Nordic Fighter DR025 User manual

MULTI AB BENGH
DR025

7
8
9
10
11

─ 3 ─
Important Safety InstructionsBefore beginning any fitness program, you should obtain a complete physical examination from your physician. When using exercise equipment, basic precautions should always be taken, including the following:* Read all instructions before using the equipment. These instructions are written to ensure your safety and to protect the unit.* Do not allow children on or near the equipment.* Use the equipment only for its intended purpose as described in this guide. Do not use accessory attachments that are not recommended by the manufacturer: such attachments might cause injuries.* Wear proper exercise clothing and shoes for your workout----no loose clothing.* Be careful when getting on or off the equipment.* Do not overexert yourself or work to exhaustion.* If you feel any pain or abnormal symptoms, stop your workout immediately and consult your physician.* Never operate the unit when it has been dropped or damaged.* Never drop or insert anything into any opening in the equipment.* Always check the unit and its cables before each use. Make sure that all fasteners and cables are secure and in good working condition.* Frayed or worn cables can be dangerous and may cause injury. Periodically check these cables for any indication of wear.* Keep hands, limbs, loose clothing and long hair well out of the way of moving parts.* Do not attempt to lift more weight than you can control safely.* Do not use the equipment outdoors.PERSONAL SAFETY DURING ASSEMBLY* Read each step in the assembly instructions and follow the steps in sequence. Do not skip ahead. If you skip ahead, you may learn later that you have to disassemble components and that you may have damaged the equipment.* Assemble and operate the equipment on a solid, level surface. Locate the unit a few feet from walls or furniture to provide easy access. The equipment is designed for your enjoyment. By following these precautions and using common sense, you will have many safe and pleasurable hours of healthful exercise with the equipment.

InstructionsTools Required─ 4 ─
Before beginning assembly please take the time to read instructions thoroughly. Please use the various lists in this manual to make sure that all parts have been included in your shipment. When ordering, use part number and description from the lists. Use only our replacement part when servicing. Failure to do so will void your warranty and could result in personal injury.The equipment is designed to provide the smoothest, most effective exercise motion possible. After assembly, you should check all functions to ensure correct operation. If you experience problems, first recheck the assembly instructions to locate any possible errors made during assembly. If you are u nable to correct the problem, call your authorized dealer. Be sure to have your serial number and this manual when calling. When all parts have been accounted for, continue on.Ratchet Wrench and SocketAdjustable WrenchRubber MalletHex Key Wrench Set

5
ltem No. Description Qty
1 Base Bracket 1
2 Support Bracket 1
3 Adjustable Bracket (outer) 1
4 Back Pad Bracket 1
5 Adjustable Bracket (inner) 1
6 Roller Bar 2
7 Shaft 1
8 Spring Pin 1
9 Bushing 4
10 Bushing 2
11 Washer φ38*φ10*4 4
12 Aluminium Grip Cap 1
13 Grip 1
14 Rubber Bumper 1
15 Foot Pad 3
16 Plastic Tube GuideRT50*100-□30*70 2
17 FOAM Bushing 8
18 Plug 3
19 Roller Pad 4
20 Back Pad 1
21 Hex Head Bolt M10*80 2
22 Hex Head Bolt M10*30 4
23 Hex Head Bolt M12*140 3
24 Socket Head Cap ScrewM8*25 1
25 Socket Set Screw M8*10 2
26 Hex Nut M6 2
27 Button Head Cap Screw M6*12 2
28 Button Head Cap Screw M10*25 4
29 Nylon Lock Nut M10 2
30 Nylon Lock Nut M12 3
31 Washer φ13*φ24*1.5 6
32 Flat Washer φ11*φ20*2 8
33 Socket Set Screw M5*3 2

6
1
2
3
4
5
6
6
7
8
9
9
9
9
10
10
11
11
11
11
12
13
14
15
15
16
16
17
17
17
17
17
17
17
17
18
18
19
19
19
19
20
21
21
22
22
22
23
23
23
24
25
25
262627
27
28
28
28
28
2929
30
30
31
31
31
31
3232
32
32
32
32
32
