Nordic Fighter DR014B User manual

DR014B

10
11
12
12

─ 3 ─
Important Safety InstructionsBefore beginning any fitness program, you should obtain a complete physical examination from your physician. When using exercise equipment, basic precautions should always be taken, including the following:* Read all instructions before using the equipment. These instructions are written to ensure your safety and to protect the unit. * Do not allow children on or near the equipment. * Use the equipment only for its intended purpose as described in this guide. Do not use accessory attachments that are not recommended by the manufacturer: such attachments might cause injuries. * Wear proper exercise clothing and shoes for your workout----no loose clothing. * Be careful when getting on or off the equipment. * Do not overexert yourself or work to exhaustion. * If you feel any pain or abnormal symptoms, stop your workout immediately and consult your physician. * Never operate the unit when it has been dropped or damaged. * Never drop or insert anything into any opening in the equipment. * Always check the unit and its cables before each use. Make sure that all fasteners and cables are secure and in good working condition. * Frayed or worn cables can be dangerous and may cause injury. Periodically check these cables for any indication of wear. * Keep hands, limbs, loose clothing and long hair well out of the way of moving parts. * Do not attempt to lift more weight than you can control safely. * Do not use the equipment outdoors. Personal Safety During Assembly* Read each step in the assembly instructions and follow the steps in sequence. Do not skip ahead. If you skip ahead, you may learn later that you have to disassemble components and that you may have damaged the equipment. * Assemble and operate the equipment on a solid, level surface. Locate the unit a few feet from walls or furniture to provide easy access. The equipment is designed for your enjoyment. By following these precautions and using common sense, you will have many safe and pleasurable hours of healthful exercise with the equipment.

InstructionsBefore beginning assembly please take the time to read ins tructions thorou ghly. Please use the various lists in this manual to make sure that all parts have been included in your shipment. When ordering , use part number and description from the lists. Use only our replacement part when servicing. Failur e to do so wi ll void your warranty and could result in personal inju ry.The equipment is designed to provide the smoothest, most effective exerci se motion possible. After ass embly, you should check all func tions to ensure correct operation. If you experience proble ms, first recheck the assemb ly instructions to locate any possible errors mad e during assembly. If you are unable to correct the proble m, call your authorized dea ler. Be sure to have your serial number and this manual when calling. When all parts have been accounted for, continue on.Tools RequiredRatche t Wrench and SocketAdjust able WrenchRubber MalletHex Key Wrench Set ─ 4 ─

Item No. Description Qty
1 Seat Frame 1
2 Bottom Frame 1
3 Grip 1
4 Seat Pad 1
5 Plug 50*100 4
6 Foot Cover 3
7 Hex Head Screw M10*75 2
8 Hex Head Screw M10*20 2
9 Flat Washer φ11*φ20*1.5 4
10 Wheel 2
11 Aluminium Ring 1
12 Aluminium Cap 1
13 Button Head Cap Screw M8*45 2
14 Flat Washer φ9*φ16*1.6 4
15 Nylon Lock Nut M8 2
16 Flat Head Cap Screw M6*16 1
17 Set Screw M5*3 2

1
2
3
4
5
5
5
5
6
6
6
7
7
88 9
9
9
9
10 10
11
12
13 14 14
15
16
17
17

─ 7 ─BHCS = Button Head Cap ScrewSHCS = Socket Head Cap ScrewFHCS = Flat Head Cap ScrewHHB = Hex Head BoltMeasurement Guide

─ 8 ─
Assemb ly of the equipment takes profes sional installers about 2 hours. If this is the firs t time you have assembled this type of equipment, plan to spend more time. It is strongly recommended to assemble the equipment by professional instal lers. You may find it quicker, safer, easier to assembl e this equipment with the help of a friend, as some of components may be large, heavy or awkward to handle alone. It is important tha t you assemble your product in a clean, clear, unclut tered area. This will enable you to move around the product while you are fittin g components and reduce the possibility of injury during assembly.As with any as sembled part, proper alignment and adjustment is critical. Whi le tighte ning the fasteners, be sure to leave roo m for adjustments. Do not fully tighten the fastener s until instructed to do so. Be careful to assemble the compon ents in the sequence pre sented in this guid e.Assembly Instructions

9
1
2
4
7
7
88 9
9
9
9

10

11

12
