norbar PneuTorque PTS-52-500 User manual

OPERATOR’S MANUAL
PNEUTORQUE®
PTS™
500/800/1000/1350/2000/2700/4000/7000
REMOTE CONTROL AIR MOTOR
Part Number 34442 | Issue 1 | Original Instructions (English)
NORBAR TORQUE TOOLS LTD
Wildmere Road, Banbury,
Oxfordshire, OX16 3JU
UNITED KINGDOM
Tel + 44 (0)1295 270333
Email [e-mail]
NORBAR TORQUE TOOLS
45–47 Raglan Avenue, Edwardstown,
SA 5039
AUSTRALIA
Tel + 61 (0)8 8292 9777
Email [e-mail]
NORBAR TORQUE TOOLS INC
36400 Biltmore Place, Willoughby,
Ohio, 44094
USA
Tel + 1 866 667 2279
Email [e-mail]
NORBAR TORQUE TOOLS PTE LTD
194 Pandan Loop
#07-20 Pantech Business Hub
SINGAPORE 128383
Tel + 65 6841 1371
Email [e-mail]
NORBAR TORQUE TOOLS (SHANGHAI) LTD
91 Building-7F, No.1122 North Qinzhou Rd,
Xuhui District, Shanghai
CHINA 201103
Tel + 86 21 6145 0368
Email [e-mail]
NORBAR TORQUE TOOLS INDIA PVT. LTD
Plot No A-168, Khairne Industrial Area,
Thane Belapur Road, Mahape,
Navi Mumbai – 400 709
INDIA
Tel + 91 22 2778 8480
Email [e-mail]
www.norbar.com
© Norbar Torque Tools Ltd 2017

1
CONTENTS
Part Numbers Covered by This Manual 2
Safety 3
Introduction 7
Parts Included 7
Explanation of Data Label 7
Accessories 8
Features and Functions 10
Set up Instructions 11
1. Torque Reaction 11
2. Air Lubrication 12
3. Tool Control Systems 12
4. Input Ports 13
5. Exhaust Port 14
6. Setting Torque for Fastener Tightening 14
Operating Instructions 15
Tightening 15
Releasing 15
Maintenance 16
Air Lubrication 16
Gearbox 16
Silencer 16
Drive Square 17
Calibration 17
Cleaning 17
Disposal 17
Specifications 18
EU Declaration of Incorporation 20
Trouble Shooting 21
Glossary of Terms 21

2
PART NUMBERS COVERED BY THIS MANUAL
This manual covers all PTS™ series remote control tools, including the following:
Part Number
Model
Direction
Maximum Torque
180271.B06
PTS™-52-500
Bi-directional
500 N·m
180272.B06
PTS™-52-800
Bi-directional
800 N·m
180273.B06
PTS™-72-1000
Bi-directional
1000 N·m
180274.B08
PTS™-72-1350
Bi-directional
1350 N·m
180275.B08
PTS™-72-2000
Bi-directional
2000 N·m
180276.B08
PTS™-80-2700
Bi-directional
2700 N·m
180277.B08
PTS™-92-4000
Bi-directional
4000 N·m
180277.B12
PTS™-92-4000
Bi-directional
4000 N·m
180279.B12
PTS™-119-7000
Bi-directional
7000 N·m
PTS™ tools are also available with a pistol grip handle, see operator’s manual part number 34438.

3
SAFETY
IMPORTANT: THIS OPERATOR’S MANUAL SHOULD BE KEPT FOR FUTURE REFERENCE.
General Safety Rules:
• For multiple hazards, read and understand the safety instructions before installing, operating, repairing,
maintaining, changing accessories on, or working near the assembly power tool for threaded fasteners.
Failure to do so can result in serious bodily injury.
• Only qualified and trained operators should install, adjust or use the assembly power tool for threaded
fasteners.
• Do not modify this assembly power tool for threaded fasteners. Modifications can reduce the
effectiveness of safety measures and increase the risks to the operator.
• Do not discard the safety instructions; give them to the operator.
• Do not use the assembly power tool for threaded fasteners if it has been damaged.
• Tools shall be inspected periodically to verify that the ratings and markings required are legibly marked
on the tool. The employer/user shall contact the manufacturer to obtain replacement marking labels
when necessary.
Projectile Hazards:
• Failure of the workpiece, of accessories or even of the tool itself can generate high-velocity projectiles.
• Always wear impact-resistant eye protection during the operation of the assembly power tool for
threaded fasteners. The grade of protection required should be assessed for each use.
• Ensure that the workpiece is securely fixed.
Entanglement Hazards:
• Entanglement hazards can result in choking, scalping and/or lacerations if loose clothing, personal
jewellery, neckware, hair or gloves are not kept away from the tool and accessories.
• Inappropriate gloves can become entangled with the rotating drive, causing severed or broken fingers.
• Rotating drive sockets and drive extensions can easily entangle rubber-coated or metal-reinforced
gloves.
• Do not wear loose-fitting gloves or gloves with cut or frayed fingers.
• Never hold the drive, socket or drive extension.
• Keep hands away from rotating drives.
Operating Hazards:
• The use of the tool can expose the operator's hands to hazards including crushing, impacts, cuts,
abrasions and heat. Wear suitable gloves to protect hands.
• These tools require the use of a suitable reaction which presents a crushing hazard. Ensure the set up
instructions in this manual are followed.
• Operators and maintenance personnel shall be physically able to handle the bulk, weight and power of
the tool.
• Hold the tool correctly; be ready to counteract normal or sudden movements and have both hands
available.

4
• Maintain a balanced body position and secure footing.
• Release the trigger in the case of an interruption of the energy supply.
• Use only lubricants recommended by the manufacturer.
• Do not use in confined spaces and beware of crushing hands between tool and workpiece.
Repetitive Motions Hazards:
• When using a power tool for threaded fasteners, the operator can experience discomfort in the hands,
arms, shoulders, neck, or other parts of the body.
• While using an assembly power tool for threaded fasteners, the operator should adopt a comfortable
posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator
should change posture during extended tasks, which can help avoid discomfort and fatigue.
• If the operator experiences symptoms such as persistent or recurring discomfort, pain, throbbing,
aching, tingling, numbness, burning sensations or stiffness, these warning signs should not be ignored.
The operator should tell the employer and consult a qualified health professional.
Accessory Hazards:
• Disconnect the assembly power tool for threaded fasteners from the energy supply before changing the
tool or accessory.
• Use only sizes and types of accessories and consumables that are recommended by the assembly
power tool for threaded fasteners manufacturer; do not use other types or sizes of accessories and
consumables.
Workplace Hazards:
• Slips, trips and falls are major causes of workplace injury. Be aware of slippery surfaces caused by the
use of the tool and also of trip hazards caused by the air line or hydraulic hose.
• Proceed with care in unfamiliar surroundings. Hidden hazards, such as electricity or other utility lines,
can exist.
• The assembly power tool for threaded fasteners is not intended for use in potentially explosive
atmospheres and is not insulated against coming into contact with electrical power.
• Make sure there are no electrical cables, gas pipes, etc., that can cause a hazard if damaged by use of
the tool.
Dust and Fume Hazards:
• Dust and fumes generated when using assembly power tools for threaded fasteners can cause ill health
(for example, cancer, birth defects, asthma and/or dermatitis); risk assessment and implementation of
appropriate controls for these hazards are essential.
• Risk assessment should include dust created by the use of the tool and the potential for disturbing
existing dust.
• Direct the exhaust to minimize disturbance of dust in a dust-filled environment.
• Where dust or fumes are created, the priority shall be to control them at the point of emission.
• All integral features or accessories for the collection, extraction or suppression of airborne dust or fumes
should be correctly used and maintained in accordance with the manufacturer's instructions.
• Use respiratory protection in accordance with employer's instructions and as required by occupational
health and safety regulations.

5
Noise Hazards:
• Unprotected exposure to high noise levels can cause permanent, disabling, hearing loss and other
problems, such as tinnitus (ringing, buzzing, whistling or humming in the ears). Therefore a risk
assessment and implementation of appropriate controls for these hazards are essential.
• Appropriate controls to reduce the risk may include actions such as damping materials to prevent
workpieces from “ringing”.
• Use hearing protection in accordance with employer's instructions and as required by occupational
health and safety regulations.
• Operate and maintain the assembly power tool for threaded fasteners as recommended in the
operator’s manual, to prevent an unnecessary increase in noise levels.
• If the assembly power tool for threaded fasteners has a silencer, always ensure it is in place and in good
working order when the assembly power tool for threaded fasteners is operating.
• Select, maintain and replace the consumable/tool as recommended in the operator’s manual, to prevent
an unnecessary increase in noise.
Vibration Hazards:
• Exposure to vibration can cause disabling damage to the nerves and blood supply of the hands and
arms.
• Wear warm clothing when working in cold conditions and keep your hands warm and dry.
• If you experience numbness, tingling, pain or whitening of the skin in your fingers or hands, stop using
the assembly power tool for threaded fasteners, tell your employer and consult a physician.
• Operate and maintain the assembly power tool for threaded fasteners as recommended in the
operator’s manual, to prevent an unnecessary increase in vibration levels.
• Do not use worn or ill-fitting sockets or extensions, as this is likely to cause an increase in vibration.
• Select, maintain and replace the consumable/tool as recommended in the operator’s manual, to prevent
an unnecessary increase in vibration levels.
• Support the weight of the tool in a stand, tensioner or balancer, if possible.
• Hold the tool with a light but safe grip, taking account of the required hand reaction forces, because the
risk from vibration is generally greater when the grip force is higher.
Additional Safety Instructions for Pneumatic Power Tools:
• Air under pressure can cause severe injury:
o Always shut off air supply, drain hose of air pressure and disconnect tool from air supply when not
in use, before changing accessories or when making repairs;
o Never direct air at yourself or anyone else.
• Whipping hoses can cause severe injury. Always check for damaged or loose hoses and fittings.
• Cold air shall be directed away from the hands.
• Air lines with safe disconnect couplings, as supplied, are recommended. Whenever universal twist
couplings (claw couplings) are used, lock pins shall be installed and whipcheck safety cables shall be
used to safeguard against possible hose-to-tool and hose-to-hose connection failure.
• Do not exceed the maximum air pressure stated on the tool.

6
• For torque control and continuous rotation tools, the air pressure has a safety critical effect on
performance. Therefore, requirements for length and diameter of the hose shall be specified.
• Never carry an air tool by the hose.
PTS™ Specific Safety Instructions:
• This tool is intended for use with threaded fasteners. Other uses within the limits of the tool may be
appropriate. Please contact Norbar for guidance.
• The user (or the user’s employer) shall assess the specific risks that can be present as a result of each
use. This Operator’s Manual contains sufficient information for the end user to be able to perform an
initial risk assessment.
• Unexpected direction of drive square movement can cause a hazardous situation.
• Isolate the tool from all energy sources before changing or adjusting the drive square or socket.
Markings on Tool
Pictograms on Tool
Meaning
Read and understand Operator’s Manual.
If a Reaction is purchased from Norbar it will include this label:
Unexpected tool movement due to reaction forces or breakage of drive square or
reaction bar may cause injuries.
There is a risk of crushing between the reaction bar and workpiece.
Keep hands away from reaction bar.
Keep hands away from tool output.

7
INTRODUCTION
The PneuTorque® PTS™ series are non-impacting, air driven power tools designed for applying torque to
threaded fasteners. Remote control versions have no direction/shut-off control on the tool but rely on external
pneumatic circuitry (not provided) to provide this function. This opens up numerous application possibilities
for the PneuTorque® ranging from simple stall shut-off in a hazardous working environment to sophisticated,
multi-spindle torque and angle shut-off systems.
Together with the external pneumatic circuitry an external pressure regulator (Lubro Control Unit) is needed;
this allows the air pressure to be adjusted to determine the stall torque from the graph provided. There are
models to cover torque capacities of 500 N∙m to 7000 N∙m.
The PTS™ must always be operated with the following:
• Filtered dry air supply. Minimum recommended compressor rating: 6.9 bar (100 psi), 19 l/s (40 CFM).
• Lubro Control Unit or similar Filter, Regulator and Lubricator Unit ½” Bore (12 mm).
• Impact or high quality sockets.
Parts Included
Description
Model:
PTS™-52
PTS™-72
PTS™-80
PTS™-92
PTS™-119
Visual
Difference
Reaction Bar
Retaining Circlip
26588
26486
26486
26486
26482
Operator’s
Manual &
language USB
drive
34442
34442
34442
34442
34442
Explanation of Data Label:
A: Norbar Serial Number (First 4 digits = Year of manufacture).
B: Norbar Part Number, including reference to square drive size.
C: Maximum calibrated Torque value.
D: Maximum rated air pressure.
E: Maximum free-running speed (achieved when tool is set to the air pressure for the max. torque value).
F: Instruction to read operator’s manual before use.
A
B
C
D
E
F
FIGURE 1 – Data Label

8
Accessories
Description
Part Number
PTS™-52
PTS™-72
PTS™-80
PTS™-92
PTS™-119
Lubro Control Unit
16074
16074
16074
16074
16074
¾” Drive Square
(fixing screw)
18544
(25351.30)
18779
(25352.45)
-
-
-
1” Drive Square
(fixing screw)
18545
(25351.30)
18492
(25352.45)
TBC
18934
(25352.60)
-
1 ½” Drive Square
(fixing screw)
-
-
-
18935
(25352.60)
18959
(25352.80)
Reaction Bar
[NOTE 1]
18298
18298
TBC
-
-
Reaction Adaptor
[NOTE 1]
18558
18290
TBC
-
-
Single-Sided Reaction
Plate
18576
18292
TBC
18979
16687
Double-Sided
Reaction Plate
18590
18293
TBC
18980
18981
Weld Ring
18694
18695
18695
18696
18697
6” Blade Nose
Extension
(¾”)
18601.006
(1”)
19007.006
TBC
-
-
9” Blade Nose
Extension
(¾”)
18601.009
(1”)
19007.009
TBC
-
-
12” Blade Nose
Extension
(¾”)
18601.012
(1”)
19007.012
TBC
-
-
6” Splined Nose
Extension
(¾”)
19045.006
(¾”)
19046.006
(1”)
19285.006
TBC
(1”)
19047.006
-
9” Splined Nose
Extension
(¾”)
19045.009
(¾”)
19046.009
(1”)
19285.009
TBC
(1”)
19047.009
-

9
Description
Part Number
PTS™-52
PTS™-72
PTS™-80
PTS™-92
PTS™-119
12” Splined Nose
Extension
(¾”)
19045.012
(¾”)
19046.012
(1”)
19285.012
TBC
(1”)
19047.012
-
Lifting Handle
-
19363
19363
19363
19363
Lightweight Aluminium
Reaction
-
18494
TBC
18936
18961
[NOTE 2]
Standard Steel
Reaction
18646
19289
19289
19291
19293
Twin Solenoid Valve
60310
60310
60310
60310
60310
Tool Controller
(TTT based)
60244
60244
60244
60244
60244
Tool Controller
(T-Box XL™ based)
60302
60302
60302
60302
60302
NOTE 1: Requires both the ‘Reaction Bar’ and ‘Reaction Adaptor’ to be used together.
NOTE 2: Max. Torque 6000 N·m

10
FEATURES AND FUNCTIONS
• A single efficient bi-directional air motor.
• Excellent power to weight ratio.
• ±3% repeatability. Accuracy better than ±3% (see calibration certificate).
• Very quiet operation reducing the need for protection with sound pressure level at 80.7 dB(A).
• Fast operation for rapid rundown. Up to 60% faster than PT-72 model.
• The splined reaction provides fast and safe fitment of a range of reactions.
• Replaceable square drive designed to shear, avoiding internal damage to the tool.
• Models covering 8 torque ranges from 500 N·m up to 7000 N·m.
• Wide range of compatible tool controllers and solenoid valves.
• Wide range of transducers available.
• Norbar’s in-house ‘Engineer-to-Order’ team offer customised / integrated design solutions featuring the
PTS™ Remote.
Drive Square
Air Inlet Port
Exhaust
Circlip
FIGURE 2 – Features
Reaction Spline

11
SET UP INSTRUCTIONS
1. Torque Reaction
The reaction plate is used to take the torque reaction force (which is equal and opposite to the tool output)
and can also be used to mount the tool.
NOTE: The remote control tools are not supplied with a reaction plate/bar as standard.
Norbar offer several types of reaction bar (like the double-sided reaction plate shown in Figure 4) and weld
rings (figure 3) which allow users to integrate the reaction spline into their own custom reaction solutions.
Alternatively, contact Norbar’s Engineer-to-Order team for a bespoke design and quotation for a reaction
solution.
The conventional way to retain the tool within the reaction spline is via the circlip which locates in the groove
at the front of the spline feature.
If using a conventional reaction bar: It is essential that the reaction plate rests squarely against a solid
object or surface adjacent to the fastener to be tightened. The contact area must be within the shaded area
of Figure 5, with the contact area as large as possible.
WARNING: CARE MUST BE TAKEN TO ENSURE THAT THE REACTION PLATE IS ONLY
USED WITHIN THE LIMITATIONS SHOWN IN FIGURE 5.
For special applications or where extra length sockets must be used, the standard arm may be extended but
only within the limitations shown on Figure 5.
WARNING: FAILURE TO OBSERVE THE LIMITATIONS SHOWN IN FIGURE 5 WHEN
MODIFYING STANDARD REACTION PLATES MAY RESULT IN PREMATURE
WEAR OR DAMAGE TO THE TOOL.
FIGURE 4 – Double-Sided
Reaction Plate Option
FIGURE 5 – Effect of Long Sockets
Standard Length
Socket
Torque Reaction should be
taken in the shaded areas only
Extra Length
Socket
FIGURE 3 – Weld Ring

12
Standard drive square extensions MUST NOT be used as these will cause serious damage to the tool output
drive. A range of nose extensions is available for applications where access is restricted. These are
designed to support the final drive correctly.
When the PneuTorque® is in operation the reaction plate rotates in the opposite direction to the output drive
square and must be allowed to rest squarely against a solid object or surface adjacent to the bolt to be
tightened. (See Figure 6).
WARNING: ALWAYS KEEP HANDS CLEAR OF THE REACTION PLATE WHEN THE
TOOL IS IN USE OR SERIOUS INJURY MAY RESULT.
2. Air Lubrication
The tool must be used with oil lubrication in the supplied air. This is achieved by using a Lubro Control Unit
(not supplied).
Set the air lubrication:
a. Fill Lubro Control Unit with appropriate air-tool grade oil.
b. Ensure the tool drive is free to rotate.
c. Run the tool – adjust the tool to max pressure according to the setting data.
d. Adjust Lubrication Unit to supply 4 drops of oil per minute.
See Lubro Control Unit Operator’s Manual for more details.
3. Tool Control Systems
The remote control air motor requires a separate external pneumatic circuit (not supplied) for on/off and
clockwise / anticlockwise control of the tool. The direction of tool rotation is determined by pressurising either
the clockwise or anti-clockwise air inlet ports.
A Lubro Control Unit (Part Number 16074 - not supplied) is required to lubricate the air and control the air
pressure so the correct torque is applied. Check the oil level in the Lubro Control Unit and fill to the correct
level.
Ensure air hoses are clean and free from dirt before connecting. The air supply hoses and control valves must
be ½” bore (12mm) and the hose from the supply to the control system must not be longer than 5 metres or the
tools performance will be impaired. If the supply hose must be longer than 5 metres then ¾” bore must be
used.
Examples of pneumatic control circuits are shown in Figures 7 and Figure 8.
Reaction point
Clockwise Operation
Anti-Clockwise Operation
FIGURE 6

13
WARNING: TO AVOID HAZARD FROM WHIPPING AIR HOSES MAKE ALL
CONNECTIONS TO THE TOOL BEFORE TURNING ON THE AIR SUPPLY.
4. Input Ports
The input ports are located at the rear of the tool covered by plastic protection caps (# 16199). Connect the
clockwise supply and anti-clockwise supply to the ½” BSP connectors as shown in Figure 9.
Lubro Control Unit
Typical air/electric pilot ½” BSP spring return valve.
3 position, 5 port, capable of plowing 19 l/s,
Norbar Remote Motor
Lubro Control Unit
Lubro Control Unit
Clockwise
Anti-clockwise
Norbar Remote Motor
Typical air pilot ½” BSP spring return valve.
2 position, 3 port, capable of plowing 19 l/s,
Typical air pilot 1/8” BSP spring return valve.
2 position, 4 port , capable of plowing 19 l/s,
Typical air pilot ½” BSP spring return valve.
2 position, 3 port, capable of plowing 19 l/s,
FIGURE 7 – Example of Pneumatic Circuit
FIGURE 8 – Example of Pneumatic Circuit

14
5. Exhaust Port
The exhaust port, located under the tool, is common to both inlet ports. If required an exhaust hose can be
connected, this will reduce the sound pressure level. The exhaust hose size must not be reduced from ¾”
(19mm) or the tool performance will be reduced.
TIP: As with any pneumatic tool a fine oil mist is present in the exhaust air. Please ensure the
exhaust air cannot cause a hazard.
6. Setting Torque to Tighten Fastener
The torque created by the PneuTorque® depends on
the air pressure setting. All tools are supplied with
setting data that gives the air pressure required to
produce the correct torque output.
Set the torque output as follows:
i) Use the setting data (supplied) to find
the air pressure to achieve the required
torque.
ii) With the tool running, adjust the Lubro Control Unit (not included) until
the correct air pressure is shown on the gauge.
IMPORTANT: THE TOOL MUST BE FREE RUNNING WHILE ADJUSTING
THE AIR PRESSURE TO GIVE THE CORRECT SETTING.
IMPORTANT: CHECK THAT THE LUBRO CONTROL UNIT IS SUPPLYING
APPROXIMATELY FOUR DROPS OF OIL PER MINUTE
WHILE THE TOOL IS FREE RUNNING.
Exhaust port
¾” BSP silencer
Input port
½” BSP
(Clockwise)
FIGURE 9 – Ports
Input port
½” BSP
(Anti-clockwise)
FIGURE 10 – Setting Data
FIGURE 11 –
Lubro Control Unit

15
OPERATING INSTRUCTIONS
WARNING: KEEP HANDS CLEAR OF THE REACTION BAR AND DRIVE SOCKET.
WARNING: WHEN USING THIS TOOL IT MUST BE SUPPORTED AT ALL TIMES IN
ORDER TO PREVENT UNEXPECTED RELEASE IN THE EVENT OF
FASTENER OR COMPONENT FAILURE.
WARNING: CHANGING THE AIR PRESSURE AFTER SETTING THE PRESSURE
REGULATOR WILL CHANGE THE STALL TORQUE VALUE.
WARNING: IF EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE
MANUFACTURER, INJURY OR DAMAGE COULD RESULT.
Tightening
1. Fit PneuTorque® with the correct size impact or high quality socket.
2. Ensure the external control circuit is correctly set.
3. Fit the tool onto the fastener. Locate reaction bar adjacent to the reaction point.
4. Start the tool and allow it to continuously tighten the fastener.
Full torque will only have been applied once the tool has stalled.
5. Stop tool and remove from fastener.
Releasing
1. Fit PneuTorque® with the correct size impact or high quality socket.
2. Ensure external control circuit is correctly set.
3. Fit the tool onto the fastener. Locate reaction bar adjacent to the reaction point.
4. Start the tool to release the fastener.
TIP: If unable to release the fastener, increase the air pressure to the tool. Do not exceed the
maximum air pressure.
TIP: In the event that lubrication fails and / or contaminated air (e.g. water) enters the tool it is
strongly recommended that the tool is free run on a clean, dry and lubricated air supply for
several minutes.
WARNING: EXCEEDING THE MAXIMUM AIR PRESSURE WILL CAUSE OVERLOADING
AND MAY LEAD TO SERIOUS DAMAGE.
5. Remove tool from fastener.

16
MAINTENANCE
For optimum performance and safety, regular tool maintenance is required. The user maintenance is limited
to the replacement of the drive square and the silencers. Any other maintenance or repairs should be carried
out by Norbar or a Norbar approved distributor. Maintenance intervals will depend on the tool usage and the
environment in which it is being used:
• The maximum recommended service and recalibration interval is 12 months OR 10,000 cycles,
whichever occurs first.
• If tool exhibits abnormal performance please contact your Norbar approved distributor.
TIP: Steps the user can take to reduce the amount of maintenance required include:
1. Use the tool in a clean environment.
2. Use an air compressor fitted with a dryer.
3. Ensure the Lubro Control Unit has sufficient air-tool grade oil.
4. Ensure the Lubro Control Unit delivers air-tool grade oil at the correct rate.
5. Ensure the Lubro Control Unit is regularly maintained, see product manual.
6. Maintain the correct torque reaction.
7. In the event that lubrication fails and / or contaminated air (e.g. water) enters the tool it is
strongly recommended that the tool is free run on a clean, dry and lubricated air supply
for several minutes.
8. Prior to long periods of storage it is strongly recommended that the tool is free run on a
clean, dry and lubricated air supply for several minutes.
WARNING: GLOVES SHOULD BE WORN FOR MAINTENANCE TO AVOID CONTACT
WITH GREASE AND OIL.
Air Lubrication
Use appropriate air-tool grade oil (for example Shell Tellus S2 V15).
Gearbox
The gearbox is not user-serviceable. For more information on gearbox servicing please contact Norbar or
your Norbar approved distributor.
Silencer
The PTS™ Remote silencer (#28704) is intended to last the lifetime of the tool (under optimum operating
conditions). However, in adverse operating conditions a replacement is recommended if the user
experiences a loss of tool performance.
If silencer (#28704) needs replacing, simply unscrew exhaust port and refit with a new part.

17
Drive Square
To avoid internal damage (especially due to torque overload), the output drive square has been designed to
shear first. This saves major internal damage and allows easy square removal. For drive square part
numbers see page 8.
To replace drive square:
1. Remove the air supply.
2. Support the tool.
3. Remove the screw, then remove drive square.
If the square has sheared it may be necessary to use pliers to remove the broken parts.
4. Fit new drive square.
5. Fit new screw and tighten between 4 N·m to 5 N·m (for PTS™-52) or 8 N·m to 9 N·m (for PTS™-
72/80/92/119).
6. Connect air supply.
TIP: If the drive square fails continually then seek advice from Norbar or a Norbar approved
distributor.
Calibration
To maintain the PneuTorque® accuracy it is recommended the tool is recalibrated every 10,000 cycles or
annually, whichever comes first. Contact Norbar or a Norbar distributor for more information.
Cleaning
Keep the tool in a clean condition to aid safety. Do not use abrasives or solvent based cleaners.
Disposal
Recycling Considerations: Please recycle where possible.
The tool has no hazardous disposal requirements.
FIGURE 12 – Square Drive Replacement

18
SPECIFICATIONS
Part
Number
Model
Square
Drive
Torque
Output
Speed
Minimum
Maximum
180271.B06
PTS™-52-500
¾”
100 N·m (74 lbf·ft)
500 N·m (370 lbf·ft)
27.8 rev/min
180272.B06
PTS™-52-800
¾”
160 N·m (118 lbf·ft)
800 N·m (590 lbf·ft)
20.1 rev/min
180273.B06
PTS™-72-1000
¾”
200 N·m (147 lbf·ft)
1000 N·m (738 lbf·ft)
16.0 rev/min
180274.B08
PTS™-72-1350
1”
270 N·m (200 lbf·ft)
1350 N·m (1000 lbf·ft)
11.5 rev/min
180275.B08
PTS™-72-2000
1”
400 N·m (295 lbf·ft)
2000 N·m (1475 lbf·ft)
7.2 rev/min
180276.B08
PTS™-80-2700
1”
540 N·m (400 lbf·ft)
2700 N·m (2000 lbf·ft)
5.7 rev/min
180277.B08
PTS™-92-4000
1”
800 N·m (590 lbf·ft)
4000 N·m (2950 lbf·ft)
4.1 rev/min
180277.B12
PTS™-92-4000
1 ½”
800 N·m (590 lbf·ft)
4000 N·m (2950 lbf·ft)
4.1 rev/min
180279.B12
PTS™-119-7000
1 ½”
1400 N·m (1030 lbf·ft)
7000 N·m (5200 lbf·ft)
2.1 rev/min
Part Number
Model
Dimensions (mm)
Tool Weight Without
Reaction (kg)
L
W
ØD
H1
H2
180271.B06
PTS™-52-500
284
70
Ø52
29
77.5
4.1
180272.B06
PTS™-52-800
284
70
Ø52
29
77.5
4.1
180273.B06
PTS™-72-1000
311
70
Ø72
29
77.5
6.14
180274.B08
PTS™-72-1350
311
70
Ø72
29
77.5
6.14
180275.B08
PTS™-72-2000
344
70
Ø72
29
77.5
6.5
180276.B08
PTS™-80-2700
311
70
Ø80
29
77.5
6.05
180277.B08
PTS™-92-4000
362
70
Ø92
29
77.5
8.85
180277.B12
PTS™-92-4000
362
70
Ø92
29
77.5
8.85
180279.B12
PTS™-119-7000
385
70
Ø119
29
77.5
12.42
FIGURE 13 – Dimensions
