
phone operation without switching the device off,
but you need to ensure that no application is
currently accessing the memory card.
Charge the battery
Your battery has been partially charged at the
factory. If the device indicates a low charge, do the
following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge,
disconnect the charger from the device, then
from the wall outlet.
You do not need to charge the battery for a specific
length of time, and you can use the device while it
is charging. If the battery is completely discharged,
it may take several minutes before the charging
Get started 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

indicator appears on the display or before any calls
can be made.
Charging the device while listening to the radio may
affect the quality of reception.
GSM antenna
Your device may have internal and external
antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the
communication quality and may cause a higher
12 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

power level during operation and may reduce the
battery life.
The figure shows the GSM antenna area marked in
grey.
Headset
Warning:
When you use the headset, your ability to hear
outside sounds may be affected. Do not use the
headset where it can endanger your safety.
When connecting any external device or any
headset, other than those approved by Nokia for use
with this device, to the Nokia AV Connector, pay
special attention to volume levels.
Do not connect products that create an output signal
as this may cause damage to the device. Do not
connect any voltage source to the Nokia AV
Connector.
Get started 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Connect a USB data cable
Connect a compatible USB data cable to the USB
connector.
14 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

To modify the USB settings, select Menu >
Settings > Connectivity > USB data cable and the
desired mode.
Magnets and magnetic fields
Keep your device away from magnets or magnetic
fields.
Get started 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key (scroll key)
5Call key
6Keypad
7Maps key
8End/Power key
9Microphone
16 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

10 Camera lens
11 Loudspeaker
12 Wrist strap eyelet
13 Headset connector/Nokia AV Connector (3.5
mm)
14 Charger connector
15 Capture key
16 Micro USB cable connector
17 Memory card slot
Get started 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

Access codes
The security code helps to protect your device
against unauthorised use. The preset code is 12345.
You can create and change the code, and set the
device to request the code. Keep the code secret and
in a safe place separate from your device. If you
forget the code and your device is locked, your
device will require service. Additional charges may
apply, and all the personal data in your device may
be deleted. For more information, contact a Nokia
Care point or your device dealer.
The PIN code supplied with the SIM card protects the
card against unauthorised use. The PIN2 code
supplied with some SIM cards is required to access
certain services. If you enter the PIN or PIN2 code
incorrectly three times in succession, you are asked
for the PUK or PUK2 code. If you do not have them,
contact your service provider.
The module PIN is required to access the
information in the security module of your SIM card.
The signing PIN may be required for the digital
signature. The barring password is required when
using the call barring service.
18 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

To set how your device uses the access codes and
security settings, select Menu > Settings >
Security.
Switch on and off
Press and hold the power key.
Home screen
7
6
10
1Network signal strength
2Battery charge status
3Indicators
Get started 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.

4Network name or the operator logo
5Clock
6Date (if the home screen mode is deactivated)
7Display
8Function of the left selection key
9Function of the scroll key
10 Function of the right selection key
Keypad lock
Lock the keypad
Select Menu, and press *within 2.5 seconds.
Unlock the keypad
Select Unlock, and press *within 1.5 seconds. If
requested, enter the lock code.
Answer a call when the keypad is locked
Press the call key. When you end or reject a call, the
keypad locks automatically.
20 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
© 2010 Nokia. All rights reserved.
