Nonscio ScioBot 2.0 User manual

ScioBot 2.0 Quick Start Guide
1
Slide the battery mount about halfway
onto the first wooden stick by inserting
the wooden stick through the slots on
the battery mount.
2
Insert the T-Connector 2.0 onto the
second wooden stick. Use the slot that
goes through the entire T-Connector so
that you can slide the T-Connector half
way onto the wooden stick.
3
Connect the two pieces using the
remaining available slot on the T-
Connector.
4
Insert the motors into the motor
mounts. They will slide in and fit snugly.
Some slight forcemay be required.
Warning! Be careful not to push on the
motor lead connections as they could
be damaged!
5
Attach the wheels to the motor shafts. The motor shaft has a
D shape. If you look at the hole in the center of the wheels
you will see the same D shape. Align the flat part of the D on
the motor with the flat part on the wheel and press the shaft
into the wheel. Do this for both motors.
Wrap a rubber
band around
each wheel. The
rubber bands
help give the
ScioBot traction
on smoother
surfaces, and
protect the
wheels from
wear.
6
Use the slots in the motor mounts to attach the wheel
assemblies to the main chassis. It does not matter if the
motors are oriented on top of the wooden stick or
underneath. Just make sure they are both the same,
otherwise you will find that your ScioBot is lopsided!
7
Press the 9V Battery holder into its bracket. Connect
the microcontroller and motor controller to the
breadboard and snap the breadboard into its bracket.
nonscio.com © Nonscio

Download and install the Arduino IDE
from the official Arduino website.
www.arduino.cc/en/software
Use this basic code to get your ScioBot 2.0 going! Modify it as much as you want to
make your ScioBot do all sorts of different things!
ScioBot 2.0 Quick Start Guide
8 11
9 10
nonscio.com © Nonscio
Scan this code to get
more information on
how to program
your ScioBot 2.0! Or
visit nonscio.com
Follow the wiring schematic to complete the wiring of your ScioBot 2.0!
Connect your ScioBot 2.0 to a computer
using the supplied USB cable. This will
allow you to upload the code you write
to the ScioBot 2.0 microcontroller.
