Nokia 5330 Mobile TV Edition User manual

Nokia 5330 Mobile TV Edition User Guide
Issue 2

Contents
Safety 4
Get started 5
Keys and parts 5
Insert the SIM card and battery 6
Insert and remove the memory
card 6
Charge the battery 7
Antenna 8
Accessories 8
Switch it on 9
About your device 9
Network services 10
Access codes 10
Switch the device on and off 11
Standby mode 11
Touch music keys 13
Navigate the menus 14
Lock the keys 15
Functions without a SIM card 15
Flight profile 15
Make it your device 16
Basic settings 16
Personalise your phone 17
Connect 20
Network provider services 23
Stay in touch 24
Make calls 25
Text and messages 27
Nokia Messaging IM 31
Nokia Messaging Mail 33
Image and video 34
Capture images 34
Record video clips 35
Camera and video settings 35
Gallery 36
Print images 37
Memory card 37
Entertainment 38
Listen to music 38
Web 41
Games and applications 43
Mobile TV 44
About Mobile TV 44
Initial start-up 45
Select a channel or programme 45
Change audio output 46
Electronic Programme Guide (EPG) 46
Subscribe to a channel 46
Mobile TV settings 47
Access Mobile TV after changing SIM
card 47
Maps 48
Download maps 48
2Contents

Maps and GPS 49
Extra services 49
Organise 50
Manage contacts 50
Business cards 51
Date and time 52
Alarm clock 52
Calendar 52
To-do list 52
Notes 53
Calculator 53
Countdown timer 53
Stopwatch 53
Support and updates 54
Support 54
My Nokia 54
Download content 55
Update software using your PC 55
Software updates over the air 55
Restore factory settings 56
Green tips 56
Save energy 56
Recycle 57
Learn more 57
Product and safety
information 57
Index 65
Contents 3

Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on
when wireless phone use is
prohibited or when it may
cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
keep your hands free to
operate the vehicle while
driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions.
Switch the device off in
aircraft, near medical
equipment, fuel, chemicals,
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved
accessories and batteries. Do
not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-
resistant. Keep it dry.
4Safety

Get started
Get to know your device, insert the
battery, SIM card, and memory card, and
learn some important information
about your device.
Keys and parts
1Earpiece
2Touch music key (rewind)
3Touch music key (play/pause)
4Touch music key (fast-forward)
5Left and right selection keys
6Call key
7Keypad
8Display
9Navi™ key (scroll key)
10 End/Power key
11 Microphone
12 Nokia AV Connector (3.5 mm)
13 Charger connector
14 Micro USB cable connector
15 Volume key
16 Lock switch
17 Camera flash
18 Camera lens
19 Wrist strap eyelet
20 Memory card slot
21 Loudspeaker
Get started 5

Insert the SIM card and battery
Note: Switch off the power and
disconnect the charger and any other
device before removing the covers.
Avoid touching electronic components
while changing the covers. Always store
and use the device with the covers
attached.
The SIM card and its contacts can be
easily damaged by scratches or
bending, so be careful when handling,
inserting, or removing the card.
1 Open the back cover, and remove it.
Remove the battery.
2 Open the SIM card holder. Insert the
SIM card into the holder with the
contact surface facing down. Close
the SIM card holder.
3 Line up the battery contacts, and
insert the battery. Replace the back
cover.
Insert and remove the memory card
6Getstarted

Use only compatible microSD cards
approved by Nokia for use with this
device. Nokia uses approved industry
standards for memory cards, but some
brands may not be fully compatible with
this device. Incompatible cards may
damage the card and the device and
corrupt data stored on the card.
Your device supports microSD cards
with a capacity of up to 16 GB. The size
of a single file must not exceed 2 GB.
Insert the memory card
1 Open the cover of the memory card
slot.
2 Insert the card into the memory
card slot with the contact surface
facing down, and press until it locks
into place.
3 Close the cover of the memory card
slot.
Remove the memory card
Important: Do not remove the memory
card during an operation when the card
is being accessed. Doing so may damage
the memory card and the device, and
corrupt data stored on the card.
You can remove or replace the memory
card without switching the device off.
1 Ensure that no application is
currently accessing the memory
card.
2 Open the cover of the memory card
slot.
3 Press the memory card slightly in to
release the lock, and remove the
card.
Charge the battery
Your battery has been partially charged
at the factory. If the device indicates a
low charge, do the following:
1 Connect the charger to a wall outlet.
Get started 7

2 Connect the charger to the device.
3 When the device indicates a full
charge, disconnect the charger from
the device, then from the wall
outlet.
You can also charge the battery with a
USB cable with power from a computer.
1 Connect the USB cable to a USB port
of a computer and to your device.
2 When the battery is fully charged,
disconnect the USB cable.
You do not need to charge the battery
for a specific length of time, and you can
use the device while it is charging. If the
battery is completely discharged, it may
take several minutes before the
charging indicator appears on the
display or before any calls can be made.
Antenna
Your device may have internal and
external antennas. Avoid touching the
antenna area unnecessarily while the
antenna is transmitting or receiving.
Contact with antennas affects the
communication quality and may cause
a higher power level during operation
and may reduce the battery life.
The figure shows the antenna area
marked in grey.
Accessories
Connect a USB cable
Open the cover of the USB connector,
and connect the USB cable to the device.
8Getstarted

Headset
Warning:
Continuous exposure to high volume
may damage your hearing. Listen to
music at a moderate level, and do not
hold the device near your ear when the
loudspeaker is in use.
Warning:
When you use the headset, your ability
to hear outside sounds may be affected.
Do not use the headset where it can
endanger your safety.
When connecting any external device or
any headset, other than those approved
by Nokia for use with this device, to the
Nokia AV Connector, pay special
attention to volume levels.
Do not connect products that create an
output signal as this may cause damage
to the device. Do not connect any
voltage source to the Nokia AV
Connector.
Strap
1 Remove the back cover.
2 Attach a strap, and tighten it.
3 Replace the back cover.
Switch it on
Learn how to switch on your device, and
how to use the basic functions.
About your device
The wireless device described in this
guide is approved for use on the GSM
850, 900, 1800, 1900 MHz and WCDMA
850, 1900, 2100 MHz networks. Contact
your service provider for more
information about networks.
Your device may have preinstalled
bookmarks and links for third-party
internet sites and may allow you to
access third-party sites. These are not
affiliated with Nokia, and Nokia does
not endorse or assume liability for
them. If you access such sites, take
precautions for security or content.
Switch it on 9

Warning:
To use any features in this device, other
than the alarm clock, the device must be
switched on. Do not switch the device
on when wireless device use may cause
interference or danger.
When using this device, obey all laws
and respect local customs, privacy and
legitimate rights of others, including
copyrights. Copyright protection may
prevent some images, music, and other
content from being copied, modified, or
transferred.
Make back-up copies or keep a written
record of all important information
stored in your device.
When connecting to any other device,
read its user guide for detailed safety
instructions. Do not connect
incompatible products.
The images in this guide may differ from
your device display.
Refer to the user guide for other
important information about your
device.
Network services
To use the device you must have service
from a wireless service provider. Some
features are not available on all
networks; other features may require
that you make specific arrangements
with your service provider to use them.
Network services involve transmission
of data. Check with your service provider
for details about fees in your home
network and when roaming on other
networks. Your service provider can
explain what charges will apply.
Your service provider may have
requested that certain features be
disabled or not activated in your device.
If so, these features will not appear on
your device menu. Your device may also
have customized items such as menu
names, menu order, and icons.
Access codes
To set how your phone uses the access
codes and security settings, select
Menu > Settings > Security > Access
codes.
•The security code helps to protect
your phone against unauthorised
use. The preset code is 12345. You
can change the code and set the
phone to request the code. Some
operations require the security
code regardless of the settings, for
example if you want to restore the
factory settings. Keep the code
10 Switch it on

secret and in a safe place separate
from your phone. If you forget the
code and your phone is locked, your
phone will require service and
additional charges may apply. For
more information, contact a Nokia
Care point or your phone dealer.
•The PIN (UPIN) code, supplied with
the SIM (USIM) card, helps to protect
the card against unauthorised use.
•The PIN2 (UPIN2) code, supplied
with some SIM (USIM) cards, is
required to access certain services.
•PUK (UPUK) and PUK2 (UPUK2) codes
may be supplied with the SIM (USIM)
card. If you enter the PIN code
incorrectly three times in
succession, you are asked for the
PUK code. If the codes are not
supplied, contact your service
provider.
•The barring password is required
when using the call barring service
to restrict calls to and from your
phone (network service).
Switch the device on and off
Switch on and off
Press and hold the power key.
Enter the PIN code
If requested, enter the PIN code
(displayed as ****).
Set the time and date
If requested, enter the date, the local
time, and the time zone and the
daylight saving time of your location.
When you switch on your device for the
first time, you may be prompted to get
the configuration settings from your
service provider (network service). For
more information, contact your service
provider.
Standby mode
When the phone is ready for use, and
you have not entered any characters,
the phone is in the standby mode.
Switch it on 11

Display
1Signal strength of the cellular
network
2Battery charge status
3Indicators
4Clock
5Name of the network or the
operator logo
6Date (only if the Home screen is
deactivated)
7Display
8Function of the left selection key
9Function of the Navi key (scroll key)
10 Function of the right selection key
You may change the function of the left
and right selection key. See " Left and
right selection keys ", p. 19.
Home screen
The home screen displays a list of
selected features and information that
you can directly access.
Select Menu > Settings > Display >
Home screen.
Activate the home screen
Select Home screen mode.
Organise and personalise the home
screen
Select Personalise view.
Select a key to activate the home
screen
Select Home screen key.
Navigate in the home screen
Scroll up or down to navigate in the list,
and select Select, View, or Edit. The
arrows indicate that further
information is available.
Stop navigating
Select Exit.
Shortcuts
When your device is in the standby or
home screen mode, you can use the
following shortcuts.
12 Switch it on

List missed, received, and dialled
calls
Press the call key. To make a call, scroll
to the number or name, and press the
call key.
Start the web browser
Press and hold 0.
Call the voice mailbox
Press and hold 1.
Use other keys as shortcuts
See "Dialling shortcuts", p. 25.
Indicators
You have unread messages.
You have unsent, cancelled, or
failed messages.
The keypad is locked.
The device does not ring for
incoming calls or text
messages.
An alarm is set.
/ The device is registered to the
GPRS or EGPRS network.
/ A GPRS or EGPRS connection is
open.
/ The GPRS or EGPRS connection is
suspended (on hold).
Bluetooth connectivity is
activated.
A GPS signal is available.
(external GPS antenna
necessary).
No GPS signal available.
(external GPS antenna
necessary).
If you have two phone lines, the
second line is in use.
All incoming calls are diverted
to another number.
Calls are limited to a closed user
group.
The currently active profile is
timed.
Touch music keys
When listening to the FM radio, or using
the media player, to pause or resume
playback, skip songs, or switch between
saved stations, use the touch music
keys.
The figure shows the three touch-
sensitive areas marked in grey.
Switch it on 13

Activate the touch music keys
Select Menu > Settings > Phone >
Touch music keys.
Control the radio
Select Menu > Media > Radio. Use the
touch music keys to pause or resume
playback, and to switch between saved
radio stations.
Control the media player
Select Menu > Media > Media
player > Go to Media player. Use the
touch music keys to pause or resume
playback, and to skip songs.
To re-activate the radio or media player,
press and hold .
Navigate the menus
The phone offers you an extensive range
of functions that are grouped into
menus.
1 To access the menu, select Menu.
2 Scroll through the menu, and select
an option (for example, Settings).
3 If the selected menu contains
further submenus, select one (for
example, Call).
4 Select the setting of your choice.
5 To return to the previous menu
level, select Back.
To exit the menu, select Exit.
To change the menu view, select
Options > Main menu view. Scroll
right, and select from the available
options.
To rearrange the menu, select
Options > Organise. Scroll to the menu
item to be moved, and select Move.
Scroll to where you want to move the
menu item, and select OK. To save the
change, select Done > Yes.
14 Switch it on

Lock the keys
To prevent accidental key presses, lock
the touch music keys and the keypad.
Lock or unlock the keys
Slide the lock switch on the side of the
device. Alternatively, close or open the
slide.
Handle calls when the keys are
locked
To answer a call when the keypad is
locked, press the call key. When you end
or reject a call, the keypad locks
automatically.
When the device or keypad is locked,
calls may be possible to the official
emergency number programmed into
your device.
Functions without a SIM card
Some functions of your phone may be
used without inserting a SIM card, such
as Organiser functions and games.
Some functions appear dimmed in the
menus and cannot be used.
Flight profile
Use the Flight profile in radio sensitive
environments to deactivate all radio
frequency functions. You still have
access to offline games, the calendar,
and phone numbers. When the Flight
profile is active, is displayed.
Activate the Flight profile
Select Menu > Settings > Profiles >
Flight > Activate or Personalise.
Deactivate the Flight profile
Select any other profile.
Warning:
With the Flight profile you cannot make
or receive any calls, including
emergency calls, or use other features
that require network coverage. To make
calls, you must first activate the phone
function by changing profiles. If the
device has been locked, enter the lock
code.
If you need to make an emergency call
while the device is locked and in the
Flight profile, you may be also able to
enter an official emergency number
programmed in your device in the lock
code field and select 'Call'. The device
will confirm that you are about to exit
Flight profile to start an emergency call.
Switch it on 15

Make it your device
Set up your device, personalise it, and
connect it in several ways.
Basic settings
Phone settings
Select Menu > Settings and Phone.
Select from the following:
Language settings — To set the
language of your device, select Phone
language and a language. To set the
language of your device according to
the information on the SIM card, select
Phone language > Automatic.
Touch music keys — Activate the
touch music keys.
Memory status — View the memory
consumption.
Automatic keyguard — Set the
keypad to lock automatically after a
preset time delay when the device is in
the home screen and no function has
been used.
Security keyguard — Set the device to
prompt for the security code to unlock
the keypad.
Voice recognition — Set up voice
commands, or start voice recognition
training.
Flight query — Set the device to
prompt for the flight profile when you
switch the device on. In the flight
profile, all radio connections are closed.
Phone updates — Allow software
updates from your service provider
(network service). The available options
may vary.
Network mode — To use GSM and
(when available) 3G networks, select
Dual mode. This option is not available
during an active call.
Operator selection — Manually select
which network to use.
Help text activation — Set the device
to display help text.
Start-up tone — Play a tone when you
switch the device on.
Confirm SIM actions — Access
additional network services from your
SIM card. This option may not be
available, depending on your SIM card.
Security settings
Select Menu > Settings and Security.
When security features that restrict calls
are in use (such as call barring, closed
user group, and fixed dialling), calls may
be possible to the official emergency
number programmed into your device.
16 Make it your device

Call barring and call diverting cannot be
active at the same time.
Select from the following:
PIN code request or UPIN code
request — Set the device to request for
the PIN or UPIN code every time the
device is switched on. Some SIM cards
do not allow the code request to be
deactivated.
Call barring service — Restrict
incoming calls to and outgoing calls
from your device (network service). A
barring password is required.
Fixed dialling — Restrict your
outgoing calls to selected phone
numbers if supported by your SIM card.
When fixed dialling is activated, GPRS
connections are not possible except
while sending text messages over a
GPRS connection. In this case, the
recipient’s phone number and the
message centre number must be
included in the fixed dialling list.
Closed user group — Define a group of
people whom you can call and who can
call you (network service).
Security level — To request the
security code whenever a new SIM card
is inserted into the device, select
Phone.
Access codes — Change the security
code, PIN code, UPIN code, PIN2 code, or
barring password.
PIN2 code request — Set the device to
request the PIN2 code when using a
specific device feature protected by the
PIN2 code. Some SIM cards do not allow
the code request to be deactivated. This
option may not be available depending
on your SIM card. For details, contact
your service provider.
Code in use — Display and select the
type of PIN code to be used.
Authority certificates or User
certificates — View the list of the
authority or user certificates available
on your device.
Security module sett. — View Secur.
module details, activate Module PIN
request, or change the module PIN and
signing PIN.
Personalise your phone
Give your phone a personal touch with
ringing tones, display backgrounds, and
themes. Add shortcuts for your
preferred features, and attach
enhancements.
Profiles
Your phone has various setting groups
called profiles, which you can customise
Make it your device 17

with ringing tones for different events
and environments.
Select Menu > Settings > Profiles, the
desired profile, and from the following
options:
Activate — to activate the selected
profile
Personalise — to change the profile
settings
Timed — to set the profile to be active
for a certain time. When the time set for
the profile expires, the previous profile
that was not timed becomes active.
Themes
A theme contains elements for
personalising your phone.
Select Menu > Settings > Themes and
from the following options:
Select theme — Open the Themes
folder, and select a theme.
Theme downloads — Open a list of
links to download more themes.
Tones
You can change the tone settings of the
selected active profile.
Select Menu > Settings > Tones. You
can find the same settings in the
Profiles menu.
Lights
Personalise your device with light
effects associated with different
functions. Select Menu > Settings
andLights.
Choose a colour
Select Light colours and a colour.
Activate light effects
Select Light effects.
Display
Select Menu > Settings > Display and
from the following:
Wallpaper — to add a background
image for the home screen mode
Home screen — to activate, organise,
and personalise the home screen mode
Home screen font col. — to select the
font colour for the home screen mode
Navigation key icons — to display the
scroll key icons in the home screen
mode
Notification details — to display
details in missed call and message
notifications
Screen saver — to create and set a
screen saver
18 Make it your device

Font size — to set the font size for
messaging, contacts, and web pages
Operator logo — to display the
operator logo
Cell info display — to display the cell
identity, if available from the network
My shortcuts
With personal shortcuts, you get quick
access to frequently used functions of
your phone.
Left and right selection keys
To change the function assigned to the
left or right selection key, select
Menu > Settings > My shortcuts >
Left selection key or Right selection
key, and the desired function.
In the home screen mode, if the left
selection key is Go to, to activate a
function, select Go to > Options and
from the following:
Select options — to add or remove a
function
Organise — to rearrange the functions
Other shortcuts
Select Menu > Settings > My
shortcuts and from the following:
Navigation key — to assign other
functions from a predefined list to the
navigation key (scroll key)
Home screen key — to select the
movement of the navigation key to
activate the home screen mode
Assign dialling shortcuts
Create shortcuts by assigning phone
numbers to the number keys 2-9.
1 Select Menu > Contacts > Speed
dials, and scroll to a number key.
2 Select Assign, or, if a number has
already been assigned to the key,
select Options > Change.
3 Enter a number or search for a
contact.
Voice commands
You can use voice commands to make
phone calls, launch applications, and
activate profiles.
Select Menu > Settings > Phone.
Voice commands are language-
dependent. To set the language, select
Language settings > Phone
language and the language.
Make it your device 19

To train the voice recognition of your
device to your voice, select Voice
recognition > Voice recog. training.
To activate a voice command for a
function, select Voice recognition >
Voice commands, a feature, and the
function. indicates that the voice
command is activated.
To activate the voice command, select
Add.
To play the activated voice command,
select Play.
To use voice commands, see "Voice
dialling", p. 25.
To manage voice commands, scroll to a
function, select Options and from the
following:
Edit or Remove — to rename or
deactivate the voice command
Add all or Remove all — to activate or
deactivate voice commands for all
functions in the voice commands list
Connect
Your phone provides several features to
connect to other devices to transmit and
receive data.
Bluetooth wireless technology
Bluetooth technology allows you to
connect your device, using radio waves,
to a compatible Bluetooth device within
10 metres (32 feet).
This device is compliant with Bluetooth
Specification 2.1 + EDR supporting the
following profiles: SIM access, object
push, file transfer, headset, handsfree,
generic access, serial port, generic
object exchange, advanced audio
distribution, audio video remote
control, service discovery application,
personal area networking, phonebook
access, and generic audio/video
distribution. To ensure interoperability
between other devices supporting
Bluetooth technology, use Nokia
approved accessories for this model.
Check with the manufacturers of other
devices to determine their compatibility
with this device.
Features using Bluetooth technology
increase the demand on battery power
and reduce the battery life.
When the wireless device is in the
remote SIM mode, you can only use a
compatible connected accessory, such
as a car kit, to make or receive calls.
Your wireless device will not make any
calls, except to the emergency numbers
20 Make it your device
