norbar PneuTorque Standard Series User manual

OPERATOR’S MANUAL
PNEUTORQUE®
STANDARD SERIES
STALL TOOLS
REMOTE CONTROL AIR MOTOR
Part Number 34318 | Issue 5 | Original Instructions (English)
NORBAR TORQUE TOOLS LTD
Wildmere Road, Banbury,
Oxfordshire, OX16 3JU
UNITED KINGDOM
Tel + 44 (0)1295 270333
Email [e-mail]
NORBAR TORQUE TOOLS
45–47 Raglan Avenue, Edwardstown,
SA 5039
AUSTRALIA
Tel + 61 (0)8 8292 9777
Email [e-mail]
NORBAR TORQUE TOOLS INC
36400 Biltmore Place, Willoughby,
Ohio, 44094
USA
Tel + 1 866 667 2279
Email [e-mail]
NORBAR TORQUE TOOLS PTE LTD
194 Pandan Loop
#07-20 Pantech Business Hub
SINGAPORE 128383
Tel + 65 6841 1371
Email [e-mail]
NORBAR TORQUE TOOLS (SHANGHAI) LTD
91 Building-7F, No.1122 North Qinzhou Rd,
Xuhui District, Shanghai
CHINA 201103
Tel + 86 21 6145 0368
Email [e-mail]
NORBAR TORQUE TOOLS INDIA PVT. LTD
Plot No A-168, Khairne Industrial Area,
Thane Belapur Road, Mahape,
Navi Mumbai – 400 709
INDIA
Tel + 91 22 2778 8480
Email [e-mail]
www.norbar.com
© Norbar Torque Tools Ltd 2018

1
CONTENTS
Part Numbers Covered by This Manual 2
Safety 3
General Safety Rules 3
Projectile Hazards 3
Entanglement Hazards 3
Operating Hazards 3
Repetitive Motions Hazards 4
Accessory Hazards 4
Workplace Hazards 4
Dust and Fume Hazards 4
Noise Hazards 5
Vibration Hazards 5
Additional Safety Instructions for Pneumatic Power Tools 5
PneuTorque® Specific Safety Instructions 6
Markings on Tool 6
Introduction 7
Part Included 7
Accessories 7
Features and Functions 8
Set up Instructions 9
Torque Reaction 9
Examples of Tool Control Systems 11
Input Ports 12
Exhaust Port 12
Setting Torque for Fastener Tightening 13
Setting Torque for Fastener Loosening 13
Operating Instructions 14
Tightening 14
Releasing 15
Maintenance 16
Reaction Plate 16
Air Lubrication 16
Gearbox 16
Silencer 16
Filter 16
Drive Square 17
Cleaning 17
Disposal 17
Specifications 18
General 18
Standard Series 18
Declaration of Incorporation 20
Trouble Shooting 21
Glossary of Terms 21

2
PART NUMBERS COVERED BY THIS MANUAL
This manual covers all PneuTorque® (PT) Remote Standard Series tools; including the following:
Model
(Standard
Series)
Part Number
Square
Maximum
Torque
Single Speed
Manual Two Speed
Automatic Two
Speed
PT 1
16031.X
16031.XMTS
16031.XAUT
¾”
680 N∙m
PT 1
16011.X
16011.XMTS
16011.XAUT
1”
680 N∙m
PT 1A
16098.X
16098.XMTS
16098.XAUT
¾”
1,200 N∙m
PT 1A
16097.X
16097.XMTS
16097.XAUT
1”
1,200 N∙m
PT 2
16013.X
16013.XMTS
16013.XAUT
1”
1,700 N∙m
PT 5
16015.X
16015.XMTS
16015.XAUT
1”
3,400 N∙m
PT 6
16017.X
16017.XMTS
16017.XAUT
1½”
3,400 N∙m
PT 7
16066.X
16066.XMTS
16066.XAUT
1½”
6,000 N∙m
PT 9
16072.X
16072.XMTS
16072.XAUT
1½”
9,500 N∙m
PT 11
16046.X
16046.XMTS
-
2½”
20,000 N∙m
PT 12
18086.X
18086.XMTS
-
2½”
34,000 N∙m
PT 13
16052.X
16052.XMTS
-
2½”
47,000 N∙m
PT 14
16045.X
16045.XMTS
-
3½”
100,000 N∙m
PT 15
18089.X
18089.XMTS
-
Note A
150,000 N∙m
PT 16
18090.X
18090.XMTS
-
Note A
200,000 N∙m
PT 17
18088.X
18088.XMTS
-
Note A
250,000 N∙m
PT 18
-
16054.XMTS
-
Note A
300,000 N∙m
NOTE A: The output drive and reaction components must be engineered specifically for each
customer application. Consult Norbar.
PneuTorque® Remote Standard series tools are also supplied with a handle. These are given a part number
without an ‘X’ suffix and are covered by the operators manual part number 34317.

3
SAFETY
IMPORTANT: THIS OPERATOR’S MANUAL SHOULD BE KEPT FOR FUTURE REFERENCE.
General Safety Rules:
• For multiple hazards, read and understand the safety instructions before installing, operating, repairing,
maintaining, changing accessories on, or working near the assembly power tool for threaded fasteners.
Failure to do so can result in serious bodily injury.
• Only qualified and trained operators should install, adjust or use the assembly power tool for threaded
fasteners.
• Do not modify this assembly power tool for threaded fasteners. Modifications can reduce the
effectiveness of safety measures and increase the risks to the operator.
• Do not discard the safety instructions; give them to the operator.
• Do not use the assembly power tool for threaded fasteners if it has been damaged.
• Tools shall be inspected periodically to verify that the ratings and markings required are legibly marked
on the tool. The employer/user shall contact the manufacturer to obtain replacement marking labels
when necessary.
Projectile Hazards:
• Failure of the workpiece, of accessories or even of the tool itself can generate high-velocity projectiles.
• Always wear impact-resistant eye protection during the operation of the assembly power tool for
threaded fasteners. The grade of protection required should be assessed for each use.
• Ensure that the workpiece is securely fixed.
Entanglement Hazards:
• Entanglement hazards can result in choking, scalping and/or lacerations if loose clothing, personal
jewellery, neckware, hair or gloves are not kept away from the tool and accessories.
• Inappropriate gloves can become entangled with the rotating drive, causing severed or broken fingers.
• Rotating drive sockets and drive extensions can easily entangle rubber-coated or metal-reinforced
gloves.
• Do not wear loose-fitting gloves or gloves with cut or frayed fingers.
• Never hold the drive, socket or drive extension.
• Keep hands away from rotating drives.
Operating Hazards:
• The use of the tool can expose the operator's hands to hazards including crushing, impacts, cuts,
abrasions and heat. Wear suitable gloves to protect hands.
• These tools require the use of a suitable reaction which presents a crushing hazard. Ensure the set up
instructions in this manual are followed.
• Operators and maintenance personnel shall be physically able to handle the bulk, weight and power of
the tool.
• Hold the tool correctly; be ready to counteract normal or sudden movements and have both hands
available.

4
• Maintain a balanced body position and secure footing.
• Release the trigger in the case of an interruption of the energy supply.
• Use only lubricants recommended by the manufacturer.
• Do not use in confined spaces and beware of crushing hands between tool and workpiece.
Repetitive Motions Hazards:
• When using a power tool for threaded fasteners, the operator can experience discomfort in the hands,
arms, shoulders, neck, or other parts of the body.
• While using an assembly power tool for threaded fasteners, the operator should adopt a comfortable
posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator
should change posture during extended tasks, which can help avoid discomfort and fatigue.
• If the operator experiences symptoms such as persistent or recurring discomfort, pain, throbbing,
aching, tingling, numbness, burning sensations or stiffness, these warning signs should not be ignored.
The operator should tell the employer and consult a qualified health professional.
Accessory Hazards:
• Disconnect the assembly power tool for threaded fasteners from the energy supply before changing the
tool or accessory.
• Use only sizes and types of accessories and consumables that are recommended by the assembly
power tool for threaded fasteners manufacturer; do not use other types or sizes of accessories and
consumables.
Workplace Hazards:
• Slips, trips and falls are major causes of workplace injury. Be aware of slippery surfaces caused by the
use of the tool and also of trip hazards caused by the air line or hydraulic hose.
• Proceed with care in unfamiliar surroundings. Hidden hazards, such as electricity or other utility lines,
can exist.
• The assembly power tool for threaded fasteners is not intended for use in potentially explosive
atmospheres and is not insulated against coming into contact with electrical power.
• Make sure there are no electrical cables, gas pipes, etc., that can cause a hazard if damaged by use of
the tool.
Dust and Fume Hazards:
• Dust and fumes generated when using assembly power tools for threaded fasteners can cause ill health
(for example, cancer, birth defects, asthma and/or dermatitis); risk assessment and implementation of
appropriate controls for these hazards are essential.
• Risk assessment should include dust created by the use of the tool and the potential for disturbing
existing dust.
• Direct the exhaust to minimize disturbance of dust in a dust-filled environment.
• Where dust or fumes are created, the priority shall be to control them at the point of emission.
• All integral features or accessories for the collection, extraction or suppression of airborne dust or fumes
should be correctly used and maintained in accordance with the manufacturer's instructions.
• Use respiratory protection in accordance with employer's instructions and as required by occupational
health and safety regulations.

5
Noise Hazards:
• Unprotected exposure to high noise levels can cause permanent, disabling, hearing loss and other
problems, such as tinnitus (ringing, buzzing, whistling or humming in the ears). Therefore a risk
assessment and implementation of appropriate controls for these hazards are essential.
• Appropriate controls to reduce the risk may include actions such as damping materials to prevent
workpieces from “ringing”.
• Use hearing protection in accordance with employer's instructions and as required by occupational
health and safety regulations.
• Operate and maintain the assembly power tool for threaded fasteners as recommended in the
operator’s manual, to prevent an unnecessary increase in noise levels.
• If the assembly power tool for threaded fasteners has a silencer, always ensure it is in place and in good
working order when the assembly power tool for threaded fasteners is operating.
• Select, maintain and replace the consumable/tool as recommended in the operator’s manual, to prevent
an unnecessary increase in noise.
Vibration Hazards:
• Exposure to vibration can cause disabling damage to the nerves and blood supply of the hands and
arms.
• Wear warm clothing when working in cold conditions and keep your hands warm and dry.
• If you experience numbness, tingling, pain or whitening of the skin in your fingers or hands, stop using
the assembly power tool for threaded fasteners, tell your employer and consult a physician.
• Operate and maintain the assembly power tool for threaded fasteners as recommended in the
operator’s manual, to prevent an unnecessary increase in vibration levels.
• Do not use worn or ill-fitting sockets or extensions, as this is likely to cause an increase in vibration.
• Select, maintain and replace the consumable/tool as recommended in the operator’s manual, to prevent
an unnecessary increase in vibration levels.
• Support the weight of the tool in a stand, tensioner or balancer, if possible.
• Hold the tool with a light but safe grip, taking account of the required hand reaction forces, because the
risk from vibration is generally greater when the grip force is higher.
Additional Safety Instructions for Pneumatic Power Tools:
• Air under pressure can cause severe injury:
o Always shut off air supply, drain hose of air pressure and disconnect tool from air supply when not
in use, before changing accessories or when making repairs;
o Never direct air at yourself or anyone else.
• Whipping hoses can cause severe injury. Always check for damaged or loose hoses and fittings.
• Cold air shall be directed away from the hands.
• Air lines with safe disconnect couplings, as supplied, are recommended. Whenever universal twist
couplings (claw couplings) are used, lock pins shall be installed and whipcheck safety cables shall be
used to safeguard against possible hose-to-tool and hose-to-hose connection failure.
• Do not exceed the maximum air pressure stated on the tool.

6
• For torque control and continuous rotation tools, the air pressure has a safety critical effect on
performance. Therefore, requirements for length and diameter of the hose shall be specified.
• Never carry an air tool by the hose.
PneuTorque® Specific Safety Instructions:
• This tool is intended for use with threaded fasteners. Other uses within the limits of the tool may be
appropriate. Please contact Norbar for guidance.
• The user (or the user’s employer) shall assess the specific risks that can be present as a result of each
use. This Operator’s Manual contains sufficient information for the end user to be able to perform an
initial risk assessment.
• Unexpected direction of drive square movement can cause a hazardous situation.
• Isolate the tool from all energy sources before changing or adjusting the drive square or socket.
Markings on Tool
Pictograms on Tool
Meaning
Read and understand Operator’s Manual.
If a Reaction is purchased from Norbar it will include this label:
Unexpected tool movement due to reaction forces or breakage of drive square
or reaction bar may cause injuries.
There is a risk of crushing between the reaction bar and workpiece.
Keep hands away from reaction bar.
Keep hands away from tool output.

7
INTRODUCTION
The PneuTorque® Standard Series are non-impacting, air driven power tools designed for applying torque to
threaded fasteners. Remote control versions have no direction/shut-off control on the tool but rely on external
pneumatic circuitry (not provided) to provide this function. This opens up numerous application possibilities
for the PneuTorque® ranging from simple stall shut-off in a hazardous working environment to sophisticated,
multi-spindle torque and angle shut-off systems.
Together with the external pneumatic circuitry an external pressure regulator (Lubro Control Unit) is needed;
this allows the air pressure to be adjusted to determine the stall torque from the graph provided. There are
models to cover torque capacities of 680 N∙m to 300,000 N∙m.
The PneuTorque® must always be operated with the following:
• Filtered dry air supply. Minimum recommended compressor rating: 6.9 bar (100 psi), 19 l/s (40 CFM).
• Lubro Control Unit or similar Filter, Regulator and Lubricator Unit ½” Bore (12 mm).
• Impact or high quality sockets.
Parts Included
Model
Part Number
Reaction
Plate / Arm
Reaction
Foot
Lifting
Ring
Lubro
Control Unit
Torque
Wrench
Transporting
Trolley
PT 1 & PT 2
16420
-
-
-
-
-
PT 5 & PT 6
16544
-
-
-
-
-
PT 7
16263
16344
-
-
-
-
PT 9
16387
16394
-
-
-
-
PT 11
16322
-
16348
16074
-
-
PT 12
18994
-
19030/1
16074
-
-
PT 13
16330
-
16311
16074
13049
16326
PT 14
16308
-
16311
16074
13049
16326
PT 15
Note A
-
-
16074
-
-
PT 16
Note A
-
16311
16074
13050
-
PT 17
Note A
-
16311
16074
13050
-
PT 18
Note A
-
16311
16074
13050
-
All tools include Operators Manual (Part number 34318), Calibration Certificate & Air pressure graph (Part
number 34208)
NOTE A: The output drive and reaction components must be engineered specifically for each
customer application. Consult Norbar.
Accessories
Part
Part Number
Replacement drive square
See Maintenance
Air Filter
18280
Silencer
16457
Lubro Control Unit
16074
Telescopic nose assembly (85.5 mm to 120.5 mm) for PT1 & PT2 only
16495
Transducers
Consult Norbar

8
FEATURES AND FUNCTIONS
Replaceable Drive Square
To avoid internal damage (especially due to torque overload), the output drive square has been designed to
shear first. Tools are fitted with a drive square that can easily be replaced, alternative drive sizes are also
available.
Clockwise / Anti-Clockwise Control
Capable of tightening and releasing threaded fasteners.
Automatic Two Speed (AUT)
The automatic two speed gearbox option can reduce the fastener run down time. The initial run down is at 5
times normal operating speed before it automatically changes gear to apply the final torque.
Manual Two Speed (MTS)
The manual two speed gearbox option allows manual selection of ‘slow’ or ‘fast’ speeds, fast speed can
reduce the fastener run down time. The difference in gearbox ratios between slow and fast speeds is
approximately factor of 5.
Optional Transducers
Electronic torque transducers can be directly fitted for precise torque monitoring, giving repeatability of up to
+/- 2%.
Optional Angle Encoder
It is possible to fit an angle encoder to the PT. This measures the 6 air motor vanes and gives an output
calculated by the following formula:
Angle (degrees) = 6 x Velocity Ratio
360

9
SET UP INSTRUCTIONS
Torque Reaction
The reaction arm is used to take the torque reaction force (which is equal and opposite to the tool output) and
can also be used to mount the tool. The remote control tools are supplied with a reaction arm as standard (see
Figure 1, 2, & 3). For other types of reaction arm see Accessories.
Position the tool in the reaction arm and fix in place as detailed below.
Fit the reaction plate to the tool using the bolts provided.
Torque the bolts to the value specified on reaction arm, if no torque is specified use the following table:
Model
Reaction Plate / Arm
Fixing Bolt Size
Fixing Bolt Torque
PT 1 & PT 2
16420
2BA
9 N∙m
PT 5 & PT 6
16544
¼” BSF
19 N∙m
PT 7
16263
M10
83 N∙m
PT 9
16387
⅜” BSF
75 N∙m
PT 11
16322
M10
83 N∙m
PT 12
18994
M12
150 N∙m
PT 13
16330
M16
310 N∙m
PT 14
16308
M16
310 N∙m
PT 15
-
-
-
PT 16
-
M20
400 N∙m
PT 17
-
M20
400 N∙m
PT 18
-
M20
400 N∙m
NOTE: It is recommended to check the reaction plate bolts are correctly tightened every week.
Securely mount the reaction arm.
TIP: Take the reaction as far away from the multiplier as practical.
WARNING: IF THE REACTION PLATE IS EXTENDED FORWARD OF THE DRIVE
SQUARE, LARGER INDUCED BENDING STRESS WILL RESULT, SO THE
PLATE MAY NO LONGER BE STRONG ENOUGH.
FIGURE 1 – Typical reaction with
sliding ‘slave square’ for PT 1 to PT 5
FIGURE 2 – Typical reaction (with
adjustable foot) for PT 7 and PT 9
FIGURE 3 – Typical
reaction for PT 11

10
It is essential the reaction plate rests squarely against a solid object or surface adjacent to the fastener to be
tightened. The contact area must be within the shaded area of Figure 4, with the contact area as large as
possible.
WARNING: CARE MUST BE TAKEN TO ENSURE THAT THE REACTION ARM IS ONLY
USED WITHIN THE LIMITATIONS SHOWN IN FIGURE 4.
For special applications or where extra deep sockets must be used the standard arm may be extended but
only within the limitations shown on Figure 4. Alternative reaction devices are available.
WARNING: FAILURE TO OBSERVE THE LIMITATIONS SHOWN IN FIGURE 4 WHEN
MODIFYING STANDARD REACTION ARMS MAY RESULT IN PREMATURE
WEAR OR DAMAGE TO THE TOOL.
Standard drive square extensions MUST NOT be used as these will cause serious damage to the tool output
drive. A range of nose extensions is available for applications where access is restricted. These are
designed to support the final drive correctly.
When the PneuTorque® is in operation the reaction arm rotates in the opposite direction to the output drive
square. The reaction arm must be allowed to rest squarely against a solid object or surface adjacent to the bolt
to be tightened. (See Figure 5 & 6).
WARNING: ALWAYS KEEP HANDS CLEAR OF THE REACTION ARM WHEN THE
TOOL IS IN USE OR SERIOUS INJURY MAY RESULT.
TIP: To extend tool life ensure the reaction point remains square to the multiplier; this will
minimise stress on the output square. If the multiplier tilts under load, the reaction may not
remain square.
TIP: To help socket location with PT 1 & PT 2 tools in remote or multi-spindle applications use a
Telescopic Nose Assembly, Part number 16495.
FIGURE 5 – Clockwise (FWD) reaction
FIGURE 6 – Anti-clockwise (REV) reaction
Torque Reaction should be
taken in the shaded areas only
Extra Length
Socket
Standard Length
Socket
FIGURE 4 – Reaction limitations

11
Examples of Tool Control Systems
The remote control air motor requires a separate external pneumatic tool control system (not supplied as
standard) for on / off and clockwise / anti-clockwise control of the tool. The direction of tool rotation is
determined by pressurising either the clockwise (FWD) or anti-clockwise (REV) air inlet ports.
A Lubro Control Unit (Part Number 16074 – supplied where specified) is required to lubricate the air and control
the air pressure so the correct torque is applied. Check the oil level in the Lubro Control Unit and fill to the
correct level. (See MAINTENANCE section).
Ensure air hoses are clean and free from dirt before connecting. The air supply hoses and control valves must
be ½” bore (12mm) and the hose from the supply to the control system must not be longer than 5 metres or the
tools performance will be impaired. If the supply hose must be longer than 5 metres then ¾” bore must be
used.
Examples of tool control systems are shown in Figure 7 and Figure 8.
WARNING: TO AVOID HAZARD FROM WHIPPING AIR HOSES MAKE ALL
CONNECTIONS TO THE TOOL BEFORE TURNING ON THE AIR SUPPLY.
Lubro Control Unit
Typical air/electric pilot ½” BSP spring return valve.
3 position, 5 port , capable of flowing 19 l/s,
Norbar Remote Motor
Lubro Control Unit
Lubro Control Unit
Clockwise
Anti-clockwise
Norbar Remote Motor
Typical air pilot ½” BSP spring return valve.
2 position, 3 port, capable of flowing 19 l/s,
Typical air pilot ⅛” BSP spring return valve.
2 position, 4 port, capable of flowing 19 l/s,
Typical air pilot ½” BSP spring return valve.
2 position, 3 port , capable of flowing 19 l/s,
FIGURE 8 – Example of tool control system
FIGURE 7 – Example of tool control system

12
Input Ports
The input ports are located at the rear of the tool and covered by plastic protection caps (# 16199).
Connect the air supply to the clockwise (FWD) and anti-clockwise (REV) ½” BSP connectors as shown in
Figure 9.
Exhaust Port
The exhaust port, located on the side of the tool, is common to both inlet ports.
TIP: As with any pneumatic tool a fine oil mist is present in the exhaust air.
Please ensure the exhaust air cannot cause a hazard.
Inlet Ports
REV
FWD
Air Motor
Housing
Air Exhaust
Silencer
Output Square
Drive
FIGURE 9 – Tool features

13
Setting Torque for Fastener Tightening
The tool stall torque is determined by the air pressure set on an external Lubro Control Unit (Part Number
16074 - supplied where specified).
Tools are supplied with an Air Pressure Graph which relates the torque output to the air inlet pressure.
Set the torque output as follows:
1. Ensure the tool control system is set for the required rotation.
2. For Manual two speed tools (Part number *****.XMTS) select ‘SLOW’ speed.
3. Establish the air pressure required using the Air Pressure Graph.
4. Ensure the drive square is able to free run.
5. With the tool running, adjust the air pressure regulator until the correct pressure is shown on the air pressure
gauge.
IMPORTANT: THE TOOL MUST BE FREE RUNNING WHILE ADJUSTING THE AIR PRESSURE TO
GIVE THE CORRECT SETTING.
WHILE THE TOOL IS FREE RUNNING CHECK THAT LUBRO CONTROL UNIT IS
SUPPLYING APPROXIMATELY SIX DROPS OF OIL PER MINUTE.
Setting Torque for Fastener Loosening
1. Ensure that the tool control system is set for the required rotation.
2. Establish maximum air pressure from the associated Air Pressure Graph or tool label.
3. Adjust the pressure regulator until the correct pressure is achieved.
WARNING: EXCEEDING THE MAXIMUM AIR PRESSURE WILL CAUSE OVERLOADING
AND MAY LEAD TO SERIOUS DAMAGE.
WARNING: CHANGING THE AIR PRESSURE AFTER SETTING THE PRESSURE
REGULATOR WILL CHANGE THE STALL TORQUE VALUE.

14
OPERATING INSTRUCTIONS
WARNING: KEEP HANDS CLEAR OF THE REACTION ARM.
WARNING: WHEN USING THIS TOOL IT MUST BE SUPPORTED AT ALL TIMES IN
ORDER TO PREVENT UNEXPECTED RELEASE IN THE EVENT OF
FASTENER OR COMPONENT FAILURE.
WARNING: CHANGING THE MAINS AIR PRESSURE AFTER SETTING THE PRESSURE
REGULATOR WILL CHANGE THE STALL TORQUE VALUE.
WARNING: BEFORE USING TOOL, WEAR SUITABLE PPE, INCLUDING SAFETY
SHOES, EYE PROTECTION, GLOVES AND OVERALLS.
WARNING: IF EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE
MANUFACTURER, INJURY OR DAMAGE COULD RESULT.
Tightening
1. Fit PneuTorque® with the correct size impact or high quality
socket.
2. Ensure the external tool control system is correctly set.
3. Fit the tool onto the fastener. Locate reaction arm adjacent
to the reaction point.
4. Complete the following instructions for SINGLE SPEED,
AUTOMATIC TWO SPEED or MANUAL TWO SPEED
tools:
Single Speed (Part Number with ‘X’ suffix)
5. Start the tool and allow it to continuously tighten the fastener.
Full torque will only be applied when the motor stalls.
6. Stop tool and remove from fastener.
Manual Two Speed (Part Number “*****.XMTS”)
NOTE: ‘FAST’ speed is for initially running up of the fastener and
‘SLOW’ speed for applying the final torque.
5. Set speed selector to ‘FAST’.
TIP: To change the speed (see Figure 10):
A. Ensure tool is not running.
B. Pull selection knob out.
C. Move knob to required speed setting.
D. Ensure selection knob is fully engaged in recess.
6. Start the tool and allow it to continuously tighten the fastener.
7. When the tool motor stalls, stop the tool.
FIGURE 10 – ’FAST’ speed above,
‘SLOW’ speed below.

15
NOTE: The final torque has NOT been applied yet.
8. Set speed selector to ‘SLOW’.
9. Start the tool and allow it to continuously tighten the fastener.
Full torque will only be applied when the motor stalls.
NOTE: The air pressure calibration graph is only correct in the ‘SLOW’ setting.
10. Stop tool and remove from fastener.
TIP: Where there are several fasteners in the joint, eg. a flange, it may be desirable to tighten all
of the fasteners with the tool in ‘FAST’ gear. Then set the gear selector to ‘SLOW’ and apply
final torque.
Automatic Two Speed (Part Number “*****.XAUT”)
NOTE: These tools operate at a ‘FAST’ speed (approximately 5 times faster than normal) until
torque is detected, then the tool automatically changes to ‘SLOW’ speed for the final
tightening of the fastener.
5. Start the tool and allow it to continuously tighten the fastener.
Full torque will only be applied when the motor stalls.
6. Stop tool and remove from fastener.
TIP: If the tool will not release from the bolt, run tool in the opposite direction for a fraction of a
second.
NOTE: If the air pressure is released before the tool stalls, full torque will NOT be applied to the
fastener.
TIP: If additional angle tightening is required, the air pressure may be increased.
Do not exceed the maximum air pressure for the tool.
Ensure the air pressure is reset to the required value for future torque tightening.
Releasing
1. Fit PneuTorque® with the correct size impact or high quality
socket.
2. Ensure external tool control system is correctly set.
3. Fit the tool onto the fastener. Locate reaction arm adjacent to
the reaction point.
4. Start the tool to release the fastener.
TIP: If unable to release the fastener increase the air
pressure to the tool.
Do not exceed the maximum air pressure for the tool.
WARNING: EXCEEDING THE MAXIMUM AIR PRESSURE WILL CAUSE
OVERLOADING AND MAY LEAD TO SERIOUS DAMAGE.
5. Remove tool from fastener.
WARNING: CHANGING THE AIR PRESSURE AFTER SETTING THE PRESSURE
REGULATOR WILL CHANGE THE STALL TORQUE VALUE.

16
MAINTENANCE
To maintain optimum performance and safety, regular maintenance needs to be carried out. This section
details the user maintenance required; other maintenance or repairs should be carried out by Norbar or a
Norbar approved agent and should form part of a service. Service intervals will depend on the type of usage
of the tools and the environment in which they are being used. The maximum recommended maintenance
and recalibration interval is 12 months.
TIP: Steps the operator can take to reduce the amount of maintenance required include:
1. Use the tool in a clean environment.
2. Use an air compressor fitted with a dryer.
3. Ensure the Lubro Control Unit has sufficient hydraulic oil.
4. Ensure the Lubro Control Unit delivers hydraulic oil at the correct rate.
5. Ensure the Lubro Control Unit is regularly maintained, see product manual.
6. Maintain the correct torque reaction.
Reaction Plate
Every week check that the bolts fastening the reaction plate are tightened to the torque stamped onto the
reaction plate.
Air Lubrication
Add Fuchs Silkair VG22 or Shell Tellus S2 VX15 or equivalent good quality hydraulic oil to the Lubro control
unit.
Gearbox
Under normal operating conditions it is not necessary to re-grease the gearbox. The gearbox contains Shell
Gadus S2 V220 or equivalent good quality grease.
Silencer
The silencer (#19188) should be changed every 12 months.
This may be more frequent for high tool usage or dirty environments.
To change silencer:
1. Remove circlip from end of sleeve.
2. Slide sleeve to access silencer.
3. Change silencer.
4. Refit sleeve and circlip.
Filter
The air filter (#18280) should be changed every 12 months.
This may be more frequent for high tool usage or dirty environments.
To change filter:
1. Switch off air supply to tool.
2. Remove inlet air hose.
3. Remove filter from inside tool air inlet.
4. Fit new filter.
5. Refit inlet air hose.
TIP: To help removal use a small screwdriver or a pair of internal circlip pliers.
FIGURE 11 – Silencer location
FIGURE 12 – Air filter

17
Drive Square
To avoid internal damage (especially due to torque overload), the output drive square has been designed to
shear first. This saves major internal damage and allows easy square removal.
FIGURE 13 – Drive square fixing (left to right): Pin, Carrier Assembly, Screw and circlip.
Tool
Square
Size
Drive Square
Part Number
Fixing
Screw Torque
(N∙m)
PT 1 / PT 2
¾”
# 16424
Pin (# 26228)
-
PT 1 / PT 2
1”
# 16425
Pin (# 26228)
-
PT 5
1”
# 16549
Pin (#26242)
-
PT 6
1 ½”
# 16548
Carrier assembly.
-
PT 7
1 ½”
# 16295
M5 screw (# 25352.45)
8 – 9
PT 9
1 ½”
# 16611
M5 screw (# 25352.40)
8 – 9
PT 11
2 ½”
# 16323
M6 screw (# 25353.60)
16 – 18
PT 12
2 ½”
# 16310
M6 screw (# 25353.60) + Circlip (# 26432)
16 – 18
PT 13
2 ½”
# 16310
M6 screw (# 25353.60) + Circlip (# 26432)
16 – 18
PT 14
3 ½”
# 16309
M6 screw (# 25353.60)
16 – 18
PT 15
-
-
Application specific
-
PT 16
-
-
Application specific
-
PT 17
-
-
Application specific
-
PT 18
-
-
Application specific
-
NOTE: The drive squares are designed to be replaced by a competent service engineer with
standard tools. A new fixing screw is recommended on reassembly.
TIP: If the square has sheared it may be necessary to use pliers to remove the broken parts.
Cleaning
Keep the tool in a clean condition to aid safety. Do not use abrasives or solvent based cleaners.
Disposal
Recycling considerations:
Component
Material
Sleeve
Aluminium casting with epoxy finish.
Annulus
Alloy steel with nickel plate finish.
Reaction plate
Alloy steel with chemical black finish

18
SPECIFICATIONS
General
Repeatability: ± 5% for a given joint.
Air Supply: Maximum pressure 6.0 bar (For maximum torque capacity).
Air consumption 19 litres / sec (40 ft³/m [CFM]).
Recommended Lubrication: Fuchs Silkair VG22 or Shell Tellus S2 VX15 for the Lubro Control Unit.
Temperature Range: 0°C to +50°C (operating). -20°C to +60°C (storage).
Maximum Operating Humidity: 85% Relative Humidity at 30°C.
Maximum Vibration at Handle: < 2.5m/s² measured in accordance with ISO 28927-2.
Sound Pressure Level: The sound pressure level is 85 dB(A) uncertainty K = 3dB, measured in
accordance with BS EN ISO 11148-6
Environment: Indoor & dry outdoor use.
Standard Series
Model
Torque
Free Speed
(At maximum air pressure)
Velocity Ratio
Minimum
Maximum
Single Speed
XMTS / XAUT
Slow Speed
Fast Speed
(XMTS / AUT)
PT 1
160 N∙m
(120 lbf∙ft)
680 N∙m
(500 lbf∙ft)
30 rev/min
150 rev/min
162.284:1
29.752:1
PT 1A
270 N∙m
(200 lbf∙ft)
1200 N∙m
(900 lbf∙ft)
15 rev/min
75 rev/min
333.332:1
61.111:1
PT 2
515 N∙m
(380 lbf∙ft)
1700 N∙m
(1250 lbf∙ft)
9 rev/min
45 rev/min
508.019:1
93.137:1
PT 5
880 N∙m
(650 lbf∙ft)
3400 N∙m
(2500 lbf∙ft)
5 rev/min
25 rev/min
885.185:1
162.284:1
PT 6
880 N∙m
(650 lbf∙ft)
3400 N∙m
(2500 lbf∙ft)
5 rev/min
25 rev/min
885.185:1
162.284:1
PT 7
1762 N∙m
(1300 lbf∙ft)
6000 N∙m
(4500 lbf∙ft)
2.5 rev/min
12.5 rev/min
2032.481:1
372.622:1
PT 9
2710 N∙m
(200 lbf∙ft)
9500 N∙m
(7000 lbf∙ft)
1.8 rev/min
9 rev/min
2771.015:1
508.019:1
PT 11
4400 N∙m
(3250 lbf∙ft)
20000 N∙m
(14700 lbf∙ft)
1.2 rev/min
6 rev/min
4720.989:1
865.515:1
PT 12
9500 N∙m
(7000 lbf∙ft)
34000 N∙m
(25000 lbf∙ft)
0.5 rev/min
2.5 rev/min
10490.271:1
1923.232:1
PT 13
13550 N∙m
(10000 lbf∙ft)
47000 N∙m
(35000 lbf∙ft)
0.3 rev/min
1.5 rev/min
14778.748:1
2709.437:1
PT 14
22375 N∙m
(16500 lbf∙ft)
100000 N∙m
(73500 lbf∙ft)
0.2 rev/min
1 rev/min
25178.608:1
4616.078:1
PT 15
35000 N∙m
(25825 lbf∙ft)
150000 N∙m
(110500 lbf∙ft)
0.1 rev/min
0.5 rev/min
47373.29:1
8685.18:1
PT 16
46500 N∙m
(34400 lbf∙ft)
200000 N∙m
(147500 lbf∙ft)
0.08 rev/min
0.4 rev/min
66739.35:1
12235.65:1
PT 17
58250 N∙m
(42990 lbf∙ft)
250000 N∙m
(184300 lbf∙ft)
0.07 rev/min
0.35 rev/min
76828.14:1
14085.28:1
PT 18
70000 N∙m
(51630 lbf∙ft)
300000 N∙m
(221270 lbf∙ft)
0.06 rev/min
0.3 rev/min
83918.27:1
15385.14:1

19
Model
Dimensions (mm)
Weight (kg)
A
B
C
Minimum
C
Maximum
Tool
Reaction
Single
Speed
MTS
AUT
Single
Speed
XMTS /
XAUT
PT 1 (¾”)
108
292
378
361
83
217
10.6
14.1
2.2
PT 1 (1”)
108
298
384
366
83
217
10.6
14.1
2.2
PT 1A
108
298
384
366
83
217
11.1
14.6
2.2
PT 2
108
298
384
366
83
217
11.1
14.6
2.2
PT 5
119
348
434
417
86
264
14.0
17.5
2.5
PT 6
119
354
440
423
86
264
14.0
17.5
2.5
PT 7
144
381
467
450
146
333
17.9
23.2
6.3
PT 9
184
376
462
445
169
351
24.4
27.9
8.3
PT 11
212
470
556
-
-
500
38.6
42.1
13.3
PT 12
240
593
679
-
Blank plate
49.8
53.3
6.5
PT 13
315
553
639
-
Blank plate
102.2
105.7
6.9
PT 14
315
650
736
-
Blank plate
119.4
122.9
10.4
PT 15
-
-
-
-
Application specific
-
-
-
PT 16
410
704
790
-
Application specific
266.5
270
-
PT 17
410
777
863
-
Application specific
281.5
285
-
PT 18
520
774
860
-
Application specific
376.5
380
-
Due to continuous improvement all specifications are subject to change without prior notice.
FIGURE 14 – Smaller standard series tools
FIGURE 15 – Larger standard series tools
A
B
FIGURE 16 – PT 15 – 18
