Quick Start Guide
for Nokia N72

Copyright © 2006 Nokia. All rights reserved.
© 2006 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and
company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written
permission of Nokia is prohibited.

3
Copyright © 2006 Nokia. All rights reserved.
Model number: Nokia N72-5.
Hereinafter referred to as Nokia N72.
Insert the SIM card and battery
Keep all SIM cards out of the reach of small children.
Always switch the device off, and disconnect the charger before removing the battery.
1With the back of the device facing you, press the release
button (1), and slide the cover in the direction of the
arrow (2).
2Lift the cover (3).
3To release the SIM card holder, lift the holder up (4).
4Insert the SIM card (5). Make sure that the contact area on
the card is facing the connectors on the device and the
bevelled corner on the card is facing the base of the device.
5Close the holder, and lock it into place.

4Copyright © 2006 Nokia. All rights reserved.
6Insert the battery (6).
7Replace the back cover.
Insert the memory card
Use only Reduced Size MultiMediaCards (RS-MMC) approved by
Nokia for use with this device. Nokia utilizes the approved
industry standards for memory cards but not all other brands may function correctly or be fully
compatible with this device.
Use only compatible Reduced Size MultiMediaCards (RS-MMC) approved by Nokia for use with
this device. Other memory cards, such as Secure Digital (SD) cards, do not fit in the memory card
slot and are not compatible with this device. Using an incompatible memory card may damage
the memory card as well as the device, and data stored on the incompatible card may be
corrupted.
Use a compatible memory card to save the memory on your device. You can also back up
information from your device to a compatible memory card, for example:
• Reduced Size MultiMediaCard (RS-MMC) memory card .
• MultiMediaCard (MMC) adapter .
You do not need the adapter when you use the RS-MMC in your Nokia N72. The adapter
allows you to use the RS-MMC in another compatible device that has a full-size MMC slot.
A compatible memory card may already be inserted in your device.

5
Copyright © 2006 Nokia. All rights reserved.
1To insert a memory card, open the door of the memory card
slot (7). Place your finger in the recess on top of the door,
and lift out the door.
2Insert a compatible memory card in the slot (8). Make sure
that the contact area on the card is facing up and the
bevelled corner is facing the base of the device.
3Push the card in (9). You can hear a click when the card
locks into place.
4Close the door. You cannot use the memory card if the door is open.
Eject the memory card
1Open the door of the memory card slot.
2Press the memory card to release it from the slot.
3Remove the memory card. If the device is switched on, select OK.

6Copyright © 2006 Nokia. All rights reserved.
Important: Do not remove the memory card in the middle of an operation when the card
is being accessed. Removing the card in the middle of an operation may damage the
memory card as well as the device, and data stored on the card may be corrupted.
Charge the battery
1Connect a compatible charger to a wall outlet.
2Connect the power cord to the device. The battery indicator
bar starts scrolling. The device can be used while charging.
If the battery is completely discharged, it may take a few
minutes before the charging indicator is shown.
3When the battery is fully charged, the bar stops scrolling. Disconnect the charger, first from
the device, then from the wall outlet.
Headset
Connect a compatible headset to the Pop-PortTM connector of
your device.
Warning: When you use a headset, your ability to hear
outside sounds may be affected. Do not use a headset where it can endanger your safety.
To use standard stereo 3.5 mm headphones use Nokia Audio Adapter AD-49. Plug the cable of
the adapter into the Pop-PortTM connector of your Nokia N72 and plug your headphones into
the connector at the top of the adapter.

7
Copyright © 2006 Nokia. All rights reserved.
To answer or end a call, press the call key . During a call speak into the microphone at the
upper right corner of the call key. To adjust the volume, use the device keys.
Keys and parts
• Power key (1)
• Loudspeaker outlet (2)
• Light sensor (3) constantly observes the lighting
conditions which may cause the display and keypad to
flash in low light.
• Selection keys (4) to select commands and
items
• Call key (5)
• 5-way scroll key (6) to move around the menus.
Press the scroll key in the middle ( ) to select,
accept, or activate.
• Menu key (7) opens the main menu
• Edit key (8) opens a list of commands when you
edit text
• Microphone (9)
• Press and hold (10) as a shortcut to a Web
connection
• Clear key (11) deletes text and items
• Music key (12) opens the music player
• End key (13)
• Camera capture key (14) for still image capture with the camera
• Memory card slot (15)
• Earpiece (16)

8Copyright © 2006 Nokia. All rights reserved.
• Open the camera lens cover (17) to activate the
camera
• Camera (18) for high resolution image capture or
video recording
• LED flash (19)
• Charger connector (20)
• Pop-Port connector (21) for a compatible USB data
cable, headset, and other compatible enhancements.

9
Copyright © 2006 Nokia. All rights reserved.
Switch the device on
Press and hold .
If the device asks for a PIN code or lock code, enter the code
(displayed as ****), and press (OK). The factory setting for the
lock code is 12345. For more information on the access codes,
see the user guide for your device.
Your device has an internal antenna.
Note: As with any other radio transmitting device, do not touch the
antenna unnecessarily when the device is switched on. Contact with the antenna affects
call quality and may cause the device to operate at a higher power level than otherwise
needed. Avoiding contact with the antenna area when operating the device optimizes
the antenna performance and the battery life.
When you switch on the device for the first time, it may ask you to set the following
information: Select current city:, Time:, and Date:. Use the scroll key ( ) and the number
keys. To find the city, enter the first letters of the city name. The city you select also defines the
time zone for the clock in your device.
Press (menu key) to open the main menu.

10 Copyright © 2006 Nokia. All rights reserved.
Your service provider may have requested that certain features be disabled or not activated in
your device. If so, they will not appear on your device menu. Your device may also have been
specially configured. This configuration may include changes in menu names, menu order, and
icons. Contact your service provider for more information.
About the display
Remove the protective plastic films covering the display and camera.
A small number of missing, discoloured, or bright dots may appear on the screen. This is a
characteristic of this type of display. Some displays may contain pixels or dots that remain on
or off. This is normal, not a fault.
MMS and mobile Internet settings
Your Nokia N72 normally has MMS, GPRS, streaming, and mobile Internet settings
automatically configured in the device, based upon your service provider or network operator
information.
Essential indicators
The device is being used in a GSM network.
You have received one or several messages to the Inbox folder in Messaging.
There are messages waiting to be sent in the Outbox folder.
You have missed calls.

11
Copyright © 2006 Nokia. All rights reserved.
Shown if Ringing type is set to Silent and Message alert tone, IM alert tone, and E-mail
alert tone are set to Off.
The device keypad is locked.
A clock alarm is active.
(network service) The second phone line is being used.
All calls to the device are diverted to another number. If you have two phone lines,
the divert indicator for the first line is and for the second .
A headset is connected to the device.
A loopset is connected to the device.
The connection to a headset with Bluetooth connectivity has been lost.
A data call is active.
GPRS or EDGE packet data connection is available.
GPRS or EDGE packet data connection is active.
GPRS or EDGE packet data connection is on hold.
Bluetooth connectivity is on.
Data is being transmitted using Bluetooth connectivity.
USB connection is active.
An e-mail that has been read is waiting for you to retrieve to your device.
An e-mail that has not been read is waiting for you to retrieve to your device.

12 Copyright © 2006 Nokia. All rights reserved.
Keypad lock (keyguard)
Use the keypad lock to prevent the keys from being accidentally pressed.
To lock: In the standby mode, press , then . When the keys are locked, is shown on
the display.
To unlock: Press , then .
When the keypad lock is on, calls may be possible to the official emergency number programmed
into your device.
Opening the camera lens cover deactivates the keypad lock, if it is on. Closing the camera lens
cover returns the device to the previous mode, and keypad lock is reactivated, if it was on.
To turn on the display light when the keypad lock is on, press .
Standby mode shortcuts
• To switch between applications that are open, press and hold
. If memory is low, the device may close some applications.
The device saves any unsaved data before closing an
application.
Leaving applications running in the background increases the
demand on battery power and reduces the battery life.
• To change the profile, press , and select a profile.
• To start a connection to Web, press and hold . For more
information on Web, see the user guide for your device.
For further shortcuts available in the standby mode, see the user
guide for your device.

13
Copyright © 2006 Nokia. All rights reserved.
Tips for efficient use
• When you take a picture or record a video, press to start sending the item as a
multimedia message. You cannot send video clips that are saved in the .mp4 format in a
multimedia message.
• To send the message you are writing, press .
• In the standby mode, press to open the last dialled numbers list.
• To switch between General and Silent profiles, press and hold . If you have two phone
lines, this action switches between the two lines.
For more shortcuts, see the user guide, “Useful shortcuts”.
Transfer content from another device
To use the Transfer application, see the user guide for your device.
Nokia Content Copier is available in Nokia PC Suite to copy content from a compatible Nokia
phone. See the CD-ROM supplied with your device. Nokia Content Copier supports several Nokia
phone models. For more information on the devices supported by each Nokia PC Suite, refer to
the www.nokia-asia.com/pcsuite pages.

14 Copyright © 2006 Nokia. All rights reserved.
Help
Your device has a help function, which provides you instructions and information when using
the device. To access it from an application, select Options > Help.
Example: To view instructions on how to create a contact card, start to create a contact
card, and select Options > Help; or in the main menu, select Tools > Help and open the
instructions for Contacts. When you are reading the instructions, to switch between Help
and the application that is open in the background, press and hold .
User guide
Read the user guide to get familiar with your Nokia N72.
Further detailed information is given in the separate user guide. Do not use this get started guide
in place of the complete user guide, which provides important safety and maintenance
information.
Check www.nokia-asia.com/N72/support or your local Nokia Web site for the latest version of
the user guide, additional information, downloads, and services related to your Nokia product.
