Nokia Asha 200 User manual

Nokia 200 User Guide
Issue 1.2

Contents
Safety 4
Get started 5
Your dual SIM phone 5
Keys and parts 5
Insert a SIM card and battery 6
Insert a second SIM card 7
Charge the battery 8
Switch the phone on or off 9
Insert a memory card 9
GSM antenna 10
Connect a headset 11
Attach the wrist strap 11
Basic use 11
Support 11
Access codes 12
Set which SIM card to use 12
Lock the keys 13
Indicators 13
Copy contacts or pictures from your
old phone 14
Use your phone without a SIM card 14
Calls 14
Make a call 14
View your missed calls 15
Call the last dialled number 15
Divert calls to your voice mailbox or
another phone number 15
Contacts 16
Save a name and phone number 16
Use speed dial 16
Send your contact information 17
Write text 17
Write using the keyboard 17
Predictive text input 18
Messaging 18
Send a message 18
Save an attachment 19
Retrieve a multimedia message 20
Listen to voice messages 20
Send an audio message 20
Mail and chat 21
About Mail 21
Send a mail 21
Read and reply to mail 21
About Chat 21
Chat with your friends 21
Connectivity 22
Bluetooth 22
USB data cable 24
Clock 24
Change the time and date 24
Alarm clock 24
Pictures and videos 25
Take a picture 25
Record a video 25
Send a picture or video 26
Organise files 26
Music and audio 26
Media player 26
FM radio 27
Browse the web 29
About the web browser 29
Browse the web 29
Add a bookmark 30
Fit a web page to your phone display 30
Save on data costs 31
Clear your browsing history 31
About Social 31
2Contents

Device management 32
Update device software using your
device 32
Update phone software using your
PC 33
Restore original settings 34
Back up your pictures and other
content to a memory card 34
Protect the environment 34
Save energy 34
Recycle 34
Product and safety information 35
Contents 3

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for
use with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near
your ear when the loudspeaker is in use.
4Safety

Get started
Your dual SIM phone
You can insert two SIM cards.
Some benefits of a dual SIM phone
•You can make savings when you use services from different service providers.
•Use one phone number for personal calls and another for work, but carry only
one phone.
•Avoid network coverage variation between service providers.
Both SIM cards are available at the same time when the device is not being used, but
while one SIM card is active, for example, making a call, the other is unavailable.
If you only have one SIM card, insert the card into the SIM1 card holder. Some features
and services may only be available when using the SIM card in the SIM1 card holder.
If there is a SIM card only in the SIM2 card holder, you can only make emergency calls.
A GPRS connection cannot be open in the background. If an application is using a GPRS
connection, and you return to the home screen or switch to another application,
menu, or other view, the connection is automatically closed.
Keys and parts
1Charger connector
2Earpiece
3Screen
Get started 5

4Selection keys
5SIM manager key
6Call key
7Keypad
8Microphone
9Headset connector/Nokia AV connector (3.5 mm)
10 Micro-USB connector
11 Wrist strap hole
12 Messaging key
13 End/Power key
14 Navi™ key (scroll key)
15 Camera lens
16 Loudspeaker
17 Memory card slot
18 SIM card slot (SIM 2)
Insert a SIM card and battery
Important: This device is designed to be used with a standard SIM card (see
figure) only. Use of incompatible SIM cards may damage the card or the device, and
may corrupt data stored on the card. Please consult your mobile operator for the use
of a SIM card that has a mini-UICC cutout.
This phone is intended for use with a BL-5J battery. Always use original Nokia
batteries.
If you only have one SIM card, insert the card into the internal SIM card holder.
6 Get started

1 Place your finger in the recess at the bottom of the phone, and carefully lift and
remove the back cover.
2 If the battery is inserted, lift it out.
3 Slide the SIM card holder to unlock it (1), and use your fingernail to lift it. Make
sure the contact area would face down when the SIM card holder is lowered (2),
insert the SIM card into the holder, and lower the holder (3). Slide the card holder
to lock it (4).
4 Line up the contacts of the battery and the battery compartment, and insert the
battery. To replace the back cover, direct the top locking catches toward their
slots, and press down until the cover locks into place.
Insert a second SIM card
Have a second SIM card, but want to keep using your main SIM card? You can insert
or remove a second SIM card without switching the phone off.
1 Open the cover of the external SIM card slot, marked with .
2 Make sure the contact area of the SIM card is facing up, and insert the card. Push
the card in, until it locks into place.
3Closethecover.
Get started 7

Remove the second SIM card
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time. If the phone indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the charger from the phone,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.
8 Get started

If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Switch the phone on or off
Press and hold the power key until the phone vibrates.
You may be prompted to get the configuration settings from your network service
provider. For more information on this network service, contact your network service
provider.
Insert a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.
Your phone supports memory cards with a capacity of up to 32 GB.
1 Open the cover of the memory card slot.
2 Make sure the contact area of the memory card is facing up, and insert the card.
Push the card in, until it locks into place.
3 Close the cover of the memory card slot.
Get started 9

Important: Do not remove the memory card when an application is using it.
Doing so may damage the memory card and the device and corrupt data stored on
the card.
You can remove or replace the memory card without switching the phone off.
Remove the memory card
Push the card in, until it is released, and pull the card out.
GSM antenna
The antenna area is highlighted.
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.
10 Get started
