Nokia 6230i user guide
9236580
Issue 1

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-72 is in conformity
with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trademarks or registered trademarks of
Nokia Corporation. Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and non-
commercial use in connection with information which has been encoded in compliance with the MPEG-4
Visual Standard by a consumer engaged in a personal and non-commercial activity and (ii) for use in

connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be
implied for any other use. Additional information including that relating to promotional, internal and
commercial uses may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of
any kind, either express or implied, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or
contents of this document. Nokia reserves the right to revise this document or withdraw it at any time
without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer nearest to
you.
Export Controls
This device may contain commodities, technology or software subject to export laws and regulations from
the US and other countries. Diversion contrary to law is prohibited.
9236580 / Issue 1

4Copyright © 2005 Nokia. All rights
Contents
FOR YOUR SAFETY ............................................................................................ 12
General information.......................................................................................... 16
Overview of functions ............................................................................................................................. 16
Access codes .............................................................................................................................................. 17
Security code.......................................................................................................................................... 17
PIN codes................................................................................................................................................. 17
PUK codes................................................................................................................................................ 18
Barring password .................................................................................................................................. 18
Wallet code............................................................................................................................................. 18
Configuration settings service.............................................................................................................. 19
Nokia support on the Web..................................................................................................................... 19
1. Get started ..................................................................................................... 20
Install the SIM card and the battery................................................................................................... 20
Install a multimedia card ....................................................................................................................... 21
Charge the battery ................................................................................................................................... 22
Switch the phone on and off ................................................................................................................ 23
Normal operating position..................................................................................................................... 24
Change the covers.................................................................................................................................... 25
2. Your phone..................................................................................................... 27
Keys and connectors................................................................................................................................ 27
Standby mode............................................................................................................................................ 29
Power saving .......................................................................................................................................... 30
Indicators................................................................................................................................................. 30
Shortcuts in the standby mode......................................................................................................... 32
Keypad lock (keyguard)........................................................................................................................... 32

5Copyright © 2005 Nokia. All rights
3. Call functions ................................................................................................ 34
Make a call ................................................................................................................................................. 34
Speed dialing.......................................................................................................................................... 34
Answer or reject a call ............................................................................................................................ 35
Call waiting............................................................................................................................................. 35
Options during a call ............................................................................................................................... 36
4. Write text....................................................................................................... 38
Settings ....................................................................................................................................................... 38
Predictive text input ................................................................................................................................ 39
Traditional text input .............................................................................................................................. 40
Tips................................................................................................................................................................ 40
5. Navigate the menus ...................................................................................... 42
Access a menu function ......................................................................................................................... 42
List of menu functions ............................................................................................................................ 44
6. Menu functions ............................................................................................. 49
Messages..................................................................................................................................................... 49
Text messages (SMS)............................................................................................................................ 49
Write and send SMS messages...................................................................................................... 50
Sending options ................................................................................................................................. 50
Read and reply to an SMS message or an SMS email ............................................................ 51
Templates............................................................................................................................................. 52
Multimedia messages .......................................................................................................................... 53
Write and send a multimedia message....................................................................................... 54
Read and reply to a multimedia message .................................................................................. 56
Multimedia messages memory full .............................................................................................. 57
Folders...................................................................................................................................................... 57
Instant messages................................................................................................................................... 58

6Copyright © 2005 Nokia. All rights
Basic steps for instant messaging ................................................................................................ 59
Access the instant messaging menu............................................................................................ 60
Connect to and disconnect from the instant messaging service......................................... 61
Start an instant messaging conversation................................................................................... 61
Accept or reject an instant messaging invitation .................................................................... 63
Read a received instant message.................................................................................................. 63
Participate in an instant messaging conversation................................................................... 64
Edit your availability status............................................................................................................ 64
Contacts for instant messaging .................................................................................................... 65
Block and unblock messages.......................................................................................................... 65
Groups................................................................................................................................................... 66
Email application .................................................................................................................................. 67
Secure server connection ................................................................................................................ 67
Write and send an email ................................................................................................................. 68
Download email from your email account................................................................................. 69
Read and reply to email................................................................................................................... 69
Inbox and Other folders................................................................................................................... 70
Delete email messages..................................................................................................................... 70
Voice messages...................................................................................................................................... 71
Info messages......................................................................................................................................... 71
Service commands ................................................................................................................................ 71
Delete messages .................................................................................................................................... 72
Message settings................................................................................................................................... 72
Text message and SMS email message settings....................................................................... 72
Multimedia message settings ........................................................................................................ 73
Email settings ..................................................................................................................................... 75
Other settings ..................................................................................................................................... 76
Contacts ...................................................................................................................................................... 76

7Copyright © 2005 Nokia. All rights
Search for a contact............................................................................................................................. 77
Save names and phone numbers...................................................................................................... 77
Save multiple numbers, text items, or an image ......................................................................... 77
Copy contacts......................................................................................................................................... 78
Edit contact details .............................................................................................................................. 78
Delete contacts...................................................................................................................................... 79
My presence............................................................................................................................................ 79
Subscribed names ................................................................................................................................. 82
Add contacts to the subscribed names ....................................................................................... 83
View the subscribed names ............................................................................................................ 83
Unsubscribe a contact...................................................................................................................... 84
Business cards........................................................................................................................................ 84
Speed dials .............................................................................................................................................. 85
Voice dialing........................................................................................................................................... 85
Add and manage voice tags ........................................................................................................... 86
Make a call by using a voice tag................................................................................................... 86
Other functions in Contacts............................................................................................................... 87
Call register ................................................................................................................................................ 87
Recent calls lists.................................................................................................................................... 88
Counters and timers for calls, data, and messages..................................................................... 88
Positioning information ...................................................................................................................... 88
Settings ...................................................................................................................................................... 89
Profiles ..................................................................................................................................................... 89
Themes ..................................................................................................................................................... 90
Tones......................................................................................................................................................... 90
Display...................................................................................................................................................... 91
Time and date......................................................................................................................................... 91
My shortcuts........................................................................................................................................... 92
Connectivity............................................................................................................................................ 93

8Copyright © 2005 Nokia. All rights
Bluetooth wireless technology ...................................................................................................... 93
Set up a Bluetooth connection...................................................................................................... 93
Bluetooth wireless connection ...................................................................................................... 94
Bluetooth settings............................................................................................................................. 94
Infrared................................................................................................................................................. 95
(E)GPRS................................................................................................................................................. 96
(E)GPRS connection .......................................................................................................................... 96
(E)GPRS modem settings ................................................................................................................. 97
USB data cable ................................................................................................................................... 97
Call ............................................................................................................................................................ 98
Phone........................................................................................................................................................ 99
Enhancements..................................................................................................................................... 100
Configuration ...................................................................................................................................... 101
Security ................................................................................................................................................. 102
Restore factory settings ................................................................................................................... 103
Operator menu ....................................................................................................................................... 104
Gallery....................................................................................................................................................... 104
Media ........................................................................................................................................................ 106
Camera .................................................................................................................................................. 106
Take a photo..................................................................................................................................... 106
Record a video clip......................................................................................................................... 107
Camera settings .............................................................................................................................. 107
Media player........................................................................................................................................ 107
Set up the phone for a streaming service ............................................................................... 108
Music player ........................................................................................................................................ 108
Play the music tracks transferred to the phone .................................................................... 109
Music player settings .................................................................................................................... 109
Radio...................................................................................................................................................... 111
Listen to the radio .......................................................................................................................... 111

9Copyright © 2005 Nokia. All rights
Tune a radio channel ..................................................................................................................... 111
Basic radio functions..................................................................................................................... 112
Voice recorder ..................................................................................................................................... 113
Record sound ................................................................................................................................... 113
List of recordings ............................................................................................................................ 114
Define a storage folder ................................................................................................................. 114
Equalizer ............................................................................................................................................... 114
Push to talk ............................................................................................................................................. 115
Push to talk menu.............................................................................................................................. 115
Connect to and disconnect from the push to talk service ..................................................... 116
Make and receive a push to talk call............................................................................................ 117
Make a group call........................................................................................................................... 117
Make a one-to-one call................................................................................................................ 117
Receive a group or a one-to-one call....................................................................................... 118
Callback requests ............................................................................................................................... 118
Send a callback request................................................................................................................ 119
Respond to a callback request.................................................................................................... 119
Save the callback request sender............................................................................................... 120
Add a one-to-one contact............................................................................................................... 120
Create and set up groups................................................................................................................. 120
Push to talk settings ......................................................................................................................... 122
Organizer.................................................................................................................................................. 124
Alarm clock .......................................................................................................................................... 124
When the alarm time expires...................................................................................................... 124
Calendar................................................................................................................................................ 125
Make a calendar note.................................................................................................................... 125
When the phone sounds an alarm for a note......................................................................... 126
To-do list .............................................................................................................................................. 126
Notes...................................................................................................................................................... 126

10Copyright © 2005 Nokia. All rights
Wallet.................................................................................................................................................... 127
Access the wallet menu................................................................................................................ 128
Save card details............................................................................................................................. 128
Personal notes ................................................................................................................................. 129
Create a wallet profile .................................................................................................................. 129
Wallet settings ................................................................................................................................ 130
Guidelines for making purchases with the wallet................................................................. 131
Synchronization.................................................................................................................................. 132
Synchronize from your phone..................................................................................................... 132
Synchronization settings.............................................................................................................. 133
Synchronize from a compatible PC ........................................................................................... 133
Applications ............................................................................................................................................ 134
Games.................................................................................................................................................... 134
Launch a game ................................................................................................................................ 134
Game downloads ............................................................................................................................ 134
Game settings.................................................................................................................................. 134
Collection ............................................................................................................................................. 134
Launching an application............................................................................................................. 135
Other application options ............................................................................................................ 135
Download an application ............................................................................................................. 135
Calculator............................................................................................................................................. 137
Countdown timer ............................................................................................................................... 137
Stopwatch ............................................................................................................................................ 138
Web ........................................................................................................................................................... 139
Basic steps to access and use services......................................................................................... 139
Set up browsing.................................................................................................................................. 140
Connect to a service.......................................................................................................................... 140
Browse pages ...................................................................................................................................... 141
Browse with phone keys............................................................................................................... 141

11Copyright © 2005 Nokia. All rights
Options while browsing ................................................................................................................ 142
Direct calling.................................................................................................................................... 143
Appearance settings.......................................................................................................................... 143
Cookies.................................................................................................................................................. 144
Scripts over secure connection ...................................................................................................... 144
Bookmarks............................................................................................................................................ 144
Receive a bookmark ....................................................................................................................... 145
Download files .................................................................................................................................... 145
Service inbox ....................................................................................................................................... 145
Service inbox settings ................................................................................................................... 146
Cache memory .................................................................................................................................... 147
Browser security................................................................................................................................. 147
Security module .............................................................................................................................. 147
Certificates ....................................................................................................................................... 148
Digital signature ............................................................................................................................. 149
SIM services ............................................................................................................................................ 150
7. PC connectivity............................................................................................ 151
PC Suite.................................................................................................................................................... 151
(E)GPRS, HSCSD, and CSD................................................................................................................... 151
Data communication applications.................................................................................................... 152
8. Battery information..................................................................................... 153
Charging and Discharging................................................................................................................... 153
CARE AND MAINTENANCE............................................................................. 155
ADDITIONAL SAFETY INFORMATION............................................................. 157

12Copyright © 2005 Nokia. All rights
FOR YOUR SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal. Read the
complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or when it
may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELLING
Don't use the phone at a refuelling point. Don't use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Don't use the phone where blasting is in progress.

13Copyright © 2005 Nokia. All rights
USE SENSIBLY
Use only in the normal position as explained in the product documentation.
Don't touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all important
information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the end key as many times
as needed to clear the display and return to the start screen. Key in the
emergency number, then press the call key. Give your location. Do not end the
call until given permission to do so.

14Copyright © 2005 Nokia. All rights
■ABOUT YOUR DEVICE
The wireless device described in this guide is approved for use on the EGSM 900, GSM 1800,
and GSM 1900 network. Contact your service provider for more information about networks.
When using the features in this device, obey all laws and respect privacy and legitimate
rights of others.
Warning: To use any features in this device, other than the alarm clock, the device
must be powered on. Do not switch the device on when wireless device use may
cause interference or danger.
■Network Services
To use the phone you must have service from a wireless service provider. Many of the
features in this device depend on features in the wireless network to function. These
Network Services may not be available on all networks or you may have to make specific
arrangements with your service provider before you can utilize Network Services. Your
service provider may need to give you additional instructions for their use and explain what
charges will apply. Some networks may have limitations that affect how you can use
Network Services. For instance, some networks may not support all language-dependent
characters and services.
Your service provider may have requested that certain features be disabled or not activated
in your device. If so, they will not appear on your device menu. Your device may also have
been specially configured for your network provider. This configuration may include changes
in menu names, menu order and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some
features of this device, such as multimedia messaging (MMS), browsing, e-mail application,
instant messaging, presence-enhanced contacts, remote synchronization, and content
downloading using the browser or MMS, require network support for these technologies.

15Copyright © 2005 Nokia. All rights
■SHARED MEMORY
The following features in this device may share memory: contacts, text and instant
messages, e-mail, voice tags, calendar, to-do notes, and JavaTM games and applications, and
note application. Use of one or more of these features may reduce the memory available for
the remaining features sharing memory. For example, saving many Java applications etc.,
may use all of the available memory. Your device may display a message that the memory is
full when you try to use a shared memory feature. In this case, delete some of the
information or entries stored in the shared memory features before continuing. Some of the
features, such as Java applications, may have a certain amount of memory specially allotted
to them in addition to the memory shared with other features.
Note that gallery files share a different memory. For further information see Gallery on
page 104.
■Enhancements
A few practical rules about accessories and enhancements:
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement, grasp and pull
the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted and are operating
properly.
• Installation of any complex car enhancements must be made by qualified personnel only.

16Copyright © 2005 Nokia. All rights
General information
■Overview of functions
The Nokia 6230i phone provides many functions that are practical for daily use,
such as a calendar, a clock, an alarm clock, a radio, a music player, and a built-in
camera. You can personalize your phone with Nokia Xpress-onTM color covers.
Your phone also supports the following functions:
• Enhanced data rates for GSM evolution (EDGE), see (E)GPRS on page 96.
• Extensible hypertext markup language (XHTML) browser, see Web on
page 139.
• Email application, see Email application on page 67.
• Instant messaging, see Instant messages on page 58.
• Presence-enhanced contacts, see My presence on page 79.
• Push to talk, see Push to talk on page 115.
• Java 2 Micro Edition (J2METM), see Applications on page 134.
• Bluetooth technology, see Bluetooth wireless technology on page 93.
• Multimedia card to extend the memory capacity of your phone to store images
and video clips.

17Copyright © 2005 Nokia. All rights
■Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against
unauthorized use. The preset code is 12345. Change the code, and keep the new
code secret and in a safe place separate from your phone. To change the code, and
to set the phone to request the code, see Security on page 102.
If you enter an incorrect security code five times in succession, the phone ignores
further entries of the code. Wait for 5 minutes, and enter the code again.
PIN codes
• The personal identification number (PIN) code (4 to 8 digits) helps to protect
your SIM card against unauthorized use. The PIN code is usually supplied with
the SIM card. Set the phone to request the PIN code each time the phone is
switched on. See Security on page 102.
• The PIN2 code may be supplied with the SIM card and is required for some
functions.
• The module PIN is required to access the information in the security module.
See Security module on page 147. The module PIN is supplied with the SIM
card if the SIM card has a security module in it.
• The signing PIN is required for the digital signature. See Digital signature on
page 149. The signing PIN is supplied with the SIM card if the SIM card has a
security module in it.

18Copyright © 2005 Nokia. All rights
If you enter an incorrect PIN code three times in succession, the phone may
display PIN blocked or PIN code blocked and ask you to enter the PUK code.
PUK codes
The personal unblocking key (PUK) code (8 digits) is required to change a blocked
PIN code. The PUK2 code is required to change a blocked PIN2 code.
If the codes are not supplied with the SIM card, contact your local service provider
for the codes.
Barring password
The barring password (4 digits) is required when using the Call barring service. See
Security on page 102. You can obtain the password from your service provider.
Wallet code
The wallet code (4 to 10 digits) is required to access the wallet services. If you
enter an incorrect wallet code three times in succession, the wallet application is
blocked for 5 minutes. If you give three more incorrect entries, the time doubles.
For further information, see Wallet on page 127.

19Copyright © 2005 Nokia. All rights
■Configuration settings service
Before you use multimedia messaging, instant messaging and presence, push to
talk, email application, synchronization, streaming, and the browser, you must
have the proper configuration settings on your phone. You may receive the
settings directly as a configuration message, which you save to your phone. For
more information on availability, contact your network operator, service provider,
or nearest authorized Nokia dealer.
When you have received the settings as a configuration message, and the settings
are not automatically saved and activated, Configuration settings received is
displayed.
To save the received settings, select Show >Save. If the phone requests Enter
settings’ PIN:, enter the PIN code for the settings, and select OK. To receive the PIN
code, contact the service provider that supplies the settings.
If no settings are saved yet, these settings are saved and set as default
configuration settings. Otherwise, the phone asks Activate saved configuration
settings?.
To discard the received settings, select Show >Discard.
■Nokia support on the Web
Check <www.nokia.com/support> or your local Nokia Web site for the latest
version of this guide, additional information, downloads, and services related to
your Nokia product.

20Copyright © 2005 Nokia. All rights
1. Get started
■Install the SIM card and the battery
Always switch the device off and disconnect the charger before removing the battery.
Keep all SIM cards out of the reach of small children. For availability and information on
using SIM card services, contact your SIM card vendor. This may be the service provider,
network operator, or other vendor.
This device is intended for use with the BL-5C battery.
The SIM card and its contacts can easily be damaged by scratches or bending, so
be careful when handling, inserting, or removing the card.
1. With the back of the phone facing you, push the
back cover release button (1).
2. Slide the back cover to remove it from the phone (2).
3. To remove the battery, lift it as
shown (3).
4. To release the SIM card holder,
gently pull the locking clip of the
card holder, and open it (4).
