CCS Technical Documentation
RH-3 Series Transceivers
Issue 1 06/2003 Confidential Nokia Corporation
Disassembly
RH-3
Disassembly CCS Technical Documentation
Page 2 Nokia Corporation Confidential Issue 1 06/2003
CCS Technical Documentation Disassembly
RH-3
Issue 1 06/2003 Nokia Corporation Confidential Page 3
ESD Protection
Step-by-Step Disassembly Instructions
Remove the battery cover (B-cover)
1 Turn the phone off.
2 Remove the battery cover (B-cover) by pushing down on the release button.
3 Remove battery.
Push here
B-cover
S
lide B-cover this way
RH-3
Disassembly CCS Technical Documentation
Page 4 Nokia Corporation Confidential Issue 1 06/2003
Remove A-cover
Snaps
CCS Technical Documentation Disassembly
RH-3
Issue 1 06/2003 Nokia Corporation Confidential Page 5
Remove screws using a nonconductive screwdriver
Remove LCD Assembly
6 screws
RH-3
Disassembly CCS Technical Documentation
Page 6 Nokia Corporation Confidential Issue 1 06/2003
Separate PWB from D-cover Assembly
Power Key Removal
Power Button
CCS Technical Documentation Disassembly
RH-3
Issue 1 06/2003 Nokia Corporation Confidential Page 7
PIFA Antenna Removal
Other Item Removal
• Headset jack (in PIFA antenna)
• Whip assembly
• DC jack
• Microphone
• Buzzer gasket
• Vibra motor
PIFA antenna
DO NOT TOUCH gold contacts with bare
fingers!
RH-3
Disassembly CCS Technical Documentation
Page 8 Nokia Corporation Confidential Issue 1 06/2003
